2BUTD-JD0101BF0001PixLeap

PixLeap User Manual Suzhou Jupiter Semi Co.,Ltd Beyond flat, into depth——experience 3D. The PixLeap utilizes advanced lenticular lens technology to delivery tangible stereoscopic effects, making every image spring to life. Whether it’s family photos, artistic creations, or digital collectibles, this device breathes new vitality into each scene with stunning 3D immersion. Memory is no longer a flat snapshot, but a tangible moment rich with warmth and depth. User Guide： ① Power On/off To power on the device, plug the included 12V/2A power adapter into the device’s power port,then connect the other end to an outlet. Note:  Only the labeled Type-C port can be used for power.  The unlabeled Type-C port must NOT be used for power. The device turns on automatically when powered and shuts down when disconnected. ② Optimal 3D viewing  Recommended view distance:0.5~0.9meters.  Avoid strong or direct light to maintain optimal image quality. Additional Notes:  Standby Mode:When the device is not in use, you can set the screen to activate standby mode. The display will turn off completely while maintaining minimal power consumption. To reactivate, simply touch the screen again.  Optical Safety:As an optical technology product, brief dizziness or discomfort may occur for some users. Maintain a using distance of over 20cm to minimize risk. If symptoms arise, look away from the screen for a few minutes until naturally relieved.  For safe use only at altitudes of 2000m and below  For safe use only under non-tropical climate conditions Safety & Maintenance：  The front screen is made of high-transparency glass with excellent stability. However, please avoid impacts or scratches, as they may compromise the visual quality.  Always disconnect the power before cleaning.Gently wipe the surface with a soft, dry cloth. Do not use alcohol or other corrosive liquids.  This product is not waterproof. Keep it away from humid environments to prevent internal damage.Avoid contact with liquid and do not use the product in damp conditions for extended periods. Warranty information：  Warranty policy：Enjoy a 7-day no-reason-asked return policy from the date of purchase (the product must be undamaged and include all accessories), complemented by a 1-year free repair warranty.  Exceptions: The warranty does not cover damages resulting from improper use, unauthorized modifications or repairs or use beyond the designated period.  Customer Service：For support, please contact our customer service team via [email protected] Product Specification 2D Display Size 10.1 inch 2D Resolution Ratio 1200(H)*1920(V) 3D View Area 135.36mm (H) ×216.576mm (V) System Android 11 Internal memory 2GB Storage 32GB WIFI WIFI6 Input Power Supply 12V 2A Input power interface USB type-C View Angle ±35° 3D Photo Format JPEG/PNG Product Dimension 258.28*164.06*62.47mm Application Environment 20±15°，20~65%RH Latest on-line user manual：https://eu.jupiter-semi.com/spec/10.1/ FCC Caution. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. JUPITER https://eu.jupiter-semi.com/app/ Scan QR code to download Aeon Moments APP for full experience.

Suzhou Jupiter Semi Co., Ltd 10F, Building E3, Al Industrial Park, No. 88 Jinjihu Avenue, SIP, Suzhou 215000, China 1 | P a g e Attestation Statements To: Federal Communications Commission Date: Mar. 4, 26 7435 Oakland Mills Road, Columbia, MD 21046, USA Subject: Attestation of Compliance with FCC Covered List Software Requirements FCC ID: 2BUTD-JD0101BF0001 Product Name: PixLeap This letter serves as an attestation that the equipment identified above ☐ is / ☒ is not (select one) "covered" software as defined under the Federal Communications Commission (FCC) Covered List requirements, as outlined in FCC 22-84 and KDB 986446. Specifically, the undersigned certifies that the equipment for which authorization is sought: 1. Does not contain cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors, assignees, parents, subsidiaries, affiliates, or any entity that has rebranded or relabeled software produced by the aforementioned entities. 2. Does not have the capability to store, run, or deliver any software identified on the FCC Covered List, including but not limited to cybersecurity and anti-virus software. To support this attestation, the appendix evaluation documentation has been prepared and is included in the certification filing. This attestation is based on a thorough evaluation of the device's design, functionality, and software environment. The undersigned affirms that the information provided is accurate and complete to the best of their knowledge. Sincerely yours, Applicant Signature Printed Name: Chunqin Ji Title: Product Project Director Address: 10F, Building E3, Al Industrial Park, No. 88 Jinjihu Avenue, SIP, Suzhou 215000, China Tel.: 18913752966 Email: [email protected] Suzhou Jupiter Semi Co., Ltd 10F, Building E3, Al Industrial Park, No. 88 Jinjihu Avenue, SIP, Suzhou 215000, China 2 | P a g e Evaluation regarding to the Covered List Software: Compliance Methodology Evaluation Process Results Device is Inherent compliance ☐ The Chipset(s) used is limited to run the Cybersecurity or anti-virus software. The MCU “XXX“, The RF chip “XXX“ don’t support the mentioned function. ☐ The Memory used is limited to run the Cybersecurity or anti-virus software. The memory size is XXX, so don’t support the mentioned function. ☐ There is storage capacity limitation for store or install the Cybersecurity or anti-virus software. The storage capacity is XXX, so don’t support the mentioned function. ☐ Operating system used is limited to run, install or deliver the Cybersecurity or anti-virus software. The Operating system “XXX“ don’t support the mentioned function. Device is not Inherent compliance ☒ Evaluation Based on Software Bill of Materials (SBoM) See attached “SBoM“ Note:The SBoM content is limited to the scope of covered list software (e.g. antivirus and cybersecurity software). ☐ Evaluation Based on Scan for Software on the device ☐ Evaluation Based on Filesystem scan ☐ Evaluation Based on Running software check SBOM (Software Bill of Materials) [For Device is not Inherent compliance] Section Component Name Version Supplier 1 3DPhotoFrame Version1.0.7 Suzhou Jupiter Semi Co., Ltd 2 3

Suzhou Jupiter Semi Co., Ltd 10F, Building E3, Al Industrial Park, No. 88 Jinjihu Avenue, SIP, Suzhou 215000, China Attestation Statements Not Covered Entity Applicant & Not Covered Equipment To: Federal Communications Commission Date: Feb. 25, 26 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(i) & (ii) FCC ID: 2BUTD-JD0101BF0001 Suzhou Jupiter Semi Co., Ltd (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List, established pursuant to § 1.50002 of reference chapter, as an entity producing “covered” communication equipment. The equipment for which authorization is sought is not “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List that prohibited from receiving an equipment authorization pursuant to section § 2.903 of the FCC rules. Sincerely yours, Applicant Signature Printed Name: Chunqin Ji Title: Product Project Director Address: 10F, Building E3, Al Industrial Park, No. 88 Jinjihu Avenue, SIP, Suzhou 215000, China Tel.: 18913752966 Email: [email protected]

Suzhou Jupiter Semi Co., Ltd 10F, Building E3, Al Industrial Park, No. 88 Jinjihu Avenue, SIP, Suzhou 215000, China U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: Feb. 25, 26 Ref: Attestation Statement – Part 2.911(d)(7) filing FCC ID: 2BUTD-JD0101BF0001 [Suzhou Jupiter Semi Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, [AOGES CO., LIMITED] (“the agent”) is our designated U.S. agent for service of process for the above reference FCC ID. The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges it is our responsibility to inform the FCC whenever the agent information changes. [AOGES CO., LIMITED] ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: AOGES CO., LIMITED FRN: 0033947847 Address: 1624 Market St., Ste 226, #30327 Denver CO, 80202 US Signature: Contact Person: XIAOYAN LAI Tel: 303 623 1940 Email: [email protected] Applicant Company Name: Suzhou Jupiter Semi Co., Ltd FRN: 0037971942 Address: 10F, Building E3, Al Industrial Park, No. 88 Jinjihu Avenue, SIP, Suzhou 215000, China Signature: Contact Person: Chunqin Ji Suzhou Jupiter Semi Co., Ltd 10F, Building E3, Al Industrial Park, No. 88 Jinjihu Avenue, SIP, Suzhou 215000, China Tel: 18913752966 Email: [email protected]

Suzhou Jupiter Semi Co., Ltd 10F, Building E3, Al Industrial Park, No. 88 Jinjihu Avenue, SIP, Suzhou 215000, China Feb. 25, 26 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for: FCC ID: 2BUTD-JD0101BF0001 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request permanent confidential treatment of the exhibits accompanying this certification application as outlined below :  Block Diagram  Schematics  Operational Description  Parts List  (Etc.) The above exhibits contain trade secrets and/or proprietary information that are not publicly available and materials that the Applicant has spent considerable efforts in developing. Public disclosure of these may be harmful to the Applicant and give an unfair advantage to competitors on the market. Sincerely, Applicant Signature Printed Name: Chunqin Ji Title: Product Project Director Address: 10F, Building E3, Al Industrial Park, No. 88 Jinjihu Avenue, SIP, Suzhou 215000, China Tel.: 18913752966 Email: [email protected]

Suzhou Jupiter Semi Co., Ltd 10F, Building E3, Al Industrial Park, No. 88 Jinjihu Avenue, SIP, Suzhou 215000, China Feb. 25, 26 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization for FCC ID: 2BUTD-JD0101BF0001 I, the undersigned, hereby authorize (SHENZHEN STS TEST SERVICES CO.,LTD.) to act on our behalf in all matters relating to this application for equipment certification. Any act carried out by (SHENZHEN STS TEST SERVICES CO.,LTD.) shall have the same effect as our own and I acknowledge that all responsibility for complying with the terms and conditions of certification, as specified by DERYCOM CERTIFICATION SERVICES, INC., still resides with (Suzhou Jupiter Semi Co., Ltd). We certify that we are not subject to a denial of federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862, and that no party to the application, as defined in 47 CFR §1.2002(b), is subject to a denial of federal benefits that includes FCC benefits pursuant to that section. Sincerely, Applicant Signature Printed Name: Chunqin Ji Title: Product Project Director Address: 10F, Building E3, Al Industrial Park, No. 88 Jinjihu Avenue, SIP, Suzhou 215000, China Tel.: 18913752966 Email: [email protected]

Page 1 of 5 Report No.: 2BUTD-JD0101BF0001 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Page 2 of 5 Report No.: 2BUTD-JD0101BF0001 Photo 3 Photo 4 Page 3 of 5 Report No.: 2BUTD-JD0101BF0001 Photo 5 Photo 6 Page 4 of 5 Report No.: 2BUTD-JD0101BF0001 Photo 7 Photo 8 Page 5 of 5 Report No.: 2BUTD-JD0101BF0001 Photo 9 Photo10

FCC Label

Page 1 of 4 Report No.: 2BUTD-JD0101BF0001 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Antenna Page 2 of 4 Report No.: 2BUTD-JD0101BF0001 Photo 3 Photo 4 Page 3 of 4 Report No.: 2BUTD-JD0101BF0001 Photo 5 Photo 6 Page 4 of 4 Report No.: 2BUTD-JD0101BF0001 Photo 7 Photo 8

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. MPE Report Report No.:STS2511267H01 Issued for Suzhou Jupiter Semi Co., Ltd 10F, Building E3, Al Industrial Park, No. 88 Jinjihu Avenue, SIP, Suzhou 215000, China Product Name: PixLeap Brand Name: Jupiter Model Name: JD0101BF0001 Series Model(s): N/A FCC ID: 2BUTD-JD0101BF0001 Test Standards: FCC 47CFR §2.1091 Page 2 of 10 Report No.: STS2511267H01 TEST REPORT Applicant’s Name ................. : Suzhou Jupiter Semi Co., Ltd Address ................................. : 10F, Building E3, Al Industrial Park, No. 88 Jinjihu Avenue, SIP, Suzhou 215000, China Manufacturer's Name ........... : Suzhou Jupiter Semi Co., Ltd Address ................................. : 10F, Building E3, Al Industrial Park, No. 88 Jinjihu Avenue, SIP, Suzhou 215000, China Product Description Product Name ........................ : PixLeap Brand ................................... : Jupiter Model Number ....................... : .. : JD0101BF0001 Series Model(s) ...................... : N/A Standards ............................. : FCC 47CFR §2.1091 447498 D04 Interim General RF Exposure Guidance v01 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 29 Nov. 2025 Date (s) of performance of tests ............. : 29 Nov. 2025 ~ 03 Feb. 2026 Date of Issue .......................................... : 03 Feb. 2026 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 10 Report No.: STS2511267H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 6 2. FCC 47CFR §2.1091 REQUIREMENT 7 2.1 TEST STANDARDS 7 2.2 LIMIT 7 2.3 TEST RESULT 10 Page 4 of 10 Report No.: STS2511267H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 03 Feb. 2026 STS2511267H01 ALL Initial Issue Page 5 of 10 Report No.: STS2511267H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name PixLeap Brand Jupiter Model Name JD0101BF0001 Series Model(s) N/A Model Difference N/A Product Description The EUT is PixLeap Operation Frequency: 2.4G WLAN: 802.11b/g/n/ax 20: 2412~2462 MHz 802.11n/ax40:2422~2452MHz 5.2G RLAN: IEEE 802.11a/ n(HT20)/ac(VHT20)/ax(HE20): 5.180GHz-5.240GHz IEEE 802.11n(HT40)/ac(VHT40)/ax(HE40): 5.190GHz-5.230GHz IEEE 802.11ac(VHT80) /ax(HE80): 5.210GHz 5.3G RLAN: IEEE 802.11a/ n(HT20)/ac(VHT20)/ax(HE20): 5.260GHz-5.320GHz IEEE 802.11 n(HT40)/ac(VHT40)/ax(HE40): 5.270GHz-5.310GHz IEEE 802.11ac(VHT80)/ax(HE80): 5.290GHz 5.6G RLAN: IEEE 802.11a/ n(HT20)/ac(VHT20)/ax(HE20): 5.500GHz-5.700GHz IEEE 802.11 n(HT40)/ac(VHT40)/ax(HE40): 5.510GHz-5.670GHz IEEE 802.11ac(VHT80)/ax(HE80): 5.530GHz-5.610GHz 5.8G RLAN: IEEE 802.11a/ n(HT20)/ac(VHT20)/ax(HE20): 5.745GHz-5.825GHz IEEE 802.11a/ n(HT40)/ac(VHT40)/ax(HE40): 5.755GHz-5.795GHz IEEE 802.11ac(VHT80)/ax(HE80): 5.775GHz Page 6 of 10 Report No.: STS2511267H01 Modulation Type: 2.4G WLAN: 802.11b(DSSS):CCK,DQPSK,DBPSK 802.11g(OFDM):BPSK,QPSK,16-QAM, 64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM, 64-QAM 802.11ax(OFDM, OFDMA): BPSK,QPSK,16-QAM,64-QAM,256-QAM, 1024QAM 5G RLAN: 802.11a(OFDM): BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM): BPSK,QPSK,16-QAM,64-QAM 802.11ac(OFDM): BPSK,QPSK,16-QAM,64-QAM,256-QAM 802.11ax(OFDM, OFDMA): BPSK,QPSK,16-QAM,64-QAM,256-QAM, 1024QAM Antenna gain: 2.4G WLAN:-1dBi 5.2G WLAN: 2.54dBi 5.3G WLAN: 2.88dBi 5.6G WLAN: 2.54dBi 5.8G WLAN: 2.54dBi Antenna Designation: FPC Power Rating Input: 12.0V 2.0A Adapter Model: J3028-1202000UX Brand: N/A Input: 100-240~50/60Hz 1.5A Output: 12.0V 2.0A 240W Battery N/A Hardware Version N/A Software Version N/A 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 7 of 10 Report No.: STS2511267H01 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 8 of 10 Report No.: STS2511267H01 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that fre…

Text truncated - open the document above for the full version.

ShenZhen City ZhongXinRui Technology Co.,Ltd 650B0101001 ShenZhen City ZhongXinRui Technology Co.,Ltd ShenZhen City ZhongXinRui Technology Co.,Ltd ShenZhen City ZhongXinRui Technology Co.,Ltd ShenZhen City ZhongXinRui Technology Co.,Ltd ShenZhen City ZhongXinRui Technology Co.,Ltd ShenZhen City ZhongXinRui Technology Co.,Ltd

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.:STS2511267W01 Issued for Suzhou Jupiter Semi Co., Ltd 10F, Building E3, Al Industrial Park, No. 88 Jinjihu Avenue, SIP, Suzhou 215000, China Product Name: PixLeap Brand Name: Jupiter Model Name: JD0101BF0001 Series Model(s): N/A FCC ID: 2BUTD-JD0101BF0001 Test Standards: FCC Part15.247 Page 2 of 99 Report No.: STS2511267W01 TEST REPORT Applicant’s Name ................. : Suzhou Jupiter Semi Co., Ltd Address ................................. : 10F, Building E3, Al Industrial Park, No. 88 Jinjihu Avenue, SIP, Suzhou 215000, China Manufacturer's Name ........... : Suzhou Jupiter Semi Co., Ltd Address ................................. : 10F, Building E3, Al Industrial Park, No. 88 Jinjihu Avenue, SIP, Suzhou 215000, China Product Description Product Name ........................ : PixLeap Brand Name ........................... : Jupiter Model Name .......................... : JD0101BF0001 Series Model(s) .................... : N/A Standards ............................. : FCC Part 15.247 Test Procedure........................: ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 29 Nov. 2025 Date (s) of performance of tests ............. : 29 Nov. 2025 ~ 03 Feb. 2026 Date of Issue .......................................... : 03 Feb. 2026 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 99 Report No.: STS2511267W01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 11 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 12 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 13 3. EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.2 RADIATED EMISSION MEASUREMENT 18 4. DUTY CYCLE 30 4.1 TEST STANDARD 30 4.2 TEST PROCEDURE 30 4.3 DEVIATION FROM STANDARD 30 4.4 TEST SETUP 30 4.6 TEST RESULTS 30 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 31 5.1 LIMIT 31 5.2 TEST PROCEDURE 31 5.3 DEVIATION FROM STANDARD 31 5.4 TEST SETUP 31 5.5 EUT OPERATION CONDITIONS 31 5.6 TEST RESULTS 31 6. POWER SPECTRAL DENSITY TEST 32 6.1 LIMIT 32 6.2 TEST PROCEDURE 32 6.3 DEVIATION FROM STANDARD 32 6.4 TEST SETUP 32 6.5 EUT OPERATION CONDITIONS 32 6.6 TEST RESULTS 32 Page 4 of 99 Report No.: STS2511267W01 Table of Contents Page 7. BANDWIDTH TEST 33 7.1 LIMIT 33 7.2 TEST PROCEDURE 33 7.3 DEVIATION FROM STANDARD 33 7.4 TEST SETUP 33 7.5 EUT OPERATION CONDITIONS 33 7.6 TEST RESULTS 33 8. PEAK OUTPUT POWER TEST 34 7.1 LIMIT 34 8.2 TEST PROCEDURE 34 8.3 DEVIATION FROM STANDARD 34 8.4 TEST SETUP 34 8.5 EUT OPERATION CONDITIONS 34 8.6 TEST RESULTS 34 9. ANTENNA REQUIREMENT 35 9.1 STANDARD REQUIREMENT 35 9.2 EUT ANTENNA 35 APPENDIX 1-TEST DATA 36 DUTY CYCLE 36 MAXIMUM PEAK CONDUCTED OUTPUT POWER 46 -6DB BANDWIDTH 47 MAXIMUM POWER SPECTRAL DENSITY LEVEL 57 BAND EDGE 67 CONDUCTED RF SPURIOUS EMISSION 80 APPENDIX 2-PHOTOS OF TEST SETUP 99 Page 5 of 99 Report No.: STS2511267W01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 03 Feb. 2026 STS2511267W01 ALL Initial Issue Page 6 of 99 Report No.: STS2511267W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Page 7 of 99 Report No.: STS2511267W01 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.751dB 2 Unwanted Emissions, conducted ±2.888dB 3 All emissions, radiated 9K-30MHz ±2.48dB 4 All emissions, radiated 30M-1GHz ±2.52dB 5 All emissions, radiated 1G-18GHz ±3.48dB 6 All emissions, radiated>18GHz ±4.18dB 7 Conducted Emission (9KHz-150KHz) ±2.48dB 8 Conducted Emission (150KHz-30MHz) ±2.52dB 9 Occupied Channel Bandwidth ±3.6% 10 Power Spectral Density, conducted ±1.214dB 11 Duty Cycle ±3.2% Page 8 of 99 Report No.: STS2511267W01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name PixLeap Brand Name Jupiter Model Name JD0101BF0001 Series Model(s) N/A Model Difference N/A Product Desc…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID: 2BUTD-JD0101BF0001 Setup photo AC Conduction RF Conduction Page 2 of 2 FCC ID: 2BUTD-JD0101BF0001 RE (Below 1GHz) RE (Above 1GHz)
