SW159 Micro SD TROLLEY SPEAKER Operating Instructions Technical Specifications Content Power: 80W Impedance: 4 Ω Input Sensitivity: 92±3 dB Frequency Response: 50-18K Hz S/N Ratio: ≥70dB Drive Unit: 1′′+12′′ Wireless Mic Frequency: 212.0MHZ Bluetooth Name: SW159 Power Adapter:DC9V/1.5A 1 6 BT Operation 2.Search the BT device list and select the BT name "SW159".The speaker will make a notification tone when the connection is successful. Open the mobile phone music player and play a song. The music is transferred via BT and sound comes out through the BT speaker. 3.Select the BT which is on BT device list. First connection of BT with cellophane Instructions Connect to the mobile phone which already been connected before. When the mobile phone BT is turned on, press the“MODE”and select to BT mode, the BT speaker will automatically connect to the mobile phone which is connected last time. Another way is that you can search the BT list on your mobile phone, when you find the“SW159”, select it and connect your mobile phone to the BT speaker. 1.Turn the power on, press the "MODE" key or “INPUT" key on the panel or remote control, and switch the speaker to Bluetooth channel. Then turn on the mobile phone BT function. The battery charges for 8hours before the first use of this product. It must be replaced with batteries of the same specifications when needed,otherwise, the product may not work properly or be damaged. To extend battery life, it needs to be charged regardless of the lack of power after each use. The charging time depends on the battery specifications. The charging scheme (or the power supply voltage is unstable) is generally 8-16hours. Please keep away from the product more than 2meters from CRT display or television, because of the speaker magnet field is strong, magnetic interference causes display magnetization or discoloration phenomenon. Operation wireless microphone Safety Precautions Instruction & BT Operation Safety Precautions DC9V 1.5A 2 TWS function Operation TRUE WIRELESS STEREO (TWS) TECHNOLOGY TWS technology enables user to make wireless connection between two speakers which are same model and compatible with TWS. In TWS connection, two speakers will be automatically grouped to be a Stereo-speaker System which outputs the left and right channel. Two speakers which were connected by TWS will be automatically reconnected when they are power on and both in BT mode. Long press TWS button to disconnect two speakers by TWS. DISCONNECT TWS HOW TO ESTABLISH “”1.Please switch on both speakers and select BT Mode. 2.Press the TWS button on the control panel of one of the speakers until you hear a Prompt sound.It becomes the main speaker (left channel), automatically searches for and connects with the other speaker (right channel). After connection, you will hear a Prompt sound TWS MODE MANIPULATIONS In TWS mode, manipulations to the main speaker will be simultaneously effected in the other speaker, for example, volume up and down, previous and next song selection, play and pause, power on and off. TWS CONNECTION? Reminding: Two speakers must be same model and both compatible with TWS. 3.Connect your mobile phone or BT player to the speaker by BT. After connection, you can play music with the TWS Stereo-speaker System. Please turn off the microphone after using Operation wireless microphone If you buy more than two sets of active speaker with wireless microphones and want to use together at the same time, please select standard frequency of different varieties. If not, there must be 10 meters distance at lease between two sets speaker in same frequency. So as not to cause interference and other unnecessary trouble. At the same time, don't put speakers too close to VCD/CD/DVD during using. They are strong interference frequency equipments. In order to avoid mutual interference between the same frequency and directly affects the normal work of the wireless microphone signal receiving. Please don't use the same frequency of microphone to sing at the same time in a short distance.It will lead to silence or interference. To achieve the best effect of singing, the distance of mouth and microphone should be keep in 5-15 cm, and the best angle is 45 degrees. Wireless microphone effective distance within meters. In order to not affecting the effect, 10 please do not use over than the valid range. When the battery decreased or the environment radio interference source signal is too strong, it will shorten the using distance. To adjust the microphone volume knob to you like when you are demo. This product built-in battery, especially suitable for outdoor concert, advertising, entertainment and other activities. Please charge the battery full first before using in outdoor environment. To ensurethat the speaker can be used for a long time for outdoor activities. 5 Top Panels operating instructions 1 1.USB jack 2. Micro SD jack 3. AUX input 4. Microphone input1 5. Microphone input2 6. Charging indicator light 7. DC 9V/1.5V Adapter input 8.Function Menu Music volume adjustment Music treble adjustment Music bass adjustment Microphone volume adjustment Microphone reverb adjustment Press once to switch between adjustment modes 9. Long press for recording, short press for replay recording 10.Microphone priority 11. Previous key & FM channel - key 12. Long press for True wireless stereo key short press for Play/Pause key & FM scan key 13. Next key & FM channel + key 14. Adjust according to 8 Master Volume Control 15. Short press mode Key BT cut off press for 3seconds 16. Power ON/OFF switch 17. Short press for LED light switch, long press for LED light ON/OFF 2 3 475 6 8 9 10 11 12 13 151617 14 4 Operating instructions for Remote controllers 1.Standby Key 2.Mode Key- to Select Input Signal Source 3.LED Switch 4.Volume +/- Key 5.Repeat Key 6.Track selection key 7.Mute Key 8.Previous /FM ch-Key 9.Next /FM ch+ Key 10.Play/ Pause & FM scan key 11.EQ Mode Key 3 FCC Caution: This device complies with part…
