2BV27-H01E-Badge

上滑： 进入相机，计算器 手机打开APP，保持与设备连接状态，设备点击拍照图标进入拍照页面， 点击设备屏幕拍照按钮即可拍照。 拍照同屏 切换自动休眠模式（10分钟内未使用自动息屏或长亮) 删除当前图片（左右滑动可选择需要删除的图片） 一键分享： 设备间互传图片，A设备点击“分享图片”进入发送模式；B设备点击“接收图片” 进入接收模式 使用说明书 产品介绍 type-c充电接口 喇叭孔 电源键 蓝牙键 APP下载与连接 1.扫描二维码下载并安装“ZRun”APP（浏览器、微信等 都可扫码） 2.APP连接方式 设备开机后，短按蓝牙键进入蓝牙匹配模式，查看蓝牙地址。 打开手机蓝牙，进入APP点击添加设备，选择H01，扫描到对应 设备直接点击即可连接，出线蓝牙图标变绿表示连接成功。 吧唧操作说明 下滑： 进入菜单 左滑/右滑： 切换图片、视频 吧唧功能介绍 休眠： 删除： 亮度： 手电筒： 点击切换亮度 进入应援灯，点击闪烁，上下滑切换颜色，右滑或任意键退回图片 注意事项 续航时间与亮度设置有关，请合理调整保持电量充足， 低电量会影响传输速度。 视频文件较大，传输时长会相应变长。 蓝牙有效距离有效，请勿远距离使用。 故障处理 蓝牙连接失败：重启设备和APP，重新刷新配对并检查手机蓝牙 是否已经开启。 内容不显示：重新上传文件或者内存已满。 按键无响应：长按电源键10秒强制重启。 Swipe up: Access camera and calculator Open the APP on your phone and keep it connected to the device. Tap the camera icon on the device to enter the photo page, then tap the photo button on the device screen to take a picture. Photo Mirroring: Switch auto-sleep mode (auto screen-off after 10 minutes of inactivity or always-on) Delete the current picture (swipe lef t or right to select the picture to delete) One-Key Share: Transfer pictures between devices. Device A taps "Share Picture" to enter send mode; Device B taps "Receive Picture" to enter receive mode. Instruction Manual Product Introduction Type-C Charging Por t Speaker Hole Power Button Bluetooth Button APP Download & Connection 1.Scan the QR code to download and install the "ZRun" APP (can be scanned via browsers, WeChat, etc.). 2.APP Connection Method After turning on the device, short-press the Bluetooth button to enter BT pairing mode and check the BT address.Turn on BT on your phone, open the APP and tap Add Device, select H01, find the corresponding device and tap it directly to connect. The Bluetooth icon turning green indicates a successful connection. Badge Operation Instructions Swipe down: Enter menu Swipe left / right: Switch between pictures and videos Badge Function Introduction Sleep: Delete: Brightness: Flashlight: Tap to adjust brightness Enter suppor t light mode. Tap to flash, swipe up/down to switch colors, swipe right or press any key to return to pictures. Precautions Battery life is related to brightness settings. Please adjust it properly to keep sufficient power, as low battery will affect transmission speed. Video files are large, so the transmission time will be longer accordingly. The Bluetooth has an effective working distance, please do not use it remotely. Troubleshooting Bluetooth connection failed: Restar t the device and the APP, refresh the pairing again, and check if the phone's Bluetooth is turned on. Content not displayed: Re-upload the file or the memor y may be full. Button unresponsive: Long press the power button for 10 seconds to force a restar t. 中 English 上にスワイプ ： カメラ、電卓を開く スマホでAPPを開き、デバイスと接続した状態を保ちます。デバイス側 のカメラアイコンをタップして撮影ページに入り、デバイスの画面 にあるシャッターボタンを押せば撮影可能です。 スマホ連動撮影 ： 自動スリープモードを切り替えます（10分間未使用で画面オフ、または常時点灯）。 現在の画像を削除します（左右にスワイプして削除したい画像を選択できます）。 ワンタッチ共有 ： デバイス間で画像を送受信します。Aデバイスの「画像をシェア」をタップして送信 モードに、Bデバイスの「画像を受信」をタップして受信モードにします。 取扱説明書 製品紹介 Type-C充電ポート スピーカー穴 電源ボタン Bluetoothボタン APPのダウンロードと接続方法 1.QRコードを読み取って「ZRun」APPをダウンロードし、 インストールしてください（ブラウザやWeChatなどのスキャン 機能をご利用いただけます）。 2.APPとの接続手順 デバイスの電源を入れた後、Bluetoothボタンを短く押してペアリング モードに入り、Bluetoothアドレスを確認します。スマートフォンの Bluetoothをオンにし、APP内に入って「デバイスを追加」をクリックします。 「H01」を選択し、スキャンされた該当デバイスを直接クリックすると接続 できます。Bluetoothアイコンが緑色に変われば、接続成功です。 バッジの操作方法 下にスワイプ ： メニューを開く 左／右にスワイプ ： 画像や動画を切り替える バッジの機能紹介 スリープ ： 削除 ： 明るさ ： ライト ： タップして明るさを切り替えます。 応援ライト（ペンライト）モードに入ります。タップで点滅し、上下スワイプで色を変 更、右スワイプまたは任意のボタンで画像画面に戻ります。 注意事項 稼働時間は明るさの設定によって異なります。バッテリー残量を十分 に保つよう、設定を調整してください。充電が少ないと転送速度に影 響が出ます。 動画ファイルは容量が大きいため、転送に時間がかかります。 Bluetoothの有効距離には限りがあります。遠く離れての使用 はお控えください。 トラブルシューティング（故障の対処法） Bluetooth接続ができない場合： デバイスとAPPを再起動し、 ペアリングリストを再更新して、スマホのBluetoothがオン になっているか確認してください。 コンテンツが表示されない場合： ファイルを再アップロード してください。または、メモリがいっぱいの可能性があります。 ボタンが反応しない場合： 電源ボタンを10秒間長押しして、強制的 に再起動してください。 Japanese 위로 스와이프 : 카메라, 계산기로 이동 스마트폰에서 APP을 실행하고 기기와 연결 상태를 유지한 뒤, 기기에서 카메라 아이콘을 클릭해 촬영 페이지로 이동합니다. 기기 화면의 촬영 버튼을 누르면 바로 촬영됩니다. 스마트폰 연동 촬영 : 자동 대기 모드를 전환합니다 (10분간 미사용 시 화면 자동 소등 또는 상시 켜짐). 현재 이미지를 삭제합니다 (좌우로 스와이프하여 삭제할 이미지를 선택할 수 있음). 원터치 공유 : 기기 간 이미지 상호 전송. A 기기에서 ‘이미지 공유’를 클릭해 전송 모드로 진입; B 기기에서 ‘이미지 수신’을 클릭해 수신 모드로 진입. 사용 설명서 제품 소개 Type-C 충전 단자 스피커 구멍 전원 버튼 블루투스 버튼 APP 다운로드 및 연결 1.QR 코드를 스캔하여 ‘ZRun’ APP을 다운로드하고 설치 하세요 (브라우저, 위챗 등으로 스캔 가능). 2.APP 연결 방법 기기 전원을 켠 후 블루투스 버튼을 짧게 눌러 페어링 모드로 진 입한 뒤 블루투스 주소를 확인합니다. 스마트폰의 블루투스를 켜고 APP에 들어가 ‘기기 추가’를 클릭한 후 H01을 선택하세요. 검색된 해당 기기를 클릭하면 바로 연결되며, 블루투스 아이콘이 초록색으로 변하면 연결 성공입니다. 배지 조작 방법 아래로 스와이프 : 메뉴로 이동 왼쪽/ 오른쪽으로 스와이프 : 이미지, 동영상 전환 배지 기능 소개 대기 모드 : 삭제 : 밝기 : 손전등 : 클릭하여 밝기를 전환합니다. 응원등 모드로 진입, 클릭 시 점멸, 상하 스와이프로 색상 전환, 우측 스와이프 또는 임의의 버튼으로 이미지 화면으로 복귀. 주의 사항 배터리 지속 시간은 밝기 설정에 따라 달라집니다. 배터리 잔량을 충분히 유지할 수 있도록 설정을 조정해 주세요. 저전력 상태에서는 전송 속도에 영향을 줄 수 있습니다. 동영상 파일은 용량이 크기 때문에 전송 시간이 길어질 수 있습니다. 블루투스 유효 거리는 제한이 있습니다. 멀리 떨어뜨려 사용하지 마세요. 고장 처리 (문제 해결) 블루투스 연결 실패: 기기와 APP 을 재시작하고, 페어링 목록을 새로고 침한 후 스마트폰 블루투스가 켜져 있는지 확인해 주세요. 콘텐츠가 표시되지 않음: 파일을 다시 업로드하거나, 메모리가 꽉 찼는지 확인하세요. 버튼이 반응하지 않음: 전원 버튼을 10 초간 길게 눌러 강제로 재시동하세요. Korean Deslizar hacia arriba: Entrar en la cámara, calculadora Abre la APP en el móvil y mantén la conexión con el dispositivo. En el dispositivo, haz clic en el icono de la cámara para ir a la página de fotografía y pulsa el botón de disparo en la pantalla del dispositivo para tomar la foto. Fotografía sincronizada: Cambiar el modo de suspensión automática (apagado automático de la pantalla tras 10 minutos de inactividad o encendido permanente). Eliminar la imagen actual (desliza a izquierda o derecha para seleccionar la imagen que deseas eliminar). Compar tir con un toque: Transmisión mutua de imágenes entre dispositivos. El dispositivo A hace clic en “Compar tir imagen” para entrar en modo de envío; el dispositivo B hace clic en “Recibir imagen” para entrar en modo de recepción. Manual de usuario Presentación del producto Puer to de carga Type-C Orificio del altavoz Botón de encendido Botón Bluetooth Descarga y conexión de la APP 1.Escanea el código QR para descargar e instalar la APP “ZRun” (…

Text truncated - open the document above for the full version.

Shenzhenshi Hanhongsheng Technology Co., Ltd Covered Equipment Certification Attestation Letter 5/14/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2BV27-H01 Shenzhenshi Hanhongsheng Technology Co., Ltd (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Shenzhenshi Hanhongsheng Technology Co., Ltd (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Shenzhenshi Hanhongsheng Technology Co., Ltd (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Signed: Printed name: Wei Tong Title: Manager Company Name: Shenzhenshi Hanhongsheng Technology Co., Ltd Date: 5/14/2026

Shenzhenshi Hanhongsheng Technology Co., Ltd U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: May 14, 2026 Ref: Attestation Statement – Part 2.911(d)(7) filing FCC ID: 2BV27-H01 Shenzhenshi Hanhongsheng Technology Co., Ltd(“the applicant”) certifies that, as of the date of the filing of the application, CLF Import and Export Limited (“the agent”) is our designated U.S. agent for service of process for the above reference FCC ID. The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges it is our responsibility to inform the FCC whenever the agent information changes. CLF Import and Export Limited ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: CLF Import and Export Limited FRN: 0033489683 Address: 1312 17th Street #692, Denver, CO 80202, United States Signature: Contact Person: David Chen Tel: +1 949 254 2565 Email: [email protected] Applicant Company Name: Shenzhenshi Hanhongsheng Technology Co., Ltd FRN: 0038408936 Address: Room 1708, Building A, Sichuang Science and Technology Park, No. 6 Guansheng 2nd Road, Guanlan High-Tech Park, Longhua District, Shenzhen China Signature: Contact Person: Wei Tong Tel: 18928486196 Email: [email protected]

DATE: May 14, 2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen CCUT Quality Technology Co., Ltd. (1F, Building 35, Changxing Technology Indstrl Park Changzhen Community, Yutang Street,Shenzhen,China) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Shenzhenshi Hanhongsheng Technology Co., Ltd (Room 1708, Building A, Sichuang Science and Technology Park, No. 6 Guansheng 2nd Road, Guanlan High-Tech Park, Longhua District, Shenzhen China). <Signature> Name: Wei Tong Title: Manager Company: Shenzhenshi Hanhongsheng Technology Co., Ltd

Date: May 14, 2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature> Name: Wei Tong Title: Manager Company: Shenzhenshi Hanhongsheng Technology Co., Ltd

DATE: May 14, 2026 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BV27-H01 Product Name: E-Badge Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: Wei Tong Title: Manager Company: Shenzhenshi Hanhongsheng Technology Co., Ltd

Shenzhenshi Hanhongsheng Technology Co., Ltd Model Difference Statement DATE: May 14, 2026 FCC ID: 2BV27-H01 Dear Sir/Madam, Added models H02, H03, H04, H05, H06, H07, H08 basis of the original product H01 The color of appearance and model name of series models listed are different from the main model, but the circuit and the electronic construction are the same, declared by the manufacturer. Sincerely, <Signature> Name: Wei Tong Title: Manager Company: Shenzhenshi Hanhongsheng Technology Co., Ltd

Report No: DSP26050001-1E FCC ID: 2BV27-H01 Annex A. EUT External Photos EUT View 1 EUT View 2 Report No: DSP26050001-1E FCC ID: 2BV27-H01 Model: H01 EUT View 3 EUT View 4 Report No: DSP26050001-1E FCC ID: 2BV27-H01 EUT View 5 EUT View 6 Report No: DSP26050001-1E FCC ID: 2BV27-H01 EUT View 7 EUT View 8

Report No: DSP26050001-1E FCC ID: 2BV27-H01 Annex D. Label FCC Label Sample Label Size: 1.5cm*1cm FCC Label Specifications Text is Black in color and is justified. Labels are printed in indelible ink on permanent adhesive backing or silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Where the EUT is constructed in two or more sections connected by wires and marketed together, the above statement is required to be affixed only to the main control unit. When the EUT is so small or for such use that it is not practicable to place the statement on it, the above information shall be placed in a prominent location in the instruction manual or pamphlet supplied to the user or, alternatively, shall be placed on the container in which the device is marketed. FCC Label Location

Report No: DSP26050001-1E FCC ID: 2BV27-H01 Annex B. EUT Internal Photos EUT View 1 EUT View 2 Integral ANT Report No: DSP26050001-1E FCC ID: 2BV27-H01 EUT View 3 EUT View 4 Report No: DSP26050001-1E FCC ID: 2BV27-H01 EUT View 5

FCC ID: 2BV27-H01 RF Exposure Evaluation According to KDB 447498 D01 General RF Exposure Guidance v06 and part 2.1093，Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Here, The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. For BLE Max Conducted Power(dBm) Tune-up Power(dBm) Max Tune-up Power(dBm) Max Power(mW) Frequency(MHz) Min. distance(mm) Calc. thresholds limit 7.51 7(±1) 8 6.31 2402 5 1.9558964 3.0 So a SAR test is not required

Report No: DSP26050001-1E FCC Test Report Page 1 of 33 FCC TEST REPORT FCC ID: 2BV27-H01 Report No. : DSP26050001-1E Applicant : Shenzhenshi Hanhongsheng Technology Co., Ltd Product Name : E-Badge Model Name : H01 Test Standard : FCC Part 15.247 Date of Issue : 2026-05-12 Shenzhen CCUT Quality Technology Co., Ltd. 1F, Building 35, Changxing Technology Industrial Park, Yutang Street, Guangming District, Shenzhen, Guangdong, China; (Tel.:+86-755-23406590 website: www.ccuttest.com) This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen CCUT Quality Technology Co., Ltd. Report No: DSP26050001-1E FCC Test Report Page 2 of 33 Test Report Basic Information Applicant..................................: Shenzhenshi Hanhongsheng Technology Co., Ltd Address of Applicant...............: Room 1708, Building A, Sichuang Science and Technology Park, No. 6 Guansheng 2nd Road, Guanlan High-Tech Park, Longhua District, Shenzhen China Manufacturer..........................: Shenzhenshi Hanhongsheng Technology Co., Ltd Address of Manufacturer........: Room 1708, Building A, Sichuang Science and Technology Park, No. 6 Guansheng 2nd Road, Guanlan High-Tech Park, Longhua District, Shenzhen China Product Name.........................: E-Badge Brand Name.............................: - Main Model..............................: H01 Series Models..........................: H02, H03, H04, H05, H06, H07, H08 Test Standard..........................: FCC Part 15 Subpart C KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.4-2014 ANSI C63.10-2020 Date of Test .............................: 2026-05-07 to 2026-05-11 Test Result...............................: PASS Tested By ................................: (Colin Chen) Reviewed By............................: (Lorzix Luo) Authorized Signatory............: (Lahm Peng) Note : This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen CCUT Quality Technology Co., Ltd.. All test data presented in this test report is only applicable to presented test sample. Report No: DSP26050001-1E FCC Test Report Page 3 of 33 CONTENTS 1. General Information ....................................................................................................................................................5 1.1 Product Information .............................................................................................................................................5 1.2 Test Setup Information..........................................................................................................................................6 1.3 Compliance Standards ...........................................................................................................................................7 1.4 Test Facilities ........................................................................................................................................................7 1.5 List of Measurement Instruments ..........................................................................................................................8 1.6 Measurement Uncertainty .....................................................................................................................................9 2. Summary of Test Results ........................................................................................................................................... 10 3. Antenna Requirement ............................................................................................................................................... 11 3.1 Standard and Limit.............................................................................................................................................. 11 3.2 Test Result .......................................................................................................................................................... 11 4. Conducted Emissions ................................................................................................................................................ 12 4.1 Standard and Limit.............................................................................................................................................. 12 4.2 Test Procedure.................................................................................................................................................... 12 4.3 Test Data and Results .......................................................................................................................................... 13 5. Radiated Emissions ................................................................................................................................................... 16 5.1 Standard and Limit.............................................................................................................................................. 16 5.2 Test Procedure.................................................................................................................................................... 16 5.3 Test Data and Results .......................................................................................................................................... 18 6. Band-edge Emissions(Radiated) ............................................................................................................................... 22 6.1 Standard and Limit.............................................................................................................................................. 22 6.2 Test Procedure.................................................................................................................................................... 22 6.3 Test Data and Results ...................…

Text truncated - open the document above for the full version.

Page 1 of 3 1. General Information 1.1 Antenna Information Manufacturer: Shenzhenshi Hanhongsheng Technology Co., Ltd Address of Manufacturer: Room 1708, Building A, Sichuang Science and Technology Park, No. 6 Guansheng 2nd Road, Guanlan High-Tech Park, Longhua District, Shenzhen China Product Name: 2.4GHz Antenna Model Name: H01 Frequency Range: 2400MHz - 2500MHz Type of Antenna: Integral Antenna Antenna Gain: 0dBi (Max.) Impedance: 50 ohm Antenna View: Page 2 of 3 2. Antenna Specification information 2.1 Gain Frequency Peak Gain (dBi) Polarity 2400MHz 0 Horizontal 2400MHz -0.54 Vertical 2450MHz -1.25 Horizontal 2450MHz -1.51 Vertical 2500MHz -1.68 Horizontal 2500MHz -1.27 Vertical Page 3 of 3 2.2 Radiation Pattern View

Report No: DSP26050001-1E FCC ID: 2BV27-H01 Annex C. Test Photos Radiated Emission Test View 1 Radiated Emission Test View 2 Report No: DSP26050001-1E FCC ID: 2BV27-H01 Conducted Emission Test View 1
