2BV35LM103IOTLITEEdgeBox

Product Features •Triple-core Cortex A7 + single-core Cortex M0, with a maximum clock speed of 1.5 GHz . •1 x Fully Isolated RS485 ( RS232 Multiplexed) Interface •1 x 100M/10M Ethernet interface •Multi-protocol support: Modbus , BACnet , OPC UA , IEC104 , DLT/645 , S7 , etc. •Supports MQTT cloud communication •Supports online monitoring of web services . •Supports alarm settings and push notifications •Support edge computing •Supports JavaScript scripts for logic control •Supports remote monitoring and firmware upgrades •Operating temperature: -40 ～ 85°C •Supports 4G •Supports a maximum of 1024 data points Product Introduction 103-IoTlite is designed for specific data acquisition and protocol conversion in industrial, commercial, or enterprise environments, acting as a bridge between devices and cloud platforms, SCADA , and MES systems. It requires professional installation, embeds standard data acquisition drivers, and provides proprietary protocol integration. It provides data externally via Modbus , BACnet , and OPC UA services. It transmits data with cloud platforms using MQTT and HTTP protocols, providing a unified data interface, making it ideal for digital factories, smart buildings, and energy management. Product Specifications Hardware parameters Memory256MB DDR3 Nand flash512MB NAND Flash Power supplyDC9V ~ 30V , supports reverse connection protection, overcurrent protection, etc. LED indicator lightPOWER , SYS , serial port transmit/receive indicators Enclosure protection ratingIP50 Power consumption The maximum average power consumption of the entire device is ≤ 5W . Under extreme conditions, the instantaneous peak power consumption of wireless data transmission may reach 10W . The effective output power of the power supply provided by the user must be >10W. Installation methodSupports wall mounting and DIN rail back mounting, DIN rail side mounting. SIM card Micro SIM card ( 12 × 15mm ) I/O interface Serial port1xRS485 Network port1xLAN port Power connector1x3-pin terminal Environmental parameters Operating relative humidity20-90 % No condensation Relative humidity during storage and transportation 15 % –95 % No condensation Northbound Data Services The gateway provides various data services for automatic control systems such as SCADA , power, and BA . •Modbus service •BACnet service •OPC UA service •IEC104 service •OPC XML-DA Server IoT The gateway communicates with the cloud server via the MQTT protocol. •Standard MQTT client •Thingsboard •IoTDA •Amazon •Customized private cloud connection •LM ThingsIoT Value-Added Cloud Services 103-IoTlite 1xLAN 1xRS485 4G www.lmgateway.com IoT product supplier [email protected] m List of southbound data acquisition drivers (supports customization of private protocols) 103-IoTlite 1xLAN 1xRS485 4G www.lmgateway.com IoT product supplier [email protected] m Data acquisition driver Serial PortNetwork port Meter Modbus Modbus RTUModbus TCP ModbusAsciiModbus RTU_over_TCP ModbusRTUBroadcast ModbusRTU Monitoring ModbusRTU Service DLT645 DLT645-1997 DLT645_over_TCP DLT645-2007 DLT645.98 DLT645 Monitor CJ188CJ188CJ188_over_TCP Mbus MBus_EnergyMeter MBus_EN1434 PLC Mitsubishi Mitsubishi Fx3UMC_Qna-3EBinary Mitsubishi Fx485MC_Qna-1EBinary EtherNet /IP CIP SiemensSiemens S7-200 PPI Siemens S7-200 Network Siemens S7-300 Network Siemens S7-400 Network Siemens S7-1200 Network Siemens S7-1500 Network FetchWrite ABAllen_Bradley_DF1AB NET Omron HOSTLINK-FINS OMRON_FINS HOSTLINK-CMODE MatsushitaMewtocolEtherNet /IP CIP YokogawaYokogawa PLC Rich MachineFUJI_SPH_NET KEYENCE KEYENCE host link communication OPC OPC UA OPC DA OPC XML DA IEC IEC104 IEC61850 Smart Buildings BACnet BACnet MS/TP BACnet IP BACnet Routing Hitachi Elevator IT Interface MQTT Client HTTP Client Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. FCC compliance statement 103-IoTlite 1xLAN 1xRS485 4G www.lmgateway.com IoT product supplier [email protected] m This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or a…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 1 / 54 1. Effective (Isotropic) Radiated Power Output Data 1.1 Test Result 1.1.1 B2_1.4MHz_EIRP Band: 2 / Bandwidth: 1.4MHz / NTNV Modulation Frequency (MHz) RB Allocation Conducted Power (dBm) Gain (dBi) EIRP (dBm) Verdict Size Offset Result Limit QPSK 1850.7 1 0 23.74 -4.09 19.65 <=33.01 Pass 2 23.68 -4.09 19.59 <=33.01 Pass 5 23.58 -4.09 19.49 <=33.01 Pass 3 0 23.48 -4.09 19.39 <=33.01 Pass 2 23.43 -4.09 19.34 <=33.01 Pass 3 23.40 -4.09 19.31 <=33.01 Pass 6 0 22.39 -4.09 18.30 <=33.01 Pass 1880 1 0 23.73 -4.09 19.64 <=33.01 Pass 2 23.67 -4.09 19.58 <=33.01 Pass 5 23.57 -4.09 19.48 <=33.01 Pass 3 0 23.49 -4.09 19.40 <=33.01 Pass 2 23.47 -4.09 19.38 <=33.01 Pass 3 23.49 -4.09 19.40 <=33.01 Pass 6 0 23.08 -4.09 18.99 <=33.01 Pass 1909.3 1 0 24.39 -4.09 20.30 <=33.01 Pass 2 24.29 -4.09 20.20 <=33.01 Pass 5 24.08 -4.09 19.99 <=33.01 Pass 3 0 24.25 -4.09 20.16 <=33.01 Pass 2 24.13 -4.09 20.04 <=33.01 Pass 3 24.03 -4.09 19.94 <=33.01 Pass 6 0 23.09 -4.09 19.00 <=33.01 Pass 16QAM 1850.7 1 0 22.39 -4.09 18.30 <=33.01 Pass 2 22.42 -4.09 18.33 <=33.01 Pass 5 22.42 -4.09 18.33 <=33.01 Pass 3 0 22.41 -4.09 18.32 <=33.01 Pass 2 22.42 -4.09 18.33 <=33.01 Pass 3 22.43 -4.09 18.34 <=33.01 Pass 6 0 21.61 -4.09 17.52 <=33.01 Pass 1880 1 0 22.90 -4.09 18.81 <=33.01 Pass 2 22.86 -4.09 18.77 <=33.01 Pass 5 22.87 -4.09 18.78 <=33.01 Pass 3 0 23.13 -4.09 19.04 <=33.01 Pass 2 23.07 -4.09 18.98 <=33.01 Pass 3 23.10 -4.09 19.01 <=33.01 Pass 6 0 22.02 -4.09 17.93 <=33.01 Pass 1909.3 1 0 23.20 -4.09 19.11 <=33.01 Pass 2 23.37 -4.09 19.28 <=33.01 Pass 5 23.24 -4.09 19.15 <=33.01 Pass 3 0 23.20 -4.09 19.11 <=33.01 Pass 2 23.16 -4.09 19.07 <=33.01 Pass 3 23.09 -4.09 19.00 <=33.01 Pass 6 0 22.25 -4.09 18.16 <=33.01 Pass Note1: EIRP=Conducted Power+Antenna Gain SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 2 / 54 1.1.2 B2_3MHz_EIRP Band: 2 / Bandwidth: 3MHz / NTNV Modulation Frequency (MHz) RB Allocation Conducted Power (dBm) Gain (dBi) EIRP (dBm) Verdict Size Offset Result Limit QPSK 1851.5 1 0 23.75 -4.09 19.66 <=33.01 Pass 7 23.90 -4.09 19.81 <=33.01 Pass 14 23.68 -4.09 19.59 <=33.01 Pass 8 0 22.72 -4.09 18.63 <=33.01 Pass 4 22.76 -4.09 18.67 <=33.01 Pass 7 22.70 -4.09 18.61 <=33.01 Pass 15 0 22.92 -4.09 18.83 <=33.01 Pass 1880 1 0 23.64 -4.09 19.55 <=33.01 Pass 7 23.75 -4.09 19.66 <=33.01 Pass 14 23.58 -4.09 19.49 <=33.01 Pass 8 0 22.52 -4.09 18.43 <=33.01 Pass 4 22.57 -4.09 18.48 <=33.01 Pass 7 22.52 -4.09 18.43 <=33.01 Pass 15 0 22.49 -4.09 18.40 <=33.01 Pass 1908.5 1 0 24.52 -4.09 20.43 <=33.01 Pass 7 24.57 -4.09 20.48 <=33.01 Pass 14 24.12 -4.09 20.03 <=33.01 Pass 8 0 23.50 -4.09 19.41 <=33.01 Pass 4 23.48 -4.09 19.39 <=33.01 Pass 7 23.37 -4.09 19.28 <=33.01 Pass 15 0 23.42 -4.09 19.33 <=33.01 Pass 16QAM 1851.5 1 0 23.07 -4.09 18.98 <=33.01 Pass 7 23.22 -4.09 19.13 <=33.01 Pass 14 23.05 -4.09 18.96 <=33.01 Pass 8 0 22.06 -4.09 17.97 <=33.01 Pass 4 22.12 -4.09 18.03 <=33.01 Pass 7 22.08 -4.09 17.99 <=33.01 Pass 15 0 21.97 -4.09 17.88 <=33.01 Pass 1880 1 0 22.41 -4.09 18.32 <=33.01 Pass 7 22.58 -4.09 18.49 <=33.01 Pass 14 22.43 -4.09 18.34 <=33.01 Pass 8 0 21.61 -4.09 17.52 <=33.01 Pass 4 21.67 -4.09 17.58 <=33.01 Pass 7 21.64 -4.09 17.55 <=33.01 Pass 15 0 21.57 -4.09 17.48 <=33.01 Pass 1908.5 1 0 23.20 -4.09 19.11 <=33.01 Pass 7 23.35 -4.09 19.26 <=33.01 Pass 14 22.95 -4.09 18.86 <=33.01 Pass 8 0 22.47 -4.09 18.38 <=33.01 Pass 4 22.50 -4.09 18.41 <=33.01 Pass 7 22.40 -4.09 18.31 <=33.01 Pass 15 0 22.46 -4.09 18.37 <=33.01 Pass Note1: EIRP=Conducted Power+Antenna Gain SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 3 / 54 1.1.3 B2_5MHz_EIRP Band: 2 / Bandwidth: 5MHz / NTNV Modulation Frequency (MHz) RB Allocation Conducted Power (dBm) Gain (dBi) EIRP (dBm) Verdict Size Offset Result Limit QPSK 1852.5 1 0 23.83 -4.09 19.74 <=33.01 Pass 13 23.65 -4.09 19.56 <=33.01 Pass 24 23.58 -4.09 19.49 <=33.01 Pass 12 0 22.68 -4.09 18.59 <=33.01 Pass 6 22.63 -4.09 18.54 <=33.01 Pass 13 22.61 -4.09 18.52 <=33.01 Pass 25 0 22.60 -4.09 18.51 <=33.01 Pass 1880 1 0 23.66 -4.09 19.57 <=33.01 Pass 13 23.54 -4.09 19.45 <=33.01 Pass 24 23.60 -4.09 19.51 <=33.01 Pass 12 0 22.41 -4.09 18.32 <=33.01 Pass 6 22.39 -4.09 18.30 <=33.01 Pass 13 22.44 -4.09 18.35 <=33.01 Pass 25 0 22.40 -4.09 18.31 <=33.01 Pass 1907.5 1 0 24.40 -4.09 20.31 <=33.01 Pass 13 24.41 -4.09 20.32 <=33.01 Pass 24 24.06 -4.09 19.97 <=33.01 Pass 12 0 23.30 -4.09 19.21 <=33.01 Pass 6 23.33 -4.09 19.24 <=33.01 Pass 13 23.45 -4.09 19.36 <=33.01 Pass 25 0 23.46 -4.09 19.37 <=33.01 Pass 16QAM 1852.5 1 0 22.87 -4.09 18.78 <=33.01 Pass 13 22.80 -4.09 18.71 <=33.01 Pass 24 22.77 -4.09 18.68 <=33.01 Pass 12 0 21.82 -4.09 17.73 <=33.01 Pass 6 21.79 -4.09 17.70 <=33.01 Pass 13 21.78 -4.09 17.69 <=33.01 Pass 25 0 21.82 -4.09 17.73 <=33.01 Pass 1880 1 0 22.58 -4.09 18.49 <=33.01 Pass 13 22.52 -4.09 18.43 <=33.01 Pass 24 22.60 -4.09 18.51 <=33.01 Pass 12 0 21.48 -4.09 17.39 <=33.01 Pass 6 21.47 -4.09 17.38 <=33.01 Pass 13 21.54 -4.09 17.45 <=33.01 Pass 25 0 21.53 -4.09 17.44 <=33.01 Pass 1907.5 1 0 23.67 -4.09 19.58 <=33.01 Pass 13 23.71 -4.09 19.62 <=33.01 Pass 24 23.42 -4.09 19.33 <=33.01 Pass 12 0 22.49 -4.09 18.40 <=33.01 Pass 6 22.52 -4.09 18.43 <=33.01 Pass 13 22.52 -4.09 18.43 <=33.01 Pass 25 0 22.36 -4.09 18.27 <=33.01 Pass Note1: EIRP=Conducted Power+Antenna Gain SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 4 / 54 1.1.4 B2_10MHz_EIRP Band: 2 / Bandwidth: 10MHz / NTNV Modulation Frequency (MHz) RB Allocation Conducted Power (dBm) Gain (dBi) EIRP (dBm) Verdict Size Offset Result Limit QPSK 1855 1 0 23.71 -4.09 19.62 <=33.01 Pass 25 23.54 -4.09 19.45 <=33.01 Pass 49 23.47 -4.09 19.38 <=33.01 Pass 25 0 22.63 -4.09 18.54 <=33.01 Pass 13 22.57 -4.09 18.48 <=33.01 Pass 25 22.56 -4.09 18.47 <=33.01 Pass 50 0 22.61 -4.09 18.52 <=33.01 Pass 1880 1 0 23.57 -4.09 19.48 <=33.01 Pass 25 23.47 -4.09 19.38 <=…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01-A04 Rev.A/1 Page: 1 of 2 Appendix Test Setup Photos for SZCR2605001848AT FCC ID: 2BV35LM103IOTLITE SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01-A04 Rev.A/1 Page: 2 of 2 Test Setup Photo Field strength of spurious radiation below 1GHz Field strength of spurious radiation above 1GHz - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/2 Report No.: SZCR260500184801 Page: 1 of 28 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZCR2605001848AT Applicant: LMGateway Co., Ltd. Address of Applicant: Rm206, Bldg2, FutureSciTechCity, MeilinAve, Huangshan, China Manufacturer: LMGateway Co., Ltd. Address of Manufacturer: Room 206, Building 2, Future Science and Technology City, No. 59, Meilin Avenue, economic development Zone, Huangshan City, Anhui Province Factory: LMGateway Co., Ltd. Address of Factory: Room 206, Building 2, Future Science and Technology City, No. 59, Meilin Avenue, Economic Development Zone, Huangshan City, Anhui Province Equipment Under Test (EUT): EUT Name: EdgeBox Model No.: 103lite Trade Mark: LM Gateway FCC ID: 2BV35LM103IOTLITE Standard(s) : 47 CFR Part 2 47 CFR Part 22 47 CFR Part 24 47 CFR Part 27 Date of Receipt: 2026-05-06 Date of Test: 2026-05-08 to 2026-05-12 Date of Issue: 2026-05-18 Test Result: Pass * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/2 Report No.: SZCR260500184801 Page: 2 of 28 Revision Record Version Chapter Date Modifier Remark 01 2026-05-18 Original Authorized for issue by: Calvin Weng/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/2 Report No.: SZCR260500184801 Page: 3 of 28 2 Test Summary Test Item FCC Rule No. Requirements Verdict Effective (Isotropic) Radiated Output Power Data §2.1046 §22.913 §24.232 §27.50(b) §27.50(c) §27.50(d) ERP≤ 7W(LTE Band 5) EIRP≤ 2W(LTE Band 2) ERP≤ 3W(LTE Band 13) ERP≤ 3W(LTE Band 12) EIRP≤ 1W(LTE Band 4,66) PASS Peak-Average Ratio §22.913 §24.232 §27.50(a) §27.50(d) ≤13dB PASS Bandwidth §2.1049(h) OBW: No limit EBW: No limit PASS Band Edge Compliance §2.1051 §22.917 §24.238 §27.50(g) §27.50(h) §27.53(c) ≤ -13dBm (LTE Band5) ≤ -13dBm (LTE Band2) ≤ -13dBm (LTE Band12) ≤ -13dBm (LTE Band4,66) Refer to clause 6.4 for LTE Band13 PASS Spurious emissions at antenna terminals §2.1051 §22.917 §24.238 §27.50(g) §27.50(h) §27.53(c) ≤ -13dBm (LTE Band5) ≤ -13dBm (LTE Band2) ≤ -13dBm (LTE Band12) ≤ -13dBm (LTE Band4,66) Refer to clause 6.5 for LTE Band13 PASS Field strength of spurious radiation §2.1051 §22.917 §24.238 §27.50(g) §27.50(h) §27.53(c) ≤ -13dBm (LTE Band5) ≤ -13dBm (LTE Band2) ≤ -13dBm (LTE Band12) ≤ -13dBm (LTE Band4,66) Refer to clause 6.6 for LTE Band13 PASS Frequency stability §2.1055 §22.355 §24.235 §27.54 ≤ ±2.5ppm. PASS SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/2 Report No.: SZCR260500184801 Page: 4 of 28 3 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Test Summary ........................................................................................................................................... 3 3 Contents .................................................................................................................................................... 4 4 General Information .................................................................................................................................. 6 4.1 Details of E.U.T. ................................................................................................................................. 6 4.2 Test Frequency .................................................................................................................................. 7 4.3 Test Environment ............................................................................................................................... 8 4.4 Description of Support Units .............................................................................................................. 9 4.5 Measurement Uncertainty .................................................................................................................. 9 4.6 Test Location .................................................................................................................................... 10 4.7 Test Facility ...................................................................................................................................... 10 4.8 Deviation from Standards ................................................................................................................. 10 4.9 Abnormalities from Standard Conditions ......................................................................................... 10 5 Equipment List ........................................................................................................................................ 11 6 Radio Spectrum Matter Test Results .................................................................................................... 13 6.1 Effective (Isotropic) Radiated Output Power Data ........................................................................... 13 6.1.1 E.U.T. Operation .......................................................................................................................... 13 6.1.2 Test Setup Diagram ..................................................................................................................... 13 6.1.3 Measurement Data ...................................................................................................................... 13 6.2 Peak-Average Ratio ......................................................................................................................... 14 6.2.1 E.U.T. Operation .......................................................................................................................... 14 6.2.2 Test Setup Diagram ...........................................................................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 1 / 54 1. Effective (Isotropic) Radiated Power Output Data 1.1 Test Result 1.1.1 B66_1.4MHz_EIRP Band: 66 / Bandwidth: 1.4MHz / NTNV Modulation Frequency (MHz) RB Allocation Conducted Power (dBm) Gain (dBi) EIRP (dBm) Verdict Size Offset Result Limit QPSK 1710.7 1 0 23.92 -4.09 19.83 <=30 Pass 2 23.75 -4.09 19.66 <=30 Pass 5 23.49 -4.09 19.40 <=30 Pass 3 0 23.45 -4.09 19.36 <=30 Pass 2 23.38 -4.09 19.29 <=30 Pass 3 23.33 -4.09 19.24 <=30 Pass 6 0 22.41 -4.09 18.32 <=30 Pass 1745 1 0 23.31 -4.09 19.22 <=30 Pass 2 23.32 -4.09 19.23 <=30 Pass 5 23.25 -4.09 19.16 <=30 Pass 3 0 23.25 -4.09 19.16 <=30 Pass 2 23.21 -4.09 19.12 <=30 Pass 3 23.19 -4.09 19.10 <=30 Pass 6 0 22.22 -4.09 18.13 <=30 Pass 1779.3 1 0 23.76 -4.09 19.67 <=30 Pass 2 23.59 -4.09 19.50 <=30 Pass 5 23.50 -4.09 19.41 <=30 Pass 3 0 23.41 -4.09 19.32 <=30 Pass 2 23.38 -4.09 19.29 <=30 Pass 3 23.35 -4.09 19.26 <=30 Pass 6 0 22.40 -4.09 18.31 <=30 Pass 16QAM 1710.7 1 0 22.53 -4.09 18.44 <=30 Pass 2 22.53 -4.09 18.44 <=30 Pass 5 22.51 -4.09 18.42 <=30 Pass 3 0 22.38 -4.09 18.29 <=30 Pass 2 22.40 -4.09 18.31 <=30 Pass 3 22.38 -4.09 18.29 <=30 Pass 6 0 21.42 -4.09 17.33 <=30 Pass 1745 1 0 22.30 -4.09 18.21 <=30 Pass 2 22.33 -4.09 18.24 <=30 Pass 5 22.30 -4.09 18.21 <=30 Pass 3 0 22.30 -4.09 18.21 <=30 Pass 2 22.25 -4.09 18.16 <=30 Pass 3 22.25 -4.09 18.16 <=30 Pass 6 0 21.45 -4.09 17.36 <=30 Pass 1779.3 1 0 22.28 -4.09 18.19 <=30 Pass 2 22.34 -4.09 18.25 <=30 Pass 5 22.28 -4.09 18.19 <=30 Pass 3 0 22.59 -4.09 18.50 <=30 Pass 2 22.57 -4.09 18.48 <=30 Pass 3 22.54 -4.09 18.45 <=30 Pass 6 0 21.58 -4.09 17.49 <=30 Pass Note1: EIRP=Conducted Power+Antenna Gain SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 2 / 54 1.1.2 B66_3MHz_EIRP Band: 66 / Bandwidth: 3MHz / NTNV Modulation Frequency (MHz) RB Allocation Conducted Power (dBm) Gain (dBi) EIRP (dBm) Verdict Size Offset Result Limit QPSK 1711.5 1 0 23.38 -4.09 19.29 <=30 Pass 7 23.36 -4.09 19.27 <=30 Pass 14 23.10 -4.09 19.01 <=30 Pass 8 0 22.35 -4.09 18.26 <=30 Pass 4 22.34 -4.09 18.25 <=30 Pass 7 22.27 -4.09 18.18 <=30 Pass 15 0 22.24 -4.09 18.15 <=30 Pass 1745 1 0 23.15 -4.09 19.06 <=30 Pass 7 23.26 -4.09 19.17 <=30 Pass 14 22.97 -4.09 18.88 <=30 Pass 8 0 22.20 -4.09 18.11 <=30 Pass 4 22.23 -4.09 18.14 <=30 Pass 7 22.20 -4.09 18.11 <=30 Pass 15 0 22.18 -4.09 18.09 <=30 Pass 1778.5 1 0 23.72 -4.09 19.63 <=30 Pass 7 23.69 -4.09 19.60 <=30 Pass 14 23.40 -4.09 19.31 <=30 Pass 8 0 22.55 -4.09 18.46 <=30 Pass 4 22.55 -4.09 18.46 <=30 Pass 7 22.48 -4.09 18.39 <=30 Pass 15 0 22.51 -4.09 18.42 <=30 Pass 16QAM 1711.5 1 0 22.43 -4.09 18.34 <=30 Pass 7 22.52 -4.09 18.43 <=30 Pass 14 22.31 -4.09 18.22 <=30 Pass 8 0 21.25 -4.09 17.16 <=30 Pass 4 21.27 -4.09 17.18 <=30 Pass 7 21.33 -4.09 17.24 <=30 Pass 15 0 21.26 -4.09 17.17 <=30 Pass 1745 1 0 22.17 -4.09 18.08 <=30 Pass 7 22.32 -4.09 18.23 <=30 Pass 14 22.16 -4.09 18.07 <=30 Pass 8 0 21.46 -4.09 17.37 <=30 Pass 4 21.48 -4.09 17.39 <=30 Pass 7 21.46 -4.09 17.37 <=30 Pass 15 0 21.39 -4.09 17.30 <=30 Pass 1778.5 1 0 22.29 -4.09 18.20 <=30 Pass 7 22.44 -4.09 18.35 <=30 Pass 14 22.18 -4.09 18.09 <=30 Pass 8 0 21.64 -4.09 17.55 <=30 Pass 4 21.66 -4.09 17.57 <=30 Pass 7 21.59 -4.09 17.50 <=30 Pass 15 0 21.64 -4.09 17.55 <=30 Pass Note1: EIRP=Conducted Power+Antenna Gain SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 3 / 54 1.1.3 B66_5MHz_EIRP Band: 66 / Bandwidth: 5MHz / NTNV Modulation Frequency (MHz) RB Allocation Conducted Power (dBm) Gain (dBi) EIRP (dBm) Verdict Size Offset Result Limit QPSK 1712.5 1 0 23.54 -4.09 19.45 <=30 Pass 13 23.29 -4.09 19.20 <=30 Pass 24 23.12 -4.09 19.03 <=30 Pass 12 0 22.41 -4.09 18.32 <=30 Pass 6 22.20 -4.09 18.11 <=30 Pass 13 22.13 -4.09 18.04 <=30 Pass 25 0 22.20 -4.09 18.11 <=30 Pass 1745 1 0 23.39 -4.09 19.30 <=30 Pass 13 23.18 -4.09 19.09 <=30 Pass 24 23.15 -4.09 19.06 <=30 Pass 12 0 22.20 -4.09 18.11 <=30 Pass 6 22.21 -4.09 18.12 <=30 Pass 13 22.20 -4.09 18.11 <=30 Pass 25 0 22.35 -4.09 18.26 <=30 Pass 1777.5 1 0 23.83 -4.09 19.74 <=30 Pass 13 23.71 -4.09 19.62 <=30 Pass 24 23.44 -4.09 19.35 <=30 Pass 12 0 22.61 -4.09 18.52 <=30 Pass 6 22.58 -4.09 18.49 <=30 Pass 13 22.55 -4.09 18.46 <=30 Pass 25 0 22.56 -4.09 18.47 <=30 Pass 16QAM 1712.5 1 0 22.54 -4.09 18.45 <=30 Pass 13 22.39 -4.09 18.30 <=30 Pass 24 22.28 -4.09 18.19 <=30 Pass 12 0 21.25 -4.09 17.16 <=30 Pass 6 21.20 -4.09 17.11 <=30 Pass 13 21.14 -4.09 17.05 <=30 Pass 25 0 21.29 -4.09 17.20 <=30 Pass 1745 1 0 22.53 -4.09 18.44 <=30 Pass 13 22.48 -4.09 18.39 <=30 Pass 24 22.46 -4.09 18.37 <=30 Pass 12 0 21.53 -4.09 17.44 <=30 Pass 6 21.54 -4.09 17.45 <=30 Pass 13 21.55 -4.09 17.46 <=30 Pass 25 0 21.57 -4.09 17.48 <=30 Pass 1777.5 1 0 22.85 -4.09 18.76 <=30 Pass 13 22.78 -4.09 18.69 <=30 Pass 24 22.66 -4.09 18.57 <=30 Pass 12 0 21.65 -4.09 17.56 <=30 Pass 6 21.63 -4.09 17.54 <=30 Pass 13 21.71 -4.09 17.62 <=30 Pass 25 0 21.77 -4.09 17.68 <=30 Pass Note1: EIRP=Conducted Power+Antenna Gain SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 4 / 54 1.1.4 B66_10MHz_EIRP Band: 66 / Bandwidth: 10MHz / NTNV Modulation Frequency (MHz) RB Allocation Conducted Power (dBm) Gain (dBi) EIRP (dBm) Verdict Size Offset Result Limit QPSK 1715 1 0 23.48 -4.09 19.39 <=30 Pass 25 23.09 -4.09 19.00 <=30 Pass 49 22.82 -4.09 18.73 <=30 Pass 25 0 22.11 -4.09 18.02 <=30 Pass 13 21.82 -4.09 17.73 <=30 Pass 25 21.70 -4.09 17.61 <=30 Pass 50 0 21.84 -4.09 17.75 <=30 Pass 1745 1 0 23.26 -4.09 19.17 <=30 Pass 25 23.23 -4.09 19.14 <=30 Pass 49 23.14 -4.09 19.05 <=30 Pass 25 0 22.23 -4.09 18.14 <=30 Pass 13 22.23 -4.09 18.14 <=30 Pass 25 22.21 -4.09 18.12 <=30 Pass 50 0 22.25 -4.09 18.16 <=30 Pass 1775 1 0 23.53 -4.09 19.44 <=30 Pass 25 23.21 -4.09 19.12 <=30 Pass 49 23.09 -4.09 19.00 <=30 Pass 25 0 22.25 -4.09 18.16 <=30 Pass 13 22.18 -4.09 18.09 <=30 Pass 25 22.14 -4.09 18.05 <=30 Pass 50 0 22.22 -4.09 18.13 <=30 Pass …

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 1 / 18 1. Effective (Isotropic) Radiated Power Output Data 1.1 Test Result 1.1.1 B13_5MHz_ERP Band: 13 / Bandwidth: 5MHz / NTNV Modulation Frequency (MHz) RB Allocation Conducted Power (dBm) Gain (dBi) ERP (dBm) Verdict Size Offset Result Limit QPSK 779.5 1 0 23.10 1.25 22.20 <=34.77 Pass 13 22.83 1.25 21.93 <=34.77 Pass 24 22.33 1.25 21.43 <=34.77 Pass 12 0 21.95 1.25 21.05 <=34.77 Pass 6 21.81 1.25 20.91 <=34.77 Pass 13 21.55 1.25 20.65 <=34.77 Pass 25 0 21.77 1.25 20.87 <=34.77 Pass 782 1 0 22.91 1.25 22.01 <=34.77 Pass 13 22.35 1.25 21.45 <=34.77 Pass 24 21.96 1.25 21.06 <=34.77 Pass 12 0 21.66 1.25 20.76 <=34.77 Pass 6 21.38 1.25 20.48 <=34.77 Pass 13 21.14 1.25 20.24 <=34.77 Pass 25 0 21.41 1.25 20.51 <=34.77 Pass 784.5 1 0 22.94 1.25 22.04 <=34.77 Pass 13 22.62 1.25 21.72 <=34.77 Pass 24 22.63 1.25 21.73 <=34.77 Pass 12 0 21.54 1.25 20.64 <=34.77 Pass 6 21.47 1.25 20.57 <=34.77 Pass 13 21.55 1.25 20.65 <=34.77 Pass 25 0 21.47 1.25 20.57 <=34.77 Pass 16QAM 779.5 1 0 22.18 1.25 21.28 <=34.77 Pass 13 21.99 1.25 21.09 <=34.77 Pass 24 21.61 1.25 20.71 <=34.77 Pass 12 0 21.28 1.25 20.38 <=34.77 Pass 6 21.16 1.25 20.26 <=34.77 Pass 13 20.91 1.25 20.01 <=34.77 Pass 25 0 21.14 1.25 20.24 <=34.77 Pass 782 1 0 22.06 1.25 21.16 <=34.77 Pass 13 21.54 1.25 20.64 <=34.77 Pass 24 21.16 1.25 20.26 <=34.77 Pass 12 0 20.79 1.25 19.89 <=34.77 Pass 6 20.52 1.25 19.62 <=34.77 Pass 13 20.30 1.25 19.40 <=34.77 Pass 25 0 20.57 1.25 19.67 <=34.77 Pass 784.5 1 0 22.01 1.25 21.11 <=34.77 Pass 13 21.72 1.25 20.82 <=34.77 Pass 24 21.77 1.25 20.87 <=34.77 Pass 12 0 20.72 1.25 19.82 <=34.77 Pass 6 20.76 1.25 19.86 <=34.77 Pass 13 20.76 1.25 19.86 <=34.77 Pass 25 0 20.83 1.25 19.93 <=34.77 Pass Note1: ERP=Conducted Power+Antenna Gain-2.15 SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 2 / 18 1.1.2 B13_10MHz_ERP Band: 13 / Bandwidth: 10MHz / NTNV Modulation Frequency (MHz) RB Allocation Conducted Power (dBm) Gain (dBi) ERP (dBm) Verdict Size Offset Result Limit QPSK 782 1 0 23.36 1.25 22.46 <=34.77 Pass 25 22.54 1.25 21.64 <=34.77 Pass 49 22.12 1.25 21.22 <=34.77 Pass 25 0 21.94 1.25 21.04 <=34.77 Pass 13 21.46 1.25 20.56 <=34.77 Pass 25 21.15 1.25 20.25 <=34.77 Pass 50 0 21.55 1.25 20.65 <=34.77 Pass 16QAM 782 1 0 22.51 1.25 21.61 <=34.77 Pass 25 21.78 1.25 20.88 <=34.77 Pass 49 21.41 1.25 20.51 <=34.77 Pass 12 0 22.22 1.25 21.32 <=34.77 Pass 19 21.39 1.25 20.49 <=34.77 Pass 38 21.13 1.25 20.23 <=34.77 Pass 27 0 20.96 1.25 20.06 <=34.77 Pass Note1: ERP=Conducted Power+Antenna Gain-2.15 SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 3 / 18 2. Frequency Stability 2.1 Test Result 2.1.1 B13_10MHz Band: 13 / Bandwidth: 10MHz Modulation Frequency (MHz) RB Allocation Temp. (°C) Voltage Freq. Error (Hz) Freq. vs. Rated (ppm) Verdict Size Offset Result Limit QPSK 782 50 0 20 LV 0.329 0.0004 -2.5 to 2.5 Pass NV -0.229 -0.0003 -2.5 to 2.5 Pass HV 0.615 0.0008 -2.5 to 2.5 Pass -30 NV 0.200 0.0003 -2.5 to 2.5 Pass -20 NV 0.730 0.0009 -2.5 to 2.5 Pass -10 NV -0.300 -0.0004 -2.5 to 2.5 Pass 0 NV -0.057 -0.0001 -2.5 to 2.5 Pass 10 NV 0.243 0.0003 -2.5 to 2.5 Pass 30 NV 0.114 0.0001 -2.5 to 2.5 Pass 40 NV -1.059 -0.0014 -2.5 to 2.5 Pass 50 NV -0.343 -0.0004 -2.5 to 2.5 Pass SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 4 / 18 3. 99% & 26dB Bandwidth 3.1 Test Result 3.1.1 Band13_OBW Band: 13 / NTNV Bandwidth (MHz) Modulation Frequency (MHz) RB Allocation 99% Occupied Bandwidth (MHz) Verdict Size Offset Result Limit 5 QPSK 782 25 0 4.516 / Pass 16QAM 782 25 0 4.509 / Pass 10 QPSK 782 50 0 8.939 / Pass 16QAM 782 27 0 4.914 / Pass 3.1.2 Band13_XDB Band: 13 / NTNV Bandwidth (MHz) Modulation Frequency (MHz) RB Allocation 26dB Bandwidth (MHz) Verdict Size Offset Result Limit 5 QPSK 782 25 0 5.025 / Pass 16QAM 782 25 0 4.975 / Pass 10 QPSK 782 50 0 9.795 / Pass 16QAM 782 27 0 5.825 / Pass SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 5 / 18 3.2 Test Graph 3.2.1 Band13_OBW Band13_5MHz_QPSK_MCH_782MHz_RB_25_0_NTNV Band13_5MHz_16QAM_MCH_782MHz_RB_25_0_NTNV SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 6 / 18 Band13_10MHz_QPSK_MCH_782MHz_RB_50_0_NTNV Band13_10MHz_16QAM_MCH_782MHz_RB_27_0_NTNV SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 7 / 18 3.2.2 Band13_XDB Band13_5MHz_QPSK_MCH_782MHz_RB_25_0_NTNV Band13_5MHz_16QAM_MCH_782MHz_RB_25_0_NTNV SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 8 / 18 Band13_10MHz_QPSK_MCH_782MHz_RB_50_0_NTNV Band13_10MHz_16QAM_MCH_782MHz_RB_27_0_NTNV SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 9 / 18 4. Peak-Average Ratio 4.1 Test Result 4.1.1 B13_10MHz Band: 13 / Bandwidth: 10MHz / NTNV Modulation Frequency (MHz) RB Allocation Peak-Average Ratio (dB) Verdict Size Offset Result Limit QPSK 782 50 0 5.76 <=13 Pass 16QAM 782 27 0 6.38 <=13 Pass SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 10 / 18 4.2 Test Graph 4.2.1 B13_10MHz Band13_10MHz_QPSK_MCH_782MHz_RB_50_0_NTNV Band13_10MHz_16QAM_MCH_782MHz_RB_27_0_NTNV SGS-CSTC Standards Technical Services Co., Ltd Report No.: SZCR2605001848AT Page 11 / 18 5. Spurious Emission 5.1 Test Result 5.1.1 B13_5MHz Band: 13 / Bandwidth: 5MHz / NTNV Modulation Frequency (MHz) RB Allocation Spurious Emission Verdict Size Offset Result Limit QPSK 779.5 1 0 Refer To Test Graph Pass 25 0 Refer…

Text truncated - open the document above for the full version.
