2BV3R-9781MT01Wellness Heart rate, sleep and breathing monitor

Product User Guide 1. Product Overview This application is a wellness monitoring solution designed to track sleep-related physiological indicators. By connecting with compatible smart hardware, the system can collect and analyze physiological data such as heart rate, respiratory rate, sleep duration, and sleep patterns.The application automatically generates daily reports to help users better understand their sleep habits and physiological trends over time. In addition, the application provides comprehensive device management features, including multi-user access, time zone and region configuration, and real-time device status monitoring, making it easy to manage and review sleep-related data. 2. Core Functions 2.1 Device Setup and Network Configuration Preparation Before configuring the device, please ensure that: * The device is connected to a power source. * Network configuration is completed within 5 minutes after powering on the device. Bluetooth is automatically enabled during this period. If network configuration is not completed within 5 minutes: * Disconnect and reconnect the power supply, or * Press and hold the Reset button on the side of the device for approximately 5 seconds to restart network configuration mode. Network Configuration Steps 1. Create an Account Register an account using your email address and log in to the app. 2. Add a Device On the Home page, tap the “+” button. Follow the on-screen instructions to: * Enable Bluetooth * Grant Location permissions (if required by your mobile device) Then tap Start Adding Device. 3. Connect the Device Select the target device with a name beginning with “ZKYL” from the device list and tap Connect. 4. Configure the Network Wi-Fi Version * Enter the Wi-Fi password when prompted. * Only 2.4 GHz Wi-Fi networks are supported. 5. Complete Setup After successful connection: * Assign a device name. * Select the installation location. Once setup is complete, the device will appear on the Home page. 2.2 Device Management Users can access the Device Details page using either of the following methods: * Tap the device card on the Home page. * Tap the Settings icon in the upper-right corner of the device card. Device Details Features Real-Time Monitoring View device status and current sensor readings. Alert Management Receive alert notifications and customize alert settings when applicable. Parameter Configuration Configure user information, device time zone, and regional settings. System Settings Access additional device configuration options through the Settings menu. 2.3 Device Sharing After the device is successfully configured, the first user who completes setup automatically becomes the device owner. The owner may use the Device Sharing feature to grant access to family members or caregivers. Authorized users can view available monitoring information associated with the device, enabling convenient sharing of wellness information with authorized users. 2.4 Data Monitoring Installation Requirements For optimal performance: * Install the device approximately 80 cm (31.5 inches) above the head area of the bed. * Adjust the device so that the sensor is directed toward the chest area of the monitored individual. Sleep Report Generation The device automatically collects sleep-related data while the user is sleeping. After the monitoring session is complete, the application generates a detailed analysis report that may include: * Sleep Quality Scores * Respiratory Monitoring Summary * Estimated Stress-Related Wellness Metrics * Heart Rate Trends * Sleep Duration Statistics Users may select individual report sections to view additional information, trends, and wellness insights. Data Interpretation All scores, indicators, and wellness insights provided by the application are generated using proprietary algorithms and are intended solely for informational and general wellness purposes. Results may vary and should not be relied upon for medical or healthcare decisions。 Important Notice This product is intended for general wellness and sleep monitoring purposes only. It is not a medical device and is not intended to diagnose, treat, cure, monitor, or prevent any disease or medical condition. The information provided by this product should not be used as a substitute for professional medical advice. Please consult a qualified healthcare professional regarding any health concerns. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: * Reorient or relocate the receiving antenna. * Increase the separation between the equipment and receiver. * Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. * Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RF Exposure Information The device has been evaluated to meet general RF exposure requir…

Text truncated - open the document above for the full version.

Page 1 of 10 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com RF Exposure Evaluation For Mogi Trend LLC Wellness Heart rate, sleep and breathing monitor Test Model: ZQ-SM-W-A2 Prepared for : Mogi Trend LLC Address : 2810 N Church St, PMB 86270, Wilmington, Delaware, 19802, USA Prepared by : Guangzhou LCS Compliance Testing Laboratory Ltd. Address : No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel : (+86) 020-39166689 Fax : (+86) 020-39166619 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : June 10, 2026 Number of tested samples : 2 Sample No. : C06096016-1, C06096016-2 Serial number : Prototype Date of Test : June 10, 2026 ~ June 23, 2026 Date of Report : June 24, 2026 Page 2 of 10 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com RF Exposure Evaluation Report Reference No. ................. : LCSC06096016EC Date of Issue ................................... : June 24, 2026 Testing Laboratory Name ............ : Guangzhou LCS Compliance Testing Laboratory Ltd. Address ........................................... : No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Testing Location Procedure ............ : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name .......................... : Mogi Trend LLC Address ........................................... : 2810 N Church St, PMB 86270, Wilmington, Delaware, 19802, USA Test Specification Standard .......................................... : FCC KDB publication 447498 D01 General RF Exposure Guidance v06 FCC CFR 47 part1 1.1310 FCC CFR 47 part2 2.1093 Test Report Form No. ................... : TRF-4-E-215 A0 TRF Originator ................................ : Guangzhou LCS Compliance Testing Laboratory Ltd. Master TRF ..................................... : Dated 2011-03 Guangzhou LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Guangzhou LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Guangzhou LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. EUT Description. ........................... : Wellness Heart rate, sleep and breathing monitor Trade Mark ...................................... : Lamaari Test Model ...................................... : ZQ-SM-W-A2 Ratings ............................................ : Please Refer to Page 6 Result ........................................... : PASS Compiled by: Reviewed by: Approved by: Ace Yao/ Administrators Justin Zhu/ Technique Director Gavin Liang/ Manager Page 3 of 10 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com RF Exposure Evaluation Test Result Pass The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSC06096016EC June 24, 2026 Date of issue EUT......................................... : Wellness Heart rate, sleep and breathing monitor Test Model............................... : ZQ-SM-W-A2 Applicant............................... : Mogi Trend LLC Address.................................. : 2810 N Church St, PMB 86270, Wilmington, Delaware, 19802, USA Telephone............................... : / Fax.......................................... : / Manufacturer........................ : Anhui Import and Export CO., LTD Address................................... : Tianmao Building, 107 Science Road, Hefei, Anhui, China Telephone............................... : / Fax.......................................... : / Factory................................... : Anhui Import and Export CO., LTD Address................................... : Tianmao Building, 107 Science Road, Hefei, Anhui, China Telephone............................... : / Fax.......................................... : / Page 4 of 10 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Revision History Report Version Issue Date Revision Content Revised By 000 June 24, 2026 Initial Issue -- Page 5 of 10 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EC Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1,Qianfeng North Road, Shiqi, Panyu District, Guangzhou, City, Guangdong China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com TABLE OF CONTENTS Description Page 1. PRODUCT INFORMATION ................................................................................................................................... 6 2. EVALUATION METHOD AND LIMIT ................................................................................................................... 7 3. REFER EVALUATION METHOD ........................................................................................................................…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID:2BV3R-9781MT01 Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Setup Photos of the EUT Test Setup Photo(s) of Radiated Emissions Measurement Fig. 1 Fig. 2 Page 2 of 2 FCC ID:2BV3R-9781MT01 Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Setup Photo(s) of Conducted Emissions Measurement Fig. 3 Test Setup Photo(s) of RF Conducted Measurement Fig. 4

Page 1 of 34 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com FCC TEST REPORT For Mogi Trend LLC Wellness Heart rate, sleep and breathing monitor Test Model: ZQ-SM-W-A2 Prepared for : Mogi Trend LLC Address : 2810 N Church St, PMB 86270, Wilmington, Delaware, 19802, USA Prepared by : Guangzhou LCS Compliance Testing Laboratory Ltd. Address : No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel : (+86) 020-39166689 Fax : (+86) 020-39166619 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : June 10, 2026 Number of tested samples : 2 Sample No. : C06096016-1, C06096016-2 Serial number : Prototype Date of Test : June 10, 2026 ~ June 23, 2026 Date of Report : June 24, 2026 Page 2 of 34 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com FCC TEST REPORT FCC CFR 47 PART 15 C(15.247) Report Reference No. ................. : LCSC06096016EA Date of Issue .................................. : June 24, 2026 Testing Laboratory Name ............ : Guangzhou LCS Compliance Testing Laboratory Ltd. Address .......................................... : No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Testing Location/ Procedure .......... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ......................... : Mogi Trend LLC Address .......................................... : 2810 N Church St, PMB 86270, Wilmington, Delaware, 19802, USA Test Specification Standard ......................................... : FCC CFR 47 PART 15 C(15.247) Test Report Form No.................... : TRF-4-E-145 A/0 TRF Originator ................................ : Guangzhou LCS Compliance Testing Laboratory Ltd. Master TRF ..................................... : Dated 2011-03 Guangzhou LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Guangzhou LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Guangzhou LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. EUT Description. .......................... : Wellness Heart rate, sleep and breathing monitor Trade Mark ..................................... : Lamaari Test Model ...................................... : ZQ-SM-W-A2 Ratings ........................................... : Please Refer to Page 6 Result ............................................ : PASS Compiled by: Supervised by: Approved by: Ace Yao/ Administrators Justin Zhu/ Technique Director Gavin Liang/ Manager Page 3 of 34 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com FCC -- TEST REPORT Test Model.......................... : ZQ-SM-W-A2 EUT.................................... : Wellness Heart rate, sleep and breathing monitor Applicant........................... : Mogi Trend LLC Address.............................. : 2810 N Church St, PMB 86270, Wilmington, Delaware, 19802, USA Telephone.......................... : / Fax..................................... : / Manufacturer..................... : Anhui Import and Export CO., LTD Address.............................. : Tianmao Building, 107 Science Road, Hefei, Anhui, China Telephone.......................... : Fax..................................... : Factory.............................. : Anhui Import and Export CO., LTD Address.............................. : Tianmao Building, 107 Science Road, Hefei, Anhui, China Telephone.......................... : / Fax..................................... : / Test Result PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSC06096016EA June 24, 2026 Date of issue Page 4 of 34 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Revision History Report Version Issue Date Revision Content Revised By 000 June 24, 2026 Initial Issue --- Page 5 of 34 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com TABLE OF CONTENTS 1. GENERAL INFORMATION ........................................................................................................................ 6 1.1. DESCRIPTION OF DEVICE (EUT) ............................................................................................................. 6 1.2. SUPPORT EQUIPMENT LIST ..................................................................................................................... 7 1.3. EXTERNAL I/O CABLE ............................................................................................................................. 7 1.4. DESCRIPTION OF TEST FACILITY ..........…

Text truncated - open the document above for the full version.

Page 1 of 38 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com FCC TEST REPORT For Mogi Trend LLC Wellness Heart rate, sleep and breathing monitor Test Model: ZQ-SM-W-A2 Prepared for : Mogi Trend LLC Address : 2810 N Church St, PMB 86270, Wilmington, Delaware, 19802, USA Prepared by : Guangzhou LCS Compliance Testing Laboratory Ltd. Address : No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel : (+86) 020-39166689 Fax : (+86) 020-39166619 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : June 10, 2026 Number of tested samples : 2 Sample No. : C06096016-1, C06096016-2 Serial number : Prototype Date of Test : June 10, 2026 ~ June 23, 2026 Date of Report : June 24, 2026 Page 2 of 38 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com FCC TEST REPORT FCC CFR 47 PART 15 C(15.247) Report Reference No. ................. : LCSC06096016EB Date of Issue ................................... : June 24, 2026 Testing Laboratory Name ............ : Guangzhou LCS Compliance Testing Laboratory Ltd. Address ........................................... : No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Testing Location/ Procedure .......... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ......................... : Mogi Trend LLC Address ........................................... : 2810 N Church St, PMB 86270, Wilmington, Delaware, 19802, USA Test Specification Standard ......................................... : FCC CFR 47 PART 15 C(15.247) Test Report Form No. ................... : TRF-4-E-147 A/0 TRF Originator ................................ : Guangzhou LCS Compliance Testing Laboratory Ltd. Master TRF ..................................... : Dated 2011-03 Guangzhou LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Guangzhou LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Guangzhou LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. EUT Description. ........................... : Wellness Heart rate, sleep and breathing monitor Trade Mark ..................................... : Lamaari Test Model ...................................... : ZQ-SM-W-A2 Ratings ............................................ : Please Refer to Page 6 Result ........................................... : Pass Compiled by: Supervised by: Approved by: Ace Yao/ Administrators Justin Zhu/ Technique Director Gavin Liang/ Manager Page 3 of 38 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com FCC -- TEST REPORT Test Model............................... : ZQ-SM-W-A2 EUT......................................... : Wellness Heart rate, sleep and breathing monitor Applicant............................... : Mogi Trend LLC Address.................................. : 2810 N Church St, PMB 86270, Wilmington, Delaware, 19802, USA Telephone............................... : / Fax.......................................... : / Manufacturer........................ : Anhui Import and Export CO., LTD Address................................... : Tianmao Building, 107 Science Road, Hefei, Anhui, China Telephone............................... : Fax.......................................... : Factory................................... : Anhui Import and Export CO., LTD Address................................... : Tianmao Building, 107 Science Road, Hefei, Anhui, China Telephone............................... : / Fax.......................................... : / Test Result Pass The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSC06096016EB June 24, 2026 Date of issue Page 4 of 38 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Revision History Report Version Issue Date Revision Content Revised By 000 June 24, 2026 Initial Issue -- Page 5 of 38 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com TABLE OF CONTENTS 1. GENERAL INFORMATION ........................................................................................................................ 6 1.1. DESCRIPTION OF DEVICE (EUT) ............................................................................................................. 6 1.2. SUPPORT EQUIPMENT LIST ..................................................................................................................... 7 1.3. EXTERNAL I/O CABLE ......................................................................................................…

Text truncated - open the document above for the full version.

Page 39 of 58 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com 11N40SISO_Ant1_2437_30~1000 11N40SISO_Ant1_2437_1000~26500 Page 40 of 58 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com 11N40SISO_Ant1_2452_0~Reference 11N40SISO_Ant1_2452_30~1000 Page 41 of 58 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com 11N40SISO_Ant1_2452_1000~26500 Page 42 of 58 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com B.6 Duty Cycle Test Result TestMode Antenna Frequency[MHz] Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] xFactor 11B Ant1 2412 0.74 0.80 92.50 0.34 2437 0.73 0.79 92.41 0.34 2462 0.73 0.79 92.41 0.34 11G Ant1 2412 0.12 0.18 66.67 1.76 2437 0.11 0.18 61.11 2.14 2462 0.12 0.18 66.67 1.76 11N20SISO Ant1 2412 0.11 0.18 61.11 2.14 2437 0.11 0.18 61.11 2.14 2462 0.12 0.18 66.67 1.76 11N40SISO Ant1 2422 0.08 0.14 57.14 2.43 2437 0.07 0.13 53.85 2.69 2452 0.08 0.14 57.14 2.43 Page 43 of 58 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 Page 44 of 58 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com 11G_Ant1_2412 11G_Ant1_2437 Page 45 of 58 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com 11G_Ant1_2462 11N20SISO_Ant1_2412 Page 46 of 58 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com 11N20SISO_Ant1_2437 11N20SISO_Ant1_2462 Page 47 of 58 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com 11N40SISO_Ant1_2422 11N40SISO_Ant1_2437 Page 48 of 58 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com 11N40SISO_Ant1_2452 Page 49 of 58 FCC ID:2BV3R-9781MT01 Report No.: LCSC06096016EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com B.7 Emissions in Restricted Bands Test Result TestMode Antenna ChName Frequency [MHz] Detector Freq [MHz] Result [dBm] Gain [dBi] DC Factor [dB] Result [dBuV/m] Limit [dBuV/m] Verdict 11B Ant1 Low 2412 AV 2310.000 -57.81 3.49 0.34 41.28 ≤54 PASS AV 2389.960 -46.89 3.49 0.34 52.20 ≤54 PASS AV 2390.000 -46.89 3.49 0.34 52.20 ≤54 PASS Peak 2310.000 -49.3 3.49 0.00 49.45 ≤74 PASS Peak 2389.960 -40.8 3.49 0.00 57.95 ≤74 PASS Peak 2390.000 -40.8 3.49 0.00 57.95 ≤74 PASS High 2462 AV 2483.500 -46.32 3.49 0.34 52.77 ≤54 PASS AV 2483.560 -46.41 3.49 0.34 52.68 ≤54 PASS AV 2500.000 -57.31 3.49 0.34 41.78 ≤54 PASS Peak 2483.500 -39.71 3.49 0.00 59.04 ≤74 PASS Peak 2483.670 -38.68 3.49 0.00 60.07 ≤74 PASS Peak 2500.000 -48.58 3.49 0.00 50.17 ≤74 PASS 11G Ant1 Low 2412 AV 2310.000 -57.01 3.49 1.76 43.50 ≤54 PASS AV 2389.960 -49.72 3.49 1.76 50.79 ≤54 PASS AV 2390.000 -49.72 3.49 1.76 50.79 ≤54 PASS Peak 2310.000 -48.28 3.49 0.00 50.47 ≤74 PASS Peak 2389.180 -38.18 3.49 0.00 60.57 ≤74 PASS Peak 2390.000 -39.9 3.49 0.00 58.85 ≤74 PASS High 2462 AV 2483.500 -47.57 3.49 1.76 52.94 ≤54 PASS AV 2483.560 -48.38 3.49 1.76 52.13 ≤54 PASS AV 2500.000 -56.84 3.49 1.76 43.67 ≤54 PASS Peak 2483.500 -35.36 3.49 0.00 63.39 ≤74 PASS Peak 2483.560 -33.24 3.49 0.00 65.51 ≤74 PASS Peak 2500.000 -49.65 3.49 0.00 49.10 ≤74 PASS 11N20SISO Ant1 Low 2412 AV 2310.000 -58.36…

Text truncated - open the document above for the full version.
