2BV7Z-PR08Smart 3D Face Recognition Lock

Jiangxi krovi Information Technology Co., Ltd.

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: May 28, 2026
Application Purpose: Original Equipment
Equipment Note: Smart 3D Face Recognition Lock
Frequency Range: 2412.00000000 - 2462.00000000
Company: Jiangxi krovi Information Technology Co., Ltd.
Country: China
