2BVEN-AP2501SMART ADJUSTABLE ULTRASONIC BARK CONTROL

Adjustable Smart Ultrosonic Bark Control Please read the manual carefully before using User Manual User Manual Package Content 1 Main Unit Charging Cable Adjustable Smart Ultrosonic Bark Control Please read the manual carefully before using User Manual 1 2 Product Overview TYPE-C Retractable Hanging Hole Solar Panel Rotatable Ultrasonic Port Fixed Ultrasonic Port Microphone Charging Port Retractable Stand Retractable Stand Light 1-4 Gear Knob Smart Button 2 3 Features One - Button Control Work log for recording triggered events Adjustable ultrasonic range up to 180° Powerful three ultrosonic speakers Customizable ultrasonic frequency and sensitivity Automatic barking detection Solar energy as sub charging supplement IPX4 waterproof More than 30 days of battery life 3 4 Quick Start Guide a.Adjust Ultrasonic Coverage b.Device Off Rotate the rotatable ultrasonic port on the left or/and right side of the main unit to achieve up to 180° Turn the knob to the OFF position, lights turn off, and the buzzer beeps twice. c.Manual Mode Turn the knob to the 1/2 position, Light 1/2 will flash in blue intermittently, and the buzzer beeps once. d.BLE Mode Press the button, Light 4 will flash in blue. Connect APP via Bluetooth sensitivity. If connection fails, Light 4 will flash in red for 3s, then remains a constant-on state. If connectionsucceeds, Light 4 will remain blue, and the buzzer plays music. Customize bark detection sensitivity (40dB-80dB) and frequency (20Khz-45Khz) on the APP. e.Auto Mode If connection fails after 10s or disconnects, Light 4 will turn off and Light 3 will flash in blue intermittently. f.Low Battery When the device's battery level is below 5%, the buzzer beeps twice and repeats 4 times, and Light 4 will flash in red. 4 5 APP Operation Step 1: Prepare Your Mobile Device 1.Download Peacesmart APP from Apple Store for IOS, or Google Play Store for Android. Step 2: Activate BLE Mode On The Device Locate the smart button. Press the smart button. Step 3: Complete Pairing In The APP 1.Open the APP. Choose “Add Device”. 2.Connect the device. 3.Once the connection succeeds, Light 4 will remain blue. Once the connection fails, the APP will remind you. 2.Enable Bluetooth on your smartphone (ensure Bluetooth is set to "discoverable" mode). Connection Steps 5 Scan this QR code to download the APP Function Customized Setting：Set the bark detection sensitivity of the device's built-in microphone within the range of 40dB-60dB and the ultrasonic frequency within the range of 20Khz-45Khz. Record Working Event：Automatically records bark detection and ultrasonic emissionevents of the device and presents the data in a clear format. 6 Download Data Report：Download daily working logs and statistical data of the specified device for single-day usage insights. 6 Uses Stop excessive barking Stop barking at pedestrians passing by the yard Stop barking at neighbor's dogs For indoor and outdoor use Stop dogs from barking during camping trips 7 7 Operating Guide One dog Multiple dogs 6 months to 8 yearsUnder 6 months, over 8 years 8 Ultrasonic barrier-freeUltrasonic with barriers Normal hearing Abnormal hearing 9 8 Important Safety Information a.Avoid pointing the device directly at eyes or ears of any person or animal. b. Not suitable for deaf, hard-of-hearing dogs. c.Do not use the device on dogs under 6 months, or on sick, old, pregnant, or aggressive dogs. d. Place the device beyond children's reach. Never let children use it. e. Do not soak the device in water. f. Store the device in a cool and dry place when not in use. g. Do not disassemble the device. Please contact customer service if you need to repair. 10 9 Device Charging Type-C charging port Solar energy charging Charging Status Connection Success：Light 4 flashes in blue. 0.3W. 20% efficiency Disconnect Charging: Lights for the current battery level flash blue once, then go out. Battery Level Indication：As the battery level rises for every 25%, the number of steadily lit lights increases sequentially (starting from Light 1) while the next light flashes. When fully charged, all lights stay blue. 11 Solar panels will only charge automatically when there is sufficient sunlight. Note: 10 Troubleshooting(Q&A) Q: Not respond to my dog. Answer: 1. Ensure the device is turned on. 2.Make sure the device is fully charged 3.Remove any obstacles in front of the ultrasonic emission port. 4.Make sure the dog is within 50ft coverage range and its ears stay uncovered 5.Human beings cannot hear ultrasonic sound. Notice: 1. Use ultrasound to stop unnecessary dog barking.Follow the training steps below. (Note: Different breeds of dogs respond differently to ultrasound. For best results, you can use Peacesmart APP to find the most suitable frequency for dog. 2. Position the device within the area your dog usually moves in, then switch the device to normal / enhanced / specified frequency ultrasound. Most dogs will quickly recognize that the ultrasound is disturbing them, so they will calm down and stop barking. Typically, you will notice a reduc- tion in dog’s barking within he first two weeks of using ultrasound function. 3. Excessive barking can put real stress on your relationship with your pet and disturb the peace in your neighborhood. In such cases, this device may offer a helpful solution. 12 11 Warranty 6-month Limited Warrant The warranty begins on the date of purchase. Covers defects in materials or workmanship under normal use. The warranty is void if the device has been tampered with or used imporoperly. For warranty claims, please contact customer service at http://www.peacesmart.tech/. Procedure for Repair Work If the unit is malfunctioning, please refer to the "Troubleshooting”(Page 12) in the manual before sending it back for service. A copy of the sales receipt showing the purchase date may be required before warranty work is initiated. Please include a brief explanation outlining the problem, and include your name, address, city/state/zip code,…
