2BVFO-BUP-TS-C1-ABrush up cares IoT Toothbrush Sterilizer

Brush up Cares Toothbrush Sterilizer User Manual 1. Product Overview Brushup Cares is a smart toothbrush sterilizer designed to promote better oral hygiene habits through UV-C sterilization and intelligent usage tracking. • UV-C LED sterilization • Automatic drying system • Smart brushing detection (via lid operation) • Individual storage for hygiene protection 2. Key Features UV-C Sterilization Effectively reduces bacteria on toothbrush bristles using UV-C light. Photonic Drying (No Heat) Dries moisture without heat, helping prevent deformation and microplastic generation. Smart Brushing Detection • Open lid → brushing starts • Close lid after 2 minutes → brushing session recorded Auto Sterilization Cycle • When powered: → Continuous drying for up to 12 hours → Additional 3-minute sterilization every hour • Without power: → 3-minute sterilization only after use 3. How to Use Step 1: Install the Device • Mount on wall using adhesive holder • Ensure a dry and stable surface Step 2: Connect Power • Use USB cable or charging cradle • Green LED will turn on for ~10 seconds when powered Step 3: Start Brushing 1. Open the lid 2. Take out toothbrush 3. Brush your teeth Step 4: End Brushing • Close the lid after 2 minutes or more → Sterilization will automatically start ※ If brushing is less than 2 minutes: → Press the top button to manually activate sterilization 4. LED Indicators • Green LED (Top Button) → Power connected (lights for ~10 seconds) • Blue LED (Inside) → UV sterilization in progress ※ Blue LED visibility may vary depending on humidity 5. Cleaning & Maintenance • Do NOT rinse with water • Clean using: o Alcohol wipes o Soft dry cloth ※ This product is NOT waterproof 6. Important Notes • For full drying performance, keep the device connected to power • Water droplets inside the lid may occur due to humidity — this is normal • The device focuses on hygiene safety, not complete moisture removal 7. Safety Instructions • Do not look directly at UV-C light • Keep out of reach of children when open • Do not disassemble the product • Use only recommended power input 8. Product Specifications • Input: 5V = 255mA • Communication: Bluetooth Low Energy (BLE) • Battery: Built-in rechargeable battery • Sterilization: UV-C LED 9. Troubleshooting Q. LED is not turning on → Check power connection Q. No sterilization after use → Ensure lid is closed properly → Press button if brushing time was short Q. Water droplets inside → Normal due to humidity 10. Warranty & Support For support or inquiries, please contact: [email protected] FCC: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. The device can be used in portable exposure condition without restriction.

Page1of5FCCID:2BVFO-BUP-TS-C1-A GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com ExternalPhotosoftheEUT Fig.1 Fig.2 Page2of5FCCID:2BVFO-BUP-TS-C1-A GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com Fig.3 Fig.4 Page3of5FCCID:2BVFO-BUP-TS-C1-A GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com Fig.5 Fig.6 Page4of5FCCID:2BVFO-BUP-TS-C1-A GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com Fig.7 Fig.8 Page5of5FCCID:2BVFO-BUP-TS-C1-A GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com Fig.9

Page1of1FCCID:2BVFO-BUP-TS-C1-A GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com LabelandLocation (Size:L:3.0cmxW:2.0cm) LabelLocation BrushupcaresIoTToothbrushSterilizer Model:BUP-TS-C1-A FCCID:2BVFO-BUP-TS-C1-A

Page1of5FCCID:2BVFO-BUP-TS-C1-A GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com InternalPhotosoftheEUT Fig.1 Fig.2 Page2of5FCCID:2BVFO-BUP-TS-C1-A GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com Fig.3 Fig.4 Page3of5FCCID:2BVFO-BUP-TS-C1-A GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com Fig.5 Fig.6 Page4of5FCCID:2BVFO-BUP-TS-C1-A GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com Fig.7 Fig.8 BluetoothAntenna Page5of5FCCID:2BVFO-BUP-TS-C1-A GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com Fig.9

Page 1 of 8 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com RF Exposure Evaluation For Brush up Inc. Brush up cares IoT Toothbrush Sterilizer Test Model: BUP-TS-C1-A Prepared for : Brush up Inc. Address : 22, Sogangdae-gil, Mapo-gu, Seoul, 04111, South Korea Prepared by : Guangzhou LCS Compliance Testing Laboratory Ltd. Address : No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel : (+86) 020-39166689 Fax : (+86) 020-39166619 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : March 23, 2026 Number of tested samples : 2 Sample No. : C260318005-1, C260318005-2 Serial number : Prototype Date of Test : March 23, 2026 ~ April 08, 2026 Date of Report : April 09, 2026 Page 2 of 8 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com RF Exposure Evaluation Report Reference No. ................ : LCSC03236027EB Date of Issue .................................. : April 09, 2026 Testing Laboratory Name ............ : Guangzhou LCS Compliance Testing Laboratory Ltd. Address .......................................... : No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Testing Location/ Procedure .......... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ......................... : Brush up Inc. Address .......................................... : 22, Sogangdae-gil, Mapo-gu, Seoul, 04111, South Korea Test Specification Standard ......................................... : FCC KDB publication 447498 D01 General RF Exposure Guidance v06 FCC CFR 47 part1 1.1310 FCC CFR 47 part2 2.1093 Test Report Form No. ................... : TRF-4-E-215 A/0 TRF Originator ............................... : Guangzhou LCS Compliance Testing Laboratory Ltd. Master TRF .................................... : Dated 2011-03 Guangzhou LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Guangzhou LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Guangzhou LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test Item Description. .................. : Brush up cares IoT Toothbrush Sterilizer Trade Mark ..................................... : N/A Test Model ...................................... : BUP-TS-C1-A Ratings ........................................... : Please Refer to Page 6 Result ........................................... : PASS Compiled by: Supervised by: Approved by: Ace Yao/ Administrator Justin Zhu/ Technique Director Gavin Liang/ Manager Page 3 of 8 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com RF Exposure Evaluation EUT......................................... : Brush up cares IoT Toothbrush Sterilizer Test Model........................... : BUP-TS-C1-A Applicant............................... : Brush up Inc. Address.................................. : 22, Sogangdae-gil, Mapo-gu, Seoul, 04111, South Korea Telephone............................... : / Fax.......................................... : / Manufacturer....................... : Brush up Inc. Address................................... : 15, Misagangbyeonjungang-ro 31beon-gil, Hanam-si, Gyeonggi-do, Republic of Korea Telephone............................... : / Fax.......................................... : / Factory....................... : Brush up Inc. Address................................... : 15, Misagangbyeonjungang-ro 31beon-gil, Hanam-si, Gyeonggi-do, Republic of Korea Telephone............................... : / Fax.......................................... : / Test Result PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSC03236027EB April 09, 2026 Date of issue Page 4 of 8 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Revision History Report Version Issue Date Revision Content Revised By 000 April 09, 2026 Initial Issue --- Page 5 of 8 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EB Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com TABLE OF CONTENTS Description Page 1. PRODUCT INFORMATION ........................................................................................................................ 6 2. EVALUATION METHOD AND LIMIT ........................................................................................................ 7 3. REFER EVALUATION METHOD............................................................................................................... 7 4. CONDUCTED POWER RESULTS .................................................................…

Text truncated - open the document above for the full version.

深圳市金航标电子有限公司 http://www.BDS666.com - 1 - 产 品 技 术 规 格 书 SPECIFICATION 深圳市龙华区民治大道1079号 展滔科技大厦C座C809室 Room C809, Building C, Zhantao Technology Tower, No. 1079 Minzhi Avenue, Longhua District, Shenzhen TEL： 0755-83040901 FAX：0755-83040901 深圳市金航标电子有限公司 Shenzhen Kinghelm Electronics Co., Ltd. 深圳市金航标电子有限公司 http://www.BDS666.com - 2 - 目 录 Table of contents 规格书版本更改记录 Version rejigger track record ..............................3 1. 概述 Introduction..................................................................4 2. 外型尺寸及测试板焊盘尺寸 D i m e n s i o n s.....................4～5 3. 测试电路和匹配电路 Evaluation Board and Matching Circuits............5 4. 电气性能 Electrical Characteristics..........................................6 5. 特性曲线 Characteristic curve...................................................6 6. 方向图 Radiation Pattern...................................................7～8 7. 可靠性试验后允许误差 Post Dependability Tolerance ...............9 8. 可靠性试验 Dependability Test..........................................9～10 9. 回流焊温度 Reflow Soldering Standard Condition.....................10 10.包装尺寸 Packaging and Dimensions ....................................11 深圳市金航标电子有限公司 http://www.BDS666.com - 3 - 产品规格书版本更改记录 Version rejigger track record 版本号 Version 更改记录 Rejigger 拟制 Prepared 批准 Approve 日期 Date V1.0 首次发行 姚富鑫 贺俊驹 2015.8.11 V1.1 更改编带厚度 陈星 贺俊驹 2016.10.11 V1.2 更改产品尺寸公差值 姚富鑫 贺俊驹 2017.05.24 V1.3 修正可靠性试验说明内容8.1~8.4 姚富鑫 贺俊驹 2017.11.07 备注： 1、更改产品电性能指标时，版本号需更换（V1.0换为V2.0、V3.0......）； 2、更改产品测试方法（包括可靠性测试条件），或更改使用条件时，当前版本号加系列（V1.0 换为V1.1、V1.2......）。 深圳市金航标电子有限公司 http://www.BDS666.com - 4 - 1. 概述 INTRODUCTION 金航标微波多层陶瓷天线LA系列产品设计用于WLAN、WiFi、蓝牙、PHS，手机 多频天线, FM等小体积SMD片式设计。 kinghelm Microwave Multi-Layer Ceramic Antenna LA series are designed to be used in WLAN、WiFi、Bluetooth、PHS、 Multiple-band Mobile phone antenna, FM, etc and compact size SMD chip design. 2. 外型尺寸及测试板焊盘尺寸 Dimensions（Unit：mm） 深圳市金航标电子有限公司 http://www.BDS666.com - 5 - 3. 测试电路和匹配电路 Evaluation Board and Matching Circuits 5.6nH 0.5pF Unit:mm 50ΩFeeding Line GND VIA πType Matching Network Clearance Area 5.0 6.0 1.25 1 . 8 2.25 0 . 7 4 0 . 7 4 3 . 3 4 3 . 7 7 1.0 1.63 技术详询 深圳市金航标电子有限公司 http://www.BDS666.com - 6 - 4.电气性能Electrical Characteristics No. I tem （项目） Specifications （特性） 5.1 Central Frequency 中心频率(No matching) 2545MHz (带匹配电路测试)After Matching 2450 MHz 5.2 Band Width 通带宽度 100 MHz typ. 5.3 Peak Gain 峰值增益 5.62 dBi 5.4 V.S.W.R (in BW) 驻波比 ≤2.0 5.5 Polarization 极化方式 Linear 线性 5.6 Azimuth Beam width 方位角 Omni-directional 全向 5.7 Impedance 阻抗 50 Ω 5.特性曲线Characteristic curve 深圳市金航标电子有限公司 http://www.BDS666.com - 7 - 6.方向图及效率Radiation Pattern & Efficiency coordinates： X-Z Plane X-Y Plane 深圳市金航标电子有限公司 http://www.BDS666.com - 8 - Y-Z Plane 3D Radiation Pattern Frequency (MHz) 2400 2450 2500 Avg. Gain (dBi) -1.56 -1.28 -1.15 Peck Gain (dBi) 5.62 5.54 4.48 Efficiency (%) 71.8 73.5 75.6 深圳市金航标电子有限公司 http://www.BDS666.com - 9 - No. Item （项目） 7.可靠性试验后允许误差 Post Dependability Tolerance 经可靠性试验后允许比起始读数偏差见下表 Post Dependability Tolerance ( Refer to the table ) Post Dependability Tolerance (可靠性试验后允许附加误差) 7.1 Central Frequency 中心频率 ±5 MHz 7.2 Band Width 通带宽度 ±5 MHz 7.3 Gain 增益 ±0.1 dBi 7.4 V.S.W.R (in BW) 驻波比 ±0.1 8. 可靠性试验 Dependability Test 基准条件：温度范围 Temperature range 25±5°C 相对湿度范围 Relative Humidity range 55~75%RH 工作温度 Operating Temperature range -40°C~+85°C 贮藏温度 Storage Temperature range -40°C~+85°C 8.1 耐振动 Vibration Resist 在振动频率为10~55Hz振幅为1.5mm 沿X.Y.Z方向各振动2小时后测试符合表8.1~8.4规定。 The device should satisfy the electrical characteristics specified in paragraph 8.1~8.4 after applied to the vibration of 10 to 55Hz with amplitude of 1.5mm for 2 hours each in X , Y and Z directions. 8.2 耐跌落冲击 Drop Shock 在100cm高度处按X，Y，Z三个面分别自由跌落在木制地板上共3次后测试符合表8.1~8.4规 定。 The device should satisfy the electrical characteristics specified in paragraph 8.1~8.4 after dropping onto the hard wooden board from the height of 100cm for 3 times each facet of the 3 dimensions of the device. 8.3 耐焊接热 Solder Heat Proof 能承受经120~150°C的温度预热120秒后，在255°C+10°C的焊锡浸5±0.5秒，或300°C-10°C的 电烙铁焊接3±0.5秒，焊接面无损伤。 The device should be satisfied after preheating at 120°C~150°C for 120 seconds and dipping in soldering Sn at 255°C+10°C for 5±0.5 seconds，or electric iron 300°C-10°C for 3±0.5 seconds， without damnify. 8.4 结合力试验 Tensile Strength of Terminal 在产品电极端子上或表面上应能承受1kg垂直拉力10±1秒。 The device should not be broken after tensile force of 1.0kg is slowly applied to pull a lead pin of 深圳市金航标电子有限公司 http://www.BDS666.com - 10 - the fixed device in the lead axis direction for 10±1 seconds. 8.5 耐弯曲试验 Bending Resist Test 将产品按图焊在1.6±0.2mm的 PCB 板中间，由箭头方向施 力：1mm/S，弯曲距离：1.5mm，保持5±1S，产品金属层无脱落。 Weld the product to the center part of the PCB with the thickness 1.6±0.2mm as the illustration shows, and keep exerting force arrow-ward on it at speed of :1mm/S , and hold for 5±1S at the position of 1.5mm bending distance , so far , any peeling off of the product metal coating should not be detected . 8.6 耐湿热特性 Moisture Proof 在温度为60±2°C，相对湿度90~95%的恒温湿箱中放置96小时，在常温中恢复1~2小时后测 试，符合表8.1~8.4规定。 The device should satisfy the electrical characteristics specified in paragraph 8.1~8.4 after exposed to the temperature 60±2°Cand the relative humidity 90~95% RH for 96 hours and 1~2 hours recovery time under normal condition. 8.7 高温特性 High Temperature Endurance 在温度为85±5°C的恒温箱中放置96±2小时，在常温中恢复1~2小时后测试。符合表8.1~8.4 规定。 The device should satisfy the electrical characteristics specified in paragraph 8.1~8.4 after exposed to temperature 85±5°Cfor 96±2 hours and 1~2 hours recovery time under normal temperature. 8.8 低温特性 Low Temperature Endurance 在温度为-40°C±5°C低温箱中放置96±2小时后恢复1~2小时测试符合表8.1~8.4规定。 The device should also satisfy the electrical characteristics specified in paragraph 8.1~8.4 after exposed to the temperature -40°C±5°C for 96±2 hours and to 2 hours recovery time under normal temperature. 8.9 温度循环 Temperature Cycle Test 在-40°C温度中保持30分钟，再在+85°C温度中保持30分钟，共循环5次后在常温中恢复1~2 小时后测试符合表8.1~8.4规定。 The device should also satisfy the electrical characteristics specified in paragraph 8.1~8.4 after e…

Text truncated - open the document above for the full version.

Page 1 of 23 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Appendix A RF Test Data for BT LE(Conducted Measurement) Product Name: Brush up cares IoT Toothbrush Sterilizer Test Model: BUP-TS-C1-A Environmental Conditions Temperature: 24.1C Relative Humidity: 52.2% ATM Pressure: 100.0 kPa Test Engineer: Zhang hai Supervised by: Fengliu Tang Page 2 of 23 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com A.1 DTS Bandwidth Test Result TestMode Antenna Freq(MHz) DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE_1M Ant1 2402 0.648 2401.672 2402.320 0.5 PASS 2440 0.648 2439.672 2440.320 0.5 PASS 2480 0.648 2479.672 2480.320 0.5 PASS Page 3 of 23 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page 4 of 23 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Page 5 of 23 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com A.2 Maximum peak conducted output power Test Result Peak TestMode Antenna Freq(MHz) Conducted Peak Powert[dBm] Conducted Limit[dBm] Verdict BLE_1M Ant1 2402 3.41 ≤30 PASS 2440 2.87 ≤30 PASS 2480 2.50 ≤30 PASS Test Graphs Peak BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 Page 6 of 23 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com BLE_1M_Ant1_2480 Page 7 of 23 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com A.3 Maximum power spectral density Test Result TestMode Antenna Freq(MHz) Result[dBm/3kHz] Limit[dBm/3kHz] Verdict BLE_1M Ant1 2402 -11.56 ≤8.00 PASS 2440 -12.21 ≤8.00 PASS 2480 -12.52 ≤8.00 PASS Page 8 of 23 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page 9 of 23 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Page 10 of 23 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com A.4 Band edge measurements Test Result TestMod e Antenn a ChNam e Freq(MHz ) RefLevel[dBm ] Result[dBm ] Limit[dBm ] Verdic t BLE_1M Ant1 Low 2402 2.97 -34.66 ≤-17.03 PASS High 2480 2.02 -42.9 ≤-17.98 PASS Page 11 of 23 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Graphs BLE_1M_Ant1_Low_2402 BLE_1M_Ant1_High_2480 Page 12 of 23 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com A.5 Conducted Spurious Emission Test Result TestMode Antenna Freq(MHz) FreqRange [MHz] RefLevel [dBm] Result[dBm] Limit[dBm] Verdict BLE_1M Ant1 2402 Reference 2.12 2.12 --- PASS 30~1000 2.12 -40.31 ≤-17.88 PASS 1000~26500 2.12 -43.02 ≤-17.88 PASS 2440 Reference 0.43 0.43 --- PASS 30~1000 0.43 -39.96 ≤-19.57 PASS 1000~26500 0.43 -43.01 ≤-19.57 PASS 2480 Reference -1.16 -1.16 --- PASS 30~1000 -1.16 -42.07 ≤-21.16 PASS 1000~26500 -1.16 -43.44 ≤-21.16 PASS Page 13 of 23 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com Test Graphs BLE_1M_Ant1_2402_0~Reference BLE_1M_Ant1_2402_30~1000 BLE_1M_Ant1_2402_1000~26500 Page 14 of 23 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EA Guangzhou LCS Compliance Testing Laboratory Ltd. Add: No.44-1, Qianfeng North Road, Shiqi, Panyu District, Guangzhou, Guangdong, China Tel: +(86) 020-39166689 | E-mail: [email protected] | Web: www.lcs-cert.com BLE_1M_Ant1_2440_0~Reference BLE_1M_Ant1_2440_30~1000 Page 15 of 23 FCC ID: 2BVFO-BUP-TS-C1-A Report No.: LCSC03236027EA …

Text truncated - open the document above for the full version.

Page1of34FCCID:2BVFO-BUP-TS-C1-AReportNo.:LCSC03236027EA GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com FCCTESTREPORT For BrushupInc. BrushupcaresIoTToothbrushSterilizer TestModel:BUP-TS-C1-A Preparedfor:BrushupInc. Address:22,Sogangdae-gil,Mapo-gu,Seoul,04111,SouthKorea Preparedby:GuangzhouLCSComplianceTestingLaboratoryLtd. Address:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou, Guangdong,China Tel:(+86)020-39166689 Fax:(+86)020-39166619 Web:www.LCS-cert.com Mail:[email protected] Dateofreceiptoftestsample: March23,2026 Numberoftestedsamples: 2 SampleNo.: C260318005-1,C260318005-2 Serialnumber: Prototype DateofTest: March23,2026~April08,2026 DateofReport:April09,2026 Page2of34FCCID:2BVFO-BUP-TS-C1-AReportNo.:LCSC03236027EA GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com FCCTESTREPORT FCCCFR47PART15C(15.247) ReportReferenceNo......................:LCSC03236027EA DateofIssue.......................................:April09,2026 TestingLaboratoryName..............:GuangzhouLCSComplianceTestingLaboratoryLtd. Address................................................:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou, Guangdong,China TestingLocation/Procedure............:FullapplicationofHarmonisedstandards■ PartialapplicationofHarmonisedstandards□ Otherstandardtestingmethod□ Applicant’sName.............................:BrushupInc. Address................................................:22,Sogangdae-gil,Mapo-gu,Seoul,04111,SouthKorea TestSpecification Standard..............................................: FCCCFR47PART15C(15.247) TestReportFormNo......................:TRF-4-E-145A/0 TRFOriginator....................................:GuangzhouLCSComplianceTestingLaboratoryLtd. MasterTRF.........................................:Dated2011-03 GuangzhouLCSComplianceTestingLaboratoryLtd.Allrightsreserved. Thispublicationmaybereproducedinwholeorinpartfornon-commercialpurposesaslongasthe GuangzhouLCSComplianceTestingLaboratoryLtd.isacknowledgedascopyrightownerandsourceof thematerial.GuangzhouLCSComplianceTestingLaboratoryLtd.takesnoresponsibilityforandwillnot assumeliabilityfordamagesresultingfromthereader'sinterpretationofthereproducedmaterialduetoits placementandcontext. EUTDescription...............................:BrushupcaresIoTToothbrushSterilizer TradeMark..........................................:N/A TestModel...........................................:BUP-TS-C1-A Ratings.................................................: PleaseRefertoPage6 Result..................................................:PASS Compiledby:Supervisedby:Approvedby: AceYao/AdministratorJustinZhu/TechniqueDirectorGavinLiang/Manager Page3of34FCCID:2BVFO-BUP-TS-C1-AReportNo.:LCSC03236027EA GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com FCC--TESTREPORT TestModel...............................:BUP-TS-C1-A EUT.........................................:BrushupcaresIoTToothbrushSterilizer Applicant...............................:BrushupInc. Address..................................:22,Sogangdae-gil,Mapo-gu,Seoul,04111,SouthKorea Telephone...............................:/ Fax..........................................:/ Manufacturer........................:BrushupInc. Address...................................:15,Misagangbyeonjungang-ro31beon-gil,Hanam-si,Gyeonggi-do, RepublicofKorea Telephone...............................: Fax..........................................: Factory...................................:BrushupInc. Address...................................:15,Misagangbyeonjungang-ro31beon-gil,Hanam-si,Gyeonggi-do, RepublicofKorea Telephone...............................:/ Fax..........................................:/ TestResultPASS Thetestreportmerelycorrespondstothetestsample. Itisnotpermittedtocopyextractsofthesetestresultwithoutthewrittenpermissionofthetestlaboratory. TestReportNo.:LCSC03236027EA April09,2026 Dateofissue Page4of34FCCID:2BVFO-BUP-TS-C1-AReportNo.:LCSC03236027EA GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com RevisionHistory ReportVersionIssueDateRevisionContentRevisedBy 000April09,2026InitialIssue--- Page5of34FCCID:2BVFO-BUP-TS-C1-AReportNo.:LCSC03236027EA GuangzhouLCSComplianceTestingLaboratoryLtd. Add:No.44-1,QianfengNorthRoad,Shiqi,PanyuDistrict,Guangzhou,Guangdong,China Tel:+(86)020-39166689|E-mail:[email protected]|Web:www.lcs-cert.com TABLEOFCONTENTS 1.GENERALINFORMATION.......................…
