2BVFR-GO5BThumb Camera

GuimeetGO5UserManual I.ProductOverview 1.1ExpansionDock 1.2MainUnit II.UserInstructions 2.1FirstUse ChargingandPowerOn ConnecttheincludedfastchargingcabletotheUSB-CportoftheGO5Expansion DockandaUSB-Ccharger.Whenchargingintheoffstate,thestatusindicator oftheexpansiondockglowsredduringchargingandturnsgreenwhenfully charged. Ittakes47minutestochargeto80%batteryandapproximately65minutesfor afullcharge. ChargingReminder:PeeloffthestickeronthebackoftheGO5mainunittoensure thechargingcontactsarecleanbeforeplacingitintotheexpansiondockfor charging. GO5MainUnitChargingTime:23minutesto80%,35minutesto100% ExpansionDockChargingTime:47minutesto80%,65minutesto100% PlacetheGO5mainunitintotheexpansiondockandconnectthechargingcable tothedock.TheindicatorlightsofboththeGO5mainunitandtheexpansion dockstaysolidredduringchargingandturnoffwhenthecorrespondingmodule isfullycharged.Thedeviceisgenerallyfullychargedwhenalllightsareoff. Note:ItisrecommendedtouseadedicatedchargertochargetheGO5.Connecting toacomputer'sUSBportorotherpowerbanksmayresultininsufficientpower supply,makingitimpossibletochargetheGO5mainunitandexpansiondock simultaneously. 2.2ButtonFunctionsoftheExpansionDock PowerButton Shortpress:-Turnoffandlockthetouchscreenwhenitison. Turnonandunlockthetouchscreenwhenitisoff. Longpressfor1second:Poweron(theexpansiondockandmainunitpoweron synchronously) Longpressfor3seconds:Poweroff Longpressfor8seconds:Forcedpoweroff ShutterButton Shortpress: Inthepowered-onstate:Takeaphotoorstart/stopvideorecordingwheninthe previewinterface;returntothepreviewinterfacewheninotherinterfaces. Inthepowered-offstate:Presstheshutterbuttontoquicklyturnonthecamera andstartvideorecording. ModeButton Shortpress:Callupthepresetormodeswitchingpage;clickagaintocycle throughtheselectedoptions. *Nofunctionwhenshortpressedduringshooting. 2.3ButtonFunctionsoftheMainUnit Buttonsareinactivewhenthemainunitisinthedock. Shortpress:akeaphoto/startvideorecordingwheninthepreviewinterface; stopvideorecordingwithasecondshortpressinvideomode.(Nofunctionwhen inotherinterfaces.) Longpressfor1second:Poweron Longpressfor3seconds:Poweroff Longpressfor8seconds:Forcedpoweroff Longpressfor10seconds,release,thenclickonce:Exitlow-powermode Tap:Takeaphotoorstart/stopvideorecording (WhentheAppconnectstotheGO5forthefirsttime,confirmtheconnection bytappingtheshutterbuttonorcamerabutton.) Note:UsageoftheGO5mainunitinandoutofthedock In-dockoperationlogic:Integratedactioncamera,allbuttonsoftheGO5main unitaredisabled. Out-of-dockoperationlogic:ImagetransmissionBluetoothremotecontrol+ thumbactioncamera. Note:WhenrecordingwiththeGO5outofthedockandusingtheexpansiondock forremotepreview,dataistransmittedviaBluetooth,resultinginreducedvideo qualityforpreview.Theactualclarityoftherecordedvideoissubjecttothe recordingparametersandisnotaffectedbytheshootingmethod. 2.4TouchScreenOperation Afterthecameraispoweredon,thetouchscreendisplaysthecamerashooting interfacebydefault,andthemenubarshowsshootingmode,batterylevel, storagecapacityandotherinformation.Performfunctionaloperationsbytapping orslidingthetouchscreen. Tapthescreen:Hide/showinformation Swipedownfromthetopedge:Enterthecamerasettingspage Swiperightfromtheleftedge:Enterthealbumpage Swipeleftfromtherightedge:Entertheshootingparametersettingspage Swipeupfromthebottomedge:Entertheshootingmodeswitchingpage;slide left/righttoswitchmodes,andthepagewillautomaticallyreturntothepreview interfaceifthereisnooperationwithin3seconds. III. Specifications CategoryItemSpecification Details Specificati on Product Name Product Mode Thumb Camera l Guimeet GO 5 Input5V⎓3A Operating Temp -10°C~40°C Charging Temp 0°C~60°C Bluetooth version Bluetooth V5.3 Wi-FiversionWi-Fi5 FCC Caution： This device complies with part 15 of the FCC Rules. Operation is subject to the fo llowing two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compli ance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device , pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protec tion against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruct ions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or te levision reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the f ollowing measures: - Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC RF Radiation Exposure and SAR Statements The Thumb Camera has been tested for limbs worn Specific Absorption R ate(SAR) compliance. The FCC has established detailed SAR requirements and has established that these requirements. RF Exposure Information The radio module has b een evaluated under FCC Bulletin C95.1 and IEEE 1528 and found to be compliant to RF Exposure from radio frequency devices. This model meets the applicable g overnment requirements for exposure to radio frequency waves. The highest r eported SAR level for usage near the limbs worn. (FCC ID:2BVFR-GO5B) SAR level for usage near the body worn (0mm Gap) is 0 .123W/kg and simultaneous transmission is 0.198W/kg. (FCC ID:2BVFR-GO5C) SAR level for usage near the body worn (0mm Gap) is 0.146W/kg and simultaneous tra…
