2BVLD-C201TAutomatic Cleaning Robot

PSA24317-NTPIF4-MuwayhPV2.35GW项目清扫机 器人安装说明 版本Versions:1.0 日期Date:2025/7/22 Page 1 /of 12 内容仅经许可后才能传递、使用或透露。蓝旭科技保留所有权利。 Thecontentsmayonlybepassedon,usedormadeknownwithourexpresspermission.©Solar-LIT-Allrightsreserved. 修订履历Documentmodificationrecord 修订日期 Revisiondate 版本 Versions 修订内容 Revisioncontent 修订人 Revisedby 2025/7/221.0 新增项目陈嘉圣 部门 Established Dept. 制订 Preparedby 审核 Checkedby 批准 Approvedby 发布部门 ReleaseDept. 实施日期 Implemented Date 技术中心研发中心 会签栏 接收部门 ReceivedDept ☐销售部 □ 运维部 □ 工程部 □ 技术部 □ 产品部 □ 制造部 PSA24317-NTPIF4-MuwayhPV2.35GW项目清扫机 器人安装说明 版本Versions:1.0 日期Date:2025/7/22 Page 2 /of 12 内容仅经许可后才能传递、使用或透露。蓝旭科技保留所有权利。 Thecontentsmayonlybepassedon,usedormadeknownwithourexpresspermission.©Solar-LIT-Allrightsreserved. □质量部□采购部□综合管理部□智能研发部 本说明是太阳能清洁机器人的一般指南。、 Thismanualservesasageneralguideforthesolar-poweredcleaningrobot. 安装前，请根据我们在相关包装中提供的零件清单检查所有组件是否准备就绪。 Beforeinstallation,pleaseverifyallcomponentsarereadybycheckingagainsttheparts listprovidedintherelevantpackaging. 第1部分：机器人装配 1.机器人整机基本安装完成，出货运送到现场需要安装挂轮和挂钩； Theprimaryphaseoftherobot'sassemblyhasbeencompleted.Installationofthe suspensionwheelsandhooksshallbeconductedfollowingshipmenttothefacility. 2.拆除包装，上端部件安装挂轮和上挂钩： De-packthesystemandaffixthehangingwheelsalongwiththeuppersuspensionhook tothedesignateduppermodule. Step1:安装行走轮和尼龙挂轮，使用内六角圆柱头螺钉（M6×30）和防松螺母（M6）锁紧挂轮； Step1:InstalltheWalkingWheelandHungingWheel.Securethehangingwheelsusingsocket headcapscrews(M6×30)andlocknuts(M6). PSA24317-NTPIF4-MuwayhPV2.35GW项目清扫机 器人安装说明 版本Versions:1.0 日期Date:2025/7/22 Page 3 /of 12 内容仅经许可后才能传递、使用或透露。蓝旭科技保留所有权利。 Thecontentsmayonlybepassedon,usedormadeknownwithourexpresspermission.©Solar-LIT-Allrightsreserved. Step2:确认挂钩状态，安装上防脱挂钩，使用内六角圆柱头组合螺钉（M6×16）锁紧，安装过程 注意挂钩朝向； Step2:Inspectthehookassemblystatus,thenproceedwiththeinstallationofthe anti-disengagementhookunit.Securetheassemblyusinghexsocketheadcombinationscrews (M6×16),ensuringproperorientationofthehookduringtheinstallationprocess. Step3:接近开关延长线由端板内侧经过线防尘密封圈引出，在外侧和风载接近开关对接，对接后 使用扎带将线固定在挂钩绑线孔上； Step3:Routetheproximityswitchextensioncablethroughthedust-proofsealingring ontheendplate'sinteriorside.Connectittothewind-loadproximityswitchonthe exteriorside,thensecurethecabletothehook'swire-bindingorificeusingcableties afterconnection. 行走轮 WalkingWheel 挂轮 HungingWheel PSA24317-NTPIF4-MuwayhPV2.35GW项目清扫机 器人安装说明 版本Versions:1.0 日期Date:2025/7/22 Page 4 /of 12 内容仅经许可后才能传递、使用或透露。蓝旭科技保留所有权利。 Thecontentsmayonlybepassedon,usedormadeknownwithourexpresspermission.©Solar-LIT-Allrightsreserved. 3.拆除包装，下端部件安装挂钩，使用内六角圆柱头组合螺钉（M6×16）锁紧； Step3:Removethepackaging,installthehookonthelowerassembly,andsecureitwith hexsocketheadcombinationscrews(M6×16). 4.拧上天线，螺纹拧紧。 Rotatetheantennaclockwiseuntilfullthreadengagementisachieved. 第2部分：将清洁机器人放在面板上 1.现场需要两个人来帮忙搬运，下端外罩无法受力（红色方框），注意避让，人员分布受力点如 过线防尘密封圈 Cablepassdustseal 绑线孔 Cabletiemount PSA24317-NTPIF4-MuwayhPV2.35GW项目清扫机 器人安装说明 版本Versions:1.0 日期Date:2025/7/22 Page 5 /of 12 内容仅经许可后才能传递、使用或透露。蓝旭科技保留所有权利。 Thecontentsmayonlybepassedon,usedormadeknownwithourexpresspermission.©Solar-LIT-Allrightsreserved. 下： 1.On-siteassistancefromtwopersonnelisrequiredfortransportation.Thelowercover isnon-load-bearing(asindicatedbytheredbox)andmustbeavoided.Personnelshould distributeforceexclusivelyatthedesignatedload-bearingpointsillustratedbelow. 2.小心抬起机器人，将上端挂轮扣在面板侧边缘上，确保挂轮和上端行走轮紧密接触面板金属边 框，防脱挂钩位于面板下方。 2.Carefullylifttherobotandengagetheupperhangingwheelsontothesideedgeof thepanel.Ensureboththehangingwheelsandtheuppertravelwheelsmaintainfullcontact withthemetalframeofthepanel,withtheanti-disengagementhookpositionedbeneath thepanel. 3.小心地缓慢下降机器人的下部，直到下行走轮接触到下端面板边缘金属边框。 3.Carefullyandslowlylowerthelowersectionoftherobotuntilthelowertravelwheels makefullcontactwiththemetalframeonthebottompaneledge. Support Support （侧视图） 行走轮 WalkingWheel 防脱挂钩 Anti-drophook 挂轮 HungingWheel PSA24317-NTPIF4-MuwayhPV2.35GW项目清扫机 器人安装说明 版本Versions:1.0 日期Date:2025/7/22 Page 6 /of 12 内容仅经许可后才能传递、使用或透露。蓝旭科技保留所有权利。 Thecontentsmayonlybepassedon,usedormadeknownwithourexpresspermission.©Solar-LIT-Allrightsreserved. 注意：请记住，操作时必须非常小心，以防光伏组件或机器人受损。 Important:Exerciseextremecautionduringoperationtopreventdamagetophotovoltaic modulesortherobotsystem. 3.停机位接近开关对位：确保停机位接近开关与停机位感应片基本对中，且两者竖向间距保持在 5~15mm。 4.ParkingPositionProximitySwitchAlignment:Ensuretheparkingpositionproximity switchisroughlycenteredwiththeinductionplate,maintainingaverticalclearance of5-15mmbetweenthem. 4. PSA24317-NTPIF4-MuwayhPV2.35GW项目清扫机 器人安装说明 版本Versions:1.0 日期Date:2025/7/22 Page 7 /of 12 内容仅经许可后才能传递、使用或透露。蓝旭科技保留所有权利。 Thecontentsmayonlybepassedon,usedormadeknownwithourexpresspermission.©Solar-LIT-Allrightsreserved. 5.停机位上轮挡杆、防风支架、感应片三者对位：确保机器人轮子顶住挡杆的时候，推杆可以顺 畅的推入防风支架，同时接近开关处于感应片上方不能脱离。 5.AlignmentofParkingPositionComponents(WheelStopper,WindproofBracket&Sensor Plate),Ensurewhentherobotwheelscontactthestopperbar: Thepushrodcansmoothlyengagethewindproofbracket Theproximityswitchremainspositionedabovethesensorplatewithoutdisengagement 6.返机位接近开关对位：确保停机位接近开关与停机位感应片基本对中，且两者竖向间距保持在 5~15mm。与第4步骤一致。 6.ReturnPositionProximitySwitchAlignment Ensurethereturnpositionproximityswitchisconcentricallyalignedwiththeinduction plate,maintainingaverticalclearanceof5-15mmbetweencomponents.（Note:Same technicalrequirementsasStep4） 停机位接近开关 停机位感应片 PSA24317-NTPIF4-MuwayhPV2.35GW项目清扫机 器人安装说明 版本Versions:1.0 日期Date:2025/7/22 Page 8 /of 12 内容仅经许可后才能传递、使用或透露。蓝旭科技保留所有权利。 Thecontentsmayonlybepassedon,usedormadeknownwithourexpresspermission.©Solar-LIT-Allrightsreserved. 第3部分：试跑前的检查 Part3:Pre-RunInspection(RobotinParkingPosition) 1.按下电源开关，机器人指示灯亮红灯自检，自检通过后机器人绿灯常亮，此时机器人状态正常 可运行。 1.Power-OnSelf-Test Pressthepowerbuttontoactivatetherobot Self-testsequence: RedLED=Systeminitializing(duration:≤30sec) GreenLED(steady)=Self-testpassed/Operationalready 2.检查接近开关与感应片相对位置是否正确。 2.ProximitySwitchAlignmentVerification Requiredalignment: •Sensor-to-targetgap:5-15mm(optimal:10mm) 3.在正确位置接近开关指示灯常亮。 3.SensorStatusConfirmation PSA24317-NTPIF4-MuwayhPV2.35GW项目清扫机 器人安装说明 版本Versions:1.0 日期Date:2025/7/22 Page 9 /of 12 内容仅经许可后才能传递、使用或透…
