2BVLS-TW10Wireless Outdoor Cam

User Manual ENDE FR ES NL PL IT Model: TW10 Wireless Outdoor Cam TW10 Wireless Cam Camera MountSolar Panel Charging CableMounting Screw User Manual User Manual Packing List 1 • The power button, reset button, and charging port are located under the silicone cover. • C amera Power on/off: Press and hold the "power button" for 5 seconds until you hear the voice prompt. • Camera Reset: Press and hold the "reset button" for 5 seconds until you hear the voice prompt. Product Diagram ① ② ③ ④ Lens Spotlight Light sensor Indicator light ⑨ ⑩ ⑪ Power button USB charging port Reset button ⑥ ⑤ ① ② ③ ④ ⑦ ⑧ ⑨ ⑩ ⑪ PIR motion sensor Microphone Speaker Screw mount ⑤ ⑥ ⑦ ⑧ 2 Osaio App Please search "Osaio" on Google Play / App Store, or scanning the QR code to download the App. Osaio is our trusted cloud service partner, delivering secure and seamless video experiences for Nkccnur users. All data is stored on local servers in accordance with regional regulations, ensuring privacy and peace of mind. Android / iOS Warranty 30 days return policy and 12 months limited warranty Timely customer service via [email protected] 3 Indicator light 1.Search for "Osaio" on Google Play or the App Store to download the Osaio app; 2.Plug in your camera and wait until the indicator light flashes red; 3.Connect your phone to a 2.4 GHz Wi-Fi network, log in to the Osaio app, and tap "+" to add your camera; 4.Follow the on-screen instructions to complete the setup. Solid red light Flashing red light Flashing green light The device is ready to connect Connection is in progress Status Wi-Fi account or password is wrong, please reconnect The device is powered on and initializing or is charging Solid green light Indicator light o The device detects motion or is fully charged The device is in sleep mode or not powered on Flashing between green and red LED Indicator How to set up 4 • The recommended temperature range for devices and accessories is 0 °C to 45°C (0 °F to 113 °F). • Unless specically indicated that it is safe to do so in the user guide or instruction manual, do not use the device in an environment that exceeds the recommended low or high temperature. • Unless specically indicated that it is safe to do so in the user guide, or instruction manual, never expose the device to strong sunshine or a too-wet environment. • For pluggable equipment, the socket outlet should be easily accessible. Child Safety • THIS DEVICE IS NOT A TOY. • Choking Hazard: This product contains (or comes with) small parts, plastic elements, cables, and parts that may cause choking hazards. Keep your camera and its accessories out of the reach of small children. Consult a physician immediately if small parts are swallowed. • Strangulation Hazard: Children get strangled in cords. Keep cords out of the reach of children (more than 3 ft / 0.9 m away) Important Safety Instructions 5 Osaio App Android / iOS Garantie 30 Tage Rickgaberecht und 12 Monate eingeschrankte Garantie Rechtzeitiger Kundenservice über [email protected] Bitte laden Sie die App herunter, indem Sie nach "Osaio" suchen oder den folgenden QR-Code scannen. Osaio ist unser zuverlässiger Cloud-Service-Partner und bietet Nkccnur-Nutzern sichere und nahtlose Videoerlebnisse. Alle Daten werden gemäß den regionalen Vorschriften auf lokalen Servern gespeichert, um Datenschutz und Sicherheit zu gewährleisten. DE 6 7 1.Suchen Sie bei Google Play oder im App Store nach „Osaio“, um die Osaio-App herunterzuladen; 2.Schließen Sie Ihre Kamera an und warten Sie, bis die Kontrollleuchte rot blinkt; 3.Verbinden Sie Ihr Telefon mit einem 2,4-GHz-WLAN, melden Sie sich in der Osaio-App an und tippen Sie auf „+“, um Ihre Kamera hinzuzufügen; 4.Folgen Sie den Anweisungen in der App, um die Einrichtung abzuschließen. LED-Anzeige Kontrollleuchte Rotes Dauerlicht Blinkendes rotes Licht Blinkt zwischen grün und rot Das Gerät ist bereit für die Verbindung Wi-Fi-Konto oder Passwort ist falsch, bitte erneut verbinden Status Das Gerät erkennt Bewegung oder ist vollständig geladen. Das Gerät ist eingeschaltet und initialisiert sich oder wird geladen Grünes Dauerlicht Das Gerät bendet sich im Ruhezustand oder ist nicht eingeschaltet Anzeigelampe aus Grünes Blinklicht Verbindung ist in Arbeit Wie einrichten DE • Der empfohlene Temperaturbereich für Geräte und Zubehör beträgt 0 °C bis 45 °C (0 °F bis 113 °F). • Verwenden Sie das Gerät nicht in einer Umgebung, in der die empfohlene niedrige oder hohe Temperatur überschritten wird, es sei denn, dies ist in der Bedienung- sanleitung oder im Benutzerhandbuch ausdrücklich als sicher angegeben. • Sofern in der Bedienungsanleitung oder im Handbuch nicht ausdrücklich darauf hingewiesen wird, dass dies sicher ist, dürfen Sie das Gerät niemals starker Sonneneinstrahlung oder einer zu feuchten Umgebung aussetzen. • Bei steckbaren Geräten sollte die Steckdose leicht zugänglich sein. Kindersicherheit • DIESES GERÄT IST KEIN SPIELZEUG. • Erstickungsgefahr: Dieses Produkt enthält (oder wird mit) Kleinteilen, Kunststoele- menten, Kabeln und Teilen geliefert, die Erstickungsgefahr verursachen können. Bewahren Sie Ihre Kamera und deren Zubehör außerhalb der Reichweite von kleinen Kindern auf. Suchen Sie sofort einen Arzt auf, wenn kleine Teile verschluckt wurden. • Strangulationsgefahr: Kinder können sich in Kabeln strangulieren. Bewahren Sie Kabel außerhalb der Reichweite von Kindern auf (mehr als 0,9 m entfernt). Wichtige Sicherheitshinweise DE 8 Osaio App Scarica l'app cercando "Osaio" o scansionando il codice QR qui sotto. Osaio è il nostro partner di ducia per i servizi cloud e ore esperienze video sicure e uide agli utenti Nkccnur. Tutti i dati vengono archiviati su server locali, in conformità con le normative regionali, garantendo privacy e tranquillità. Android / iOS Garanzia Politica di restituzione di 30 giorni e garanzia limitata di 12 mesi Servizio clienti tempestivo tramite [email protected] IT 9 Indicatore LED Indicatori luminosi Luce rossa ssa Luce verde…

Text truncated - open the document above for the full version.

Covered Equipment Attestation Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(i)-(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2BVLS-TW10 TW10, NW10,NW11,NW12,NW13,NW14,NW15,N W20,NW21,NW22,NW23,NW24,NW25,NW 30,NW31,NW32,NW33,NW34,NW35,NW40 ,NW41,NW42,NW43,NW44,NW45 We, Applicant Company Name: SHENZHEN PINJIN SHIDAI TECHNOLOGY CO LTD Address: Room 814, Beike Building 59 Gaoxin South 9th Road, Nanshan District Shenzhen China Phone: 13537704457 certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. This includes the cybersecurity and anti-virus software produced or provided by Kaspersky Lab, Inc. or any of it’s successors and assignees. We certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. If you have any questions, please feel free to contact us at the address shown below. Sincerely, Signature Date: 2026-5-6 Printed Name of Signee: Tony Lee/N/A Company: SHENZHEN PINJIN SHIDAI TECHNOLOGY CO LTD Address: Room 814, Beike Building 59 Gaoxin South 9th Road, Nanshan District Shenzhen China Phone: 13537704457 Fax: N/A Email: [email protected]

SHENZHEN PINJIN SHIDAI TECHNOLOGY CO LTD Add: Room 814, Beike Building 59 Gaoxin South 9th Road, Nanshan District Shenzhen China Date: 2026-5-6 FCC ID: 2BVLS-TW10 Dear Sir/Madam, We, SHENZHEN PINJIN SHIDAI TECHNOLOGY CO LTD Hereby declares the following statement for Federal Communications Commission, All these models are exactly the same in terms of the printed circuit board, layout and electrical circuits. The difference lies in the color of the casing. Product name: Wireless Outdoor Cam Model no.: TW10, NW10,NW11,NW12,NW13,NW14,NW15,NW20,NW21,NW22,NW23,NW24,NW25, NW30,NW31,NW32,NW33,NW34,NW35,NW40,NW41,NW42,NW43,NW44,NW45 Sincerely, Name/Title： Tony Lee/N/A Company: SHENZHEN PINJIN SHIDAI TECHNOLOGY CO LTD Address: Room 814, Beike Building 59 Gaoxin South 9th Road, Nanshan District Shenzhen China Phone: 13537704457 Fax: N/A E-Mail: [email protected]

SHENZHEN PINJIN SHIDAI TECHNOLOGY CO LTD Room 814, Beike Building 59 Gaoxin South 9th Road, Nanshan District Shenzhen China Date: 2026-5-6 FCC ID: 2BVLS-TW10 Model Number: TW10, NW10,NW11,NW12,NW13,NW14,NW15,NW20,NW21,NW22,NW23,NW24,NW25,NW3 0,NW31,NW32,NW33,NW34,NW35,NW40,NW41,NW42,NW43,NW44,NW45 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, SHENZHEN PINJIN SHIDAI TECHNOLOGY CO LTD, declare that this EUT (FCC ID: 2BVLS-TW10) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： Tony Lee/N/A Company: SHENZHEN PINJIN SHIDAI TECHNOLOGY CO LTD Address: Room 814, Beike Building 59 Gaoxin South 9th Road, Nanshan District Shenzhen China Phone: 13537704457 Fax: N/A E-Mail: [email protected]

Confidentiality Request Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: FCC ID Model name 2BVLS-TW10 TW10, NW10,NW11,NW12,NW13,NW14,NW15,N W20,NW21,NW22,NW23,NW24,NW25,NW 30,NW31,NW32,NW33,NW34,NW35,NW40 ,NW41,NW42,NW43,NW44,NW45 For the products listed above, we request permanent confidentiality for all applicable exhibits as there are:  the Operational Description  the Block Diagram  the Schematics The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, Signature Date: 2026-5-6 Printed Name of Signee: Tony Lee/N/A Company: SHENZHEN PINJIN SHIDAI TECHNOLOGY CO LTD Address: Room 814, Beike Building 59 Gaoxin South 9th Road, Nanshan District Shenzhen China Phone: 13537704457 Fax: N/A Email: [email protected]

FCC ID:2BVLS-TW10 www.cotecna-toby.com TB-RF-073-3.1 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT FCC ID:2BVLS-TW10 www.cotecna-toby.com TB-RF-073-3.1 Photo 3 Appearance of EUT Photo 4 Appearance of EUT FCC ID:2BVLS-TW10 www.cotecna-toby.com TB-RF-073-3.1 Photo 5 Appearance of EUT Photo 6 Appearance of EUT

FCC ID:2BVLS-TW10 www.cotecna-toby.com TB-RF-073-3.1 Appendix I Label Appendix II Label Location FCC ID:2BVLS-TW10 Model:TW10

FCC ID:2BVLS-TW10 www.cotecna-toby.com TB-RF-073-3.1 Appendix IV EUT Internal Photographs Photo 7 Internal of EUT Photo 8 Internal of EUT WIFI Antenna FCC ID:2BVLS-TW10 www.cotecna-toby.com TB-RF-073-3.1 Photo 9 Appearance of PCB Photo 10 Appearance of PCB FCC ID:2BVLS-TW10 www.cotecna-toby.com TB-RF-073-3.1 Photo 11 Appearance of PCB Photo 12 Appearance of PCB FCC ID:2BVLS-TW10 www.cotecna-toby.com TB-RF-073-3.1 Photo 13 Appearance of PCB Photo 14 Battery Appearance

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202602-0231-1 Page: 1 of 8 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com Maximum Permissible Exposure Evaluation FCC ID: 2BVLS-TW10 Report No. : TBR-C-202602-0231-1 Applicant : SHENZHEN PINJIN SHIDAI TECHNOLOGY CO LTD Equipment Under Test (EUT) EUT Name : Wireless Outdoor Cam Model No. : TW10 Series Model No. : NW10,NW11,NW12,NW13,NW14,NW15,NW20,NW21,NW22,NW23, NW24,NW25,NW30,NW31,NW32,NW33,NW34,NW35,NW40,NW41, NW42,NW43,NW44,NW45 Brand Name : Nkccnur Sample ID : HC-C-202602-0231-01-01 Receipt Date : 2026-04-03 Test Date : 2026-04-03 to 2026-05-06 Issue Date : 2026-05-06 Standards : FCC Part 2.1091 Test Method : KDB 447498 D01 General RF Exposure Guidance v06 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Test By : Kael Li Reviewed By : Henry huang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202602-0231-1 Page: 2 of 8 www.cotecna-toby.com TB-RF-073-3.1 CONTENTS CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT.............................................................................. 4 1.1 Client Information ................................................................................................................. 4 1.2 General Description of EUT (Equipment Under Test) ................................................... 4 2. MEASUREMENT UNCERTAINTY .......................................................................................... 5 3. TEST FACILITY.......................................................................................................................... 6 4. METHOD OF MEASUREMENT FOR FCC............................................................................ 7 5. TEST RESULT............................................................................................................................ 8 Report No.: TBR-C-202602-0231-1 Page: 3 of 8 www.cotecna-toby.com TB-RF-073-3.1 Revision History Report No. Version Description Issued Date TBR-C-202602-0231-1 Rev.01 Initial issue of report 2026-05-06 Report No.: TBR-C-202602-0231-1 Page: 4 of 8 www.cotecna-toby.com TB-RF-073-3.1 1. General Information about EUT 1.1 Client Information Applicant : SHENZHEN PINJIN SHIDAI TECHNOLOGY CO LTD Address : Room 814, Beike Building 59 Gaoxin South 9th Road, Nanshan District Shenzhen China Manufacturer : SHENZHEN PINJIN SHIDAI TECHNOLOGY CO LTD Address : Room 814, Beike Building 59 Gaoxin South 9th Road, Nanshan District Shenzhen China 1.2 General Description of EUT (Equipment Under Test) EUT Name : Wireless Outdoor Cam Models No. : TW10, NW10,NW11,NW12,NW13,NW14,NW15,NW20,NW21, NW22,NW23,NW24,NW25,NW30,NW31,NW32,NW33,NW34,NW35 ,NW40,NW41,NW42,NW43,NW44,NW45 Model Different : All these models are exactly the same in terms of the printed circuit board, layout and electrical circuits. The difference lies in the color of the casing. Product Description : Operation Frequency: 2.4G Wi-Fi: 2412MHz~2462MHz Modulation Type: 802.11b: DSSS (DQPSK, DBPSK, CCK) 802.11g: OFDM (BPSK, QPSK,16QAM, 64QAM) 802.11n: OFDM (QPSK, BPSK, 16QAM, 64QAM) Antenna Gain: 3.02dBi FPC Antenna Power Rating : USB Input: DC 5V DC 3.6V 4000mAh Rechargeable Li-ion battery Software Version : 1.0 Hardware Version : 1.0 Remark: The above antenna information is declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. Report No.: TBR-C-202602-0231-1 Page: 5 of 8 www.cotecna-toby.com TB-RF-073-3.1 2. Measurement Uncertainty The reported uncertainty of measurement y±U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %. Test Item Parameters Expanded Uncertainty (ULab) Conducted Emission Level Accuracy: 9kHz~150kHz 150kHz to 30MHz ±3.50 dB ±3.10 dB Radiated Emission Level Accuracy: 9kHz to 30 MHz ±4.60 dB Radiated Emission Level Accuracy: 30MHz to 1000 MHz ±4.50 dB Radiated Emission Level Accuracy: Above 1000MHz ±4.20 dB Temperature / ±0.6°C Humidity / ±4% Supply voltages / ±2% Time / ±4% Report No.: TBR-C-202602-0231-1 Page: 6 of 8 www.cotecna-toby.com TB-RF-073-3.1 3. Test Facility The testing report were performed by the Shenzhen Toby Technology Co., Ltd., in their facilities located at 1/F., Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. At the time of testing, the following bodies accredited the Laboratory: CNAS (L5813) The Laboratory has been accredited by CNAS to ISO/IEC 17025: 2017 General Requirements for the Competence of Testing and Calibration Laboratories for the competence in the field of testing. And the Registration No.: CNAS L5813. A2LA Certificate No.: 4750.01 The laboratory has been accredited by American Association for Laboratory Accreditation(A2LA) to ISO/IEC 17025：2017 General Requirements for the Competence of Testing and Calibration Laboratories for the technical competence in the field of Electrical Testing. And the A2LA Certificate No.: 4750.01.FCC Accredited Test Site Number: 854351. Designation Number: CN1223. IC Registration No.: (11950A) The Laboratory has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing. The site registration: Site# 11950A. CAB identifier: CN0056. Report No.: TBR-C-202602-…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202602-0231-2 Page: 1 of 51 FCC ID: 2BVLS-TW10 TB-RF-073-3.1 RF Test Data for 2.4G WiFi (Conducted Measurements) General Description of EUT Product Name: Wireless Outdoor Cam Test Model: TW10 Sample ID: HC-C-202602-0231-01-01 Environmental Conditions Temperature: 25.6°C Relative Humidity: 48.6% Test Voltage: DC 3.6V Test Engineer: Kael Li Note: For a more detailed features description, please refer to the report TBR-C-202602-0231-2 The report only show the worst case data. Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202602-0231-2 Page: 2 of 51 FCC ID: 2BVLS-TW10 TB-RF-073-3.1 Contents 1. Duty Cycle ..................................................................................................................................................................................... 3 2. Maximum Conducted Output Power ............................................................................................................................................ 9 3. -6dB Bandwidth ........................................................................................................................................................................... 10 4. Occupied Channel Bandwidth .................................................................................................................................................... 16 5. Maximum Power Spectral Density Level ................................................................................................................................... 22 6. Band Edge ................................................................................................................................................................................... 28 7. Conducted RF Spurious Emission ............................................................................................................................................. 35 8. Restrict Band ............................................................................................................................................................................... 45 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202602-0231-2 Page: 3 of 51 FCC ID: 2BVLS-TW10 TB-RF-073-3.1 1. Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT b 2412 Ant1 44.81 3.49 0.12 NVNT b 2437 Ant1 44.04 3.56 0.12 NVNT b 2462 Ant1 44.91 3.48 0.12 NVNT g 2412 Ant1 11.9 9.24 0.73 NVNT g 2437 Ant1 11.57 9.37 0.73 NVNT g 2462 Ant1 11.9 9.24 0.73 NVNT n(HT20) 2412 Ant1 11.22 9.5 0.78 NVNT n(HT20) 2437 Ant1 11.22 9.5 0.78 NVNT n(HT20) 2462 Ant1 11.23 9.5 0.78 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202602-0231-2 Page: 4 of 51 FCC ID: 2BVLS-TW10 TB-RF-073-3.1 Test Graphs Duty Cycle NVNT b 2412MHz Ant1 Duty Cycle NVNT b 2437MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202602-0231-2 Page: 5 of 51 FCC ID: 2BVLS-TW10 TB-RF-073-3.1 Duty Cycle NVNT b 2462MHz Ant1 Duty Cycle NVNT g 2412MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202602-0231-2 Page: 6 of 51 FCC ID: 2BVLS-TW10 TB-RF-073-3.1 Duty Cycle NVNT g 2437MHz Ant1 Duty Cycle NVNT g 2462MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202602-0231-2 Page: 7 of 51 FCC ID: 2BVLS-TW10 TB-RF-073-3.1 Duty Cycle NVNT n(HT20) 2412MHz Ant1 Duty Cycle NVNT n(HT20) 2437MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202602-0231-2 Page: 8 of 51 FCC ID: 2BVLS-TW10 TB-RF-073-3.1 Duty Cycle NVNT n(HT20) 2462MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202602-0231-2 Page: 9 of 51 FCC ID: 2BVLS-TW10 TB-RF-073-3.1 2. Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Duty Factor (dB) Total Power (dBm) Limit (dBm) Verdict NVNT b 2412 Ant1 14.41 3.49 17.9 30 Pass NVNT b 2437 Ant1 14.29 3.56 17.85 30 Pass NVNT b 2462 Ant1 14.41 3.48 17.89 30 Pass NVNT g 2412 Ant1 8.63 9.24 17.87 30 Pass NVNT g 2437 Ant1 8.11 9.37 17.48 30 Pass NVNT g 2462 Ant1 7.82 9.24 17.06 30 Pass NVNT n(HT20) 2412 Ant1 6.5 9.5 16 30 Pass NVNT n(HT20) 2437 Ant1 5.99 9.5 15.49 30 Pass NVNT n(HT20) 2462 Ant1 5.6 9.5 15.1 30 Pass Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202602-0231-2 Page: 10 of 51 FCC ID: 2BVLS-TW10 TB-RF-073-3.1 3. -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT b 2412 Ant1 10.11 0.5 Pass NVNT b 2437 Ant1 10.09 0.5 Pass NVNT b 2462 Ant1 10.12 0.5 Pass NVNT g 2412 Ant1 15.61 0.5 Pass NVNT g 2437 Ant1 16.13 0…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202602-0231-2 Page: 1 of 32 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com Radio Test Report FCC ID: 2BVLS-TW10 Report No. : TBR-C-202602-0231-2 Applicant : SHENZHEN PINJIN SHIDAI TECHNOLOGY CO LTD Equipment Under Test (EUT) EUT Name : Wireless Outdoor Cam Model No. : TW10 Series Model No. : NW10,NW11,NW12,NW13,NW14,NW15,NW20,NW21,NW22,NW23, NW24,NW25,NW30,NW31,NW32,NW33,NW34,NW35,NW40,NW41, NW42,NW43,NW44,NW45 Brand Name : Nkccnur Sample ID : HC-C-202602-0231-01-01&HC-C-202602-0231-02-01 Receipt Date : 2026-04-03 Test Date : 2026-04-03 to 2026-05-06 Issue Date : 2026-05-06 Standards : FCC Part 15 Subpart C 15.247 Test Method : ANSI C63.10: 2020 KDB 558074 D01 15.247 Meas Guidance v05r02 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Test By : Kael Li Reviewed By : Henry huang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202602-0231-2 Page: 2 of 32 www.cotecna-toby.com TB-RF-073-3.1 Contents CONTENTS ............................................................................................................................................ 2 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 5 1.1 Client Information ................................................................................................................ 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 6 1.4 Description of Support Units .............................................................................................. 6 1.5 Description of Test Mode ................................................................................................... 7 1.6 Description of Test Software Setting ................................................................................ 8 1.7 Measurement Uncertainty .................................................................................................. 9 1.8 Test Facility......................................................................................................................... 10 2. TEST SUMMARY..................................................................................................................... 11 3. TEST SOFTWARE .................................................................................................................. 11 4. TEST EQUIPMENT AND TEST SITE .................................................................................. 12 5. CONDUCTED EMISSION TEST ........................................................................................... 13 5.1 Test Standard and Limit ................................................................................................... 13 5.2 Test Setup........................................................................................................................... 13 5.3 Test Procedure .................................................................................................................. 13 5.4 Deviation From Test Standard......................................................................................... 13 5.5 EUT Operating Mode ........................................................................................................ 13 5.6 Test Data............................................................................................................................. 13 6. RADIATED AND CONDUCTED UNWANTED EMISSIONS ............................................ 14 6.1 Test Standard and Limit ................................................................................................... 14 6.2 Test Setup........................................................................................................................... 15 6.3 Test Procedure .................................................................................................................. 16 6.4 Deviation From Test Standard......................................................................................... 17 6.5 EUT Operating Mode ........................................................................................................ 17 6.6 Test Data............................................................................................................................. 17 7. RESTRICTED BANDS AND BAND EDGE REQUIREMENT .......................................... 18 7.1 Test Standard and Limit ................................................................................................... 18 7.2 Test Setup........................................................................................................................... 18 7.3 Test Procedure .................................................................................................................. 19 7.4 Deviation From Test Standard......................................................................................... 20 7.5 EUT Operating Mode ........................................................................................................ 20 7.6 Test Data............................................................................................................................. 20 8. BANDWIDTH TEST................................................................................................................. 21 8.1 Test Standard and Limit …

Text truncated - open the document above for the full version.

ShenzhenYingjiachuangElectronicTechnologyCo.,LTD http://www.szsyjc.com 1 Address:BuildingC,HongyuGuangmingValley,No.11,YoumaGangRoad,MaTianStreet, GuangmingDistrict,ShenzhenDongguanBranch:YingjiachuangIndustrialPark,No.2 Yinhe3rdRoad,…
