2BVM4-NOTEPRIMEHyper AI Recorder

① Charge Hyper AI Note •Use the USB-C magnetic charging cable to connect to the ❹magnetic charging port. •LED indicator: •Solid red → Charging •Solid green → Fully charged ② Power On / Power Off • Power On •When the device is off, press and hold Function Button ❶for 2 seconds. •Device feedback: •Vibrates for 1 second •LED flashes bright green once •Connection status: •Slow flashing green →Waiting for Hyper AI App connection •Solid blue →Connected to Hyper AI App • Power Off •When the device is on, press and hold Function Button ❶for 2 seconds. •Device feedback: •Vibrates for 1 second •LED bright green then turns off • Auto Power Off •The device will automatically power off after 5 minutes if there is no recording, no Wi-Fi connection, no button activity, or charging. ③ Download the App •Scan the QR code to download and install the Hyper AI App. → •After installation, register with your email, then log in. ④ Connect Hyper AI Note •Open the app and tap “Add Device”, then select Hyper AI Note . •Once paired, the device will automatically reconnect when near your phone . ⑤ Start / Stop Recording • Start Recording •When the device is on, double-press Function Button ❶. •Device feedback: •1 vibration (0.3 s) •LED blue slow flashing (0.5 Hz) →Recording • Stop Recording •Double-press Function Button ❶again. •Device feedback: •2 vibrations (0.3 s) •LED solid blue →Standby mode ⑥ Sync, Transcribe and Generate AI Notes •Open the Hyper AI App to sync recordings from Hyper AI Note to your phone. •You can then: •Transcribe recordings into text •Generate structured AI notes / summaries / To-Do lists •Share recordings, transcripts and AI notes to other apps •Scan the QR code to view the full user guide. → ⑦ Keep Updated •Use the Hyper AI App to manage settings and install updates when available. ⑧ Safety & Privacy •Always comply with local laws and respect others’ privacy when recording. Hyper AI Note Quick Start Guide ❶Key❷LED❸Mic❹Magnetic Charging ① Hyper AI Note を充電する •USB-C 磁気充電ケーブルを使用して、 ❹磁気充電ポートに接続して充電します。 •LEDインジケーター： •赤色点灯 → 充電中 •緑色点灯 → 充電完了 ② 電源オン/ オフ •電源オン •電源がオフの状態で、機能ボタン❶を2秒間長押しします。 •1秒間振動します。 •LEDが緑色で1回点灯した後、以下の状態になります： •緑色ゆっくり点滅 → Hyper AI App 接続待機 •青色点灯 → Hyper AI App 接続済み •電源オフ •電源オンの状態で、機能ボタン❶を2秒間長押しします。 •1秒間振動します。 •LEDが緑色に点灯した後、消灯します。 •自動電源オフ •録音・Wi-Fi接続・ボタン操作・充電のいずれも行われていない状態が5分間続くと自 動的に電源がオフになります。 ③アプリをダウンロード •QRコードをスキャンしてHyper AI App をダウンロードし、 インストールしてください。→ •インストール後、メールアドレスで登録しログインします。 ④Hyper AI Note を接続 •アプリを開き、「デバイスを追加」をタップしてHyper AI Note を選択します。 •一度接続すると、デバイスがスマートフォンの近くにある場合 自動的に再接続されます。 ⑤録音の開始 / 停止 •録音開始 •電源オンの状態で機能ボタン❶を2回押しします。 •0.3秒振動（1回）。 •LED 青色ゆっくり点滅（0.5Hz） → 録音中。 •録音停止 •再度 機能ボタン❶を2回押しします。 •0.3秒振動（2回）。 •LED 青色点灯 → 待機状態。 ⑥ 同期・文字起こし・AIノート生成 •Hyper AI App を開き、Hyper AI Note の録音データをスマートフォンに同期します。 •録音を文字起こしし、AIノート/ 要約 / To-Doリストを生成できます。 •また、録音・文字起こし・AIノートを他のアプリへ共有することもできます。 •QRコードをスキャンすると詳細なユーザーガイドを確認できます。 → ⑦デバイスを最新の状態に保つ •Hyper AI App を使用して設定を管理し、 利用可能な場合はソフトウェア更新をインストールしてください。 ⑧ 安全とプライバシー •録音を行う際は、各地域の法律および規制を遵守し、 他者のプライバシーを尊重してください。 Hyper AI Note クイックスタートガイド ❶Key❷LED❸Mic❹磁気充電ポート ① 为 Hyper AI Note 充电 •使用 USB-C 磁吸充电线连接 ❹磁吸充电口 为设备充电 •状态❷LED •红灯常亮 → 正在充电 •绿灯常亮 → 电量充满 ② 开机 / 关机 •开机 •在关机状态下，长按功能键❶ 2 秒 •震动 1 秒 •状态❷LED：绿色高亮闪一下，然后 •绿色慢闪 → 等待Hyper AI App 连接 •蓝色常亮 → Hyper AI App已连接 •关机 •在开机状态下，长按功能键❶ 2 秒 •震动 1 秒 •状态❷LED：绿色高亮后熄灭 •自动关机 •在开机状态下，若 5 分钟内未录音、未连接 Wi-Fi、未按键操作、未充电，设备将自动关机 ③ 下载安装 App •扫描右侧二维码，下载并安装 Hyper AI App → •打开 App，使用您的 Email 注册、登录 ④连接 Hyper AI Note •打开 App，点击 「添加设备」，选择 Hyper AI Note •连接完成后，当Note靠近手机时，将自动重新连接 ⑤开始 / 停止录音 •在开机状态下，双击功能键❶，开始录音 •震动1次（0.3秒） •状态❷LED：蓝色慢闪（0.5Hz）→ 正在录音 •再次双击功能键❶，停止录音 •震动2次（0.3秒） •状态❷LED：蓝色长亮 → 进入待机状态 ⑥ 同步、转写并生成 AI 笔记 •打开Hyper AI App，将Hyper AI Note的录音同步导入手机。然后您可以： •将录音转写为文字 •选择模版生成 结构化 AI 笔记 / 要点 / To-Do •将录音、转写和 AI 笔记 分享到其他应用或平台。 •扫描右侧二维码，查看更多详细使用说明 → ⑦ 保持更新 •使用 Hyper AI App 管理设备设置，并在可用时安装软件更新，以获得最佳体验 ⑧ 安全与隐私 •在录音时，请遵守当地法律法规，并尊重他人的隐私 Hyper AI Note 智能录音卡 快速指南 ❶Key❷LED❸Mic❹磁吸充电口 FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 0cm between the radiator and your body.

Shenzhen HTT Technology Co., Ltd. Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 1 of 10 RF Exposure evaluation Report Reference No. ..................... : FCC ID............................................. : HTT202603540F03 2BVM4-NOTEPRIME Compiled by ( position+printed name+signature) . : File administrators Supervised by ( position+printed name+signature) . : Project Engineer Approved by ( position+printed name+signature) . : RF Manager Date of issue .................................... : Apr. 07, 2026 Testing Laboratory Name .............. : Shenzhen HTT Technology Co.,Ltd. Address ............................................ : 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao’an District, Shenzhen, Guangdong, China Applicant’s name ............................ : TRACUP PTE. LTD. Address ............................................ : Block 15 Beach Road #05-08 Beach Centre Singapore 189677 Standard ........................................... : 47CFR §1.1310 47CFR §2.1093 KDB447498 D01 General RF Exposure Guidance v06 Shenzhen HTT Technology Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HTT Technology Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HTT Technology Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Hyper AI Recorder Manufacturer .................................... : SHENZHEN FULLTECH TECHNOLOGY CO.,LTD. Trade Mark ........................................ N/A Model/Type reference ...................... : Note Prime Rating ............................................... : DC 3.8V From battery and DC 5.0V From external circuit Result ............................................... : PASS Report No.: HTT202603540F03 Page 2 of 10 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 2 of 10 T E S T R E P O R T Equipment under Test : Hyper AI Recorder Model /Type : Note Prime Listed Models : Note Lite, Note Nano, Note Slim, Note Core, Note Plus, Note Pro, Note Elite, Note Ultra, Note Max, Note Vision, Note Edge, Audio Core, Audio Prime, Audio Pro,Capture Vision, Capture Edge, Capture Prime, Capture Pro, Capture Ultra Model difference : The PCB board, circuit, structure and internal of these models are the same, Only model number is different for these model. Applicant : TRACUP PTE. LTD. Address : Block 15 Beach Road #05-08 Beach Centre Singapore 189677 Manufacturer : SHENZHEN FULLTECH TECHNOLOGY CO.,LTD. Address : Room 2805,Tower A, New Building of Tsinghua University Research Institute 9th Road of Gaoxin South,Yuehai Street,Nanshan District,ShenZhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: HTT202603540F03 Page 3 of 10 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 3 of 10 Contents 1 T E S T S T A N D A R D S ................................................... 4 2 S U M M A R Y .............................................................. 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Special Accessories 6 2.4 Modifications 6 3 T E S T E N V I R O N M E N T 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Statement of the measurement uncertainty 7 4 T E S T L I M I T 8 4.1 Requirement 8 4.2 Conducted Power Results 9 4.3 Manufacturing tolerance 9 4.4 Evaluation Result 10 4.5 Simultaneous Transmission for SAR Exclusion 10 5 C O N C L U S I O N 10 Report No.: HTT202603540F03 Page 4 of 10 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 4 of 10 1 T E S T S T A N D A R D S The tests were performed according to following standards: ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Device, RF Exposure, Equipment Authorization Procedures. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1093: Radiofrequency radiation exposure evaluation: portable devices Report No.: HTT202603540F03 Page 5 of 10 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 5 of 10 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Mar. 11, 2026 Testing commenced on : Mar. 11, 2026 Testing concluded on : Apr. 07, 2026 2.2 Product Description Product description: Hyper AI Recorder Model/Type reference: Note Prime Power supply: DC 3.8V From battery and DC 5.0 From external circuit Adapter Information (Auxiliary test provided by the lab): Testing sample ID： HTT202603540-1# (Engineer sample) HTT202603540-2# (Normal sample) Hardware version: / Software version: / WIFI : Supported type: 802.11b/802.11g/802.11n(HT20)/ 802.11n(HT40) Modulation: 802…

Text truncated - open the document above for the full version.

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202603540 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 1 of 2 Product Name: Hyper AI Recorder Model No.: Note Prime Test Setup Photo Radiated Emission Report No.: HTT202603540 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 2 of 2 Conducted Emission RF Test ------End------

Shenzhen HTT Technology Co., Ltd. Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ...................: FCC ID. ......................................... : HTT202603540F02 2BVM4-NOTEPRIME Compiled by ( position+printed name+signature) : File administrators Supervised by ( position+printed name+signature) : Project Engineer Approved by ( position+printed name+signature) : RF Manager Date of issue ...................................: Apr. 07, 2026 Testing Laboratory Name .............: Shenzhen HTT Technology Co.,Ltd. Address ..........................................: 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao’an District, Shenzhen, Guangdong, China Applicant’s name...........................: TRACUP PTE. LTD. Address ...........................................: Block 15 Beach Road #05-08 Beach Centre Singapore 189677 Test specification ......................... : Standard ..........................................: FCC Part 15.247 Shenzhen HTT Technology Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HTT Technology Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HTT Technology Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Equipment description ................ : Hyper AI Recorder Trade Mark ......................................: N/A Manufacturer ...................................: SHENZHEN FULLTECH TECHNOLOGY CO.,LTD. Model/Type reference .....................: Note Prime Listed Models ..................................: Note Lite, Note Nano, Note Slim, Note Core, Note Plus, Note Pro, Note Elite, Note Ultra, Note Max, Note Vision, Note Edge, Audio Core, Audio Prime, Audio Pro,Capture Vision, Capture Edge, Capture Prime, Capture Pro, Capture Ultra Modulation ......................................: GFSK Frequency ........................................ From 2402MHz to 2480MHz Ratings ............................................: DC 3.8V From battery and DC 5.0V From external circuit Result ..............................................: PASS Report No.: HTT202603540F02 Page 2 of 27 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China T E S T R E P O R T Equipment under Test : Hyper AI Recorder Model /Type : Note Prime Listed Models : Note Lite, Note Nano, Note Slim, Note Core, Note Plus, Note Pro, Note Elite, Note Ultra, Note Max, Note Vision, Note Edge, Audio Core, Audio Prime, Audio Pro,Capture Vision, Capture Edge, Capture Prime, Capture Pro, Capture Ultra Model difference : The PCB board, circuit, structure and internal of these models are the same, Only model number is different for these model. Applicant : TRACUP PTE. LTD. Address : Block 15 Beach Road #05-08 Beach Centre Singapore 189677 Manufacturer : SHENZHEN FULLTECH TECHNOLOGY CO.,LTD. Address : Room 2805,Tower A, New Building of Tsinghua University Research Institute 9th Road of Gaoxin South,Yuehai Street,Nanshan District,ShenZhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: HTT202603540F02 Page 3 of 27 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Contents 1 TEST STANDARDS .......................................................................................................................................... 4 2 SUMMARY ........................................................................................................................................................ 5 2.1 General Remarks .................................................................................................................................... 5 2.2 Product Description ................................................................................................................................. 5 2.3 Equipment Under Test ............................................................................................................................ 5 2.4 Short description of the Equipment under Test (EUT) ............................................................................ 5 2.5 EUT configuration .................................................................................................................................... 5 2.6 EUT operation mode ............................................................................................................................... 6 2.7 Block Diagram of Test Setup .................................................................................................................. 6 2.8 Related Submittal(s) / Grant (s) .............................................................................................................. 6 2.9 Modifications ........................................................................................................................................... 6 3 TEST ENVIRONMENT ...................................................................................................................................... 7 3.1 Address of the test laboratory ....................................…

Text truncated - open the document above for the full version.

Shenzhen HTT Technology Co., Ltd. Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. .................... : FCC ID. .......................................... : HTT202603540F01 2BVM4-NOTEPRIME Compiled by ( position+printed name+signature) . : File administrators Supervised by ( position+printed name+signature) . : Project Engineer Approved by ( position+printed name+signature) . : RF Manager Date of issue .................................... : Apr. 07, 2026 Testing Laboratory Name ............. : Shenzhen HTT Technology Co.,Ltd. Address ............................................ : 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao’an District, Shenzhen, Guangdong, China Applicant’s name ........................... : TRACUP PTE. LTD. Address ............................................ : Block 15 Beach Road #05-08 Beach Centre Singapore 189677 Test specification.......................... : Standard .......................................... : FCC Part 15.247 TRF Originator ................................. : Shenzhen HTT Technology Co.,Ltd. Shenzhen HTT Technology Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HTT Technology Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HTT Technology Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Hyper AI Recorder Trade Mark ....................................... : N/A Manufacturer .................................... : SHENZHEN FULLTECH TECHNOLOGY CO.,LTD. Model/Type reference ...................... : Note Prime Listed Models ................................... : Note Lite, Note Nano, Note Slim, Note Core, Note Plus, Note Pro, Note Elite, Note Ultra, Note Max, Note Vision, Note Edge, Audio Core, Audio Prime, Audio Pro,Capture Vision, Capture Edge, Capture Prime, Capture Pro, Capture Ultra Modulation Type .............................. : CCK/DSSS/OFDM Operation Frequency ....................... : From 2412 - 2462MHz Rating ............................................... : DC 3.8V From battery and DC 5.0V From external circuit Result ............................................... : PASS Report No.: HTT202603540F01 Page 2 of 35 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China T E S T R E P O R T Equipment under Test : Hyper AI Recorder Model /Type : Note Prime Listed Models : Note Lite, Note Nano, Note Slim, Note Core, Note Plus, Note Pro, Note Elite, Note Ultra, Note Max, Note Vision, Note Edge, Audio Core, Audio Prime, Audio Pro,Capture Vision, Capture Edge, Capture Prime, Capture Pro, Capture Ultra Model difference : The PCB board, circuit, structure and internal of these models are the same, Only model number is different for these model. Applicant : TRACUP PTE. LTD. Address : Block 15 Beach Road #05-08 Beach Centre Singapore 189677 Manufacturer : SHENZHEN FULLTECH TECHNOLOGY CO.,LTD. Address : Room 2805,Tower A, New Building of Tsinghua University Research Institute 9th Road of Gaoxin South,Yuehai Street,Nanshan District,ShenZhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: HTT202603540F01 Page 3 of 35 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Contents 1 TEST STANDARDS .......................................................................................................................................... 4 2 SUMMARY ........................................................................................................................................................ 5 2.1 General Remarks .................................................................................................................................... 5 2.2 Product Description ................................................................................................................................. 5 2.3 Equipment Under Test ............................................................................................................................ 5 2.4 Short description of the Equipment under Test (EUT) ............................................................................ 5 2.5 EUT configuration .................................................................................................................................... 6 2.6 EUT operation mode ............................................................................................................................... 6 2.7 Block Diagram of Test Setup .................................................................................................................. 6 2.8 Related Submittal(s) / Grant (s) .............................................................................................................. 6 2.9 Modifications ........................................................................................................................................... 6 3 TEST ENVIRONMENT .........................................................................................…

Text truncated - open the document above for the full version.

1 Appendix RF Test Data for BLE Company: : TRACUP PTE. LTD. EUT : Hyper AI Recorder FCC ID: : 2BVM4-NOTEPRIME Model Number : Note Prime Report No. : HTT202603540F02 Reviewed By : Heber He 2 1. Duty Cycle 1.1 Test Result 1.1.1 Ant1 Ant1 Mode TX Type Frequency (MHz) T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) Max. DC Variation (%) 1M SISO 2402 2.128 2.500 85.12 0.70 0.03 2440 2.128 2.500 85.12 0.70 0.03 2480 2.129 2.500 85.16 0.70 0.03 2M SISO 2402 1.076 2.500 43.04 3.66 0.03 2440 1.077 2.501 43.06 3.66 0.03 2480 1.076 2.500 43.04 3.66 0.03 3 1.2 Test Graph 1.2.1 Ant1 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV 4 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV 5 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV 6 2. Bandwidth 2.1 Test Result 2.1.1 OBW Mode TX Type Frequency (MHz) ANT 99% Occupied Bandwidth (MHz) Verdict Result Limit 1M SISO 2402 1 1.165 / Pass 2440 1 1.185 / Pass 2480 1 1.230 / Pass 2M SISO 2402 1 2.084 / Pass 2440 1 2.080 / Pass 2480 1 2.113 / Pass 2.1.2 6dB BW Mode TX Type Frequency (MHz) ANT 6dB Bandwidth (MHz) Verdict Result Limit 1M SISO 2402 1 0.760 >=0.5 Pass 2440 1 0.748 >=0.5 Pass 2480 1 0.732 >=0.5 Pass 2M SISO 2402 1 1.241 >=0.5 Pass 2440 1 1.257 >=0.5 Pass 2480 1 1.165 >=0.5 Pass 7 2.2 Test Graph 2.2.1 OBW 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV 8 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV 9 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV 10 2.2.2 6dB BW 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV 11 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV 12 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV 13 3. Maximum Conducted Output Power 3.1 Test Result 3.1.1 Power Mode TX Type Frequency (MHz) Maximum Peak Conducted Output Power (dBm) Verdict ANT1 Limit 1M SISO 2402 -0.71 <=30 Pass 2440 0.25 <=30 Pass 2480 0.46 <=30 Pass 2M SISO 2402 -0.62 <=30 Pass 2440 0.39 <=30 Pass 2480 0.60 <=30 Pass 14 4. Maximum Power Spectral Density 4.1 Test Result 4.1.1 PSD Mode TX Type Frequency (MHz) Maximum PSD (dBm) Verdict ANT1 Limit 1M SISO 2402 -0.83 <=8 Pass 2440 -0.04 <=8 Pass 2480 0.19 <=8 Pass 2M SISO 2402 -1.50 <=8 Pass 2440 -0.83 <=8 Pass 2480 -0.66 <=8 Pass 15 4.2 Test Graph 4.2.1 PSD 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV 16 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV 17 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV 18 5. Unwanted Emissions In Non-restricted Frequency Bands 5.1 Test Result 5.1.1 Ref Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) 1M SISO 2402 1 -0.90 2440 1 -0.01 2480 1 0.28 2M SISO 2402 1 -1.55 2440 1 -0.52 2480 1 -0.04 5.1.2 CSE Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) Limit (dBm) Verdict 1M SISO 2402 1 -0.90 -20.90 Pass 2440 1 -0.01 -20.01 Pass 2480 1 0.28 -19.72 Pass 2M SISO 2402 1 -1.55 -21.55 Pass 2440 1 -0.52 -20.52 Pass 2480 1 -0.04 -20.04 Pass 19 5.2 Test Graph 5.2.1 Ref 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV 20 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV 21 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV 22 5.2.2 CSE 1M_LCH_2402MHz_Ant1_NTNV 1M_LCH_2402MHz_Ant1_NTNV 23 1M_MCH_2440MHz_Ant1_NTNV 1M_HCH_2480MHz_Ant1_NTNV 24 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV 25 2M_LCH_2402MHz_Ant1_NTNV 2M_MCH_2440MHz_Ant1_NTNV 26 2M_HCH_2480MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV

1 Appendix RF Test Data for 2.4G WIFI Company: : TRACUP PTE. LTD. EUT : Hyper AI Recorder FCC ID: : 2BVM4-NOTEPRIME Model Number : Note Prime Report No. : HTT202603540F01 Reviewed By : Heber He 2 1. Duty Cycle 1.1 Test Result 1.1.1 Ant1 Ant1 Mode TX Type Frequency (MHz) T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) Max. DC Variation (%) 802.11b SISO 2412 0.206 0.418 49.28 3.07 0.03 2437 0.206 0.418 49.28 3.07 0.03 2462 0.205 0.418 49.04 3.09 0.03 802.11g SISO 2412 0.172 0.343 50.15 3.00 0.03 2437 0.172 0.343 50.15 3.00 0.06 2462 0.174 0.343 50.73 2.95 0.03 802.11n (HT20) SISO 2412 0.165 0.334 49.40 3.06 0.04 2437 0.165 0.335 49.25 3.08 0.04 2462 0.166 0.335 49.55 3.05 0.03 802.11n (HT40) SISO 2422 0.103 0.271 38.01 4.20 0.11 2437 0.100 0.271 36.90 4.33 0.06 2452 0.104 0.270 38.52 4.14 0.17 3 1.2 Test Graph 1.2.1 Ant1 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV 4 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11g_LCH_2412MHz_Ant1 (SISO)_NTNV 5 802.11g_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11g_HCH_2462MHz_Ant1 (SISO)_NTNV 6 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV 7 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV 8 802.11n(HT40)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV 9 2. Bandwidth 2.1 Test Result 2.1.1 OBW Mode TX Type Frequency (MHz) ANT 99% Occupied Bandwidth (MHz) Verdict Result Limit 802.11b SISO 2412 1 15.188 / Pass 2437 1 15.176 / Pass 2462 1 15.179 / Pass 802.11g SISO 2412 1 16.435 / Pass 2437 1 16.432 / Pass 2462 1 16.420 / Pass 802.11n (HT20) SISO 2412 1 17.530 / Pass 2437 1 17.520 / Pass 2462 1 17.508 / Pass 802.11n (HT40) SISO 2422 1 35.849 / Pass 2437 1 35.936 / Pass 2452 1 36.004 / Pass 2.1.2 6dB BW Mode TX Type Frequency (MHz) ANT 6dB Bandwidth (MHz) Verdict Result Limit 802.11b SISO 2412 1 10.166 >=0.5 Pass 2437 1 10.157 >=0.5 Pass 2462 1 10.162 >=0.5 Pass 802.11g SISO 2412 1 16.457 >=0.5 Pass 2437 1 16.459 >=0.5 Pass 2462 1 16.455 >=0.5 Pass 802.11n (HT20) SISO 2412 1 17.310 >=0.5 Pass 2437 1 17.236 >=0.5 Pass 2462 1 17.278 >=0.5 Pass 802.11n (HT40) SISO 2422 1 34.306 >=0.5 Pass 2437 1 34.610 >=0.5 Pass 2452 1 35.001 >=0.5 Pass 10 2.2 Test Graph 2.2.1 OBW 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV 11 802.11b_HCH_2462MHz_Ant1 (SISO)…
