Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
PP伄⩪ᣎਖ享 PP ᷚቨರݖᶭ҅ᶎڬܦ &$ ᧔กԡB(9B&$ਧګ ᮧᜌ Warning TIP TIP 11 • Please use the charger and USB cable provided with the device.• Åđ¿ÅÞđ¤~Óđ~ÞÞÓõđ¿~Óđ×ÅãÓ×đÅđčÓđÅÓ under extreme heat conditions.• Only use alternating current (AC) power provided by standard wall outlets. Do not use non-standard power sources (such as generators or inverters), and do not directly connect the battery to wall outlets or car cigarette lighter sockets.• Åđ¿ÅÞđôÐÅ×đÞ¤đî§đÞÅđčÓĜđôйÅ×§Å¿ĜđÅÓ other hazardous environments.• When using the device, it is recommended to maintain a distance of at least 10 cm (3.94 inches) from pacemakers to avoid potential interference. • Do not use and store the watch in dusty, hot, cold, electric, chemical areas. Please always keep the watch and accessories dry.• Do not drop, shake or knock the watch. Rough handling can break it. • Clean watch using a dry cloth. Do not use harmful chemicals or detergents.• Åđ¿ÅÞđ§××~××¾¹đÅÓđÓčÞđÞ¤đï~Þ¤đ~×đ§Þđï§¹¹ void your warranty.• Attempting to use other batteries can cause the watch to function incorrectly, or damage the watch.• To avoid accidents, never use watch while driving. • P¹~×đÞãÓ¿đÅđÞ¤đï~Þ¤đ蠟¹đĎõ§¿đ~¿đʹÅï any restrictions. Wireless devices can cause interference in aircraft. • Connect the USB cable from charging base to the AC adaptor.• Place the watch into the charging base correctly, youđ ï§¹¹đ¤~Óđ×ÐŶ¿đÅ¿čÓ¾~Þ§Å¿ “your watch is charging”. • Please charge the smartwatch fully every day or whenever the battery is low. It will take about 2 hours to fully charge. We advise emergency contacts to switch off anyvoicemail feature on their phone to prevent delay inreaching help. However, the following safeguardsare used if a voicemail is reached: • The wearer can end the current call by clicking the SOS button and the calling sequence to continue if the voicemail does not automatically disconnect. • An emergency contact can call back to the watch if they are disconnected. Remember that the watch maybe already calling the next contact unless the calling sequence has been stopped. • After SOS alarm is activated, you will hear a đ îŧđÐÓžÐÞđÅ¿čÓ¾§¿đÞ¤đ~Þ§î~Þ§Å¿đÅđÞ¤ SOS alert and allowing you approximately 10 seconds to cancel the alarm. If the SOS is not cancelled in time an SOS alert text message is immediately sent to the emergency contact numbers followed by the outgoing calls. • *đÞ¤đ~¹¹đÞÅđÞ¤đčÓ×Þđ¿ã¾Óđ~§¹×ĜđÞ¤đ×¾~ÓÞï~Þ¤ will wait another 10 seconds and attempt to call the second number. It will continue this process through your call list until connecting. • Between each call, it will have a 10 second delay, during this time, user can stop call sequence or prevent a possible false alarm by pressing SOS button. ^ÅđÞđ~¿đ§¿§Þ§~¹đ"PWđčôĜđÅoutdoors or near a window so the ï~Þ¤đ~¿đÞđ~đčôđÅ¿đÞ¤đ×~Þ¹¹§Þ×ěThis could take a few minutesdepending on your environment. The watch can automatically detect a fall. When thisoccurs the watch will give a warning message to the user. • The watch also provides Wi-Fi and LBS positioning. When GPS is unavailable, it will switch to either of these modes for locating. • The home Wi-Fi and beacons provide at-home out-of-home information in addition to optimizing watch battery life.• Please note Wi-Fi and LBS tracking service is not 100% accurate, it can be used to approximate your location only. • Some daily activities like sports or even sitting down abruptly can trigger the fall alarm. • The wearer has a short time to cancel a fall alarm by clicking cancel on the watch. If alarm is not cancelled, emergency contacts will be called. 1 Dimensions: 49.1 x 41 x 14.1mm 2 Weight: 50.6 grams 3 Battery: 700mAh (Rechargeable; magnetic 2-pin) 4 Waterproof: IP67 5 GPS locating technologies: 4G, 3G, 2G 1 At watch face, you can see time and date. 2 You have three different watch face options available. To change them, press and hold, then swipe between the two faces to change it. 3 Pull down the status bar to display battery, date, and watch settings. 12 There are two ways to activate SOS alarm.1 Press the side button for 3 seconds until you feel the watch vibrate. 2 When screen is on, long press the screen for 3 seconds until you feel the watch vibrate. 3 sec.3 sec. Please comply with the instructionsto extend the watch life: "¿Ó~¹đ×Чč~Þ§Å¿× 10 GPS "ÞÞ§¿đ~đ"PWđčô 9 Fall alarm 8 Notes on voicemail 7 Activating an SOS alarm GPS functionality may be unavailable or inaccuratein some locations (for example, if the wearer isindoors, near tall buildings, or underground). The watch battery is not removable. It can continueto discharge even when not in use, so after a longperiod of inactivity, it may not turn on. This is whyit is important to charge your smartwatch every day. When the watch is turned on, swipe leftwardsor rightwards to view all available functions.It displays watch face, pedometer, settings, stopwatch,pulse/blood pressure and temperature. It is possible that the watch will not detect every real fall.We strongly advise the wearer to press the SOS button in an emergency situation, if they are able. This smartwatch is designed for elderly userswho may be living alone. It combines manyintelligent functions, including SOS alarm,two-way talking, heart rate monitor, and manymore. The functions are complex, but theoperation is simple.Please read this operation guide carefullybefore using it. – Front – Back – Side USB Cable Charging Block Lanyard Watch Strap 1 Getting to know your watch 2 Accessories 3 Charging your watch 4 Functions and basic settings 5 Steps 6 Heart rate measurement Swipe right on the watch faceÞÅđč¿đÞ¤đ Pedometer display. Step counting is enabled bydefault and opened all day.This resets at midnight. Swipe the watch face until you reach the Pulse & Blood Pressure display. Wait for several seconds, and the screen will display your heart rate in Beats Per Minute (BPM). Quick Start Guide Emer…
Text truncated - open the document above for the full version.
Protect Connect Limited dba TruAlert Systems Unit 1202, 12F, 299QRC 287-299 Queen's Road Central Sheung Wan, Hong Kong, China Date: 2026-05-13 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA FCC ID: 2BVWK-TASW200I Applicant FRN: 0038358545 US Agent – Attestation Statement / Part 2.911(d)(7) Protect Connect Limited dba TruAlert Systems certifies that, as of 2026-05-13, we have designated ResQHub LLC to accept service of process on our behalf for FCC ID: 2BVWK- TASW200I. Protect Connect Limited dba TruAlert Systems, accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. ResQHub LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of Protect Connect Limited dba TruAlert Systems for FCC ID: 2BVWK-TASW200I. Designated Agent Information: Company Name: ResQHub LLC U.S. Agent FRN: The agent for service of process does no other business with the FCC and does not have an FRN. Address: 1309 Coffeen Ave Ste 1200 Sheridan, WY 82801, USA Contact Person: Carolina Posada Phone: +1(716)606-0048 Email: [email protected] Sincerely, Company: Protect Connect Limited dba TruAlert Systems Designated Agent: ResQHub LLC Company Representative: Anthony Chetta Designated Agent Representative: Carolina Posada Signature: Signature: Protect Connect Limited dba TruAlert Systems Unit 1202, 12F, 299QRC 287-299 Queen's Road Central Sheung Wan, Hong Kong, China
Protect Connect Limited dba TruAlert Systems Unit 1202, 12F, 299QRC 287-299 Queen's Road Central Sheung Wan, Hong Kong, China D ate: 2026-05-09 F ederal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 R ef: Attestation Statements Part 2.911(d) (5) (i) Filing FCC ID: 2BVWK-TASW200I T o Whom It May Concern: Protect Connect Limited dba TruAlert Systems certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Protect Connect Limited dba TruAlert Systems certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. S incerely, S ignatory [Anthony Chetta, Managing Partner]
Protect Connect Limited dba TruAlert Systems Unit 1202, 12F, 299QRC 287-299 Queen's Road Central Sheung Wan, Hong Kong, China D ate: 2026-05-09 F ederal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA R ef: Attestation Statements Part 2.911(d) (5) (ii) Filing FCC ID: 2BVWK-TASW200I T o Whom It May Concern: Protect Connect Limited dba TruAlert Systems certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, S ignatory [Anthony Chetta, Managing Partner]
Protect Connect Limited dba TruAlert Systems Unit 1202, 12F, 299QRC 287-299 Queen's Road Central Sheung Wan, Hong Kong, China Date: 2026-05-09 F EDERAL COMMUNICATIONS COMMISSION AUTHORIZATION AND EVALUATION DIVISION 7435 OAKLAND MILLS ROAD COLUMBIA, MD 21046 S UBJECT: FCC Application for FCC ID: 2BVWK-TASW200I Confidentiality Request T o whom it may concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. ☒ Block Diagram ☒ Tune-Up Information ☒ Operational Description, SBOM ☐ S ecurity Information ☒ Schematics ☐ Software Defined Radio (SDR) Information ☒ Parts List T he above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); ☐ External Photos ☐ Test Setup Photos ☐ Internal Photos ☐ User Manual ☐F or 45 days, pursuant to Public Notice DA 04-1705. or ☐F or 180 days pursuant to KDB 726920 D01. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. S incerely, S ignatory [Anthony Chetta, Managing Partner]
Protect Connect Limited dba TruAlert Systems Unit 1202, 12F, 299QRC 287-299 Queen's Road Central Sheung Wan, Hong Kong, China Agent Authorization C ompany: Protect Connect Limited dba TruAlert Systems A ddress: Unit 1202, 12F, 299QRC 287-299 Queen's Road Central Sheung Wan, Hong Kong, China P roduct Name: Emergency Alert Smartwatch Model Number(s): TA-SW-200i P roduct Description: Emergency Alert Smartwatch W e authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. W e declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2026-05-09 Name: Anthony Chetta Title: Managing Partner Company: Protect Connect Limited dba TruAlert Systems
Reference No.: WTX26X03067173W001/002 Page 2 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Reference No.: WTX26X03067173W001/002 Page 3 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTX26X03067173W001/002 Page 4 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6 Reference No.: WTX26X03067173W001/002 Page 5 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 7 EUT View 8 Reference No.: WTX26X03067173W001/002 Page 6 of 11 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 9
ReferenceNo.:WTX26X03067173W001/002Page1of11 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT1-PRODUCTLABELING ProposedFCCIDLabelFormat FCCID:2BVWK-TASW200I Specifications:Thelabelshallbesecurelyaffixedtoapermanentlyattachedpartofthedevice,inalocation whereitisvisibleoreasilyaccessibletotheuser,andshallnotbereadilydetachable.Thelabelshallbe sufficientlydurabletoremainfullylegibleandintactonthedeviceinallnormalconditionsofusethroughout thedevice’sexpectedlifetime. ProposedLabelLocationonEUT FCCIDLabel Location
ReferenceNo.:WTX26X03067173W001/002Page6of11 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn EXHIBIT3-EUTINTERNALPHOTOGRAPHS EUTHousingand BoardView1 Solder Board-Component View1 ReferenceNo.:WTX26X03067173W001/002Page7of11 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn Solder Board-Component View2 Solder Board-Component View3 ReferenceNo.:WTX26X03067173W001/002Page8of11 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn AntennaView GSM/WCDMA/LTEAnt.
Page: 1/10 Ref : ACR.193.11.24.BES.A WALTEK TESTING GROUP (SHENZHEN) CO., LTD 1/F., ROOM 101, BUILDING 1, HONGWEI INDUSTRIAL PARK, LIUXIAN 2ND ROAD, BLOCK 70 BAO'AN DISTRICT, SHENZHEN, GUANGDONG, 518101 CHINA MVG COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: 3823-EPGO-435 Calibrated at MVG Z.I. de la pointe du diable Technopôle Brest Iroise – 295 avenue Alexis de Rochon 29280 PLOUZANE - FRANCE Calibration date: 01/09 /2026 Accreditations #2-6789 Scope available on www.cofrac.fr The use of the Cofrac brand and the accreditation references is prohibited from any reproduction. Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed at MVG, using the CALIPROBE test bench, for use with a MVG COMO SAR system only. The test results covered by accreditation are traceable to the International System of Units (SI). COMOSAR E-Field Probe Calibration Report 9 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref : ACR.193.11.24.BES.A Page: 2/10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Name Function Date Signature Prepared by : Pedro Ruiz 1/09/2026 Checked & approved by: Technical Manager 1/09/2026 Authorized by: Geraldine Toutain Customer Name Distribution : WALTEK TESTING GROUP (SHENZHEN) CO., LTD Issue Name Date Modifications A 1/09/2026 Initial release Technical Manager Quality Manager Pedro Ruiz 1096 Pedro Ruiz COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref : ACR.193.11.24.BES.A Page: 3/10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Sensitivity _______________________________________________________________ 4 3.2 Linearity ________________________________________________________________ 5 3.3 Isotropy _________________________________________________________________ 5 3.4 Boundary Effect __________________________________________________________ 5 3.5 Probe Modulation Response _________________________________________________ 6 4 Measurement Uncertainty .......................................................................................... 6 5 Calibration Results ..................................................................................................... 6 5.1 Calibration in air __________________________________________________________ 6 5.2 Calibration in liquid _______________________________________________________ 7 6 Verification Results ................................................................................................... 8 7 List of Equipment ...................................................................................................... 9 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref : ACR.193.11.24.BES.A Page: 4/ 10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer MVG Model SSE2 Serial Number 3823-EPGO-435 Product Condition (new / used) New Frequency Range of Probe 0.15 GHz-7.5GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.189 M: Dipole 2: R2= 0.212 M: Dipole 3: R3=0.216 M: 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION MVG’s COMOSAR E field Probes are built in accordance to the IEC/IEEE 62209-1528 and FCC KDB865664 D01 standards. Figu re 1 – MVG COMOSAR Dosimetric E field Probe Probe Length 330 mm Length of Individual Dipoles 2 mm Maximum external diameter 8 mm Probe Tip External Diameter 2.5 mm Distance between dipoles / probe extremity 1 mm 3 MEASUREMENT METHOD The IEC/IEEE 62209-1528 and FCC KDB865664 D01 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their effect. All calibrations / measurements performed meet the fore-mentioned standards. 3.1 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards for frequency range 600- 7500MHz and using the calorimeter cell method (transfer method) as outlined in the standards for frequency 150-450 MHz. COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref : ACR.193.11.24.BES.A Page: 5/ 10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 3.2 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. 3.3 ISOTROPY The ax…
Text truncated - open the document above for the full version.
ReferenceNo.:WTX26X03067173W004 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 126 of 128 AntennaView GSM/WCDMA/LTEAnt. ReferenceNo.:WTX26X03067173W004 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 127 of 128 AnnexD.TestSetupPhotos NeartoMouthExposureConditions Testdistance:10mm BodyFront Wrist-wornmodeExposureConditions Testdistance:0mm BodyBack ReferenceNo.:WTX26X03067173W004 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 128 of 128 AnnexE.CalibrationCertificate Pleaserefertotheexhibitforthecalibrationcertificate *****ENDOFREPORT*****
WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 1 of 128 TESTREPORT ReferenceNo.......................: WTX26X03067173W004 FCCID....................................: 2BVWK-TASW200I Applicant...............................: ProtectConnectLimiteddbaTruAlertSystems Address.................................: Unit1202,12/F,299QRC287–299Queen'sRoadCentralSheungWan, HongKong Manufacturer ........................ ProtectConnectLimiteddbaTruAlertSystems Address................................. Unit1202,12/F,299QRC287–299Queen'sRoadCentralSheungWan, HongKong ProductName......................: EmergencyAlertSmartwatch ModelNo...............................: TA-SW-200i Standards .............................. : FCCPart2.1093 IEEEStdC95.1:2019 IEEEC95.3:2021 DateofReceiptsample.....: 2026-03-18 DateofTest ........................... : 2026-03-18to2026-03-31;2026-04-02to2026-04-20 DateofIssue........................: 2026-04-20 TestReportFormNo. ......... :WTX_IEEE_1528W TestResult ............................ :Pass Remarks: Theresultsshowninthistestreportreferonlytothesample(s)tested,thistestreportcannotbereproduced, exceptinfull,withoutpriorwrittenpermissionofthecompany.Thereportwouldbeinvalidwithoutspecific stampoftestinstituteandthesignaturesofapprover. PreparedBy: WaltekTestingGroup(Shenzhen)Co.,Ltd. Address:1/F.,Room101,Building1,HongweiIndustrialPark,Liuxian2ndRoad, Block70Bao'anDistrict,Shenzhen,Guangdong,China Tel.:+86-755-33663308Fax.:+86-755-33663309Email:[email protected] Testedby:Approvedby: LilyYang/ProjectEngineerJasonSu/Manager ReferenceNo.:WTX26X03067173W004 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 2 of 128 TABLEOFCONTENTS 1.GeneralInformation....................................................................................................................................................4 1.1ProductDescriptionforEquipmentUnderTest(EUT).........................................................................................4 1.2TestStandards.....................................................................................................................................................7 1.3TestMethodology.................................................................................................................................................7 1.4TestFacility..........................................................................................................................................................7 2.SummaryofTestResults...........................................................................................................................................8 3.SpecificAbsorptionRate(SAR)................................................................................................................................9 3.1Introduction..........................................................................................................................................................9 3.2SARDefinition......................................................................................................................................................9 4.SARMeasurementSystem......................................................................................................................................10 4.1TheMeasurementSystem.................................................................................................................................10 4.2Probe..................................................................................................................................................................10 4.3ProbeCalibrationProcess.................................................................................................................................12 4.4Phantom.............................................................................................................................................................13 4.5DeviceHolder.....................................................................................................................................................13 4.6TestEquipmentList...........................................................................................................................................14 5.TissueSimulatingLiquids.......................................................................................................................................15 5.1CompositionofTissueSimulatingLiquid...........................................................................................................15 5.2TissueDielectricParametersforHeadandBodyPhantoms.............................................................................16 5.3TissueCalibrationResult...................................................................................................................................17 6.SARMeasurementEvaluation.................................................................................................................................19 6.1PurposeofSystemPerformanceCheck............................................................................................................19 6.2SystemSetup.....................................................................................................................................................19 6.3ValidationResults..............................................................................................................................................20 7.EUTTestingPosition................................................................................................................................................21 7.1Wrist-worndevice...............................................................................................................................................21 7.2EUTAntennaPosition...................................................................................................…
Text truncated - open the document above for the full version.
ReferenceNo.:WTX26X03067173W002Page63of72 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn Band7-20MHz-QPSK-21350-1RB#0-30~1000-PA SS Band7-20MHz-QPSK-21350-1RB#0-1000~3000-P ASS Band7-20MHz-QPSK-21350-1RB#0-3000~18000 -PASS Band7-20MHz-QPSK-21350-1RB#0-18000~27000 -PASS ReferenceNo.:WTX26X03067173W002Page64of72 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn Band7-20MHz-16QAM-21350-1RB#0-0.009~0.15 -PASS Band7-20MHz-16QAM-21350-1RB#0-0.15~30-PA SS Band7-20MHz-16QAM-21350-1RB#0-30~1000-P ASS Band7-20MHz-16QAM-21350-1RB#0-1000~3000- PASS Band7-20MHz-16QAM-21350-1RB#0-3000~1800 0-PASS Band7-20MHz-16QAM-21350-1RB#0-18000~2700 0-PASS ReferenceNo.:WTX26X03067173W002Page65of72 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn AppendixF:FrequencyStability TestResult Voltage Band Bandwidt h Modulatio n Channe l RB Configure Voltag e [Vdc] Tempe rature (°C) Deviation (Hz) Deviation (ppm) Limit (ppm) Verdict Band75MHzQPSK2077525RB#0VNNT7.210.002881±2.5PASS Band75MHzQPSK2077525RB#0VLNT-6.09-0.002434±2.5PASS Band75MHzQPSK2077525RB#0VHNT-15.11-0.006038±2.5PASS Band75MHz16QAM2077525RB#0VNNT-10.71-0.004280±2.5PASS Band75MHz16QAM2077525RB#0VLNT11.740.004691±2.5PASS Band75MHz16QAM2077525RB#0VHNT-15.06-0.006018±2.5PASS Band75MHzQPSK2110025RB#0VNNT11.760.004639±2.5PASS Band75MHzQPSK2110025RB#0VLNT-9.03-0.003562±2.5PASS Band75MHzQPSK2110025RB#0VHNT-15.71-0.006197±2.5PASS Band75MHz16QAM2110025RB#0VNNT-15.69-0.006189±2.5PASS Band75MHz16QAM2110025RB#0VLNT5.360.002114±2.5PASS Band75MHz16QAM2110025RB#0VHNT-17.11-0.006750±2.5PASS Band75MHzQPSK2142525RB#0VNNT-14.49-0.005644±2.5PASS Band75MHzQPSK2142525RB#0VLNT-11.86-0.004619±2.5PASS Band75MHzQPSK2142525RB#0VHNT-18.74-0.007299±2.5PASS Band75MHz16QAM2142525RB#0VNNT-19.43-0.007568±2.5PASS Band75MHz16QAM2142525RB#0VLNT8.280.003225±2.5PASS Band75MHz16QAM2142525RB#0VHNT10.590.004125±2.5PASS Band710MHzQPSK2080050RB#0VNNT-12.93-0.005162±2.5PASS Band710MHzQPSK2080050RB#0VLNT-9.44-0.003768±2.5PASS Band710MHzQPSK2080050RB#0VHNT6.010.002399±2.5PASS Band710MHz16QAM2080050RB#0VNNT-11.57-0.004619±2.5PASS Band710MHz16QAM2080050RB#0VLNT3.890.001553±2.5PASS Band710MHz16QAM2080050RB#0VHNT-11.07-0.004419±2.5PASS Band710MHzQPSK2110050RB#0VNNT6.290.002481±2.5PASS Band710MHzQPSK2110050RB#0VLNT9.130.003602±2.5PASS Band710MHzQPSK2110050RB#0VHNT-16.22-0.006398±2.5PASS Band710MHz16QAM2110050RB#0VNNT-14.78-0.005830±2.5PASS Band710MHz16QAM2110050RB#0VLNT-12.92-0.005097±2.5PASS Band710MHz16QAM2110050RB#0VHNT-5.04-0.001988±2.5PASS Band710MHzQPSK2140050RB#0VNNT-10.53-0.004105±2.5PASS Band710MHzQPSK2140050RB#0VLNT-10.74-0.004187±2.5PASS Band710MHzQPSK2140050RB#0VHNT2.250.000877±2.5PASS Band710MHz16QAM2140050RB#0VNNT3.300.001287±2.5PASS ReferenceNo.:WTX26X03067173W002Page66of72 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn Band710MHz16QAM2140050RB#0VLNT-15.76-0.006144±2.5PASS Band710MHz16QAM2140050RB#0VHNT-8.61-0.00…
Text truncated - open the document above for the full version.
1309 Coffeen Ave Ste 1200 · Sheridan, Wyoming, 82801 · United States
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 1 | 22H | 824.2 MHz - 848.8 MHz | 580.80 mW | 244KGXW | 0.0204ppm |
| 2 | 22H | 824.2 MHz - 848.8 MHz | 603.90 mW | 247KG7W | 0.044ppm |
| 3 | 24E | 1.85 GHz - 1.91 GHz | 609.50 mW | 246KGXW | 0.0173ppm |
| 4 | 24E | 1.85 GHz - 1.91 GHz | 601.20 mW | 261KG7W | 0.0129ppm |
| 5 | 22H | 826.4 MHz - 846.6 MHz | 148.30 mW | 4M19F9W | 0.0046ppm |
| 6 | 27 | 1.71 GHz - 1.75 GHz | 136.10 mW | 4M19F9W | 0.005ppm |
| 7 | 24E | 1.85 GHz - 1.91 GHz | 115.60 mW | 4M19F9W | 0.0051ppm |
| 8 | 24E | 1.86 GHz - 1.90 GHz | 122.70 mW | 13M5G7D | 0.0078ppm |
| 9 | 24E | 1.86 GHz - 1.90 GHz | 119.10 mW | 18M0G7D | 0.0097ppm |
| 1 | 24E | 1.86 GHz - 1.90 GHz | 119.10 mW | 18M1W7D | 0.0083ppm |
| 11 | 24E | 1.85 GHz - 1.91 GHz | 122.20 mW | 2M69W7D | 0.0095ppm |
| 12 | 27 | 1.72 GHz - 1.75 GHz | 122.70 mW | 13M5G7D | 0.0123ppm |
| 13 | 27 | 1.72 GHz - 1.75 GHz | 114.00 mW | 18M0G7D | 0.0135ppm |
| 14 | 27 | 1.72 GHz - 1.75 GHz | 110.40 mW | 18M0W7D | 0.0116ppm |
| 15 | 27 | 1.71 GHz - 1.75 GHz | 121.30 mW | 4M50W7D | 0.0137ppm |
| 16 | 22H | 826.5 MHz - 846.5 MHz | 122.70 mW | 4M50G7D | 0.0149ppm |
| 17 | 22H | 829 MHz - 844 MHz | 118.00 mW | 9M02G7D | 0.0143ppm |
| 18 | 22H | 829 MHz - 844 MHz | 120.80 mW | 8M99W7D | 0.0168ppm |
| 19 | 22H | 825.5 MHz - 847.5 MHz | 121.90 mW | 2M68W7D | 0.0125ppm |
| 2 | 27 | 2.50 GHz - 2.57 GHz | 125.30 mW | 4M51G7D | 0.009ppm |
| 21 | 27 | 2.51 GHz - 2.56 GHz | 118.00 mW | 18M0G7D | 0.0085ppm |
| 22 | 27 | 2.51 GHz - 2.56 GHz | 121.10 mW | 18M0W7D | 0.0085ppm |
| 23 | 27 | 699.7 MHz - 715.3 MHz | 122.70 mW | 1M09G7D | 0.0151ppm |
| 24 | 27 | 704 MHz - 711 MHz | 115.30 mW | 9M02G7D | 0.0201ppm |
| 25 | 27 | 704 MHz - 711 MHz | 122.70 mW | 9M02W7D | 0.0149ppm |
| 26 | 27 | 779.5 MHz - 784.5 MHz | 122.20 mW | 4M51G7D | 0.0138ppm |
| 27 | 27 | 782 MHz - 782 MHz | 119.90 mW | 8M99G7D | 0.0121ppm |
| 28 | 27 | 782 MHz - 782 MHz | 114.60 mW | 8M99W7D | 0.0102ppm |
| 29 | 27 | 706.5 MHz - 713.5 MHz | 120.80 mW | 4M53G7D | 0.016ppm |
| 3 | 27 | 709 MHz - 711 MHz | 119.10 mW | 9M02G7D | 0.0155ppm |
| 31 | 27 | 709 MHz - 711 MHz | 119.40 mW | 9M02W7D | 0.017ppm |
