2BVX9RO26DMDongle

1. Pulsanti dei tasti 2. Ricevitore wireless USB Vano (riposto nel manico) 3. Pulsante Visualizza, Cattura, Home, Menu pulsante di sincronizzazione della chitarra 4. Barra di strimpellamento 5. LED di stato della chitarra 6. Pulsante CTRL 7. Vano batterie 8. LED di alimentazione 9. Leva del vibrato 10. Levetta sinistra (pulsante L3) 11. Croce direzionale 12. Pulsante di sgancio del manico 13. Pulsante della tracolla 14. Pulsante di selezione della piattaforma 15. Porta USB-C 16. Ricevitore wireless USB 17. LED di sincronizzazione del ricevitore 18.Pulsante di sincronizzazione de ricevitore 19. Tracolla per chitarra 20. Cavo USB CONTENUTO, ASPETTO E CARATTERISTICHE - VEDERE FIGURA 1 SELETTORE DI PIATTAFORMA LED DI STATO DELLA CHITARRA Connessione USB cablata e wireless Connessione Bluetooth® all'app Batteria scarica Con la chitarra accesa, premere il selettore di piattaforma per passare da una piattaforma all'altra. 1) Rimuovere e gettare il cuneo alla base della leva del vibrato. Individuare il vano del ricevitore wireless USB all'interno del manico. Utilizzare l'apertura sul manico per liberare il ricevitore wireless USB dal vano. 2) Per accedere al vano batteria, far scorrere lo sportello del vano verso il basso, nella direzione indicata dalla freccia, finché non si sgancia. Fissare il manico spingendolo saldamente nel corpo della chitarra finché non si sente un clic. Per staccare il manico, premere il pulsante di sgancio sul retro del manico e allontanarlo dal corpo della chitarra. PER INIZIARE - VEDERE FIGURA 2 CONFIGURAZIONE DELLA CONNESSIONE CONNESSIONE USB CABLATA - VEDERE FIGURA 3 1) Collegare l'estremità USB-A del cavo al PC. 2) Collegare l'estremità USB-C del cavo alla porta USB-C del controller della chitarra. 3) Premere il pulsante Home per accendere il controller della chitarra; i LED di stato della chitarra rimarranno fissi in bianco. 4) Premere il pulsante di selezione della piattaforma per scegliere una piattaforma. CONNESSIONE WIRELESS USB - VEDERE FIGURA 4 Il ricevitore wireless USB viene fornito già associato alla chitarra. Se la connessione non riesce, seguire queste istruzioni. 1) Inserire il ricevitore wireless USB nel PC e tenere premuto il pulsante di sincronizzazione del ricevitore per 3 secondi finché il LED di stato del ricevitore non inizia a lampeggiare rapidamente. 2) Accendere il controller della chitarra premendo il pulsante Home e tenere premuto il pulsante di sincronizzazione della chitarra per 3 secondi finché i LED di stato della chitarra non lampeggiano rapidamente. 3) Quando i LED di stato della chitarra rimangono fissi, la connessione è stata stabilita correttamente. 4) Premere il pulsante di selezione della piattaforma per scegliere una piattaforma. MODALITÀ RISPARMIO ENERGETICO - VEDERE FIGURA 5 Se il controller è acceso ma non viene utilizzato per più di 5 minuti, entrerà automaticamente in “modalità sospensione” per prolungare la durata della batteria. Per riaccenderlo, premere il pulsante Home. SPEGNIMENTO DEL CONTROLLER - VEDERE FIGURA 5 Tenere premuto il pulsante Home per 6 secondi per spegnere il controller. SUGGERIMENTO: Il ricevitore wireless si trova all'interno del manico della chitarra. PC2 LM PC1 CARATTERISTICHE TECNICHE Il design e le specifiche sono soggetti a modifiche senza preavviso. Cavo di carica USB: Cavo USB da 2,5 m: Da USB C a USB A, connessione wireless: Bluetooth® 5.0, Batteria ricaricabile al litio: 3,7 V, 1100 mAh; tempo di ricarica: 2 ore; alimentazione in ingresso: DC 5 V, 1 A, Temperatura di esercizio: 0 ºC--- 40 ºC, Radiofrequenza: ISM 2.4G, Banda di frequenza: 2402---2480 MHz, Radiofrequenza massima: 4 dbm, Massa: Circa 965 g SERVIZIO CLIENTI Per domande sull'installazione o sull'uso, visitare l'assistenza sul web all'indirizzo stagetour.com/support. L'app Stage Tour include video di assistenza informativi. Se si necessita ancora di aiuto, contattare il nostro team di assistenza:: [email protected] GARANZIA LIMITATA Redoctane garantisce al consumatore acquirente diretto che il prodotto sarà privo di difetti di materiali e/o di fabbricazione per il periodo di tempo specificato nel periodo di garanzia a partire dalla data di acquisto, vale a dire 2 anni, come indicato nella pagina www.stagetour.com/warranty. SICUREZZA GENERALE AVVISO: L'uso improprio delle batterie può causare perdite, surriscaldamento o esplosione delle batterie. Quando si utilizzano le batterie, assicurarsi di seguire queste istruzioni. • Non maneggiare batterie agli ioni di litio danneggiate o che perdono. • Se si entra in contatto con il materiale di una batteria che perde, eseguire le seguenti operazioni: Se il materiale viene a contatto con gli occhi, non strofinare, ma sciacquare immediatamente gli occhi con acqua pulita e consultare un medico. • Se il materiale viene a contatto con la pelle o gli indumenti, sciacquare immediatamente l'area interessata con acqua pulita. Consultare il proprio medico se si sviluppano infiammazioni o dolore. Tenere le batterie fuori dalla portata dei bambini. • Non smaltire questo la batteria nel fuoco o nei rifiuti generici. Seguire le normative locali per il riciclaggio o lo smaltimento. • Controllare periodicamente la batteria per verificare che non presenti segni di danneggiamento, rigonfiamento o perdite. Sostituire immediatamente in presenza di una qualsiasi di queste condizioni. SICUREZZA DELLA BATTERIA Redoctane Games LLC dichiara che il presente prodotto soddisfa i requisiti minimi e le altre disposizioni della Diretva 2014/30/UE sulla compatibilità elettromagnetica delle apparecchiature e la Diretva RED 2014/53/UE sulle apparecchiature radio. Il testo completo della Dichiarazione di conformità UE è disponibile al seguente indirizzo Internet: www.stagetour.com/docs DICHIARAZIONI DI CONFORMITÀ Il simbolo del cestino con ruote barrato presente su questo prodotto indica il divieto di smaltirlo con i normali rifiuti domestici e la necessità di conferirlo a un apposito centro di raccolta. © 2026 Redoctane …

Text truncated - open the document above for the full version.

Date: 2026-07-24 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2BVX9RO26DM) [RedOctane Games] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does no t utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, Signature: Name: Stephen Withers Date: 2026-07-24 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2BVX9RO26DM) [RedOctane Games] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature: Name: Stephen Withers

U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) ATTENTION: FCC Certification – Section 2.911 (d)(7) Information Designated U.S. Agent Company Name: RedOctane Games FRN: 0038358412 Contact Name: Stephen Withers Address: 3142 Constitution Dr, Livermore, CA 94551, USA Telephone No: '+1 9 25 2 45 2 009 Email: [email protected] This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted belo w. The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and i mportation OR t he c onclusion of any C ommission-related proceeding involving the equipmen t. The applicant fu rther acknowledges their responsibility to inform the F CC w henever the Designated U.S. Agent information above changes. Applicant Company name: RedOctane Games FRN: 0038358412 Grantee Code: 2BVX9 FCC ID: 2BVX9RO26DM Contact Name: Stephen Withers Address: 3142 Constitution Dr, Livermore, CA 9 4551, USA Telephone No: +1 925 245 2009 Email: [email protected] Signature: Date: 2026 -07- 24 Signed by (Printed Name/Title): Stephen Withers

Date: 2026-07-24 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Dongle / RO26DM / FCC ID: 2BVX9RO26DM) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Block Diagrams, Schematics, Operational Descriptions) required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, Signature: Name: Stephen Withers Applicant: RedOctane Games Address: 3142 Constitution Dr, Livermore, CA 94551, USA TEL: +1 925 245 2009

Date: 2026-07-24 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Eurofins Electrical Testing Service (Shenzhen) Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name: Stephen Withers Applicant: RedOctane Games Address: 3142 Constitution Dr, Livermore, CA 94551, USA TEL: +1 925 245 2009

EFGX26070286-IE-12-External Photos 1 / 4 External Photos FCC ID: 2BVX9RO26DM IC: 35476-RO26DM EFGX26070286-IE-12-External Photos 2 / 4 EFGX26070286-IE-12-External Photos 3 / 4 EFGX26070286-IE-12-External Photos 4 / 4

EFGX26070286-IE-12-Internal Photos 1 / 3 Internal Photos FCC ID: 2BVX9RO26DM IC: 35476-RO26DM EFGX26070286-IE-12-Internal Photos 2 / 3 EFGX26070286-IE-12-Internal Photos 3 / 3

Radio frequency radiation exposure evaluation: portable devices RESULT : Pass Test Specification Test item : Dongle Identification / Type No. : RO26DM FCC ID : 2BVX9RO26DM IC : 35476-RO26DM Test standard : CFR47 FCC Part 2: Section 2.1093 FCC KDB Publication 447498 D04 RSS-102 Issue 6 and f is in GHz, d is the separation distance (cm), and ERP20cm is per Formula (B.1). The example values shown in Table B.2 are for illustration only. Measurement Record: E.I.R.P = 92.80 – 95.2 = -2.40dBm ERP= -2.40 – 2.15 = -4.55dBm FCC Measurement Record: Test Mode Conducted Power (dBm) Conducted Power (mW) ERP (dBm) ERP (mW) Minimum Separation Distances (mm) Limit (mW) 2.4GHz SRD ---- ---- -4.55 0.35 5 2.72 ISED Measurement Record: Test Mode E.I.R.P (dBm) E.I.R.P (mW) Minimum Separation Distances (mm) Limit (mW) 2.4GHz SRD -2.40 0.575 5 3 For ISED, output power level shall be the higher of the maximum conducted or effective isotropic radiated power (e.i.r.p.) source-based, time-averaged output power. Hence the EUT is excluded from SAR evaluation if the distance between the antenna and the human body is equal or above one of the minimum distances depicted in the tables above, depending on the wireless protocol in use, in accordance with FCC KDB Publication 447498 D04 and RSS-102 Issue 6.

Test Report No.: EFGX26070286-IE-12-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Room 20 of 2/F., 1/F., Building 2, Spring Block & Room 102, Building 8, Autumn Block, Meishenghuigu Innovation Park, No.83, Dabao Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 1 of 43 EUROFINS ELECTRICAL TESTING SERVICE (SHENZHEN) CO., LTD. RADIO TEST - REPORT FCC Compliance Test Report for Product name: Dongle Model name: RO26DM FCC ID: 2BVX9RO26DM Test Report Number: EFGX26070286-IE-12-E01 Test Report No.: EFGX26070286-IE-12-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Room 20 of 2/F., 1/F., Building 2, Spring Block & Room 102, Building 8, Autumn Block, Meishenghuigu Innovation Park, No.83, Dabao Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 2 of 43 1 General Information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of applicant 4 1.4 Details of manufacturer 4 1.5 Application details 5 1.6 Test item 5 1.7 Test standards 5 2 Technical test 6 2.1 Summary of test results 6 2.2 Test environment 6 2.3 Measurement uncertainty 6 2.4 Test mode 7 2.5 Test equipment utilized 8 2.6 Auxiliary Equipment Used during Test: 8 2.7 Test software information: 8 2.8 Test setup 9 2.9 Test results 11 3 Technical requirement and result 12 3.1 AC power-line conducted emissions 12 3.2 Occupied bandwidth and 20 dB bandwidth 13 3.3 Radiated emissions 14 Appendix A: AC power-line conducted emissions 16 Appendix B: Occupied Channel Bandwidth 18 Appendix C: Radiated emission 21 Test Report No.: EFGX26070286-IE-12-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Room 20 of 2/F., 1/F., Building 2, Spring Block & Room 102, Building 8, Autumn Block, Meishenghuigu Innovation Park, No.83, Dabao Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 3 of 43 1 General Information 1.1 Notes The results of this test report relate exclusively to the item tested as specified in chapter “Description of test item” and are not transferable to any other test items. Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. is not responsible for any generalisations and conclusions drawn from this report. Any modification of the test item can lead to invalidity of test results and this test report may therefore be not applicable to the modified test item. The test report may only be reproduced or published in full. Reproducing or publishing extracts of the report requires the prior written approval of the Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. This document is subject to the General Terms and Conditions and the Testing and Certification System of Eurofins Electrical Testing Service (Shenzhen) Co., Ltd., available on request or accessible at www.eurofins.com. Operator: 2026-07-29 Bruce Zheng / Project Engineer Date Eurofins-Lab. Name / Title Signature Technical responsibility for area of testing: 2026-07-29 Albert Xu / Lab Manager Date Eurofins-Lab. Name / Title Signature Test Report No.: EFGX26070286-IE-12-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Room 20 of 2/F., 1/F., Building 2, Spring Block & Room 102, Building 8, Autumn Block, Meishenghuigu Innovation Park, No.83, Dabao Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 4 of 43 1.2 Testing laboratory Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Room 20 of 2/F., 1/F., Building 2, Spring Block & Room 102, Building 8, Autumn Block, Meishenghuigu Innovation Park, No.83, Dabao Road, Bao’an District, Shenzhen, Guangdong, China Telephone : +86-755-82911867 Fax : +86-755-82910749 The Laboratory has passed the Accreditation by the American Association for Laboratory Accrediation (A2LA). The Accreditation number is 5376.01 The Laboratory has been listed by industry Canada to perform electromagnetic emission measurements, The CAB identifier is CN0088 1.3 Details of applicant Name : RedOctane Games Address : 3142 Constitution Dr, Livermore, CA 94551, USA Telephone : ./. Fax : ./. 1.4 Details of manufacturer Name : RedOctane Games Address : 3142 Constitution Dr, Livermore, CA 94551, USA Telephone : ./. Fax : ./. Test Report No.: EFGX26070286-IE-12-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Room 20 of 2/F., 1/F., Building 2, Spring Block & Room 102, Building 8, Autumn Block, Meishenghuigu Innovation Park, No.83, Dabao Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 5 of 43 1.5 Application details Date of receipt of application : 2026-07-10 Date of receipt of test item : 2026-07-10 Date of test : 2026-07-10 to 2026-07-29 Date of issue : 2026-07-29 1.6 Test item Product type : Dongle Model name : RO26DM Brand : ./. Sample ID : 260710-37-004 Serial number : ./. Ratings : Input: 5V50mA Test voltage : 5Vdc RadioTechnical data Frequency range : 2402MHz – 2480MHz Radio Tech. : 2.4G SRD Frequency channel : 40 Modulation : GFSK Antenna type : Intenral antenna Additional information : ./. 1.7 Test standards Test Standards FCC Part 15 Subpart C PART 15 - RADIO FREQUENCY DEVICES Subpart C - Intentional Radiators Test Method 1: ANSI C63.4-2014, American National Standard for Methods of Measurement of Radio-Noise Emis- sions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. 2: ANSI C63.10-2020+COR. 1-2023+C63.10A-2024+ERRATA TO C63.10A-2024, American National Standard for Testing Unlicensed Wireless Devices. Test Report No.: EFGX26070286-IE-12-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Room 20 of 2/F., 1/F., Building 2, Spring Block & Room 102, Building 8, Autumn Block, Meishenghuigu Innovation Park, No.83, Dabao Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 6 of 43 2 Technical test 2.1 Summary of test results No dev…

Text truncated - open the document above for the full version.

Report No.: BL-EC2281147-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 1 / 18 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China TEST REPORT Applicant: SHENZHEN HJZ TECHNOLOGY C0., LTD. Address: Room 1403, Building 3, COFCO Business Park, Liuxian 2nd Road, Bao'an District, ShenZhen, China. Equipment Type: 2.4G RF ANT Model Name: MINI PCB ANT Brand Name: HJZ Test Standard: ANSI/IEEE Std 149-1979 Test Date Sep. 01, 2022 Date of Issue: Sep. 06, 2022 ISSUED BY: Shenzhen BALUN Technology Co., Ltd. Tested by: Mai Jintian Checked by: Tolan Tu Approved by: Wei Yanquan (Chief Engineer) _______________ _______________ _______________ Report No.: BL-EC2281147-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 2 / 18 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Revision History Version Issue Date Revisions Rev. 01 Sep. 06, 2022 Initial Issue TABLE OF CONTENTS 1 GENERAL INFORMATION ......................................................................................................... 3 1.1 Test Laboratory ..................................................................................................................... 3 1.2 Test Location ......................................................................................................................... 3 2 PRODUCT INFORMATION ......................................................................................................... 4 2.1 Applicant Information ............................................................................................................ 4 2.2 Manufacturer Information ...................................................................................................... 4 2.3 Factory Information ............................................................................................................... 4 2.4 General Description for Equipment under Test (EUT) .......................................................... 4 2.5 Ancillary Equipment .............................................................................................................. 4 2.6 Technical Information ............................................................................................................ 4 3 SUMMARY OF TEST RESULTS ................................................................................................. 5 3.1 Test Standards ...................................................................................................................... 5 3.2 Test Verdict ........................................................................................................................... 5 3.3 Test Uncertainty .................................................................................................................... 5 4 GENERAL TEST CONFIGURATIONS ........................................................................................ 6 4.1 Test Condition ....................................................................................................................... 6 4.2 Test Equipment List .............................................................................................................. 6 4.3 Test Setup ............................................................................................................................. 7 ANNEX A TEST RESULTS ............................................................................................................. 8 A.1 Gain and Efficiency ............................................................................................................... 8 ANNEX B RADIATION PATTERN .................................................................................................. 9 ANNEX C TEST SETUP PHOTO ................................................................................................. 15 ANNEX D EUT PHOTO ................................................................................................................ 17 Report No.: BL-EC2281147-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 3 / 18 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 1 GENERAL INFORMATION 1.1 Test Laboratory Name Shenzhen BALUN Technology Co., Ltd. Address Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Phone Number +86 755 6685 0100 1.2 Test Location Name Shenzhen BALUN Technology Co., Ltd. Location Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 1/F, Building B, Ganghongji High-tech Intelligent Industrial Park, No. 1008, Songbai Road, Yangguang Community, Xili Sub-district, Nanshan District, Shenzhen, Guangdong Province, P. R. China Report No.: BL-EC2281147-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 4 / 18 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 2 PRODUCT INFORMATION 2.1 Applicant Information Applicant SHENZHEN HJZ TECHNOLOGY C0., LTD. Address Room 1403, Building 3, COFCO Business Park, Liuxian 2nd Road, Bao'an District, ShenZhen, China. Contact Person Blake Cao Telephone Number 86307650 Ext 8009 Fax Number (+86) 0755-86307651 E-mail Address [email protected] 2.2 Manufacturer Information Manufacturer N/A Address N/A 2.3 Factory Information Factory N/A Address N/A 2.4 General Description for Equipment under Test (EUT) EUT Name 2.4G RF ANT Model Name Under Test MINI PC…

Text truncated - open the document above for the full version.

EFGX26070286-IE-02-Setup Photos 1 / 2 EFGX26070286-IE-02-Setup Photos 2 / 2
