2BVYE-A2Smart watch

Download APP to add device EN 1. Long press the watch button to turn on and off; turn on the device and use the phone to scan the QR code to download and install the APP; or search for "H Band" in the Apple Store/Android App Market to download and install. (Compatible systems: Android4.4 and above, Bluetooth 4.0 mobile phones; Apple mobile phones ios9.0 and above.) 2. Open the mobile phone APP, search and select the device to be bound in the APP device list. Step 1: Turn on the mobile phone Bluetooth: Step 2, open the mobile phone "H Band" APP, in the "Device" interface, click "Bind Device" "Select Device" (*Please confirm that the Bluetooth MAC address displayed on the watch is consistent when pairing). Instructions operation method slide the dial home page from bottom to top slide the dial home page from bottom to top single click the button move the dial home page to the left long press the dial for 3 seconds, slide left and right to switch the dial long press the button for 5 seconds Quick function Open the control panel Open the information interface Open the main menu Open the list interface Quick access to dial change Power on/off 1. Pedometer: Record the number of steps, distance, calories and other data of the day in detail. 2. Sleep monitoring: can record and display the total sleep time, and can view 7 days of sleep data. (You must wear the bracelet to sleep to detect data). 3. Heart rate detection: measure the current heart rate, record and display the heart rate for 24 hours a day, and automatically monitor the heart rate every 10 minutes. 4. Multi-sports mode: outdoor running, cycling, skipping, badminton, table tennis, tennis, mountaineering, walking, basketball, volleyball, dance, rowing machine, elliptical machine, yoga, aerobics, kayaking, skiing, football, golf, wrestling, fencing and other sports modes. 5. Blood pressure detection: measure current blood pressure, record and display blood pressure 24 hours a day, and automatically monitor blood pressure once an hour. 6. Blood oxygen detection: measure current blood oxygen, record and display blood oxygen 24 hours a day, and automatically monitor blood oxygen once an hour. 7. Music control: control mobile phone music play/pause/previous song/next song. 8. Camera control: open the mobile phone APP, click/shake the watch in the watch camera control interface to take a photo. 9. Weather forecast: After Bluetooth is connected to the watch, the latest real-time weather forecast can be synchronized on the watch. 10. Female physiological cycle: It needs to be set to female in the personal interface of the APP, and the corresponding cycle icon will be displayed on the watch. 11. Bluetooth call: After the APP is successfully connected to Bluetooth pairing, you can make and receive calls through the watch. 12. Music playback: After successfully connecting to the mobile phone APP, you can play the music on the mobile phone through the watch. Function Description CN 1. Нажмите и удерживайте кнопку часов, чтобы включить и выключить устройство, и используйте телефон для сканирования QR-кода, чтобы загрузить и установить приложение, или найдите «H Band» в Apple Store/Android App Store, чтобы загрузить и установить его; установить. (Совместимые системы: Android 4.4 и выше, мобильные телефоны Bluetooth 4.0; мобильные телефоны Apple iOS 9.0 и выше.) 2. Откройте мобильное приложение, найдите и выберите устройство, которое необходимо привязать, в списке устройств приложения. Шаг 1. Включите Bluetooth на вашем телефоне: Шаг 2. Откройте приложение «H Band» на своем телефоне и в интерфейсе «Устройство» нажмите «Привязать устройство» и «Выбрать устройство» (*Пожалуйста, подтвердите, что MAC-адрес Bluetooth, отображаемый на часах, соответствует при сопряжении). RU Загрузить приложение Добавить устройства Функция быстрого доступа Откройте панель управления Откройте информационный интерфейс Откройте главное меню Откройте интерфейс списка Быстро введите смену циферблата Включение/выключение питания инструкции метод работы проведите по главной странице циферблата сверху вниз. проведите по главной странице набора номера снизу вверх. нажмите кнопку одним щелчком мыши. переместите домашнюю страницу набора влево. нажмите и удерживайте циферблат в течение 3 секунд, сдвиньте влево и вправо, чтобы переключить циферблаты. нажмите и удерживайте кнопку в течение 5 секунд. 1. Шагомер: подробно записывайте количество шагов, расстояние, калории и другие данные за день. 2. Мониторинг сна: он может записывать и отображать общую продолжительность сна, а также просматривать данные сна за 7 дней. (Вы должны носить браслет во время сна, чтобы иметь возможность обнаруживать данные). 3. Обнаружение сердечного ритма: измеряйте текущую частоту сердечных сокращений, записывайте и отображайте частоту сердечных сокращений 24 часа в сутки и автоматич ески отслеживайте частоту сердечных сокращений каждые 10 минут. 4. Мультиспортивные режимы: бег на свежем воздухе, езда на велосипеде, скакалка, бадминтон, настольный теннис, теннис, альпинизм, ходьба, баскетбол, волейбол, танцы, гребной тренажер, эллиптический тренажер, йога, аэробика, гребля, катание на лыжах, футбол, Гольф, борьба, фехтование и другие спортивные режимы. 5. Обнаружение артериального давления: измеряйте текущее артериальное давление, записы вайте и отображайте артериальное давление 24 часа в сутки и автоматически контролируйте артериальное давление каждый час. 6. Обнаружение кислорода в крови: измеряйте текущий уровень кислорода в крови, записывайте и отображайте уровень кислорода в крови 24 часа в сутки и автоматически контролируйте уровень кислорода в крови каждый час. 7. Управление музыкой: управление воспроизведением музыки на мобильном телефоне/паузой/ предыдущей/следующей песней. 8. Управлен ие камерой: откройте мобильное приложение, нажмите/встряхните часы на интерфейсе управления камерой часов, чтобы сделать снимок. 9. Прогноз погоды: после подключения Bluetooth к часам на часах можно синхронизировать п…

Text truncated - open the document above for the full version.

Rev 1/26/2023 Shenzhen Shenwu Zhichuang Technology Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-05-08 FCC ID: 2BVYE-A2 Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing Shenzhen Shenwu Zhichuang Technology Co., Ltd. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Shenzhen Shenwu Zhichuang Technology Co., Ltd. certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing Shenzhen Shenwu Zhichuang Technology Co., Ltd. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Applicant: Shenzhen Shenwu Zhichuang Technology Co., Ltd. Address: 102, Building C, No. 2 Ziping Road, Xiuxin Community, Kengzi Street, Pingshan District, Shenzhen, China Contact Person: Zhang Qingyi Tel.: 15711997078 Email: [email protected] Sincerely, Signature:

Attestation Statements Date: 2026-05-08 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for(FCC ID: 2BVYE-A2) Shenzhen Shenwu Zhichuang Technology Co., Ltd., the undersigned, hereby authorize FCC US Agent, LLC to act as our designated agent for service of process, Shenzhen Shenwu Zhichuang Technology Co., Ltd. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission- related proceeding involving the equipment. FCC US Agent, LLC accepts the responsibility to act as designated agent for service of process. Applicant Information： Company name: Shenzhen Shenwu Zhichuang Technology Co., Ltd. Contact Name: Zhang Qingyi Address: 102, Building C, No. 2 Ziping Road, Xiuxin Community, Kengzi Street, Pingshan District, Shenzhen, China Telephone No: 15711997078 Email: [email protected] FRN: 0038385704 Signature: Zhang Qingyi Agent Information: Company Name: FCC US Agent, LLC Address:3722 Illinois Avenue, Saint Charles, IL, 60174, USA FRN: 0033402884 Contact Name: Tim Payne Telephone No: 708-571-3148 Email: [email protected] Signature: Tim Payne

Shenzhen Shenwu Zhichuang Technology Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: May 8, 2026 Subject; Request for Confidentiality FCC ID: 2BVYE-A2 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Zhang Qingyi Title: Project Engineer

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 Shenzhen Shenwu Zhichuang Technology Co., Ltd. Date：2026-05-08 Product Model Number: CD07, CD03, CD05, CD06, CD08, CD09, CD10, CD12, A1, A2, A3, A5, A6, A7, A8, A9, SW1, SW2, SW3, SW8 FCC ID：2BVYE-A2 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. Signature: By: Zhang Qingyi Contact Listed on FCC Wesbite Title: Project Engineer Email: [email protected] On behalf of: Shenzhen Shenwu Zhichuang Technology Co., Ltd.

Shenzhen Shenwu Zhichuang Technology Co., Ltd. Declaration Letter of Model Difference Date: 2026-05-08 FCC ID: 2BVYE-A2 Tested Model Number: CD07 Adding Model Number(s): CD03, CD05, CD06, CD08, CD09, CD10, CD12, A1, A2, A3, A5, A6, A7, A8, A9, SW1, SW2, SW3, SW8 All Adding Model Number(s) is/are same electrically identical as Tested Model Number. The motherboard configuration is the same, Difference in appearance color. Yours Sincerely, Applicant: Shenzhen Shenwu Zhichuang Technology Co., Ltd. Address: 102, Building C, No. 2 Ziping Road, Xiuxin Community, Kengzi Street, Pingshan District, Shenzhen, China Contact Person: Zhang Qingyi Tel.: 15711997078 Email: [email protected] Sincerely, Signature:

Page 1 of 5 Report No.: LGT26D048 Appendix - External Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 5 Report No.: LGT26D048 Appendix - External Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 5 Report No.: LGT26D048 Appendix - External Photographs of EUT Constructional Details Photo 5 Photo 6 Page 4 of 5 Report No.: LGT26D048 Appendix - External Photographs of EUT Constructional Details Photo 7 Photo 8 Page 5 of 5 Report No.: LGT26D048 Appendix - External Photographs of EUT Constructional Details Photo 9 Photo 10

Label Size: 20*5mm FCC ID: 2BVYE-A2

Page 1 of 4 Report No.: LGT26D048 Appendix - Internal Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 4 Report No.: LGT26D048 Appendix - Internal Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 4 Report No.: LGT26D048 Appendix - Internal Photographs of EUT Constructional Details Photo 5 Photo 6 Page 4 of 4 Report No.: LGT26D048 Appendix - Internal Photographs of EUT Constructional Details Photo 7 Photo 8 ANT

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 8 EMF TEST REPORT Product Name: Smart watch Model Number: CD07, CD03, CD05, CD06, CD08, CD09, CD10, CD12, A1, A2, A3, A5, A6, A7, A8, A9, SW1, SW2, SW3, SW8 FCC ID: 2BVYE-A2 Issued For : Shenzhen Shenwu Zhichuang Technology Co., Ltd. 102, Building C, No. 2 Ziping Road, Xiuxin Community, Kengzi Street, Pingshan District, Shenzhen, China Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26D048HA02 Sample Received Date: Apr. 09, 2026 Date of Test: Apr. 09, 2026 ~ Apr. 21, 2026 Date of Issue: Apr. 21, 2026 Report No.: LGT26D048HA02 Page 2 of 8 TEST REPORT CERTIFICATION Applicant: Shenzhen Shenwu Zhichuang Technology Co., Ltd. Address: 102, Building C, No. 2 Ziping Road, Xiuxin Community, Kengzi Street, Pingshan District, Shenzhen, China Manufacturer: Shenzhen Shenwu Zhichuang Technology Co., Ltd. Address: 102, Building C, No. 2 Ziping Road, Xiuxin Community, Kengzi Street, Pingshan District, Shenzhen, China Product Name: Smart watch Trademark: N/A Model Number: CD07, CD03, CD05, CD06, CD08, CD09, CD10, CD12, A1, A2, A3, A5, A6, A7, A8, A9, SW1, SW2, SW3, SW8 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47 CFR §2.1093 KDB 447498 D01 General RF Exposure Guidance v06 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT26D048HA02 Page 3 of 8 TABLE OF CONTENTS 1 . GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST LABORATORY 5 2 . FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 8 Report No.: LGT26D048HA02 Page 4 of 8 Revision History Rev. Issue Date Revisions 00 Apr. 21, 2026 Initial Issue Report No.: LGT26D048HA02 Page 5 of 8 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name: Smart watch Test Model Number: CD07 Series Number: CD03, CD05, CD06, CD08, CD09, CD10, CD12, A1, A2, A3, A5, A6, A7, A8, A9, SW1, SW2, SW3, SW8 Model Difference: The motherboard configuration is the same, Difference in appearance color. Frequency Bands: Bluetooth 2402-2480MHz Rating: Input: DC 5V 120mA Battery: Capacity: 240mAh Rated Voltage: 3.8V Hardware Version: N/A Software Version: N/A 1.2 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 Report No.: LGT26D048HA02 Page 6 of 8 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in KDB 447498 D01 General RF Exposure Guidance v06 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. Report No.: LGT26D048HA02 Page 7 of 8 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] • [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz. Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Report No.: LGT26D048HA02 Page 8 of 8 2.3 TEST RESULT Turn up Result Mode Turn up Power BLE 1M-GFSK -3±1.5dBm The MPE result of worst mode: RF Function Frequency (MHz) Max Turn up Power (dBm) Max Turn up Power (mW) Estimated SAR Limit Ratio Result BLE 2440 -1.50 0.71 0.221 3 0.074 Pass Note: 1. The Maximum Power Density is less than the limit, complies with the exemption requirements. ※※※※※END OF THE REPORT※※※※※

SPECIFICATIONS UNLES S OTHER SPECIFIED TOLERANCES ON： X X. X X. XX A N G L E S H O L E D I A 上海 威尔创未来通讯技术有限公司 SCALE N/AUNITmm T HIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF PBXY TECHNOLOGY Limited AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY : SeraCHECKED BY: XD DESIGNED BY: SeraAPPROVED BY: XD TITLE DOCUMENT NO. SPEC REV. P1 SHANGHAI WILLICHING FUTURE COMMUNICATION TECHNOLOGY CO., LTD Bluetooth Antenna Room J657, Area A, Floor 1, Building 2, No. 955 Liuxiang Highway, Jiading District, Shanghai Antenna Type： PCB Antenna 2/11 3216Chipantenna ForBluetooth/WLANApplications RF3216F245C3 ChipAntenna3216LAnt2.45GType0X P/N:3216F245C3 Dimension (mm) L 3.23±0.20 W 1.66±0.20 T 0.45±0.20 3/11 PartNumberInformation RAIN3216F245C3 ABCDEF A ProductSeriesAntenna B DimensionLxW 3.2X1.6mm(+-0.2mm) C Material HighKmaterial D Working Frequency 2.4~2.5GHz E FeedingmodePIFA&SingleFeeding F AntennatypeType=01 1.ElectricalSpecification Specification PartNumber RAIN3216F245F3 CentralFrequency 2450MHz Bandwidth 120(Min.) MHz ReturnLoss -6.5(Max) dB PeakGain 1.75 dBi Impedance 50 Ohm OperatingTemperature -40~+85 C MaximumPower 4W ResistancetoSoldering Heats 10(@260C) sec. Polarization Linear AzimuthBeamwidth Omni-directional Termination Ni/Au(Leadless) Remark:Bandwidth&PeakGainwasmeasuredunderevaluationboardofnextpage 4/11 2.RecommendedPCB Pattern EvaluationBoard Dimension 2 nd EvaluationBoardDimension SuggestedMatchingCircuit : 1% 5/11 LayoutDimensionsinClearancearea(Size=5.9*5.0mm) 50ohmtransmissionLine MatchingCircuit FootPrint(Unit:mm) 令2 nd LayoutDimensionsinClearancearea(Size=8.0*3.0mm) 6/11 3.MeasurementResults ReturnLoss 7/11 RadiationPattern Efficiency PeakGain Directivity 2450MHz85.65% 1.75dBi2.89dBi ChamberCoordinateSystem 8/11 measuring 4.ReliabilityandTestCondictions ITEMREQUIREMENTSTESTCONDITION Solderability 1.Wettingshallexceed90%coverage 2.Novisiblemechanicaldamage TEMP( C ) Pre-heating temperature:150C/60sec.Solder temperature:230 ± 5 C Duration:4±1sec. Solder:Sn-Ag3.0-Cu0.5 Fluxforleadfree:rosin 230C 150C 4±1 sec. 60sec S 1.Ng 2.CentralFreq.change:within±6% Pre-heating temperature:150C/60sec.Solder temperature:260±5C Duration:10±0.5sec. Solder:Sn-Ag3.0-Cu0.5 Fluxforleadfree:rosin 1.N g T Component Adhesion (Pulltest) 1.Novisiblemechanicaldamage Insert10cmwireintotheremainingopen eyebend,theendsofevenwirelengths upwardandwindtogether. Terminalshallnotberemarkably damaged. Thermalshock 1.Novisiblemechanicaldamage 2.CentralFreq.change:within±6% +85C=>30±3min -40C=>30±3min Testcycle:10cycles Thechipshallbestabilizedatnormal conditionfor2~3hoursbefore measuring. Phase Temperature(C) Time(min) 1 +85±5C 30±3 2 Room Temperature Within 3sec 3 -40±2C 30±3 4 Room Temperature Within 3sec Resistanceto High Temperature 1.Novisiblemechanicaldamage 2.CentralFreq.change:within±6% 3.Nodisconnectionorshortcircuit. Temperature:85±5C Duration:1000±12hrs Thechipshallbestabilizedatnormal conditionfor2~3hoursbefore measuring Resistanceto Low Temperature 1.Novisiblemechanicaldamage 2.CentralFreq.change:within±6% 3.Nodisconnectionorshortcircuit. Temperature:-40±5C Duration:1000±12hrs Thechipshallbestabilizedatnormal conditionfor2~3hoursbefore measuring. Humidity 1.Novisiblemechanicaldamage 2.CentralFreq.change:within±6% 3.Nodisconnectionorshortcircuit. Temperature:40±2C Humidity:90%to95%RH Duration:1000±12hrs Thechipshallbestabilizedatnormal conditionfor2~3hoursbefore . omonent Cp Adhesion (Pushtest) olderheat Resistance ovisiblemechanicaldamae ovisiblemechanicaldamae hedeviceshouldbereflow soldered(230±5Cfor10sec.)toa tinnedcoppersubstrateAdynometer forcegaugeshouldbeappliedthe sideofthecomponent.Thedevicemust with-ST-F0.5Kgwithoutfailureofthe terminationattachedtocomponent 9/11 5.SolderingandMounting Mildlyactivatedrosinfluxesarepreferred.Theminimumamountofsoldercan leadtodamagefromthestressescausedbythedifferenceincoefficientsof expansionbetweensolder,chipandsubstrate.Theterminationsaresuitable forallwaveandre-flowsolderingsystems.Ifhandsolderingcannotbe avoided,thepreferredtechniqueistheutilizationofhotairsolderingtools. ReflowSoldering PRE-HEATINGSOLDERINGNATURAL 10smax. 250~260 230 180 150 60~120s30~60s TIME(sec.) IronSoldering PRE-HEATINGSOLDERINGNATURAL within3s 350 300 150 Over60s Gradualcooling TIME(sec.) Recommendedtemperatureprofilesforre-flowsolderinginFigure1. Productsattachmentwithasolderingironisdiscouragedduetotheinherent processcontrollimitations.Intheeventthatasolderingironmustbe employedthefollowingprecautionsarerecommended. ‧Preheatcircuitandproductsto150C ‧Nevercontacttheceramicwiththeirontip ‧Usea20wattsolderingironwithtipdiameterof1.0mm ‧280Ctiptemperature(max) ‧1.0mmtipdiameter(max) ‧Limitsolderingtimeto3sec. COOLING COOLING 10/11 6.PackagingInformation TapeSpecification: ReelSpecification:(7’’,Φ180mm) Tape Width(mm) A(mm)B(mm)C(mm)D(mm)Chip/Reel(pc s) 8 9.0±0.560±213.5±0. 5 178±2 4000 11/11 7.StorageandTransportationInformation StorageConditions Tomaintainthesolderabilityofterminalelectrodes: 1.Temperatureandhumidityconditions:-10~40Cand30~70%RH. 2.Recommendedproductsshouldbeusedwithin6monthsfromthetimeof delivery. 3.Thepackagingmaterialshouldbekeptwherenochlorineorsulfurexists intheair. TransportationConditions 1.Productsshouldbehandledwithcaretoavoiddamageorcontamination fromperspirationandskinoils. 2.Theuseoftweezersorvacuumpickupisstronglyrecommendedfor individualcomponents. 3.Bulkhandlingshouldensurethatabrasionandmechanicalshockare minimized.

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 44 RF TEST REPORT Product Name: Smart watch Model Number: CD07, CD03, CD05, CD06, CD08, CD09, CD10, CD12, A1, A2, A3, A5, A6, A7, A8, A9, SW1, SW2, SW3, SW8 FCC ID: 2BVYE-A2 Issued For : Shenzhen Shenwu Zhichuang Technology Co., Ltd. 102, Building C, No. 2 Ziping Road, Xiuxin Community, Kengzi Street, Pingshan District, Shenzhen, China Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26D048RF02 Sample Received Date: Apr. 09, 2026 Date of Test: Apr. 09, 2026 ~ Apr. 21, 2026 Date of Issue: Apr. 21, 2026 Report No.: LGT26D048RF02 Page 2 of 44 TEST REPORT CERTIFICATION Applicant: Shenzhen Shenwu Zhichuang Technology Co., Ltd. Address: 102, Building C, No. 2 Ziping Road, Xiuxin Community, Kengzi Street, Pingshan District, Shenzhen, China Manufacturer: Shenzhen Shenwu Zhichuang Technology Co., Ltd. Address: 102, Building C, No. 2 Ziping Road, Xiuxin Community, Kengzi Street, Pingshan District, Shenzhen, China Product Name: Smart watch Trademark: N/A Model Number: CD07, CD03, CD05, CD06, CD08, CD09, CD10, CD12, A1, A2, A3, A5, A6, A7, A8, A9, SW1, SW2, SW3, SW8 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2020 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT26D048RF02 Page 3 of 44 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST LABORATORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 TEST SOFTWARE AND POWER LEVEL 9 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.5 EQUIPMENTS LIST 11 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 TEST PROCEDURE 14 3.3 TEST SETUP 14 3.4 EUT OPERATING CONDITIONS 14 3.5 TEST RESULTS 15 4. RADIATED EMISSION MEASUREMENT 17 4.1 RADIATED EMISSION LIMITS 17 4.2 TEST PROCEDURE 19 4.3 TEST SETUP 19 4.4 EUT OPERATING CONDITIONS 20 4.5 FIELD STRENGTH CALCULATION 20 4.6 TEST RESULTS (BAND EDGE REQUIREMENTS) 25 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 26 5.1 LIMIT 26 5.2 TEST PROCEDURE 26 5.3 TEST SETUP 26 5.4 EUT OPERATION CONDITIONS 26 5.5 TEST RESULTS 26 6. POWER SPECTRAL DENSITY TEST 27 6.1 LIMIT 27 6.2 TEST PROCEDURE 27 6.3 TEST SETUP 27 6.4 EUT OPERATION CONDITIONS 27 Report No.: LGT26D048RF02 Page 4 of 44 6.5 TEST RESULTS 27 7. BANDWIDTH TEST 28 7.1 LIMIT 28 7.2 TEST PROCEDURE 28 7.3 TEST SETUP 28 7.4 EUT OPERATION CONDITIONS 28 7.5 TEST RESULTS 28 8. PEAK OUTPUT POWER TEST 29 8.1 LIMIT 29 8.2 TEST PROCEDURE 29 8.3 TEST SETUP 29 8.4 EUT OPERATION CONDITIONS 29 8.5 TEST RESULTS 29 9. ANTENNA REQUIREMENT 30 9.1 STANDARD REQUIREMENT 30 9.2 EUT ANTENNA 30 APPENDIX I - TEST RESULTS 31 1. DUTY CYCLE 31 2. BANDWIDTH 33 3. MAXIMUM CONDUCTED OUTPUT POWER 36 4. MAXIMUM POWER SPECTRAL DENSITY 38 5. UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS 40 APPENDIX II - MEASUREMENT PHOTOS 44 Report No.: LGT26D048RF02 Page 5 of 44 Revision History Rev. Issue Date Revisions 00 Apr. 21, 2026 Initial Issue Report No.: LGT26D048RF02 Page 6 of 44 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 Part 15.247 Meas Guidance v05r02. FCC Part 15.247, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Report No.: LGT26D048RF02 Page 7 of 44 1.1 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Occupied Channel Bandwidth ±0.46% 2 RF Output Power, Conducted ±0.71dB 3 Power Spectral Density, Conducted ±1.57dB 4 Unwanted Emission, Conducted ±0.63dB 5 Conducted emission ±2.80dB 6 All Emissions, Radiated (0.009-30MHz) ±2.16dB 7 All Emissions, Radiated (30MHz-1GHz) ±4.61dB 8 All Emissions, Radiated (1GHz-18GHz) ±5.49dB 9 Temperature ±0.5°C 10 Humidity ±2% 11 Duty Cycle ±2.3% Note: The measurement uncertainty is not included in the test result. Report No.: LGT26D048RF02 …
