2BW6X-X5X5 Charge

Shenzhen Jiasheng Electronic Technology Co., Ltd.

Click to zoom

Application Details

Equipment Class: DCD - Part 15 Low Power Transmitter Below 1705 kHz
Date of Grant: Aug 27, 2026
Application Purpose: Original Equipment
Equipment Note: X5 Charge
Frequency Range: 0.11010000 - 0.20500000
Company: Shenzhen Jiasheng Electronic Technology Co., Ltd.
Country: China
