2BW83-W086Magnetic Wireless Charger

Magnetic Wireless Charger Compatibility: 1. Phone case ① Compatible with smooth surface phone case thinner than 4mm ② Not compatible with a. Any foreign object between your smartphone and the magnetic wireless charger , such as metal, credit card, door keys, coins and NFC cards b. Phone cases may affect wireless charging, such as phone case with thickness of >4mm or a case with bump surface or stand c. PopSockets, ring holder and etc. 2. Power adaptor Please connect this product to a power adaptor of PD30W or above through a Type-C fast charging cable to ensure fast wireless charging 3. Charging cable Please use an original charging cable supplied with the magnetic wireless charging to ensure fast and safe charging. Overview: Warning: 1. Do no dismantle the product or refit or modify it by yourself. 2. Do not store the product in the humid enviorment. 3. Do not keep or use the product near heat source. 4. Do not install the wireless car charger over an air bag cover or within the air bag deployment zone. 5. Avoid using bent or damaged USB cable. 6. Do not install while driving 7. Keep the magnetic wireless charging or the accessories away from the children. Specifications： Product name: Magnetic Wireless Charger Model: W086 Input: 5V/3A 9V/3A 12V/2.5A 15V/3A Output: 25W Max. Charging distance: ≤5mm Working temperature: -10°C~40°C Input port: Type-C Packing list： 1* Magnetic wireless charger 1* Air vent clip 1* Charging cable 1* Metal ring 1* User manual The display status of indicator light: Precautions for use: a. Please follow up the munual instruction to use an adapter with sufficient power supply.as it will cause slow charging or shortage of the power. b.Don't connect the magnetic wireless charger to the in-car USB port directly.There won't be enough power as it will cause slow charging. c. Please use the original C-C charging cable supplied together with magnetic wireless charger as it will cause slow charging if the current or power is not sufficient. d. Please check if there is metal objects between the phone and charger, Don't use or place metal plates, credit card, Popsockets on the back of your phone when charging. e. Ensure your phone case is thinner than 4mm, otherwise the phone will not be able to wireless charge. f. The charging speed will be slow if the temperature is too high. Turn off navigation and other unsued apps whilst also lowering the temperature of the car air conditioner. The perfect temperature would be -20 C-40C while working. The product would probably can't function properly when the temperature is too high or too low. Charging cable How to Install Step 1: Unscrew the fixed nut completely, let the ball pass through the fixed nut. Then push the ball firmly into the groove on the back of the magnetic wireless charger, then tighten the fixing nut. Step 2: Insert the wireless charger into a suitable place, then twist the turn-knob to adjust the length of iron hook to fit the blade of vent joint joint Step 3: Tighten the fixed nut to secure the wireless charger firmly and adjust the angle of the wireless charger to fit your view. Step 4: Use the original charging cable supplied to connect the wireless charger to the car charger of PD30W or above. Then put the phone on the wireless charger, it will automatically magnetic the phone and sart charging. joint Ball Turn-knob Iron hook Support stand Magnetic wireless charger State Indicator Light Power on The RGB light breathes The RGB light breathes. Tap the buttonto change the color of light. Stand by Charging The RGB light goes out. Fully Charged The RGB light goes out. FOD Red light flickers. FCC Information and Copyright This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment .This equipment should be installed and operated with minimum distance 20cm between the radiator& your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

Rev 1/26/2023 Dongguan Dubang Plastic Products Co.,Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-07-20 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID:2BW83-W086 Dongguan Dubang Plastic Products Co.,Ltd certifies that the equipment for which authorization is sought is not“covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Dongguan Dubang Plastic Products Co.,Ltd certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, (Applicant signature) (Song Youxiong) Rev 1/26/2023 Dongguan Dubang Plastic Products Co.,Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-07-20 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID:2BW83-W086 Dongguan Dubang Plastic Products Co.,Ltd certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Song Youxiong)

Dongguan Dubang Plastic Products Co.,Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: July 20, 2026 Subject; Request for Confidentiality FCC ID:2BW83-W086 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description FCC Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Song Youxiong Title: Manager

Dongguan Dubang Plastic Products Co.,Ltd Product Similarity Declaration Product name: Magnetic Wireless Charger Model name:W086,W087, W053,W088,S271,S236,SF-W086, SW182 FCC ID:2BW83-W086 The product has multiple colors. these product are same PCB Layout, Schematics, BOM. Only for different appearance color and model name for different market require. Sincerely yours, Applicant Signature Printed Name:Song Youxiong Title:Manager Address: Building 5, Huihai Industrial Park, Dalingshan Town, Dongguan City, Guangdong Province, China Email:[email protected]

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 Dongguan Dubang Plastic Products Co.,Ltd Date：2026-07-20 Product Model Number: W086,W087, W053,W088,S271,S236,SF-W086, SW182 FCC ID:2BW83-W086 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following:  Testing  Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out byQAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. By: Song Youxiong Contact Listed on FCC Wesbite Title: Manager Email: [email protected] On behalf of: Dongguan Dubang Plastic Products Co.,Ltd

Page 1 of 4 Shenzhen NTT Testing Technology Co.,Ltd. 1B, Building 2, Factory Building & 103, Building 3, Factory Building, Dayang Industrial Park, No.4, Industrial Avenue, Tangwei Community, Fuhai Sub-district, Bao 'an District, Shenzhen City, Guangdong, China FCC ID:2BW83-W086 External Photos Page 2 of 4 Shenzhen NTT Testing Technology Co.,Ltd. 1B, Building 2, Factory Building & 103, Building 3, Factory Building, Dayang Industrial Park, No.4, Industrial Avenue, Tangwei Community, Fuhai Sub-district, Bao 'an District, Shenzhen City, Guangdong, China Label&location Page 3 of 4 Shenzhen NTT Testing Technology Co.,Ltd. 1B, Building 2, Factory Building & 103, Building 3, Factory Building, Dayang Industrial Park, No.4, Industrial Avenue, Tangwei Community, Fuhai Sub-district, Bao 'an District, Shenzhen City, Guangdong, China Page 4 of 4 Shenzhen NTT Testing Technology Co.,Ltd. 1B, Building 2, Factory Building & 103, Building 3, Factory Building, Dayang Industrial Park, No.4, Industrial Avenue, Tangwei Community, Fuhai Sub-district, Bao 'an District, Shenzhen City, Guangdong, China

FCC ID LABELING AND LOCATION FCC ID Label FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925) Input:DC5V/3A,DC9 V/3A, DC12V/2.5A DC15V/3A Output:25W/15W/10 W/7.5W/5W FCC ID:2BW83-W086 65mm 65mm

Page 1 of 2 Shenzhen NTT Testing Technology Co.,Ltd. 1B, Building 2, Factory Building & 103, Building 3, Factory Building, Dayang Industrial Park, No.4, Industrial Avenue, Tangwei Community, Fuhai Sub-district, Bao 'an District, Shenzhen City, Guangdong, China FCC ID:2BW83-W086 Internal Photos Page 2 of 2 Shenzhen NTT Testing Technology Co.,Ltd. 1B, Building 2, Factory Building & 103, Building 3, Factory Building, Dayang Industrial Park, No.4, Industrial Avenue, Tangwei Community, Fuhai Sub-district, Bao 'an District, Shenzhen City, Guangdong, China Coil ANT

Shenzhen NTT Testing Technology Co.,Ltd. Report No.:SZNTT26027312E1-2 SZNTT-TR832-0 Tel:0755-27889935 Web:http://www.ntt-testing.com Page 1 of 15 MPE REPORT Magnetic Wireless Charger MODEL No.: W086,W087, W053,W088,S271,S236,SF-W086,SW182 FCC ID:2BW83-W086 REPORT NO.:SZNTT26027312E1-2 ISSUE DATE: Jul. 13, 2026 Prepared for Dongguan Dubang Plastic Products Co.,Ltd Building 5, Huihai Industrial Park, Dalingshan Town, Dongguan City, Guangdong Province, China Prepared by Shenzhen NTT Testing Technology Co.,Ltd. 1B, Building 2, Factory Building & 103, Building 3, Factory Building, Dayang Industrial Park, No.4, Industrial Avenue, Tangwei Community, Fuhai Sub-district, Bao 'an District, Shenzhen City, Guangdong, China Shenzhen NTT Testing Technology Co.,Ltd. Report No.: SZNTT26014193E1-2 SZNTT-TR832-0 Tel:0755-27889935 Web:http://www.ntt-testing.com Page 2 of 15 TABLE OF CONTENT Test Report Description Page 1. SUMMARY OF TEST RESULT ......................................................................................................4 2. GENERAL INFORMATION .............................................................................................................5 2.1. DESCRIPTION OF DEVICE (EUT) ................................................................................................................................ 5 2.2. TEST SETUP ................................................................................................................................................................ 6 2.3. DESCRIPTION OF TEST FACILITY ................................................................................................................................ 7 2.4. MEASUREMENT UNCERTAINTY ................................................................................................................................... 7 3. MEASURING DEVICE AND TEST EQUIPMENT .......................................................................8 3.1. FOR MPE MEASUREMENT ......................................................................................................................................... 8 4. RF EXPOSURE.................................................................................................................................9 4.1. MEASURING STANDARD .............................................................................................................................................. 9 4.2. REQUIMENTS ............................................................................................................................................................... 9 4.3. TEST CONFIGURATIO ................................................................................................................................................. 10 4.4. LIMITS ......................................................................................................................................................................... 11 4.5. MEASURING RESULTS ............................................................................................................................................... 12 5. PHOTOGRAPHS OF TEST SETUP ...........................................................................................15            !"#           !" # $                               ! "    #  $%                           ! "    #  &' $   (   $  )* (+,-(+,. (+/(+,,01.201/-034(+,- 0(2,1 * 5       3  2622/2+7   1612+827 9  -,+2+- +2 (   % #+:  #   #    ! 0; )     !     *  *<** *  # *  % *  #   # # %  #      % *     **             0; )     !     * % %   ! %   !   *  %  **           &' 6&=* '  7  !  *    3 =*       #   * !               # % 0; )     !                  ! Shenzhen NTT Testing Technology Co.,Ltd. Report No.: SZNTT26014193E1-2 SZNTT-TR832-0 Tel:0755-27889935 Web:http://www.ntt-testing.com Page 4 of 15 1. SUMMARY OF TEST RESULT EMISSION Description of Test Item Standard & Limits Results MPE FCC Part 1(1.1310) and Part 2(2.1091) KDB 680106 D01 Wireless Power Transfer v04 Pass Note: N/A is an abbreviation for Not Applicable. Shenzhen NTT Testing Technology Co.,Ltd. Report No.: SZNTT26014193E1-2 SZNTT-TR832-0 Tel:0755-27889935 Web:http://www.ntt-testing.com Page 5 of 15 2. GENERAL INFORMATION 2.1. Description of Device (EUT) EUT : Magnetic Wireless Charger Model Number : W086,W087,W053,W088,S271,S236 ,SF-W086,SW182 Power Rating : Input: Type-C: DC5V/3A,DC9V/3A,DC12V/2.5A,DC15V/3A Output: Wireless: 25W/15W/10W/7.5W/5W Operation Frequency for WPT : 111-205 KHz&360kHz Modulation : MSK Antenna Type: : Coil Antenna Date of Received : Jul.01, 2026 Date of Test : Jul.01, 2026 to Jul.13, 2026 Shenzhen NTT Testing Technology Co.,Ltd. Report No.: SZNTT26014193E1-2 SZNTT-TR832-0 Tel:0755-27889935 Web:http://www.ntt-testing.com Page 6 of 15 2.2. Test Setup Shenzhen NTT Testing Technology Co.,Ltd. Report No.: SZNTT26014193E1-2 SZNTT-TR832-0 Tel:0755-27889935 Web:http://www.ntt-testing.com Page 7 of 15 2.3. Description of Test Facility 2.4. Measurement Uncertainty Parameter Uncertainty Temperature ±1°C Humidity ±5% DC…

Text truncated - open the document above for the full version.

SPECIFICATION Product type code: DESC FYC0062024091501 Revision : A.1 Customer CUST: C006 Fine P/N for Pan-Asia materials: FYC006008 Customer part number EL.X.XQ00000049 1、Dimension DIMENSION: (mm) 2. Schematic Diagram: A 21.46±0.5 B 39.3±0.5 C 0.8±0.2 D 95±3 E 2.5 Max (without yellow glue) F 2.0-2.4 (Excluding release paper thickness) pour ： 1.Wires do not cross or branch out; 2.The coil is back-mounted with magnetic sheets measuring φ 42.5*5.3*0.9 (0.9-1.0) mm, featuring L-shaped double slots with central openings. A φ18*0.75 mm small magnetic sheet is attached to one side, while the other side carries a φ 15*0.08 mm standard adhesive tape with a tear-off notch. 3.One side of the magnetic disc is coated with φ42*6*0.3mm foam material featuring a tear-off notch, while both sides are bonded with adhesive backing. 4. Initial line sleeve: φ1.0mm black heat-shrinkable tube, length 85±3mm; 3、Winding specification: order number NO. terminal TERMINAL Wire diameter WIRE number of turns Turns direction of winding Winding Direction 1 S F Litz0.08*65p 11Ts CW IV. ELECTRICAL CHARACTERISTICS: Temperature: 25±10°C, Relative Humidity: 65±20% order num ber NO. proje ct ITEM terminal TERMINAL standard SPECIFICATION test condition TEST FREQUENCY measuring and test instruments TEST EQUIPMENTS 1 IND. S-F 8.5uH ±5% 360KHz/1.0V TH2810 2 DCR S-F ≤85mΩ 25°C TH2810 3 ACR S-F 150mΩ Max 360KHz/1.0V TH2810 Pseudonym/Date PREPARED BY/DATE Review/Date CHECKED BY/DATE Approved/Date APPROVED BY/DATE Wei Bingfu 2024/11/02 Qi Lezheng 2024/11/02 Hu Wei 2024/11/02
