2BW9U-WFL001Waffle HOME

Waffle HOME Model: WFL001GRA-GLB/WFL001MNT-GLB/WFL001PUR-GLB Quick Start Guide 2 Power On Press and hold the # key on the phone for 3 seconds to power on the device . You can download the Waffle APP from the app store to configure the phone . Once configured , the phone will be ready to use . Configure Telephone [ Configure Using The Waffle App ] I. Adding equipment On the main screen, click the "+Pair New Device" button to begin the pairing process. This process consists of 5 steps; please follow the prompts to complete it. Step 1: ADDRESS In the Pair New Device interface, select "Home". Once you enter the search interface, make sure your Waffle Home is turned on and close to your phone. Then, find the corresponding device in the search list and tap it. Once the device is located, the device interface will change to a Bluetooth icon. After filling in the CHILD'S NAME and DEVICE NICKNAME using the app, click Next. After entering the device address interface, fill in your home address information and click "NEXT". Step 2: Choose a Phone Number Select a mobile number and click the confirm button. Step 3: Connect to Wi-Fi 3 Configure the Wi-Fi network for your device. Enter the Wi-Fi name and password, then click the Continue button. Step 4: Contacts (Configure Contacts) Click the "Add Contact" button to configure device contact information. Step 5: Set up Schedule Determine the time periods during which this device is allowed to make calls, send messages, and connect to the internet. Once the settings are complete, click "Finish Setup" to complete pairing. II. Bluetooth Disconnection and Connection Enter the Devices interface and select the corresponding device you want to operate. In the device's Wi-Fi settings, click the "Disconnect" button to disconnect the Bluetooth connection; click the "Connect" button to reconnect the Bluetooth connection. When the Bluetooth icon ① is displayed on the device interface, it indicates that the device is currently in Bluetooth connection mode. Note: Before syncing contact information, Wi-Fi information, and performing related configuration operations to the device, please ensure that the device is connected to Bluetooth. III. Distribute to contact persons Enter the Devices interface and select the corresponding device you want to operate. Access the Contacts page on your device to add or modify contact information. After adding or modifying, click the "Sync Now" button to synchronize the contact information to your device. IV. Wi-Fi Information Distribution Enter the Devices interface and select the corresponding device you want to operate. Access the device's Wi-Fi settings page, enter the Wi-Fi name and password, and save. 4 Click the "Sync Now" button to synchronize Wi-Fi information to your device. IV. Icon Status On The Phone's LCD Screen: Boot screen Bluetooth pairing WiFi search WiFi error WiFi connected SIP connected Send voice message Voice message not sent Dialing in progress Call connected Handset mode Speaker mode Hang up Low battery Keys Functions After the device is initialized, the following functions can be accessed: Numeric keypad : ➢ Number keys: 0-9 keys (Press and hold the "0" key for 3 seconds to input the "+" sign or dial the international prefix) ; ➢ Symbol keys: * key, # key ( press and hold for 3 seconds to turn on/off ) . Function keys : ➢ Dialing key: ❖ Answer key: Press the answer button briefly when a call comes in to answer the phone; ❖ Hang-up key: Press briefly during a call to hang up; ❖ Dialing key: Select a contact or enter a number to make a call; ❖ Back key: Double-click to return to the main interface; 5 ❖ Play key: Select a contact in the voice message menu to play the voice message; ❖ After receiving a voice message, press the dialing key briefly in the voice message menu to enter the voice message. ➢ Navigation keys "</>": Switch between interfaces and contacts by looking left and right; ➢ Message key: Press the key briefly to enter the voice message menu, use the navigation keys to switch, select a contact and press the key briefly to speak; ➢ Hands-free key: Used to switch between hands-free and earpiece during a call ; ➢ Volume control keys "+/-" : Used to adjust the volume during a call. Note: The actual functions of the equipment shall prevail. Basic Call Functions Call: 1. Pick up the handset, press the keys to enter the number, and press the dial soft key to make a call . 2. Double-click the dial key to enter the contact menu. Press "<" or ">" to switch contacts, and press the soft key to make a call . Answer: When a call comes in while the phone is in standby mode, simply pick up the handset or press the key to answer the call. You can also press the corresponding line key or answer function key to answer the call. Users can press the corresponding buttons or lift the handle to switch between headset, handle, and hands-free calling. End call: Note: During a call, you can press the hands-free key to switch audio between handset and hands-free mode. Note: You may place the device back onto the base to reject incoming calls. 6 In handset mode : Place the device back on the dock or press the hang-up soft key to end the call . In hands-free mode : Press the hang-up soft key to end the call . Send a voice message: 1. On the standby screen, press " < " or " >" to switch contacts. 2. After selecting a contact, briefly press the voice message button to record a message; press it again to send the voice message. Note: Voice messages can be recorded for a maximum of 20 seconds and will automatically stop recording. Play voice message: 1. Double-click the voice message button from the standby screen to access the voice message list. 2. Short press the " < " or " >" keys to switch lists. 3. Select a contact from the list and press the dial button to play a voice message. 4. When your device receives a new voice message , you can do the following: • After switching to the voicemail interface, briefly press the dial but…

Text truncated - open the document above for the full version.

Rev 1/26/2023 Just Waffle Inc Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-08-10 FCC ID: 2BW9U-WFL001 Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing Just Waffle Inc certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Just Waffle Inc certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing Just Waffle Inc certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Applicant: Just Waffle Inc Address: 2810 North Church Street Suite 89975, Wilmington, Delaware 19802, United States Contact Person: Sean Andrews Tel.: +1(310) 361-4022 Email: [email protected] Sincerely, Signature:

Attestation Statements Date: 2026-08- 10 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for(FCC ID: 2BW9U-WFL001) Just Waffle Inc, the undersigned, hereby authorize Just Waffle Inc to act as our designated agent for service of process, Just Waffle Inc accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Just Waffle Inc accepts the responsibility to act as designated agent for service of process. Applicant Information ： Company name: Just Waffle Inc Contact Name: Sean Andrews Address: 2810 North Church Street Suite 89975, Wilmington, Delaware 19802, United States Telephone No: +1(310) 361-4022 Email: [email protected] FRN: 0038598405 Signature: Sean Andrews Agent Information: Company Name: Just Waffle Inc Address:2810 North Church Street Suite 89975, Wilmington, Delaware 19802, United States FRN: 0038598405 Contact Name: Sean Andrews Telephone No: +1(310) 361-4022 Email: [email protected] Signature: Sean Andrews

Just Waffle Inc Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 11, 2026 Subject; Request for Confidentiality FCC ID: 2BW9U-WFL001 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Sean Andrews Title: Partner

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 Just Waffle Inc Date：2026-08-10 Product Model Number: WFL001GRA-GLB, WFL001MNT-GLB, WFL001PUR-GLB FCC ID：2BW9U-WFL001 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. Signature: By: Sean Andrews Contact Listed on FCC Wesbite Title: Partner Email: [email protected] On behalf of: Just Waffle Inc

Just Waffle Inc Declaration Letter of Model Difference Date: 2026-08-07 FCC ID: 2BW9U-WFL001 Tested Model Number: WFL001GRA-GLB Adding Model Number(s): WFL001MNT-GLB, WFL001PUR-GLB All Adding Model Number(s) is/are same electrically identical as Tested Model Number. Only model name and color are different for market purpose. Yours Sincerely, Applicant: Just Waffle Inc Address: 2810 North Church Street Suite 89975, Wilmington, Delaware 19802, United States Contact Person: Sean Andrews Tel.: +1(310) 361-4022 Email: [email protected] Sincerely, Signature:

Page 1 of 6 Report No.: LGT26G129 Appendix - External Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 6 Report No.: LGT26G129 Appendix - External Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 6 Report No.: LGT26G129 Appendix - External Photographs of EUT Constructional Details Photo 5 Photo 6 Page 4 of 6 Report No.: LGT26G129 Appendix - External Photographs of EUT Constructional Details Photo 7 Photo 8 Page 5 of 6 Report No.: LGT26G129 Appendix - External Photographs of EUT Constructional Details Photo 9 Photo 10 Page 6 of 6 Report No.: LGT26G129 Appendix - External Photographs of EUT Constructional Details Photo 11

Rated Input: DC 5V 1A Made in Weihai, China SN: WHGA26061000001 FCC ID: 2BW9U-WFL001 Model: WFL001MNT-GLB Designed by Just Waffle Pte Ltd

Page 1 of 7 Report No.: LGT26G129 Appendix - Internal Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 7 Report No.: LGT26G129 Appendix - Internal Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 7 Report No.: LGT26G129 Appendix - Internal Photographs of EUT Constructional Details Photo 5 Photo 6 ANT Page 4 of 7 Report No.: LGT26G129 Appendix - Internal Photographs of EUT Constructional Details Photo 7 Photo 8 Page 5 of 7 Report No.: LGT26G129 Appendix - Internal Photographs of EUT Constructional Details Photo 9 Photo 10 Page 6 of 7 Report No.: LGT26G129 Appendix - Internal Photographs of EUT Constructional Details Photo 11 Photo 12 Page 7 of 7 Report No.: LGT26G129 Appendix - Internal Photographs of EUT Constructional Details Photo 13

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 8 EMF TEST REPORT Product Name: Waffle HOME Model Number: WFL001GRA-GLB, WFL001MNT-GLB, WFL001PUR-GLB FCC ID: 2BW9U-WFL001 Issued For : Just Waffle Inc 2810 North Church Street 89975 Wilmington, DE, 19802 US Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26G129HA03 Sample Received Date: Jul. 21, 2026 Date of Test: Jul. 21, 2026 ~ Aug. 07, 2026 Date of Issue: Aug. 07, 2026 Report No.: LGT26G129HA03 Page 2 of 8 TEST REPORT CERTIFICATION Applicant: Just Waffle Inc Address: 2810 North Church Street 89975 Wilmington, DE, 19802 US Manufacturer: Just Waffle Inc Address: 2810 North Church Street 89975 Wilmington, DE, 19802 US Product Name: Waffle HOME Trademark: WAFFLE Model Number: WFL001GRA-GLB, WFL001MNT-GLB, WFL001PUR-GLB Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47 CFR §2.1093 KDB 447498 D01 General RF Exposure Guidance v06 PASS Prepared by: Approved by: Chris Chen Engineer Technical Director Report No.: LGT26G129HA03 Page 3 of 8 TABLE OF CONTENTS 1 . GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST LABORATORY 5 2 . FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 8 Report No.: LGT26G129HA03 Page 4 of 8 Revision History Rev. Issue Date Revisions 00 Aug. 07, 2026 Initial Issue Report No.: LGT26G129HA03 Page 5 of 8 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name: Waffle HOME Test Model Number: WFL001GRA-GLB Series Number: WFL001MNT-GLB, WFL001PUR-GLB Model Difference: The product comes in three color options, here, the three color variants of the product are referred to by the colors of the handset: Graphite balck, Mint green, and purple. These variants differ only in color; all other hardware and software components are identical. Frequency Bands: Bluetooth 2402-2480MHz 2.4G WLAN IEEE 802.11b/g/n/ax (20MHz): 2412~2462MHz IEEE 802.11n/ax (40MHz):2422~2452MHz 5G WLAN IEEE 802.11a/n(HT20)/ ac(VHT20)/ax(HE20): 5.180GHz-5.240GHz IEEE 802.11n(HT40)/ ac(VHT40)/ax(HE40): 5.190GHz-5.230GHz IEEE 802.11a/n(HT20)/ ac(VHT20)/ax(HE20): 5.260GHz-5.320GHz IEEE 802.11 n(HT40)/ ac(VHT40)/ax(HE40): 5.270GHz-5.310GHz IEEE 802.11a/n(HT20)/ ac(VHT20)/ax(HE20): 5.500GHz-5.700GHz IEEE 802.11 n(HT40)/ ac(VHT40)/ax(HE40): 5.510GHz-5.670GHz IEEE 802.11a/n(HT20)/ ac(VHT20)/ax(HE20): 5.745GHz-5.825GHz IEEE 802.11a/n(HT40)/ac(VHT40)/ax(HE40): 5.755GHz-5.795GHz Rating: Input: DC 5V 1A Battery: Capacity: 1050mAh Rated Voltage: 3.7V Hardware Version: 03KS20 Software Version: V01 1.2 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 Report No.: LGT26G129HA03 Page 6 of 8 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in KDB 447498 D01 General RF Exposure Guidance v06 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. Report No.: LGT26G129HA03 Page 7 of 8 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] • [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz. Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Report No.: LGT26G129HA03 Page 8 of 8 2.3 TEST RESULT Turn up Result Mode Turn up Power BLE 1M-GFSK -4±1dBm BLE 2M-GFSK -4±1dBm 2.4G WIFI-802.11b 8.8±1dBm 2.4G WIFI-802.11g 8±1dBm 2.4G WIFI-802.11n(HT20) 7±1dBm 2.4G WIFI-802.11n(HT40) 7±1dBm 2.4G WIFI-802.11ax(HE20) 8.8±1dBm 2.4G WIFI-802.11ax(HE40) 8.8±1dBm 5G WIFI-802.11a 5.5±1.5dBm 5G WIFI-802.11n(HT20) 4.5±1.5dBm 5G WIFI-802.11n(HT40) 4.5±1dBm 5G WIFI-802.11ac(VHT20) 4.5±1.5dBm 5G WIFI-802.11ac(VHT40) 5±1dBm 5G WIFI-802.11ax(HE20) 4.5±1.5dBm 5G WIFI-802.11ax(HE40) 4.5±1dBm The MPE result of worst mode: RF Function Frequency (MHz) Max Turn up Power (dBm) Max Turn up Power (mW) Estimated SAR Limit Ratio Result BLE 2402 -3.00 0.50 0.155 3 0.052 Pass 2.4G WIFI 2412 9.80 9.55 2.966 3 0.989 Pass 5G WIFI 5180 7.00 5.01 2.281 3 0.760 Pass Note: 1. The Bluetooth and WLAN can’t simultaneous transmission at t…

Text truncated - open the document above for the full version.

测试环境和天线安装位置 Testing environment and Antenna location on the product 物料实拍图 Material Picture 物料规格描述 Material spec 报告名称：Report Name KS20 天线规格书KS20 Antenna Specification 项目信息描述：Project Information本次调试客户需求：Customer Requirement of This Test本次报告重点事项：The Focus of This Test 2.4G/5.8G 天线2.4G/5.8G Antenna 本次调试结论如下：Conclusion as below地址：Address: 地址：深圳市龙岗区龙岗大道8288号大运软件小镇55栋1楼Address: 1/F, Building 55, Universiade Software Town, 8288 Long gang Avenue, Longgang District, Shenzhen 测试前准备工作 Readiness before testing 修改方案示意图 Circuit proposal 测试类型 Category 回波损耗 Return Loss WIFI 天线效率测试 Antenna Efficiency Test WIFI 天线匹配电路 Matching Circuit 测试内容和数据 Testing Items and Raw Data 所属子项目 Test Item 测试数据 Testing Data 无源测试(自由空间) Passive Test 0 Ω 0 Ω Phi=0° Phi=90° Theta=90° WIFI/5.8G 2400MHz2450MHz 2D方向图 2D Directional Diagram WIFI/2.4G 无源测试(自由空间) Passive Test 3D方向图 3D Directional Diagram 无源测试(自由空间) Passive Test 3D方向图 3D Directional Diagram 2500MHz 无源测试(自由空间) Passive Test 3D方向图 3D Directional Diagram 5500MHz 签发批准：刘永坚Approved by 日期： 2026年7月7日Date 制作人：龙琼Prepared by 审核人：杨华Reviewed by Antenna Size:

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 53 RF TEST REPORT Product Name: Waffle HOME Model Number: WFL001GRA-GLB, WFL001MNT-GLB, WFL001PUR-GLB FCC ID: 2BW9U-WFL001 Issued For : Just Waffle Inc 2810 North Church Street 89975 Wilmington, DE, 19802 US Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26G129RF05 Sample Received Date: Jul. 21, 2026 Date of Test: Jul. 21, 2026 ~ Aug. 07, 2026 Date of Issue: Aug. 07, 2026 Report No.: LGT26G129RF05 Page 2 of 53 TEST REPORT CERTIFICATION Applicant: Just Waffle Inc Address: 2810 North Church Street 89975 Wilmington, DE, 19802 US Manufacturer: Just Waffle Inc Address: 2810 North Church Street 89975 Wilmington, DE, 19802 US Product Name: Waffle HOME Trademark: WAFFLE Model Number: WFL001GRA-GLB, WFL001MNT-GLB, WFL001PUR-GLB Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2020 + Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024 PASS Prepared by: Approved by: Chris Chen Vita Li Engineer Technical Director Report No.: LGT26G129RF05 Page 3 of 53 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST LABORATORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 TEST SOFTWARE AND POWER LEVEL 9 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.5 EQUIPMENTS LIST 11 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 TEST PROCEDURE 14 3.3 TEST SETUP 14 3.4 EUT OPERATING CONDITIONS 14 3.5 TEST RESULTS 15 4. RADIATED EMISSION MEASUREMENT 17 4.1 RADIATED EMISSION LIMITS 17 4.2 TEST PROCEDURE 19 4.3 TEST SETUP 19 4.4 EUT OPERATING CONDITIONS 20 4.5 FIELD STRENGTH CALCULATION 20 4.6 TEST RESULTS (BAND EDGE REQUIREMENTS) 25 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 27 5.1 LIMIT 27 5.2 TEST PROCEDURE 27 5.3 TEST SETUP 27 5.4 EUT OPERATION CONDITIONS 27 5.5 TEST RESULTS 27 6. POWER SPECTRAL DENSITY TEST 28 6.1 LIMIT 28 6.2 TEST PROCEDURE 28 6.3 TEST SETUP 28 6.4 EUT OPERATION CONDITIONS 28 Report No.: LGT26G129RF05 Page 4 of 53 6.5 TEST RESULTS 28 7. BANDWIDTH TEST 29 7.1 LIMIT 29 7.2 TEST PROCEDURE 29 7.3 TEST SETUP 29 7.4 EUT OPERATION CONDITIONS 29 7.5 TEST RESULTS 29 8. PEAK OUTPUT POWER TEST 30 8.1 LIMIT 30 8.2 TEST PROCEDURE 30 8.3 TEST SETUP 30 8.4 EUT OPERATION CONDITIONS 30 8.5 TEST RESULTS 30 9. ANTENNA REQUIREMENT 31 9.1 STANDARD REQUIREMENT 31 9.2 EUT ANTENNA 31 APPENDIX I - TEST RESULTS 32 1. DUTY CYCLE 32 2. BANDWIDTH 35 3. MAXIMUM CONDUCTED OUTPUT POWER 40 4. MAXIMUM POWER SPECTRAL DENSITY 43 5. UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS 46 APPENDIX II - MEASUREMENT PHOTOS 53 Report No.: LGT26G129RF05 Page 5 of 53 Revision History Rev. Issue Date Revisions 00 Aug. 07, 2026 Initial Issue Report No.: LGT26G129RF05 Page 6 of 53 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 Part 15.247 Meas Guidance v05r02. FCC Part 15.247, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020 + Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024. Report No.: LGT26G129RF05 Page 7 of 53 1.1 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Occupied Channel Bandwidth ±0.46% 2 RF Output Power, Conducted ±0.71dB 3 Power Spectral Density, Conducted ±1.57dB 4 Unwanted Emission, Conducted ±0.63dB 5 Conducted emission ±2.80dB 6 All Emissions, Radiated (0.009-30MHz) ±2.16dB 7 All Emissions, Radiated (30MHz-1GHz) ±4.61dB 8 All Emissions, Radiated (1GHz-18GHz) ±5.49dB 9 All Emissions, Radiated (18GHz-40GHz) ±4.31dB 10 Temperature ±0.5°C 11 Humidity ±2% 12 Duty Cycle ±2.3% Note: The measurement uncertainty is not included in the test result. Report No.: LGT26G129RF05 Page 8 of 53 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: Waffle HOME Test Model Number: WFL001GRA-GLB Series Number: WFL001MNT-GLB, WFL001PUR-GLB Model Difference: The product comes in three color options, here, the three color variants of the product are referred to by the colors of the handset: Graphite balck, Mint green, and purple. These variants differ only in color; all other hardware and software components are identical. Product Description: Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Radio Technology: BLE Bluetooth Configuration: BLE (1M PHY, 2M PHY) Number Of Channel: 40 Antenna Designation: Monopole Antenna Antenna Gain (dBi) 4.16 Channel …

Text truncated - open the document above for the full version.

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 81 RF TEST REPORT Product Name: Waffle HOME Model Number: WFL001GRA-GLB, WFL001MNT-GLB, WFL001PUR-GLB FCC ID: 2BW9U-WFL001 Issued For : Just Waffle Inc 2810 North Church Street 89975 Wilmington, DE, 19802 US Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26G129RF06 Sample Received Date: Jul. 21, 2026 Date of Test: Jul. 21, 2026 ~ Aug. 07, 2026 Date of Issue: Aug. 07, 2026 Report No.: LGT26G129RF06 Page 2 of 81 TEST REPORT CERTIFICATION Applicant: Just Waffle Inc Address: 2810 North Church Street 89975 Wilmington, DE, 19802 US Manufacturer: Just Waffle Inc Address: 2810 North Church Street 89975 Wilmington, DE, 19802 US Product Name: Waffle HOME Trademark: WAFFLE Model Number: WFL001GRA-GLB, WFL001MNT-GLB, WFL001PUR-GLB Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2020 + Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024 PASS Prepared by: Approved by: Chris Chen Vita Li Engineer Technical Director Report No.: LGT26G129RF06 Page 3 of 81 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST LABORATORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3. EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.2 RADIATED EMISSION MEASUREMENT 18 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 29 4.1 LIMIT 29 4.2 TEST PROCEDURE 29 4.3 DEVIATION FROM STANDARD 29 4.4 TEST SETUP 29 4.5 EUT OPERATION CONDITIONS 29 4.6 TEST RESULTS 29 5. POWER SPECTRAL DENSITY TEST 30 5.1 LIMIT 30 5.2 TEST PROCEDURE 30 5.3 DEVIATION FROM STANDARD 30 5.4 TEST SETUP 30 5.5 EUT OPERATION CONDITIONS 30 5.6 TEST RESULTS 30 6. BANDWIDTH TEST 31 6.1 LIMIT 31 6.2 TEST PROCEDURE 31 6.3 DEVIATION FROM STANDARD 31 6.4 TEST SETUP 31 6.5 EUT OPERATION CONDITIONS 31 6.6 TEST RESULTS 31 Report No.: LGT26G129RF06 Page 4 of 81 7. PEAK OUTPUT POWER TEST 32 7.1 LIMIT 32 7.2 TEST PROCEDURE 32 7.3 DEVIATION FROM STANDARD 32 7.4 TEST SETUP 32 7.5 EUT OPERATION CONDITIONS 32 7.6 TEST RESULTS 32 8. ANTENNA REQUIREMENT 33 8.1 STANDARD REQUIREMENT 33 8.2 EUT ANTENNA 33 APPENDIX I - TEST RESULTS 34 1. DUTY CYCLE 34 2. BANDWIDTH 41 3. MAXIMUM CONDUCTED OUTPUT POWER 55 4. MAXIMUM POWER SPECTRAL DENSITY 56 5. UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS 63 APPENDIX II - MEASUREMENT PHOTOS 81 …

Text truncated - open the document above for the full version.
