2BWCR-DL188RC Car

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter. Radiation Exposure Statement The device has been evaluated to meet general RF exposure requirement in portable exposure condition without restriction.

Shantou Dilun Technology Co., Ltd. Covered Equipment Certification Attestation Letter 6/10/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2BWCR-DL188 Shantou Dilun Technology Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Shantou Dilun Technology Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Shantou Dilun Technology Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Signed: Printed name: Wang Xibiao Title: manager Company Name: Shantou Dilun Technology Co., Ltd. Date: 6/10/2026

UNITEDSTATESDESIGNATEDAGENTLETTER Date:2026-06-10 TO:FederalCommunicationCommission EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MID21046 ApplicantU.S.designatedagent CompanyName:ShantouDilunTechnology Co.,Ltd. CompanyName:PicusAdvisorsUSLLC ContactName:WangXiBiaoContactName:IvanWang Address:No.13,DacheweiMiddle Road,YongxinIndustrial Zone,YongxinVillage, LianshangTown,Chenghai District,ShantouCity, GuangdongProvince,China Address:5855SOVEREIGNDRSTEB- 1,HOUSTON,TX77036 UnitedStates City/Province/Zip:GuangdongChinaCity/Province/Zip:HOUSTON,TX77036 Telephone:13692042941Telephone:713-391-4488 Email:[email protected]:[email protected] FRN:0038476636FRN:0034336891 ApplicableEquipment:FCCID:2BWCR-DL188 ATTN:DirectorofCertification: We,<ShantouDilunTechnologyCo.,Ltd.>and<PicusAdvisorsUSLLC>understandandacknowledge theapplicantsconsentandthedesignatedagent’sobligationtoacceptserviceofprocessintheUnited Statesformattersrelatedtotheapplicableequipment,andatthephysicalU.S.addressande-mailofthe designatedagentlistedabove. We,<ShantouDilunTechnologyCo.,Ltd.>and<PicusAdvisorsUSLLC>acknowledgetheapplicant’s acceptanceofitsobligationtomaintainanagentforserviceofprocessintheUnitedStatesfornoless thanoneyearaftereitherthegranteehaspermanentlyterminatedallmarketingandimportationofthe applicableequipmentwithintheU.S.,ortheconclusionofanyCommission-relatedadministrativeor judicialproceedinginvolvingtheequipment,whicheverislater. ApplicantU.S.designatedagent PicusAdvisorsUSLLC Name (Printed) :WangXiBiaoName (Printed) :IvanWang Title:ManagerTitle:CEO Signature:Signature:

Shantou Dilun Technology Co., Ltd. DATE: 6/10/2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen Tongzhou Testing Co.,Ltd. (1st Floor, Building 1, Haomai High-tech Park, Huating Road 387, Dalang Street, Longhua, Shenzhen, China) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Shantou Dilun Technology Co., Ltd. (No. 13, Dachewei Middle Road, Yongxin Industrial Zone, Yongxin Village, Lianshang Town, Chenghai District, Shantou City, Guangdong Province, China) <Signature> Name: Wang Xibiao Title: manager Applicant Company: Shantou Dilun Technology Co., Ltd.

Date: 6/10/2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature> Name: Wang Xibiao Title: manager Company: Shantou Dilun Technology Co., Ltd.

DATE: 6/10/2026 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BWCR-DL188 Product Name: RC Car Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: Wang Xibiao Title: manager Company: Shantou Dilun Technology Co., Ltd.

Shantou Dilun Technology Co., Ltd. No. 13, Dachewei Middle Road, Yongxin Industrial Zone, Yongxin Village, Lianshang Town, Chenghai District, Shantou City, Guangdong Province, China Date: 2026/6/10 Dear Sir/Madam, We, Shantou Dilun Technology Co., Ltd., Hereby declares the following statement, PCB board, circuit, structure and internal of these model(s) are the same, Only model name and appearance color are different for these model: FCC ID: 2BWCR-DL188 Product name: RC Car Model no.: DL-188, DL-178, DL-168, DL-158, DL-148, DL-138, DL-128, DL-118 Sincerely, Name/Title： Wang Xibiao / manager Company: Shantou Dilun Technology Co., Ltd. Address: No. 13, Dachewei Middle Road, Yongxin Industrial Zone, Yongxin Village, Lianshang Town, Chenghai District, Shantou City, Guangdong Province, China Phone: 13692042941 Fax: N/A E-Mail: [email protected]

Report No.: TZ0035260513PH02 Page 1 of 3 External Photographs of EUT External Photo 1 External Photo 2 Report No.: TZ0035260513PH02 Page 2 of 3 External Photo 3 External Photo 4 Report No.: TZ0035260513PH02 Page 3 of 3 External Photo 5 External Photo 6

The size of the label is 15mm*10mm with White forecolor. The size of the logo is 5mm*5mm. FCC ID: 2BWCR-DL188

Report No.: TZ0035260513PH03 Page 1 of 3 Internal Photographs of EUT Internal Photo 1 Internal Photo 2 Report No.: TZ0035260513PH03 Page 2 of 3 Internal Photo 3 Internal Photo 4 Report No.: TZ0035260513PH03 Page 3 of 3 Internal Photo 5 PCB antenna

FCC ID: 2BWCR-DL188 Page 1 of 2 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd RADIO FREQUENCY EXPOSURE Limit According to section B.4 of 447498 D04 Interim General RF Exposure Guidance v01 SAR-based thresholds are derived based on frequency, power, and separation distance of the RF source. The formula defines the thresholds in general for either available maximum time-averaged power or maximum time-averaged ERP, whichever is greater. If the ERP of a device is not easily determined, such as for a portable device with a small form factor, the applicant may use the available maximum time-averaged power exclusively if the device antenna or radiating structure does not exceed an electrical length of λ/4. As for devices with antennas of length greater than λ/4 where the gain is not well defined, but always less than that of a half-wave dipole (length λ/2), the available maximum time-averaged power generated by the device may be used in place of the maximum time-averaged ERP, where that value is not known. The separation distance is the smallest distance from any part of the antenna or radiating structure for all persons, during operation at the applicable ERP. In the case of mobile or portable devices, the separation distance is from the outer housing of the device where it is closest to the antenna. The SAR-based exemption formula of § 1.1307(b)(3)(i)(B), repeated here as Formula (B.2), applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power or effective radiated power (ERP), whichever is greater, of less than or equal to the threshold Pth (mW). This method shall only be used at separation distances from 0.5 cm to 40 cm and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by Formula (B.2). Where and f is in GHz, d is the separation distance (cm), and ERP 20cm is per Formula (B.1). FCC ID: 2BWCR-DL188 Page 2 of 2 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Results RF Exposure at Separation distance (cm): 0.5 Mode Antenna Frequency [MHz] Conducted Power [dBm] Manufacturing tolerance Antenna Gain [dBi] Max of ERP and Conducted Power including Tune Up SAR- based exemption threshold Pth [mW] Target Power [dBm] Tolerance ±[dB] [dBm] [mW] SRD Ant1 2420 -8.6 -9 1 1.13 -8 0.16 2.77 SRD Ant1 2445 -8.71 -9 1 1.13 -8 0.16 2.75 SRD Ant1 2470 -8.77 -9.5 1 1.13 -8.5 0.14 2.73 Max of ERP and Conducted Power including Tune Up (dBm) = Max Conducted Tune Up Power(dBm) and Max Conducted Tune Up Power(dBm) + Antenna Gain(dBi)-2.15), whichever is greater. The Maximum Erp is used for Routine Evaluation Exemption according to B.4 of 447498 D04 Interim General RF Exposure Guidance v01. So, the SAR evaluation is not required.

Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 1 of 23 Appendix Test Data for SRD (Conducted Measurement) Product Name: RC Car Trade Mark: / Test Model: DL-188 FCC ID: 2BWCR-DL188 Environmental Conditions Temperature: 23.5°C Relative Humidity: 58% ATM Pressure: 100.0 kPa Test Engineer: Allen Lai Supervised by: Max Zhang NOTE N/A Appendix A: DTS Bandwidth Test Result Test Mode Antenna Frequency [MHz] DTS BW [MHz] FL [MHz] FH [MHz] Limit [MHz] Verdict SRD Ant1 2420 0.512 2419.852 2420.364 0.5 PASS SRD Ant1 2445 0.520 2444.848 2445.368 0.5 PASS SRD Ant1 2470 0.520 2469.852 2470.372 0.5 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 2 of 23 Test Graphs SRD-Ant1-2420-PASS SRD-Ant1-2445-PASS Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 3 of 23 SRD-Ant1-2470-PASS Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 4 of 23 Appendix B: Occupied Channel Bandwidth Test Result Test Mode Antenna Frequency [MHz] OCB [MHz] FL [MHz] FH [MHz] Limit [MHz] Verdict SRD Ant1 2420 1.0867 2419.5608 2420.6475 --- --- SRD Ant1 2445 1.0762 2444.5759 2445.6521 --- --- SRD Ant1 2470 1.0680 2469.5772 2470.6452 --- --- Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 5 of 23 Test Graphs SRD-Ant1-2420 SRD-Ant1-2445 Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 6 of 23 SRD-Ant1-2470 Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 7 of 23 Appendix C: Maximum peak conducted output power Test Result Peak Test Mode Antenna Frequency [MHz] Conducted Peak Power [dBm] Conducted Limit [dBm] Verdict SRD Ant1 2420 -8.60 ≤30 PASS SRD Ant1 2445 -8.71 ≤30 PASS SRD Ant1 2470 -8.77 ≤30 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 8 of 23 Test Graphs Peak SRD-Ant1-2420-PASS SRD-Ant1-2445-PASS Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 9 of 23 SRD-Ant1-2470-PASS Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 10 of 23 Appendix D: Maximum peak power spectral density Test Result Test Mode Antenna Frequency [MHz] Result [dBm/3kHz] Limit [dBm/3kHz] Verdict SRD Ant1 2420 -9.17 ≤8.00 PASS SRD Ant1 2445 -9.29 ≤8.00 PASS SRD Ant1 2470 -9.33 ≤8.00 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 11 of 23 Test Graphs SRD-Ant1-2420-PASS SRD-Ant1-2445-PASS Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 12 of 23 SRD-Ant1-2470-PASS Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 13 of 23 Appendix E: Band edge measurements Test Result Test Mode Antenna Ch. Name Frequency [MHz] Ref. Level [dBm] Result [dBm] Limit [dBm] Verdict SRD Ant1 Low 2420 -9.10 -48.87 ≤-29.1 PASS SRD Ant1 High 2470 -9.84 -48.85 ≤-29.84 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 14 of 23 Test Graphs SRD-Ant1-2420-PASS SRD-Ant1-2470-PASS Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 15 of 23 Appendix F: Conducted Spurious Emission Test Result Test Mode Antenna Frequency [MHz] Freq. Range [MHz] Ref. Level [dBm] Result [dBm] Limit [dBm] Verdict SRD Ant1 2420 0~Reference -9.12 -9.12 --- PASS SRD Ant1 2420 30~1000 -9.12 -62.41 ≤-29.12 PASS SRD Ant1 2420 1000~26500 -9.12 -37.52 ≤-29.12 PASS SRD Ant1 2445 0~Reference -9.28 -9.28 --- PASS SRD Ant1 2445 30~1000 -9.28 -61.36 ≤-29.28 PASS SRD Ant1 2445 1000~26500 -9.28 -37.22 ≤-29.28 PASS SRD Ant1 2470 0~Reference -9.28 -9.28 --- PASS SRD Ant1 2470 30~1000 -9.28 -61.8 ≤-29.28 PASS SRD Ant1 2470 1000~26500 -9.28 -36.15 ≤-29.28 PASS Note: offset(dB) in Reference test plots = cable loss(dB) + attenuator factor(dB); For spurious emissions plots from 30MHz to 26.5GHz, the cable loss and attenuator factors have been set in the 'Input Correction' of the Spectrum Analyzer during the test. Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 16 of 23 Test Graphs SRD-Ant1-2420-0~Reference-PASS SRD-Ant1-2420-30~1000-PASS Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 17 of 23 SRD-Ant1-2420-1000~26500-PASS SRD-Ant1-2445-0~Reference-PASS Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 18 of 23 SRD-Ant1-2445-30~1000-PASS SRD-Ant1-2445-1000~26500-PASS Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 19 of 23 SRD-Ant1-2470-0~Reference-PASS SRD-Ant1-2470-30~1000-PASS Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 20 of 23 SRD-Ant1-2470-1000~26500-PASS Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 21 of 23 Appendix G: Duty Cycle Test Result Test Mode Antenna Frequency [MHz] ON Time [ms] Period [ms] Duty Cycle [%] Duty Cycle Factor [dB] SRD Ant1 2420 1.27 1.40 90.71 0.42 SRD Ant1 2445 1.28 1.40 91.43 0.39 SRD Ant1 2470 1.27 1.39 91.37 0.39 Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 22 of 23 Test Graphs NTNV-SRD-Ant1-2420 NTNV-SRD-Ant1-2445 Appendix Test Data of the Report No.: TZ0035260513FRF02 Page 23 of 23 NTNV-SRD-Ant1-2470

Report No.: TZ0035260513FRF12 Page 1 of 30 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Tongzhou Testing Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Tongzhou Testing Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report apply only to the specific sample(s) tested under stated test conditions. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. TEST REPORT Report Number : TZ0035260513FRF12 Product Name : RC Car Model/Type reference : DL-188, DL-178, DL-168, DL-158, DL-148, DL-138, DL-128, DL-118 FCC ID : 2BWCR-DL188 Prepared for : Shantou Dilun Technology Co., Ltd. No. 13, Dachewei Middle Road, Yongxin Industrial Zone, Yongxin Village, Lianshang Town, Chenghai District, Shantou City, Guangdong Province, China Prepared By : Shenzhen Tongzhou Testing Co.,Ltd. 1st Floor, Building 1, Haomai High-tech Park, Huating Road 387, Dalang Street, Longhua, Shenzhen, China Standards : FCC CFR Title 47 Part 15C, ANSI C63.10-2020 + Cor.1-2023 Date of Test : 2026-05-12 ~ 2026-05-20 Date of Issue : 2026-05-20 Prepared by : Nancy Li Reviewed by : Allen Lai Approved by : Max Zhang (Authorized Officer) Report No.: TZ0035260513FRF12 Page 2 of 30 ** Report Revise Record ** Report Version Revise Time Issued Date Valid Version Notes V1.0 / 2026-05-20 Valid Initial release Report No.: TZ0035260513FRF12 Page 3 of 30 TABLE OF CONTENTS 1. G E N E R A L I N F O R M A T I O N ....................................................... 4 1.1. Client Information ................................................................................................................... 4 1.2. Description of Device (EUT) ................................................................................................... 4 1.3. Wireless Function Tested in this Report .............................................................................. 4 1.4. EUT configuration ................................................................................................................... 5 1.5. Description of Test Facility .................................................................................................... 5 1.6. Statement of the Measurement Uncertainty ......................................................................... 6 1.7. Measurement Uncertainty ...................................................................................................... 6 1.8. Description of Test Modes ..................................................................................................... 6 1.9. Frequency of Channels .......................................................................................................... 6 2. T E S T M E T H O D O L O G Y ............................................................ 8 2.1. EUT Configuration .................................................................................................................. 8 2.2. EUT Exercise ........................................................................................................................... 8 2.3. Test Sample ............................................................................................................................. 8 3. S Y S T E M T E S T C O N F I G U R A T I O N .............................................. 9 3.1. Justification ............................................................................................................................. 9 3.2. EUT Exercise Software ........................................................................................................... 9 3.3. Special Accessories ............................................................................................................... 9 3.4. Block Diagram/Schematics .................................................................................................... 9 3.5. Equipment Modifications ....................................................................................................... 9 3.6. Test Setup ................................................................................................................................ 9 4. S U M M A R Y O F T E S T R E S U L T S ............................................... 10 5. T E S T R E S U L T .................................................................... 11 5.1. On Time and Duty Cycle ....................................................................................................... 11 5.2. Maximum Peak Conducted Output Power Measurement ................................................. 12 5.3. Power Spectral Density Measurement ................................................................................ 13 5.4. 6 dB Spectrum Bandwidth and Occupied Channel Bandwidth Measurement ............... 14 5.5. Radiated Emissions Measurement ...................................................................................... 15 5.6. Conducted Spurious Emissions and Band Edges Test .................................................... 23 5.8. Band-edge measurements for radiated emissions ........................................................... 25 5.9. Antenna Requirements ......................................................................................................... 28 6. L I S T O F M E A S U R I N G E Q U I P M E N T ......................................... 29 7. T E S T S E T U P P H O T O G R A P H S O F E U T ..................................... 30 8. E X T E R I O R P H O T O G R A P H S O F E U T ........................................ 30 9. I N T E R I O R P H O T O G R A P H S O F E U T ........................................ 30 Report No.: TZ0035260513FRF12 Page 4 of 30 1. G E N E R A L I N F O R M A T I O N 1.1. Clie…

Text truncated - open the document above for the full version.

Shenzhen Ouchao Technology Co., Ltd 303, Building 34, Longzhu Garden, Xixiang Street, Bao’an District, Shenzhen, China 2.4G PCB Antenna Datasheet Customer Name Product name 2.4G PCB Antenna Customer Part Name Date: 2026/04/28 Prepared by: Reviewed by Antenna Specifications 1. Frequency Range: 2410 MHz – 2470 MHz 2.Antenna Type: PCB Antenna 3.Impedance: 50Ω 4.Transmission Power: -10 dBm Description 2400-2500MHz Unit VSWR ≤1.5 DB Average Antenna Gain ≤2 DB Average Antenna Gain ≥38 ％ Frequency Efficiency（％） Average Gain （dB） Peak Gain（dBi） 2400 37.8 -4.76 1.09 2450 38.3 -4.82 1.13 2500 37.9 -4.78 1.10

Report No.: TZ0035260513PH01 Page 1 of 2 Test Setup Photos of the EUT Radiated Emission Below 1GHz Radiated Emission Above 1GHz RF Conducted Test Report No.: TZ0035260513PH01 Page 2 of 2
