2BWD4INTTYPEAIntellisteer Wireless Steering

1 2 Revision Description A First Edition B Second Edition Revision History USER MANUAL Revision B – 5/29/2017 © 2013 Canada Metal (Pacific) Limited. All rights reserved. The information contained in this document is the sole property of Canada Metal (Pacific) Limited. Any reproduction in part or whole without the written permission of Canada Metal (Pacific) Limited is prohibited. Canada Metal (Pacific) Limited will not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance or use of this document. To the best of our knowledge, the information in this document was correct at the time it was produced. However, Canada Metal (Pacific) Limited cannot accept liability for any inaccuracies or omissions it may contain. In addition, our policy of continuous product improvement may change specifications without notice. As a result, Canada Metal (Pacific) Limited cannot accept liability for any differences between the product and this document. Please visit www.intellisteer.com to en- sure you have the most up-to-date version of the documentation for your product. 3 4 CONTENTS 1 Introduction. ................................................................................ 4 2 Installation. ................................................................................. 6 2.1 Included Parts ......................................................................... 6 2.2 Tools Required ........................................................................ 6 2.3 Battery Installation or Replacement .................................... 7 2.4 Mounting Receiver ................................................................. 8 2.5 Crimp Connections ................................................................ 8 2.6 Connecting To A Standalone Drive Unit .............................. 9 2.7 Connecting To An Autopilot System .................................. 10 2.8 Power Cable Gauge Recommendations .......................... 12 2.9 Verify Installation .................................................................. 13 3 Operation. ................................................................................. 14 3.1 Power On/Off ........................................................................ 14 3.2 Steering ................................................................................. 15 3.3 Auto Shut Off ........................................................................ 16 3.4 Overload Protection ............................................................. 16 4 Adding Or Replacing A Pendant. ........................................... 17 4.1 Pairing Pendant To Receiver .............................................. 17 5 Appendix. .................................................................................. 18 5.1 Warnings ............................................................................... 18 5.2 Troubleshooting .................................................................... 19 5.3 Specification .......................................................................... 20 5.4 FCC/CE Statements ............................................................ 21 5.5 Limited Warranty .................................................................. 21 1. Introduction Congratulations on your purchase of an Intellisteer Wire- less Controller. This simple yet powerful system is designed to free you from the need to hand steer your boat from the helm, providing wireless jog steering control from anywhere on your boat. There is an Intellisteer model suitable for almost any boat. Whether you have cable or hydraulic steering, with an au- topilot or without, Intellisteer has a configuration that can provide you with the freedom of wireless steering. This manual covers the installation and operation of the standalone version of the Intellisteer, designed to interface with an existing au- topilot and drive installation whether or not the existing course computer is opera- tional. As long as the drive unit is functional, Intellisteer can control it. 5 6 If you do not have an existing autopilot installation, there are other Intellisteer system packages which bundle the wireless controller with a specially designed steering drive unit. These include: • Intellisteer Type R provides remote steering for auxiliary or primary outboards or even sterndrives • Intellisteer Type S provides a helm replacement for remote steering of cable steered boats • Intellisteer Type T provides a helm replacement for remote steering of cable steered boats with tilt steering • Intellisteer Type H provides remote steering for hydraulically steered boats. Instructions covering the installation of these Intellisteer steering drives are included with the drive units in the system kits. More information can be found at www.intellisteer.com 2. Installation The Intellisteer Wireless Controller is designed to be used with any reversing steering drive unit requiring less than 25A peak operating current, whether mechanical or hydraulic. While Intellisteer can be integrated with an Autopilot Course Computer, it does not require one to operate. It is not suita- ble for use with “all in one” cockpit autopilots with an integrat- ed course computer. It is also not suitable for use on boats with a positive ground system. It should not be fitted to boats where the maximum horse- power of the engines exceeds the maximum horsepower rating for the vessel as stated on the vessel manufacturers tag. 2.1 Included Parts Before installation, check your kit includes all required parts: • Intellisteer Wireless Receiver • Intellisteer Wireless Pendant • Pendant Lanyard • 7 Blue Crimp Connectors (14- 16 GA) • 4 Red Crimp Connectors (18-22 GA) • 25A Inline fuse & Fuse Holder • 4 Mounting Screws 2.2 Tools Required • Medium (#1) Phillips screwdriver for Receiver mounting screws. • Multi-meter for troubleshooting • Hand crimp tool (double action recommended) 7 …

Text truncated - open the document above for the full version.

CMP Group Ltd 7733 Progress Way, Delta, BC, Canada Delta City Canada Date: [June 30, 2026] Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BWD4INTTYPEA FRN: 0038491197 US Agent – Attestation Statement / Part 2.911(d)(7) CMP Group Ltd certifies, that as of [June 30, 2026], we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: 2BWD4INTTYPEA. CMP Group Ltd , accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission- related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of CMP Group Ltd for FCC ID: 2BWD4INTTYPEA. Designated Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, Company: CMP Group Ltd Designated Agent: FCC US Agent, LLC Company Representative: Ruari Macleod Designated Agent Representative: Tim Payne Signature: Email: [email protected] Tel:+1(604)942-2010 Signature:

CMP Group Ltd June 18, 2026 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for FCC ID: 2BWD4INTTYPEA CMP Group Ltd (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, (Applicant signature): (Applicant printed name): Ruari Macleod CMP Group Ltd June 18, 2026 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for FCC ID: 2BWD4INTTYPEA CMP Group Ltd (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature (Applicant printed name): Ruari Macleod

CMP Group Ltd June 18, 2026 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR Intellisteer Wireless Steering / INTREMOTE /FCCID: 2BWD4INTTYPEA To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the Schematics, Block diagram, Operation description required to be submitted with this application be permanently withheld from public review. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Signature: Name Ruari Macleod Position Engineering Manager Company Name CMP Group Ltd Address 7733 Progress Way, Delta, BC, Canada Tel +1(604) 940-2010 Fax +1(604) 940-2650 Email [email protected]

CMP Group Ltd June 18, 2026 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen NCT Testing Technology Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name Ruari Macleod Position Engineering Manager Company Name CMP Group Ltd Address 7733 Progress Way, Delta, BC, Canada Tel +1(604) 940-2010 Fax +1(604) 940-2650 Email [email protected]

Report No.: NCT260221236E1-1 FCC ID : 2BWD4INTTYPEA Product Name : Intellisteer Wireless Steering Model : INTREMOTE Report No.: NCT260221236E1-1 Photos of EUT External Report No.: NCT260221236E1-1 Report No.: NCT260221236E1-1 Report No.: NCT260221236E1-1

Made in PRC Fabriqué en RPC FCC ID: 2BWD4INTTYPEA INTREMOTE 03LABOC15332 22mm x 15mm Label location

Report No.: NCT260221236E1-1 Internal Report No.: NCT260221236E1-1 Report No.: NCT260221236E1-1 Report No.: NCT260221236E1-1 ANT

FCC ID: 2BWD4INTTYPEA RF Exposure Evaluation According to KDB 447498 D01 General RF Exposure Guidance v06 and part 2.1093， Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f (GHz) ] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Here, Note: EIRP = Peak Level – 95.2 Max Power = EIRP – Gain Gain = 3dBi So a SAR test is not required Freque ncy (MHz) Peak Level (dBuV/m) Max Power (dBm) Target power tolerance (dB) Max tune up power tolerance (dBm) Max Power (mW) Min. Distanc e (mm) Calc. threshol ds limit 315.00 96 67.62 -30.58 -30±1 -29 0.0013 5.00 0.0004 3.0

深圳市创遥科技有限公司 SHENZHEN C&Y TECHNOLOGY CO.,LTD 文件名称 产品名称 产品型号 图纸编号 生效日期 遥控器 CY2123 Description：Antenna specification Description: The remote control uses PCB board antenna radiation power, antenna width 2.0 mm, 3dBi gain, SWR < 2.0 制作 审核 核准

Page 1 of 29 FCC TEST REPORT FCC ID: 2BWD4INTTYPEA Product : Intellisteer Wireless Steering Model Name : INTREMOTE Brand : Report No. : NCT260221236E1-1 Prepared for CMP Group Ltd 7733 Progress Way, Delta, BC, Canada Prepared by Shenzhen NCT Testing Technology Co., Ltd. A101&2F B2, Fuqiao 6th Area, Xintian Community, Fuhai Street, Baoan District, Shenzhen, People’s Republic of China TEL: 400-8868-419 FAX: 86-755-27790922 Report No.: NCT260221236E1-1 Page 2 of 29 1 TEST RESULT CERTIFICATION Applicant’s name : CMP Group Ltd Address : 7733 Progress Way, Delta, BC, Canada Manufacture's name : SHENZHEN CHUANGYAO SCIENCE & TECHNOLOGY CO.,LTD Address : 5th Floor block 27,Lianchuang Technical Zone, bulan road, Longgang district, Shenzhen,China Product name : Intellisteer Wireless Steering Model name : INTREMOTE Standards : FCC CFR47 Part 15 Section 15.231 Test procedure : ANSI C63.10:2020 Date of test : May 18, 2026 - May. 31, 2026 Date of Issue : June 18, 2026 This device described above has been tested by NCT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NCT, this document may be altered or revised by NCT, personal only, and shall be noted in the revision of the document. Test Engineer: Keven Wu / Engineer Technical Manager: Henry Wang / Manager Report No.: NCT260221236E1-1 Page 3 of 29 Table of Contents Page 1 TEST RESULT CERTIFICATION 2 2. SUMMARY OF TEST RESULTS 5 2.1 EST FACILITY 6 2.2 MEASUREMENT UNCERTAINTY 6 3. GENERAL INFORMATION 7 3.1 GENERAL DESCRIPTION OF EUT 7 3.2 DESCRIPTION OF TEST MODES 8 3.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 3.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 8 3.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 4. EMC EMISSION TEST 11 4.1 CONDUCTED EMISSION MEASUREMENT 11 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 11 4.1.2 TEST PROCEDURE 12 4.1.3 DEVIATION FROM TEST STANDARD 12 4.1.4 TEST SETUP 12 4.1.1 EUT OPERATING CONDITIONS 12 4.1.6 TEST RESULTS 12 4.2 RADIATED EMISSION MEASUREMENT 13 4.2.1 RADIATED EMISSION LIMITS 13 4.2.2 TEST PROCEDURE 14 4.2.3 TEST SETUP 15 4.2.4 EUT OPERATING CONDITIONS 15 4.2.5 TEST RESULTS 16 5. BANDWIDTH TEST 22 5.1 APPLIED PROCEDURES / LIMIT 22 5.2 TEST PROCEDURE 22 5.3 DEVIATION FROM STANDARD 22 5.4 TEST SETUP 22 5.5 EUT OPERATION CONDITIONS 22 5.6 TEST RESULTS 23 6. CALCULATION OF AVERAGE FACTOR 24 7. DWELL TIME 26 7.1 APPLICABLE STANDARD 26 7.2 TEST PROCEDURE 26 7.5 EUT OPERATION CONDITIONS 26 Report No.: NCT260221236E1-1 Page 4 of 29 Table of Contents Page 7.6 TEST RESULTS 27 8. ANTENNA REQUIREMENT 28 9. TEST SETUP PHOTO 29 10. EUT CONSTRUCTIONAL DETAILS 29 Report No.: NCT260221236E1-1 Page 5 of 29 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.231) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A / 15.209,15.231b Fundamental &Radiated Spurious Emission Measurement PASS / 15.231c Occupy Bandwidth PASS / 15.231a Dwell time PASS / 15.203 Antenna Requirement PASS / NOTE: (1)” N/A” denotes test is not applicable in this Test Report Report No.: NCT260221236E1-1 Page 6 of 29 2.1 EST FACILITY Site Description EMC Lab. : Accredited by CNAS, 2022-09-27 The certificate is valid until 2028.01.07 The Laboratory has been assessed and proved to be in compliance with CNAS-CL01:2006 (identical to ISO/IEC 17025:2017) The Certificate Registration Number is L8251 Designation Number: CN1347 Test Firm Registration Number: 894804 Accredited by A2LA, June 14, 2023 The Certificate Registration Number is 6837.01 Accredited by Industry Canada, November 09, 2018 The Conformity Assessment Body Identifier is CN0150 Company Number: 30806 Name of Firm : Shenzhen NCT Testing Technology Co., Ltd. Site Location : A101&2F B2, Fuqiao 6th Area, Xintian Community, Fuhai Street, Baoan District, Shenzhen, People’s Republic of China 2.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 Parameter Uncertainty RF output power, conducted ±1.0dB Power Spectral Density, conducted ±2.2dB Radio Frequency ± 1 x 10 -6 Bandwidth ± 1.5 x 10 -6 Time ±2% Duty Cycle ±2% Temperature ±1°C Humidity ±5% DC and low frequency voltages ±3% Conducted Emissions (150kHz~30MHz) 3.64dB Radiated Emission(9KHz~30MHz) 4.51dB Radiated Emission(30MHz~1GHz) 5.03dB Radiated Emission(1GHz~25GHz) 4.74dB Radiated Emission(25GHz~40GHz) 3.38dB Remark: The coverage Factor (k=2), and measurement Uncertainty for a level of Confidence of 95% Report No.: NCT260221236E1-1 Page 7 of 29 3. GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT Product Name : Intellisteer Wireless Steering Model Name : INTREMOTE Sample ID : 260221236A# Sample(s) Status: : Engineer sample Series Model : / Model Different.: : / Operating frequency : 315.0096 MHz Number of Channels : 1 channels Type of Modulation : ASK Antenna installation : Internal antenna Antenna Gain : 3 dBi Power supply : DC 3V from Battery Hardware Version : V1.0 Software Version : V1.0 Remark：the Antenna gain is provided by customer from Antenna spec. and the laboratory will not be responsible for the accumulated calculation results which covers the information provided by the applicant. Report No.: NCT260221236E1-1 Page 8 of 29 3.2 DESCRIPTION OF TEST MODES For All Emission Final Test Mode Description Transmitting mode Keep the EUT in continuously transmitting mode Note: (1) Fully-charged battery is used during the test 3.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED Radiated Emission Test Radiated Spurious 3.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) The EUT has been tested as an independent unit together with other necessary accessories or support units. The …

Text truncated - open the document above for the full version.

Report No.: NCT260221236E1-1 FCC ID : 2BWD4INTTYPEA Product Name : Intellisteer Wireless Steering Model : INTREMOTE Report No.: NCT260221236E1-1 Photos of Test Setup Report No.: NCT260221236E1-1
