2BWSR-BG09Dash cam

High Definition Dashcam Smartphone WiFi Version OPERATING INSTRUCTION Installation Notes ①Turn off the car engine. ②Insert the TF card into the recorder card slot correctly. [Note] Please use a high-speed TF card (ABOVE CLASS10), the capacity is not less than 2MB, the TF card supports up to 128GB. ③Connect the red power line to the 12V power supply, the white ACC ignition control line, and the black ground. Start the engine, check that the machine is installed correctly, the red light is on and flashing, and the machine starts to enter the recording state. ④This manual is a general version, and the functions involved may be slightly different from the model you purchased. After comparison and factory test, it has little impact on the use of this model. Key function description SWITCH In the power-on state, short press to start/pause the recording function, and long press for 3 seconds to turn off. PHOTO In the recording state, short press this key to take pictures. In the power-on state, long press this button to restore the factory settings. It can be used to retrieve the default WiFi account and connection password. RESET After the power is turned on, gently poke the button with a sharp object to reset and restart the system. LED Indicator light status, can be used to check whether the car recorder is in some normal state. Built-in red and blue lights. The red colour indicates the WiFi operation status, when the hotspot is not connected, the red light stays on for a long time; when the hotspot is connected, the red light flashes once every second. The blue light indicates the recording status, when recording normally, the blue light flashes once per second; when recording stops or does not work, the blue light stays on for a long time. MIC Used to record the sound at the time while recording. Default is on, APP can set the default status within the settings after connecting to the hotspot of the recorder. INDICATOR STATUS DESCRIPTION WORKING CONDITION INDICATOR STATUS WiFi connected video record The red light is always on, and the blue light flashes every second No video recording Red and blue light are always on WiFi not connected video record Red light flashes fast, blue light flashes every second INSTALLING ⚫ It is the best to mount the dash camera in the upper edge of the car’s front windshield, beneath the rear-view mirror or next to it. ⚫ Clean the mounting area carefully and ensure the windshield is not damp. ⚫ Ensure there is unobstructed view to the camera and that the vision of the driver is not blocked. ⚫ Ensure that the selected mounting area is suitable for the length of the USB charging cable ⚫ Remove the protective film of the fastening tape of the camera holder and fasten the holder by pressing it firmly on the windshield ⚫ Insert an empty microSD card in the dedicated slot. ⚫ Connect the camera carefully to camera holder and connect the USB charging cable. The USB charging cable is long enough so that in most passenger cars it can be mounted along the edge of the windshield to the charging socket. ⚫ The camera switches on automatically when the power is turned on. INSTALL POSITION SOFTWARE INSTALLATION AND OPERATION APP download and installation 1. Wi-Fi function allows to transmit recordings from the dash camera directly to the mobile device and to view them from there. 2. Download “FinalCamX” app for Android or iOS from Google play or Apple store. or scan the QR code to install on the right: 3. Start the Wi-Fi function of the dash camera by power on the camera. Wi-fi will be auto turn on once camera is turn on. 4. Searched the Wi-fi name and enter password to use the APP: WiFi Name: CAR_DVR_XXXX Password: 1234567890 VIDEO/PHOTO PLAYBACK Playback on APP: Open the mobile APP to find videos and photos. COMPUTER: The recordings can also be viewed in the computer. For this you need a separate memory card reader for microSD card. The recordings are in a separate file on the card and they can be freely used and downloaded in to the computer. No separate program is needed for downloading or viewing. FCC Caution. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one ormore of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body.

Attestation Statements Date: 2026-06-26 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for(FCC ID: 2BWSR-BG09) Shenzhen Bigaoni Electronics Co., Ltd, the undersigned, hereby authorize FCC US Agent, LLC to act as our designated agent for service of process, Shenzhen Bigaoni Electronics Co., Ltd accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. FCC US Agent, LLC accepts the responsibility to act as designated agent for service of process. Applicant Information： Company name: Shenzhen Bigaoni Electronics Co., Ltd Contact Name: David Liu Address: Room 228, Zhongzhengcaifu Building, No.6093 Bao’an Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen City, China. Telephone No: 18718778212 Email: [email protected] FRN: 0038585899 Signature: David Liu Agent Information: Company Name: FCC US Agent, LLC Address:3722 Illinois Avenue, Saint Charles, IL, 60174, USA FRN: 0033402884 Contact Name: Tim Payne Telephone No: 708-571-3148 Email: [email protected] Signature: Tim Payne

Rev 1/26/2023 Shenzhen Bigaoni Electronics Co., Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-06-26 FCC ID: 2BWSR-BG09 Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing Shenzhen Bigaoni Electronics Co., Ltd certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Shenzhen Bigaoni Electronics Co., Ltd certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing Shenzhen Bigaoni Electronics Co., Ltd certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Applicant: Shenzhen Bigaoni Electronics Co., Ltd Address: Room 228, Zhongzhengcaifu Building, No.6093 Bao’an Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen City, China. Contact Person: David Liu Tel.: 18718778212 Email: [email protected] Sincerely, Signature:

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 Shenzhen Bigaoni Electronics Co., Ltd Date：2026-06-26 Product Model Number: BG09, BG10, BG11, BG12, BG13, BG14, BG15, BG16, BG17 FCC ID：2BWSR-BG09 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. Signature: By: David Liu Contact Listed on FCC Wesbite Title: CEO Email: [email protected] On behalf of: Shenzhen Bigaoni Electronics Co., Ltd

Shenzhen Bigaoni Electronics Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: June 26, 2026 Subject; Request for Confidentiality FCC ID: 2BWSR-BG09 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: David Liu Title: CEO

Shenzhen Bigaoni Electronics Co., Ltd Declaration Letter of Model Difference Date: 2026-06-26 FCC ID: 2BWSR-BG09 Tested Model Number: BG09 Adding Model Number(s): BG10, BG11, BG12, BG13, BG14, BG15, BG16, BG17 All Adding Model Number(s) is/are same electrically identical as Tested Model Number. Only difference in model name. Yours Sincerely, Applicant: Shenzhen Bigaoni Electronics Co., Ltd Address: Room 228, Zhongzhengcaifu Building, No.6093 Bao’an Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen City, China. Contact Person: David Liu Tel.: 18718778212 Email: [email protected] Sincerely, Signature:

Page 1 of 4 Report No.: LGT26F077 Appendix - External Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 4 Report No.: LGT26F077 Appendix - External Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 4 Report No.: LGT26F077 Appendix - External Photographs of EUT Constructional Details Photo 5 Photo 6 Page 4 of 4 Report No.: LGT26F077 Appendix - External Photographs of EUT Constructional Details Photo 7 Photo 8

Label Size:18*37mm Model Number: BG09 FCC ID: 2BWSR-BG09

Page 1 of 4 Report No.: LGT26F077 Appendix - Internal Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 4 Report No.: LGT26F077 Appendix - Internal Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 4 Report No.: LGT26F077 Appendix - Internal Photographs of EUT Constructional Details Photo 5 Photo 6 Wi-Fi ANT Page 4 of 4 Report No.: LGT26F077 Appendix - Internal Photographs of EUT Constructional Details Photo 7

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 8 EMF TEST REPORT Product Name: Dash cam Model Number: BG09, BG10, BG11, BG12, BG13, BG14, BG15, BG16, BG17 FCC ID: 2BWSR-BG09 Issued For : Shenzhen Bigaoni Electronics Co., Ltd Room 228, Zhongzhengcaifu Building, No.6093 Bao’an Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen City, China. Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26F077HA02 Sample Received Date: Jun. 09, 2026 Date of Test: Jun. 09, 2026 ~ Jun. 24, 2026 Date of Issue: Jun. 24, 2026 Report No.: LGT26F077HA02 Page 2 of 8 TEST REPORT CERTIFICATION Applicant: Shenzhen Bigaoni Electronics Co., Ltd Address: Room 228, Zhongzhengcaifu Building, No.6093 Bao’an Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen City, China. Manufacturer: Shenzhen Bigaoni Electronics Co., Ltd Address: Room 228, Zhongzhengcaifu Building, No.6093 Bao’an Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen City, China. Product Name: Dash cam Trademark: Begonia Model Number: BG09, BG10, BG11, BG12, BG13, BG14, BG15, BG16, BG17 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47 CFR §2.1091 KDB 447498 D01 General RF Exposure Guidance v06 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT26F077HA02 Page 3 of 8 TABLE OF CONTENTS 1 . GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST LABORATORY 5 2 . FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 EUT OPERATION CONDITION 7 2.4 CLASSIFICATION 7 2.5 TEST RESULT 8 Report No.: LGT26F077HA02 Page 4 of 8 Revision History Rev. Issue Date Revisions 00 Jun. 24, 2026 Initial Issue Report No.: LGT26F077HA02 Page 5 of 8 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name: Dash cam Test Model Number: BG09 Series Number: BG10, BG11, BG12, BG13, BG14, BG15, BG16, BG17 Model Difference: Only difference in model name. Frequency Bands: 2.4G WLAN 802.11b/g/n(20MHz): 2412~2462MHz 802.11n(40MHz):2422~2452MHz Rating: Input: DC 5V-18V Hardware Version: N/A Software Version: N/A 1.2 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 Report No.: LGT26F077HA02 Page 6 of 8 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 0.3-3.0 614 1.63 *(100) 3.0-30 1842/f 4.89/f *(900/f 2 ) 30-300 61.4 0.163 1.0 300 - 1500 -- -- F/300 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 1.34-30 824/f 2.19/f *(180/f 2 ) 30-300 27.5 0.073 0.2 300 - 1500 -- -- F/1500 1500 – 100000 -- -- 1.0 F= Frequency in MHz * = Plane-wave equivalent power density. Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. Report No.: LGT26F077HA02 Page 7 of 8 2.3 EUT OPERATION CONDITION EUT was enabled to transmit and receive at lowest, middle and highest channels. 2.4 CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance from the antenna should be included in the User manual. So, this device is classified as Mobile device. Report No.: LGT26F077HA02 Page 8 of 8 2.5 TEST RESULT Turn up Result Mode Turn up Power 2.4G WIFI-802.11b 16±1dBm 2.4G WIFI-802.11g 15±1dBm 2.4G WIFI-802.11n(HT20) 15±1dBm 2.4G WIFI-802.11n(HT40) 15±1dBm The MPE result of worst mode: RF Function Max Turn up Power (dBm) Max Turn up Power (mW) ANT Gain (dBi) ANT Gain (gain of antenna in linear scale) Power Density (mW/cm²) Limit (mW/cm²) Ratio Result 2.4G WIFI 17.00 50.12 1.42 1.39 0.014 1 0.014 Pass Note: 1. The RF Exposure is less than the limit, complies with the exemption requirements. ※※※※※END OF THE REPORT※※※※※

Shenzhen hetuo Science Co.,Ltd. T003 Antenna Specification ProjectT003 Antenna RevisionA1 Product Descriptiononboard Product No DATE2025.05.13 Antenna Tpe y PCB Antenna ShenzhenhetuoScienceCo.,Ltd. ProductOverview&Dimension Front 10mm 4mm ShenzhenhetuoScienceCo.,Ltd. Purpose ThisreportistomeasuretheperformanceofBTantennaforT003.Theantenna operatingfrequencyat2.4~2.5GHz,Alltestdataareshowedasbelow. Content 1.ProductOverview&Dimension 2.Testsystem 3.AntennaMatchingNetwork 4.TestResult 4.1S11Parameter 4.2Testcoordinate 4.32DPattern 4.4OTAData 4.5BTBootmeasured 5.AntennaAssembly&environmentalprocessing 3 ShenzhenhetuoScienceCo.,Ltd. 2.TestSystem SequenceNumberTestItemequipment SparameterVSWRAgilent5071C&Agilent5062A OTATestTRP&TISCMW500&CMW270 ETS&SATIMO ETS&SATIMO Gain&EfficiencyGain&Efficiency Agilent5071C 4 ShenzhenhetuoScienceCo.,Ltd. S11—(BTANT)-L/R ShenzhenhetuoScienceCo.,Ltd. TestResult Samplestatus&coordinates ShenzhenhetuoScienceCo.,Ltd. TestResult Gain&Efficiency——BT-ANT(L) Frequency(MHz)Efficiency(%)PeakGAIN(dBi) 240025.871.08 241027.620.89 242028.320.59 243029.670.38 244031.910.47 245032.401.26 246030.911.42 247029.451.11 248028.471.34 249027.180.78 250026.461.38 ShenzhenhetuoScienceCo.,Ltd. TestResult 2D&3D——BT-ANT ShenzhenhetuoScienceCo.,Ltd. TestResult 2D&3D——BT-ANT ShenzhenhetuoScienceCo.,Ltd. TestResult 2D&3D——BT-ANT 深圳市合拓科技有限公司 Thanksforyourcomment! Shenzhen hetuo Science Co.,Ltd. 地址深圳市宝安区西乡恒丰工业城 C6 栋 1202B Address: 1202B, Building C6, Hengfeng Industrial City, Xixiang, Bao 'an District, Shenzhen RF:

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 62 RF TEST REPORT Product Name: Dash cam Model Number: BG09, BG10, BG11, BG12, BG13, BG14, BG15, BG16, BG17 FCC ID: 2BWSR-BG09 Issued For : Shenzhen Bigaoni Electronics Co., Ltd Room 228, Zhongzhengcaifu Building, No.6093 Bao’an Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen City, China. Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26F077RF02 Sample Received Date: Jun. 09, 2026 Date of Test: Jun. 09, 2026 ~ Jun. 24, 2026 Date of Issue: Jun. 24, 2026 Report No.: LGT26F077RF02 Page 2 of 62 TEST REPORT CERTIFICATION Applicant: Shenzhen Bigaoni Electronics Co., Ltd Address: Room 228, Zhongzhengcaifu Building, No.6093 Bao’an Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen City, China. Manufacturer: Shenzhen Bigaoni Electronics Co., Ltd Address: Room 228, Zhongzhengcaifu Building, No.6093 Bao’an Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen City, China. Product Name: Dash cam Trademark: Begonia Model Number: BG09, BG10, BG11, BG12, BG13, BG14, BG15, BG16, BG17 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2020 + Cor.1-2023 PASS Prepared by: Approved by: Chris Chen Vita Li Engineer Technical Director Report No.: LGT26F077RF02 Page 3 of 62 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST LABORATORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 RADIATED EMISSION MEASUREMENT 15 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 25 4.1 LIMIT 25 4.2 TEST PROCEDURE 25 4.3 DEVIATION FROM STANDARD 25 4.4 TEST SETUP 25 4.5 EUT OPERATION CONDITIONS 25 4.6 TEST RESULTS 25 5. POWER SPECTRAL DENSITY TEST 26 5.1 LIMIT 26 5.2 TEST PROCEDURE 26 5.3 DEVIATION FROM STANDARD 26 5.4 TEST SETUP 26 5.5 EUT OPERATION CONDITIONS 26 5.6 TEST RESULTS 26 6. BANDWIDTH TEST 27 6.1 LIMIT 27 6.2 TEST PROCEDURE 27 6.3 DEVIATION FROM STANDARD 27 6.4 TEST SETUP 27 6.5 EUT OPERATION CONDITIONS 27 6.6 TEST RESULTS 27 Report No.: LGT26F077RF02 Page 4 of 62 7. PEAK OUTPUT POWER TEST 28 7.1 LIMIT 28 7.2 TEST PROCEDURE 28 7.3 DEVIATION FROM STANDARD 28 7.4 TEST SETUP 28 7.5 EUT OPERATION CONDITIONS 28 7.6 TEST RESULTS 28 8. ANTENNA REQUIREMENT 29 8.1 STANDARD REQUIREMENT 29 8.2 EUT ANTENNA 29 APPENDIX I - TEST RESULTS 30 1. DUTY CYCLE 30 2. BANDWIDTH 35 3. MAXIMUM CONDUCTED OUTPUT POWER 44 4. MAXIMUM POWER SPECTRAL DENSITY 45 5. UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS 50 APPENDIX II - MEASUREMENT PHOTOS 62 Report No.: LGT26F077RF02 Page 5 of 62 Revision History Rev. Issue Date Revisions 00 Jun. 24, 2026 Initial Issue Report No.: LGT26F077RF02 Page 6 of 62 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020 + Cor.1-2023. Report No.: LGT26F077RF02 Page 7 of 62 1.1 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Occupied Channel Bandwidth ±0.46% 2 RF Output Power, Conducted ±0.71dB 3 Power Spectral Density, Conducted ±1.57dB 4 Unwanted Emission, Conducted ±0.63dB 5 Conducted emission ±2.80dB 6 All Emissions, Radiated (0.009-30MHz) ±2.16dB 7 All Emissions, Radiated (30MHz-1GHz) ±4.61dB 8 All Emissions, Radiated (1GHz-18GHz) ±5.49dB 9 All Emissions, Radiated (18GHz-40GHz) ±4.31dB 10 Temperature ±0.5°C 11 Humidity ±2% 12 Duty Cycle ±2.3% Note: The measurement uncertainty is not included in the test result. Report No.: LGT26F077RF02 Page 8 of 62 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: Dash cam Test Model Number: BG09 Series Number: BG10, BG11, BG12, BG13, BG14, BG15, BG16, BG17 Model Difference: Only difference in model name. Product Description: Operation Frequency: 802.11b/g/n(20MHz): 2412~2462MHz 802.11n(40MHz):2422~2452MHz Modulation Type: 802.11b(DSSS):CCK,DQPSK,DBPSK 802.11g(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM Number of Channel: 802.11b/g/n(20MHz): 11CH 802.11n(40MHz): 7CH Antenna Designation: PCB Antenna Antenna Gain(dBi): 1.42 Channel List: Please refer to the Note 3.…

Text truncated - open the document above for the full version.

Report No.: LGT26F077RF02 Page 44 of 62 3. Maximum Conducted Output Power 3.1 Test Result 3.1.1 Power Mode TX Type Frequency (MHz) Maximum Peak Conducted Output Power (dBm) Verdict ANT1 Limit 802.11b SISO 2412 16.13 <=30 Pass 2437 15.89 <=30 Pass 2462 15.80 <=30 Pass 802.11g SISO 2412 14.69 <=30 Pass 2437 15.23 <=30 Pass 2462 15.46 <=30 Pass 802.11n (HT20) SISO 2412 14.76 <=30 Pass 2437 15.23 <=30 Pass 2462 15.43 <=30 Pass 802.11n (HT40) SISO 2422 15.08 <=30 Pass 2437 15.08 <=30 Pass 2452 15.22 <=30 Pass Note1: Antenna Gain: Ant1: 1.42dBi; Report No.: LGT26F077RF02 Page 45 of 62 4. Maximum Power Spectral Density 4.1 Test Result 4.1.1 PSD Mode TX Type Frequency (MHz) Maximum PSD (dBm) Verdict ANT1 Limit(dBm/3kHz) 802.11b SISO 2412 -11.08dBm/3kHz <=8 Pass 2437 -11.57dBm/3kHz <=8 Pass 2462 -11.23dBm/3kHz <=8 Pass 802.11g SISO 2412 -19.32dBm/3kHz <=8 Pass 2437 -18.67dBm/3kHz <=8 Pass 2462 -17.94dBm/3kHz <=8 Pass 802.11n (HT20) SISO 2412 -18.79dBm/3kHz <=8 Pass 2437 -18.25dBm/3kHz <=8 Pass 2462 -18.02dBm/3kHz <=8 Pass 802.11n (HT40) SISO 2422 -21.37dBm/3kHz <=8 Pass 2437 -21.66dBm/3kHz <=8 Pass 2452 -20.71dBm/3kHz <=8 Pass Note1: Antenna Gain: Ant1: 1.42dBi; Report No.: LGT26F077RF02 Page 46 of 62 4.2 Test Graph 4.2.1 PSD 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV Report No.: LGT26F077RF02 Page 47 of 62 802.11g_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11g_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11g_HCH_2462MHz_Ant1 (SISO)_NTNV Report No.: LGT26F077RF02 Page 48 of 62 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV Report No.: LGT26F077RF02 Page 49 of 62 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV Report No.: LGT26F077RF02 Page 50 of 62 5. Unwanted Emissions In Non-restricted Frequency Bands 5.1 Test Result 5.1.1 Ref Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) 802.11b SISO 2412 1 3.46 2437 1 3.68 2462 1 3.44 802.11g SISO 2412 1 -4.32 2437 1 -3.57 2462 1 -3.46 802.11n (HT20) SISO 2412 1 -4.11 2437 1 -3.90 2462 1 -3.47 802.11n (HT40) SISO 2422 1 -6.29 2437 1 -6.63 2452 1 -6.58 5.1.2 CSE Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) Limit (dBm) Verdict 802.11b SISO 2412 1 3.46 -16.54 Pass 2437 1 3.68 -16.32 Pass 2462 1 3.44 -16.56 Pass 802.11g SISO 2412 1 -4.32 -24.32 Pass 2437 1 -3.57 -23.57 Pass 2462 1 -3.46 -23.46 Pass 802.11n (HT20) SISO 2412 1 -4.11 -24.11 Pass 2437 1 -3.90 -23.90 Pass 2462 1 -3.47 -23.47 Pass 802.11n (HT40) SISO 2422 1 -6.29 -26.29 Pass 2437 1 -6.63 -26.63 Pass 2452 1 -6.58 -26.58 Pass Report No.: LGT26F077RF02 Page 51 of 62 5.2 Test Graph 5.2.1 Ref 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV Report No.: LGT26F077RF02 Page 52 of 62 802.11g_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11g_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11g_HCH_2462MHz_Ant1 (SISO)_NTNV Report No.: LGT26F077RF02 Page 53 of 62 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)…
