2BWWK-F63GPS Tracker
ShenZhen ArBolo Technology Co., Ltd.
Click to zoom
Application Details
- Equipment Class
- PCB - PCS Licensed Transmitter
- Date of Grant
- Jul 08, 2026
- Application Purpose
- Original Equipment
- Equipment Note
- GPS Tracker
- Frequency Range
- 824.00000000 - 849.00000000
