2BWYYFANB02ceiling fan with light

FCC Warning Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‐‐Reorient or relocate the receiving antenna. ‐‐Increase the separation between the equipment and receiver. ‐‐Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐‐Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Product: Ceiling Fan with Light Model: 2-F115 Brand: FSZDORJ Manufacturer: zhongshanshixushengsuliaozhipinyouxiangongsi Addrss: zhongshanshihenglanzhenchanganbeilu282haoDdong2louzhiyi FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, Human proximity to the antenna shall not be less than 20cm(8 inches) during normal operation. Ceiling Fan with Light

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: CLF Import and Export Limited Contact Name: David Chen FRN: 0033489683 Address: 1312 17th Street #692,Denver,CO 80202,Unite States Telephone No: (949)254-2565 Email: [email protected] EIN: 98-1720547 Applicant: Company name: zhongshanshixushengsuliaozhipinyouxiangongsi Product Description: ceiling fan with light Grantee code: 2BWYY FCC ID: 2BWYYFANB02 FRN: 0038634077 Contact Name: Li Rong Address: zhongshanshihenglanzhenchanganbeilu282haoDdong2louzhiyi Telephone No: +86 13380899988 Fax No: +86-0760-87687452 Email: [email protected] [zhongshanshixushengsuliaozhipinyouxiangongsi] certifies that, as of the date of this filing of the application with the TCB, [CLF Import and Export Limited ]is our designated US agent for service of process for the above referenced FCC ID. [zhongshanshixushengsuliaozhipinyouxiangongsi] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [CLF Import and Export Limited] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2026/07/13 Applicant’s Name: Li Rong US Agent’s Name: David Chen Title: General Manager Title: Manager Signature Signature

Attestation Statement. Old Code: C5266091 24 New Code: 00015544 Ed.3 Change reason: FRN is added to the Applicant information section. 1/1 TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: zhongshanshixushengsuliaozhipinyouxiangongsi Grantee code: 2BWYY FCC ID: 2BWYYFANB02 FRN: 0038634077 Contact Name: Li Rong Address: zhongshanshihenglanzhenchanganbeilu282haoDdong2louzhiyi Telephone No: +86 13380899988 Fax No: +86-0760-87687452 Email: [email protected] i. [zhongshanshixushengsuliaozhipinyouxiangongsi] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [zhongshanshixushengsuliaozhipinyouxiangongsi] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [zhongshanshixushengsuliaozhipinyouxiangongsi] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered” equipment . Date: 2026/07/13 Applicant’s Name: Li Rong Title: General Manager Signature The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

zhongshanshixushengsuliaozhipinyouxiangongsi Code 00018768 Ed. 1 Item 1. The device is able to install software/program installation? ☐ Yes, go to Item 2. ☒ No. In this case, the rest of the items do not apply. The device cannot support installation of Kaspersky cybersecurity or anti-virus software. Device ceiling fan with light Company name zhongshanshixushengsuliaozhipinyouxiangongsi Grantee code 2BWYY FCC ID 2BWYYFANB02 FRN 0038634077 Contact name Li Rong Address zhongshanshihenglanzhenchanganbeilu282haoDdong2louzhiyi Telephone number +86 13380899988 E-mail [email protected] Chipset/module information FL216CM Operating System (if applicable) / Storage Capacity (hard drive or other permanent memory storage, if applicable) / 2 Item 2. Technical Requirements for Kaspersky Cybersecurity Software: # General Requirements (For all Devices) Yes / No or N/A Comments 1 Internet connection for activation and updates (For all Operating Systems) N/A # General Requirements (For Windows Devices) Yes / No or N/A Comments 1 Storage: 1500 MB free space on the hard drive N/A 2 Operating System: Microsoft Windows 8, 8.1, 10 & 11 Home / Pro / Enterprise Microsoft Windows 7 Starter / Home Basic & Premium / Professional / Ultimate SP1 or higher N/A 3 Processor: 1 GHz or higher (x86 or x64) N/A 4 Memory (RAM)1 GB (32-bit) or 2 GB (64-bit) N/A 5 Screen Resolution: Minimum resolution of 1024 x 768 N/A # General Requirements (For macOS devices) Yes / No or N/A Comments 1 Operating System macOS® 13 – 14 N/A 2 Memory (RAM)4 GB N/A 3 Storage: 3455 MB free space on the hard drive N/A # General Requirements (For Android Devices) Yes / No or N/A Comments 1 Storage: 150 MB free space N/A 2 Operating System: Android™ 10 – 14 N/A 3 Screen Resolution: Minimum resolution of 320 x 480 N/A # General Requirements (for iOS devices) Yes / No or N/A Comments 3 1 Storage: 150 MB free space N/A 2 Operating System: iOS® 17 N/A # General Requirements (For Linux system) Yes / No or N/A Comments 1 Hard drive: 1 GB of free space N/A 2 CPU: Intel Pentium 1 GHz or higher 3 RAM: 1 GB 4 Minimum software requirements: AlmaLinux OS 8 or later; AlterOS 7.5 or later; Astra Linux Common Edition 2.12 or later; CentOS 6.7 or later; Debian GNU/Linux 10.0 or later; EulerOS 2.0 or later; Oracle Linux 7.3 or later ; Red Hat Enterprise Linux 6.7 or later ; Rocky Linux 8.5 or later ; SUSE Linux Enterprise Server 12.5 or later; Ubuntu 12.04 or later ; Uncom OS Home / Business / Education / Enterprise 2.2 or later; ALT Linux Workstaton / Workstation K / Server / Education 8 or later; ROSA Linux Workstation / Server 12 or later ; RED OS 7.3 and later ; 4 After reviewed the technical requirements, is the device capable of supporting the installation of Kaspersky software? ☐ Yes, go to Item 3. ☒ No. In this case, the rest of the items do not apply. The device cannot support installation of Kaspersky software Item 3. Connectivity Capabilities: # Physical Interface Purpose Justification 1 1 # Wireless Interface Purpose Justification 1 1 After the review of this items, the device: ☒ Cannot support installation of any cybersecurity or anti-virus software on the covered list. ☐ Potentially can operate with any cybersecurity or anti-virus software on the covered list – additional third- party proof is provided to demonstrate compliance with requirements as of 2.911(d)5(i),(ii) – “Proof of Compliance with Covered List Software Requirements” of this document applies Signature: Name: Li Rong Date: 2026.07.13 1 The justification field is used to justify why the software cannot be received through that interface. Check the annex for more indications.

zhongshanshixushengsuliaozhipinyouxiangongsi Product Similarity Declaration Product name: c eiling f an with light Model name: 1-F115, 2-F115, 2-F105-D, 3-F105-D, 1-F116, 1-F109, F109-Hui, 1-F098-D, 2-F098-D, 1-F115 600, 2-F115 600, 3-F105 600, 2-F105 600, F126- 600, F126-500, 1-F115-F-500, 2-F115-F-500, 2-F105-F-500, 3-F105-F-500, 2- F105-F-500-RGB, 3-F105-F-500-RGB, 1-F115-F-600, 2-F115-F-600, 2-F105-F- 600, 3-F105-F-600, 2-F105-F-600-RGB, 3-F105-F-600-RGB, 1-F098-F-500, 2- F098-F-500, 1-F098-F-600, 2-F098-F-600, 1-F128, 2-F128, 1-F129, 2-F129, 1- F130, 2-F130, 1-F131, 2-F131, 1-F132, 2-F132 FCC ID: 2BWYYFANB02 Signature We (zhongshanshixushengsuliaozhipinyouxiangongsi) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only differences is model name and the appearance colour. : Name: Li Rong Address: zhongshanshihenglanzhenchanganbeilu282haoDdong2louzhiyi

TCBCALLpágina1 FileFCCID:2BWYYFANB02 PleaseuploadanexhibitthatexplainshowdoestheTCBverifythenewagentinformation: 1-IstheaddressoftheagentavalidphysicalUSmailingaddress(notaUSpostofficebox,notavirtualmailbox,notP.O.Boxes,notavacantlot,notapublicbuilding, etc.) ○Wehavecheckediftheaddressexistsinarealandpotentialbuilding(Googlemaps)+officialUSregister,afterthisverificationandtheevidencebelowwecan guaranteethefollowing: notaUSpostofficebox notavirtualmailbox notP.O.Boxes notavacantlot notapublicbuilding(note) ►WecheckedtheFCCFRNSearchbasedontheinformationprovidedbythegrantee. Ontheofficialregisterfrom:https://opencorporates.com/companies/us_co/20231240414 Ingoogle: TCBCALLpágina2 ►CONCLUSIONbyTCB:TheASOPdefinedandprovidedbygranteeisVALIDandconfirmed.Thereforetheexhibit"2BWYYFANB02"includedinthefileisok. 2-IstheagentphysicallylocatedatthatvalidUSaddresssuchthattheagentcanbelegallyservedatthataddress? Yes,checkabove 3-Hasthelistedagentclearlyagreedinwritingtoserveastheagentforthegranteeatthataddress? Yes,itisincludedintheexhibit"2BWYYFANB02" TCBCALLpágina3 >

C5266091_X10_Ed.2 1/1 zhongshanshixushengsuliaozhipinyouxiangongsi Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2026-07-13 Subject: Request for Confidentiality FCC ID: 2BWYYFANB02 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Li Rong Title: General Manager

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: zhongshanshixushengsuliaozhipinyouxiangongsi Address: zhongshanshihenglanzhenchanganbeilu282haoDdong2louzhiyi Product Name: ceiling fan with light Model Number: 1-F115, 2-F115, 2-F105-D, 3-F105-D, 1-F116, 1-F109, F109- Hui, 1-F098-D, 2-F098-D, 1-F115 600, 2-F115 600, 3-F105 600, 2-F105 600, F126-600, F126-500, 1-F115-F-500, 2-F115-F-500, 2-F105-F-500, 3-F105-F- 500, 2-F105-F-500-RGB, 3-F105-F-500-RGB, 1-F115-F-600, 2-F115-F-600, 2- F105-F-600, 3-F105-F-600, 2-F105-F-600-RGB, 3-F105-F-600-RGB, 1-F098-F- 500, 2-F098-F-500, 1-F098-F-600, 2-F098-F-600, 1-F128, 2-F128, 1-F129, 2- F129, 1-F130, 2-F130, 1-F131, 2-F131, 1-F132, 2-F132 FCC Identifier: 2BWYYFANB02 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Li Rong 2026-07-13 Title: General Manager Signature of applicant:

Shenzhen QC Testing Laboratory Co., Ltd. Page 1 of3 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 http://www.qctest.com.cn Product Name: c e i l i n g f a n w i t h l i g h t Test Model No.: 2-F115 EUT Constructional Details Shenzhen QC Testing Laboratory Co., Ltd. Page 2 of3 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 http://www.qctest.com.cn Shenzhen QC Testing Laboratory Co., Ltd. Page 3 of3 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 http://www.qctest.com.cn ------End------

Shenzhen QC Testing Laboratory Co., Ltd. Page 1 of6 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 http://www.qctest.com.cn Product Name: c e i l i n g f a n w i t h l i g h t Test Model No.: 2-F115 EUT Constructional Details： Shenzhen QC Testing Laboratory Co., Ltd. Page 2 of6 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 http://www.qctest.com.cn Shenzhen QC Testing Laboratory Co., Ltd. Page 3 of6 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 http://www.qctest.com.cn Shenzhen QC Testing Laboratory Co., Ltd. Page 4 of6 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 http://www.qctest.com.cn Shenzhen QC Testing Laboratory Co., Ltd. Page 5 of6 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 http://www.qctest.com.cn Antenna Shenzhen QC Testing Laboratory Co., Ltd. Page 6 of6 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 http://www.qctest.com.cn -----End------

Shenzhen QC Testing Laboratory Co., Ltd. Page 1 of 2 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 http://www.qctest.com.cn FCC ID: 2BWYYFANB02 RF Exposure Evaluation FCC KDB publication 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, and highest channel individually. Shenzhen QC Testing Laboratory Co., Ltd. Page 2 of 2 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 http://www.qctest.com.cn Test Result of RF Exposure Evaluation For worst case Antenna Gain: -3.45dBi Test Frequency （MHz） Minimum Separation Distance (cm) Output Power (dBm) Target power (dBm) Target power (mW) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At 20 cm (mW/cm 2 ) Test Results 2402 20 1.84 2±1 1.995 0.45 1 0.0002 Pass The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure.

Shenzhen QC Testing Laboratory Co., Ltd. Report No.: QCT26FR-1745E-01 Page 1 of 41 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 http://www.qctest.com.cn FCC PART 15.247 TEST REPORT On Behalf of zhongshanshixushengsuliaozhipinyouxiangongsi zhongshanshihenglanzhenchanganbeilu282haoDdong2louzhiyi FCC ID: 2BWYYFANB02 Model: 1-F115, 2-F115, 2-F105-D, 3-F105-D, 1-F116, 1-F109, F109-Hui, 1-F098-D, 2-F098-D, 1-F115 600, 2-F115 600, 3-F105 600, 2-F105 600, F126-600, F126-500, 1-F115-F-500, 2-F115-F-500, 2-F105-F-500, 3-F105-F-500, 2-F105-F-500-RGB, 3-F105-F-500-RGB, 1-F115-F-600, 2-F115-F-600, 2-F105-F-600, 3-F105-F-600, 2-F105-F-600-RGB, 3-F105-F-600-RGB, 1-F098-F-500, 2-F098-F-500, 1-F098-F-600, 2-F098-F-600, 1-F128, 2-F128, 1-F129, 2-F129, 1-F130, 2-F130, 1-F131, 2-F131, 1-F132, 2-F132 July 10, 2026 T hi s Repor t Concer ns: Or iginal Report Equi pm ent T ype: c eiling f an with light Test Engineer: Fan Yang / Report Number: QCT26FR-1745E-01 Test Date: July 2-9, 2026 Test Result: Pass Reviewed By: Vincent Yang / Approved By: Kendy Wang / Prepared By: Shenzhen QC Testing Laboratory Co., Ltd. East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 Shenzhen QC Testing Laboratory Co., Ltd. Report No.: QCT26FR-1745E-01 Page 2 of 41 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 http://www.qctest.com.cn Table of Contents 1. GENERAL INFORMATION ................................................................................................. 5 1.1 Product Description for Equipment under Test (EUT) ............................................................. 5 1.2 System Test Configuration ...................................................................................................... 6 1.3 Test Facility.............................................................................................................................. 7 1.4 Measurement Uncertainty ........................................................................................................ 7 2. SUMMARY OF TEST RESULTS ........................................................................................ 8 3. LIST OF TEST AND MEASUREMENT INSTRUMENTS .................................................... 9 3.1 Radiated Emission Test ........................................................................................................... 9 3.2 RF Conducted test ................................................................................................................... 9 4. ANTENNA REQUIREMENT .............................................................................................. 10 5. CONDUCTED EMISSIONS ............................................................................................... 11 5.1 Applicable Standard............................................................................................................... 11 5.2 Limit ....................................................................................................................................... 11 5.3 Test setup .............................................................................................................................. 11 5.4 EMI Test Receiver Setup ....................................................................................................... 11 5.5 Test procedure....................................................................................................................... 11 5.6 Test Data ............................................................................................................................... 11 6. CONDUCTED PEAK OUTPUT POWER ........................................................................... 14 6.1 Applicable Standard............................................................................................................... 14 6.2 Limit ....................................................................................................................................... 14 6.3 Test setup .............................................................................................................................. 14 6.4 Test Procedure ...................................................................................................................... 15 6.5 Test Data ............................................................................................................................... 15 7. CHANNEL BANDWIDTH & 99% OCCUPIED BANDWIDTH ........................................... 18 7.1 Applicable Standard............................................................................................................... 18 7.2 Limit ....................................................................................................................................... 18 7.3 Test setup .............................................................................................................................. 18 7.4 Test Procedure ...................................................................................................................... 18 7.5 Test Data ............................................................................................................................... 19 8. POWER SPECTRAL DENSITY ........................................................................................ 24 8.1 Applicable Standard............................................................................................................... 24 8.2 Limit .................................................................................................…

Text truncated - open the document above for the full version.

AntennaSpecification ANTSPEC ModelName 2.4GANT CenterFrequency 2402MHz OperatingFrequency 2400-2480MHz OCW N/A OperatingTemperature Range 125 °C Numberofchannels1 AntennaAssembly Type Gain ＜ -3.5dBi Outputpower ≤3dBm ModulationType GFSK Adaptivity N/A Polarization LinearPolarization AzimuthBeamPatternDirectional Impedance 50Ohm AntennaSize Manufacturer 中山市熠凡灯饰有限公司 ZhongShanYiFanLightingCo.,Ltd 中国广东省中山市古镇镇海洲教昌工业区创兴路28号第4 层之 1 Floor4-1,No.28ChuangxingRoad,JiaochangIndustrial Zone,Haizhou,GuzhenTown,ZhongshanCity,Guangdong Province,China Wire antenna 80mm ITEM TestResults Gain Frequency (MHz) Gain(dBi) 2400-3.45 2410-3.62 2420-3.88 2430-4.01 2440-3.82 2450-3.84 2460-4.05 2470-4.20 2480-4.15 VSWR FrequencyVSWR 2400MHz 8.95 2440MHz 8.67 2480MHz 8.13 ReturnLoss Frequency (MHz) ReturnLoss(dB) 2400-1.94 2440-2.01 2480 -2.14 AnnexATestSetupPhotos AnnexBFigures 1 ． 2DRadiationPattern Phi=0° Max:-5 Min:-8.5 Scale:0.5/div Phi=90° Max:-4 Min:-18 Scale:2/div Gain 0 330 300 270 240 210 180 Angle(°) Gain 0 330 300 270 240 210 180 Angle(°) 2400MHz 2410MHz 2420MHz 2430MHz 2440MHz 2450MHz 2460MHz 2470MHz 2480MHz 2400MHz 2410MHz 2420MHz 2430MHz 2440MHz 2450MHz 2460MHz 2470MHz 2480MHz 150 120 120 150 60 90 30 60 30 90 Theta=90° Gain 240 210 Scale:1/div Angle(°) 2．3DRadiationPattern TotalGain Azimuth=-65.7 Elevation=-86.7 Roll=114.4 Z X 2400MHz 2400MHz 2410MHz 2420MHz 2430MHz 2440MHz 2450MHz 2460MHz 2470MHz 2480MHz Max:-4 Min:-13 270 300 330 120 150 180 -10 -16 60 30 90 -8 -6 -12 -14 0 -2 -4 Y TotalGain Azimuth=-65.7 Elevation=-86.7 Roll=114.4 Z X 2440MHz TotalGain Azimuth=-65.7 Elevation=-86.7 Roll=114.4 Z X 2480MHz -10 -16 -18 -18 -16 -10 -6 -8 -6 -8 -12 -14 -14 -12 -2 -4 -4 Y Y Antennasize

Shenzhen QC Testing Laboratory Co., Ltd. Page 1 of 2 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 http://www.qctest.com.cn Product Name: c e i l i n g f a n w i t h l i g h t Test Model No.: 2-F115 Photograph of Test Setup Conducted Emissions Radiated Emissions (30 MHz - 1 GHz) Radiated Emissions (Above 1 GHz) Shenzhen QC Testing Laboratory Co., Ltd. Page 2 of 2 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 http://www.qctest.com.cn RF Conducted measurement ------End------
