2BX47-CW-M6Pet Intelligent Feeder

宠物智能喂食器CW-M6 使用说明书 Pet Intelligent FeederUser Manual 使用前请仔细阅读使用说明书，并妥善保管 Please read the user manual carefully before use and keep it properly 国内版喜瓜下载Download of the overseas version of JoyPaw Catalog 目录 使用引导/Using guidance....................................................................................1 1.下载APP/Download the app ..........................................................................1 2.登录注册/log in to register ..............................................................................1 3.开启设备/Turn on the device ..........................................................................2 4.添加设备/Add equipment ...............................................................................3 5.进入设备/Enter the equipment ......................................................................7 6.实时画面/Live video/image .............................................................................8 7.设备设置/Equipment settings ........................................................................9 8.喂食报告/Feeding Report .............................................................................10 9.图库/Gallery .....................................................................................................11 10.云服务/Cloud services .................................................................................12 【附于文后】产品环保信息/Product environmental protection information.. 【附于文后】产品规格参数/Product specification parameters ........................ 售后服务与支持/After-sales service and support .......................【附于文后】 非保修条例Non-warranty regulations ............................................【附于文后】 维修卡/Maintenance card ................................................................【附于文后】 扫描包装上的二维码，或者应用市场下载。 打开“喜瓜”APP，点击【登录】，点击【国别地区】选择您的国别，输入手 机号，点击【获取验证码】，将手机收到的验证码输入后点击【登录/注册】 即可完成注册，点击【登录】即可成功登录APP。 1 Using guidance 使用引导 1.下载APP/Download the APP 2.登录-注册/Log in-Register Open the “JoyPaw" APP, click on 【Login】, click on 【Country/Region】 to select your country, enter your mobile phone number, click on 【Get Verification Code】, input the verification code received on your phone and then click on 【Login/Registration】 to complete the registration. Click on 【Login】 to successfully log in to the APP. 2)安卓手机可以通过华为、小米、OPPO、VIVO等应用商店搜 “喜瓜” 进 行下载。 Scan the QR code on the packaging, or download it from the app store。 1)苹果手机可进入 APP Store 搜索 “喜瓜” 进行下载。 1) You can search for "JoyPaw" in the App Store on your iPhone and download it. 2) Android phones can be downloaded by searching for “JoyPaw” in the application stores of Huawei, Xiaomi, OPPO, VIVO, etc. 给设备上电/Power on the equipment 2 3.开始设备/Start the equipment 进入APP后根据下图提示 4.添加设备/Add equipment After entering the APP, follow the prompts shown in the picture below. 3 1. 国内版喜瓜APP下载 1. Overseas of JoyPaw APP 长按3秒解绑设备 Long press for 3 seconds to unbind the device 长按3秒进入出粮模式 Long press for 3 seconds to enter the grain output mode 粮仓盖 Warehouse roof 食盆 Dish tray 摄像头 Camera 粮仓 Granary 锁扣 Hook or clasp 2. 在首页点击右上角“+”， 点击“添加设备”，进 入添加设备页面。 3. 扫描发现设备，点击绑定。 2. On the home page, click the "+" button at the top right corner, then click "Add Device" to enter the device addition page. 3. Scan the device and click "Bind". 4 4. 点击设备选择2.4G 频段网络配网添加。 4. Click on the device, select the 2.4G frequency band network, and add it to the network configuration. 5 5. 正在连接设备。 5. Connecting the device. 7. 连接成功。 7. Connection successful. 6 5.进入设备/Enter the equipment APP添加设备成功后，点击【首页】设备卡片即可进入设备。 7 After successfully adding the device to the APP, click on the device card on the "Home" page to enter the device. 6.实事画面/Actual scene/image 用户进入设备操作页面，可观看当前宠物实时状态。 对讲:用户点击可与设备进行对讲。 录像:用户点击可录制当前实时画面并保存至图库。 截图:用户点击可截取当前画面。 Users can access the device operation page and view the real-time status of their pets . Intercom: Clicked by the user to communicate with the device. Recording: Clicked by the user to record the current live scene and save it to the gallery. Screenshot: Clicked by the user to capture the current scene. 7.设备设置/Equipment settings 用户点击设备右上【三个点】进入设置页面对设备进行参数设置操作。 The user clicks the "three dots" on the top right of the device to enter the settings page and perform parameter setting operations for the device. 89 1011 8.喂食报告/Feeding Report 用户进入设备操作页面，可观看当前宠物实时状态。 When the user enters the device operation page, they can view the real- time status of their pet. 保存的文件为用户【实时画面、回放】的录像、截图、【AI观察报告】的下 载。用户可点击文件进行预览，可长按某一文件，进入全选状态、删除操作。 9.图库/Gallery The saved files include the video recordings, screenshots and download of the "AI observation report" for the user's "live feed and playback". Users can preview the files by clicking on them. They can also long press a file to enter the full selection state and perform deletion operations. 12 13 用户点击【云服务】，可以进入服务购买页面。 10.云服务/Cloud services When the user clicks on "Cloud Services", they can access the service purchase page. 宠物喂食器 产品环保信息 产品中有害物质的名称及含量 部件名称 有 害 物 质 铅(Ph) 汞(Hg) 镉(Cd) 六价铬[Cr(VI] 多溴联苯(PBB) 多溴二苯醚(PBDE) 零苯二甲酸二(2-乙基)己脂(DEHP) 零苯二甲酸丁基苄酯(BBP) 零苯二甲酸二正丁酯(DBP) 零苯二甲酸二异丁酯(DIBP) 本表格依据SJ/T11346的规定编制 表示该有害物质在该部件所有均质材料中的含量均在GB/T26572规定的限量 要求以下。 本标识内数字表示产品在正常使用状态下的环保使用期限为10年。 Product environmental protection information The names and contents of the harmful substances in the product Harmful substances Component Name Pet Feeder Lead (Ph) Mercury (Hg) Cadmium (Cd) Hexavalent chromium [Cr(VI)] Polybrominated Biphenyls (PBB) Polybrominated diphenyl ethers (PBDE) Zero phthalic acid di-(2-ethylhexyl) ester (DEHP) Tributyl benzyl zero phthalate (BBP) Zero Benzyl Adipate Di-N-butyl Ester (DBP) Zero Benzyl Adipate Diisobutyl Ester (DIBP) This table is compiled in accordance with the provisions of SJ/T11346 表示该有害物质至少在该部件的某一均质材料中的含量超出GB/T26572规定 的限量要求。 It indicates that the content of this harmful substance in all homogeneous materials of this component is below the limit requirements stipulated in It indicates that the content of this harmful substance in at least one homogeneous material of this component exceeds the limit requirements stipulated in GB/T26…

Text truncated - open the document above for the full version.

Shenzhen PetCanTalk Smart Technology Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 3, 2026 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID or Grantee Code: FCC ID: 2BX47-CW-M6 Applicant FRN: 0038857421 [Shenzhen PetCanTalk Smart Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, HOPEK CORPORATION INC is our designated U.S. agent for service of process for the above referenced FCC ID. [Shenzhen PetCanTalk Smart Technology Co., Ltd.] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. HOPEK CORPORATION INC accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: HOPEK CORPORATION INC U.S. Agent FRN: 0034562900 Address: 16755 Coyote Bush Dr Unit 84, San Diego, CA 92127 United States Contact Person: Yangyang Xu Tel.: 561-875-9826 Email: [email protected] Sincerely, Shenzhen PetCanTalk Smart Technology Co., Ltd. HOPEK CORPORATION INC Tina Wei / Manager Yangyang Xu / Manager (sign) (sign)

Rev 1/26/2023 (Shenzhen PetCanTalk Smart Technology Co., Ltd.) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 3, 2026 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing (FCC ID: 2BX47-CW-M6) [Shenzhen PetCanTalk Smart Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [Shenzhen PetCanTalk Smart Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti- virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, (Applicant signature) (Applicant printed name) Tina Wei Title: Manager Rev 1/26/2023 (Shenzhen PetCanTalk Smart Technology Co., Ltd.) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 3, 2026 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing (FCC ID: 2BX47-CW-M6) [Shenzhen PetCanTalk Smart Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Tina Wei Title: Manager

Shenzhen PetCanTalk Smart Technology Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 3, 2026 Confidentiality Request regarding application for certification of FCC ID: 2BX47-CW-M6 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type Block Diagram Operational Description Schematics The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type Sincerely, (signature) Name: Tina Wei Title: Manager

Shenzhen PetCanTalk Smart Technology Co., Ltd. Model Difference Data: September 3, 2026 Product description: Pet Intelligent Feeder FCC ID: 2BX47-CW-M6 Model name: CW-M6, CW-M8, XLY-M6 Trade Name: N/A All the model are the same circuit and RF module, only the model name are different. Size: Regards Sincerely Client’s signature: Client’s name / title: Tina Wei (Manager) Contact information / address: No. A209, New Hao Yidu Science and Technology E- Station, 7018 Cai Tian Road, Lianhua Village Community, HuaFu Street, Futian District, Shenzhen

Shenzhen PetCanTalk Smart Technology Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: September 3, 2026 SUBJECT: FCC Application for FCC ID: 2BX47-CW-M6 To Whom It May Concern: We, the undersigned, hereby authorize Colin Huang at Shenzhen DACE Testing Technology Co., Ltd. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Shenzhen DACE Testing Technology Co., Ltd. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Sincerely, (signature) Name: Tina Wei Title: Manager

External Appendix FCC ID: 2BX47-CW-M6 Model: CW-M6

Label Location: Pet Intelligent Feeder Model: CW-M6 FCC ID: 2BX47-CW-M6 FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Internal Appendix FCC ID: 2BX47-CW-M6 Model: CW-M6 ANT

Shenzhen PetCanTalk Smart Technology Co., Ltd. FCC §15.247 (i), §2.1091 – RF Exposure FCC ID: 2BX47-CW-M6 Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength € (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength € (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density Shenzhen PetCanTalk Smart Technology Co., Ltd. MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna, R=20cm Test Result of RF Exposure Evaluation Mode Modes& Channe l Freq. (MHz) Tune up Produce power Maximu m peak output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm2) Limit (mW /cm2) Result 2.4G WIFI 802.11b& 2462 16±1 17 50.1187 1.1429 (0.58dBi) 0.0114 1 Pass

V1.0 Report No.: DACE260731002RF001 102, Building H1, & 1/F., Building H, Hongfa Science & Technology Park, Tangtou Community, Shiyan Subdistrict, Bao'an District, Shenzhen, Guangdong, China Web: http://www.dace-lab.com Tel: +86-755-23010613 E-mail: [email protected] Page 1 of 79 RF TEST REPORT For Shenzhen PetCanTalk Smart Technology Co., Ltd. Product Name: Pet Intelligent Feeder Test Model(s): CW-M6 Report Reference No. : DACE260731002RF001 FCC IC : 2BX47-CW-M6 Applicant’s Name : Shenzhen PetCanTalk Smart Technology Co., Ltd. Address : No. A209, New Hao Yidu Science and Technology E-Station, 7018 Cai Tian Road, Lianhua Village Community, HuaFu Street, Futian District, Shenzhen Testing Laboratory : Shenzhen DACE Testing Technology Co., Ltd. Address : 102, Building H1, & 1/F., Building H, Hongfa Science & Technology Park, Tangtou Community, Shiyan Subdistrict, Bao'an District, Shenzhen, Guangdong, China Test Specification Standard : 47 CFR Part 15.247 Date of Receipt : July 31, 2026 Date of Test : July 31, 2026 to August 7, 2026 Date of Issue : August 7, 2026 Result : Pass Note: This report shall not be reproduced except in full, without the written approval of Shenzhen DACE Testing Technology Co., Ltd. This document may be altered or revised by Shenzhen DACE Testing Technology Co., Ltd. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample V1.0 Report No.: DACE260731002RF001 102, Building H1, & 1/F., Building H, Hongfa Science & Technology Park, Tangtou Community, Shiyan Subdistrict, Bao'an District, Shenzhen, Guangdong, China Web: http://www.dace-lab.com Tel: +86-755-23010613 E-mail: [email protected] Page 2 of 79 Apply for company information Applicant’s Name : Shenzhen PetCanTalk Smart Technology Co., Ltd. Address : No. A209, New Hao Yidu Science and Technology E-Station, 7018 Cai Tian Road, Lianhua Village Community, HuaFu Street, Futian District, Shenzhen Product Name : Pet Intelligent Feeder Test Model(s) : CW-M6 Series Model(s) : CW-M8, XLY-M6 Test Specification Standard(s) : 47 CFR Part 15.247 NOTE1: The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Compiled by: Supervised by: Approved by: Lucy Mo / Test Engineer Arron Liu / Project Engineer Tom Chen / Manager August 7, 2026 August 7, 2026 August 7, 2026 V1.0 Report No.: DACE260731002RF001 102, Building H1, & 1/F., Building H, Hongfa Science & Technology Park, Tangtou Community, Shiyan Subdistrict, Bao'an District, Shenzhen, Guangdong, China Web: http://www.dace-lab.com Tel: +86-755-23010613 E-mail: [email protected] Page 3 of 79 Revision History Of Report Version Description REPORT No. Issue Date V1.0 Original DACE260731002RF001 August 7, 2026 V1.0 Report No.: DACE260731002RF001 102, Building H1, & 1/F., Building H, Hongfa Science & Technology Park, Tangtou Community, Shiyan Subdistrict, Bao'an District, Shenzhen, Guangdong, China Web: http://www.dace-lab.com Tel: +86-755-23010613 E-mail: [email protected] Page 4 of 79 CONTENTS 1 TEST SUMMARY ........................................................................................................................................... 6 1.1 TEST STANDARDS .................................................................................................................................. 6 1.2 SUMM ARY OF TEST RESULT .................................................................................................................... 6 2 GENERAL INFORMATION ............................................................................................................................ 8 2.1 CLIENT INFORMATION ............................................................................................................................. 8 2.2 DESCRIPTION OF DEVICE (EUT) .............................................................................................................. 8 2.3 DESCRIPTION OF TEST MODES ................................................................................................................ 8 2.4 DESCRIPTION OF SUPPORT UNITS ........................................................................................................... 8 2.5 OPERATION FREQUENCY EACH OF CHANNEL ............................................................................................ 9 2.6 EQUIPMENTS USED DURING THE TEST .................................................................................................. 10 2.7 STATEMENT OF THE MEASUREMENT UNCERTAINTY ............................................................................... 12 3 EVALUATION RESULTS (EVALUATION) ................................................................................................... 13 3.1 ANTENNA REQUIREMENT ....................................................................................................................... 13 3.1.1 Conclusion: ............................................................................................................................. 13 4 RADIO SPECTRUM MATTER TEST RESULTS (RF) ................................................................................. 14 4.1 CONDUCTED EMISSION AT AC POWER LINE ........................................................................................... 14 4.1.1 E.U.T. Operation: .................................................................................................................... 14 4.1.2 Test Setup Diagram: ............................................................................................................... 14 4.1.3 Test Data: .............................................................................................................…

Text truncated - open the document above for the full version.

V1.0 Report No.: DACE260731002RF001 102, Building H1, & 1/F., Building H, Hongfa Science & Technology Park, Tangtou Community, Shiyan Subdistrict, Bao'an District, Shenzhen, Guangdong, China Web: http://www.dace-lab.com Tel: +86-755-23010613 E-mail: [email protected] Page 1 of 79 RF TEST REPORT For Shenzhen PetCanTalk Smart Technology Co., Ltd. Product Name: Pet Intelligent Feeder Test Model(s): CW-M6 Report Reference No. : DACE260731002RF001 FCC IC : 2BXZG-CW-M6 Applicant’s Name : Shenzhen PetCanTalk Smart Technology Co., Ltd. Address : No. A209, New Hao Yidu Science and Technology E-Station, 7018 Cai Tian Road, Lianhua Village Community, HuaFu Street, Futian District, Shenzhen Testing Laboratory : Shenzhen DACE Testing Technology Co., Ltd. Address : 102, Building H1, & 1/F., Building H, Hongfa Science & Technology Park, Tangtou Community, Shiyan Subdistrict, Bao'an District, Shenzhen, Guangdong, China Test Specification Standard : 47 CFR Part 15.247 Date of Receipt : July 31, 2026 Date of Test : July 31, 2026 to August 7, 2026 Date of Issue : August 7, 2026 Result : Pass Note: This report shall not be reproduced except in full, without the written approval of Shenzhen DACE Testing Technology Co., Ltd. This document may be altered or revised by Shenzhen DACE Testing Technology Co., Ltd. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample V1.0 Report No.: DACE260731002RF001 102, Building H1, & 1/F., Building H, Hongfa Science & Technology Park, Tangtou Community, Shiyan Subdistrict, Bao'an District, Shenzhen, Guangdong, China Web: http://www.dace-lab.com Tel: +86-755-23010613 E-mail: [email protected] Page 2 of 79 Apply for company information Applicant’s Name : Shenzhen PetCanTalk Smart Technology Co., Ltd. Address : No. A209, New Hao Yidu Science and Technology E-Station, 7018 Cai Tian Road, Lianhua Village Community, HuaFu Street, Futian District, Shenzhen Product Name : Pet Intelligent Feeder Test Model(s) : CW-M6 Series Model(s) : CW-M8, XLY-M6 Test Specification Standard(s) : 47 CFR Part 15.247 NOTE1: The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Compiled by: Supervised by: Approved by: Lucy Mo / Test Engineer Arron Liu / Project Engineer Tom Chen / Manager August 7, 2026 August 7, 2026 August 7, 2026 V1.0 Report No.: DACE260731002RF001 102, Building H1, & 1/F., Building H, Hongfa Science & Technology Park, Tangtou Community, Shiyan Subdistrict, Bao'an District, Shenzhen, Guangdong, China Web: http://www.dace-lab.com Tel: +86-755-23010613 E-mail: [email protected] Page 3 of 79 Revision History Of Report Version Description REPORT No. Issue Date V1.0 Original DACE260731002RF001 August 7, 2026 V1.0 Report No.: DACE260731002RF001 102, Building H1, & 1/F., Building H, Hongfa Science & Technology Park, Tangtou Community, Shiyan Subdistrict, Bao'an District, Shenzhen, Guangdong, China Web: http://www.dace-lab.com Tel: +86-755-23010613 E-mail: [email protected] Page 4 of 79 CONTENTS 1 TEST SUMMARY ........................................................................................................................................... 6 1.1 TEST STANDARDS .................................................................................................................................. 6 1.2 SUMM ARY OF TEST RESULT .................................................................................................................... 6 2 GENERAL INFORMATION ............................................................................................................................ 8 2.1 CLIENT INFORMATION ............................................................................................................................. 8 2.2 DESCRIPTION OF DEVICE (EUT) .............................................................................................................. 8 2.3 DESCRIPTION OF TEST MODES ................................................................................................................ 8 2.4 DESCRIPTION OF SUPPORT UNITS ........................................................................................................... 8 2.5 OPERATION FREQUENCY EACH OF CHANNEL ............................................................................................ 9 2.6 EQUIPMENTS USED DURING THE TEST .................................................................................................. 10 2.7 STATEMENT OF THE MEASUREMENT UNCERTAINTY ............................................................................... 12 3 EVALUATION RESULTS (EVALUATION) ................................................................................................... 13 3.1 ANTENNA REQUIREMENT ....................................................................................................................... 13 3.1.1 Conclusion: ............................................................................................................................. 13 4 RADIO SPECTRUM MATTER TEST RESULTS (RF) ................................................................................. 14 4.1 CONDUCTED EMISSION AT AC POWER LINE ........................................................................................... 14 4.1.1 E.U.T. Operation: .................................................................................................................... 14 4.1.2 Test Setup Diagram: ............................................................................................................... 14 4.1.3 Test Data: .............................................................................................................…

Text truncated - open the document above for the full version.

Antenna Describe 1.Antenna Describe: Antenna Plate IFA Antenna Gain 0.58dBi Frequency Range 2400 – 2500MHz Connector Type PCB Model Name 2.4G-M6 Company Name Dezhou Lingcheng District Kaishun Plastic Products Co., Ltd Company Address West Section, Zhangxiqiao Village, Mi Town, Ling County, Dezhou City, Shandong Province, P.R.China 2.External View Drawing: Picture of Antenna 3.Antenna Radiation Pattern Radiation pattern @2400MHz Total Average Gain: -0.41 dBi Phi 0° 45° 90° 135° 180° 235° 270° 315° Gain -0.1-0.3-0.7-0.5-0.1-0.5-0.7-0.7 Radiation pattern @2450MHz Total Average Gain: -0.26 dBi Phi 0° 45° 90° 135° 180° 235° 270° 315° Gain - 0 .58 0.1 -0.3-0.5-0.1-0.2-0.6-0.3 Radiation pattern @2500MHz Total Average Gain: -0.22 dBi Phi 0° 45° 90° 135° 180° 235° 270° 315° Gain 0 -0.1-0.2-0.50 -0.3-0.5-0.2

Setup Appendix FCC ID: 2BX47-CW-M6 Model: CW-M6
