2BXDBGLT-VWT-01Kids Walkie Talkies

User Manual *Please read this manual before use [email protected] - 01 - This product is covered by a 1-year warranty. Warranty and Support 1-Year Warranty If you have any questions, please include your order number and contact our 24-hour online support team via email [email protected] 24-Hour Online Support For full warranty details and terms applicable to this product, visit: www.glitsh.shop Alternatively, scan the QR code below for direct access: Product Overview 1- Back Button 2- Antenna 3- Camera 4- Display 5- Volume Up 6- Volume Down 7- Power Switch 8- MIC Port 9- Call button/OK Button 10- Type-C Interface 11- Lanyard Hole 12- Speaker 13- Left Navigation Key 14- Right Navigation Key - 02 - [email protected] 1 10 11 7 6 5 2 3 4 14 8 12 13 9 Video Call Basic Button Operations Power On / Off 1.Short press the left/right keys to navigate and select the desired function on the main interface.(Call key) to enter. 2.After selecting a function, press the OK key (Call key) to enter. 3.To exit the function, press the Back Button. 4.Long press “+” to increase volume; long press “-” to decrease volume. 5.Hold OK to use voice intercom. The transmission is one-way: the other party can only speak after the key is released by the current speaker. Slide the power switch upward to turn on, downward to turn off. When the power switch is turned on, the six-icon main interface appears as shown below: 1.Video Call 2.Micro Chat 3.Camera 4.Gallery 5.Theme 6. Game - 03 - [email protected] Menu Functions a. Short press OK to call, then long press OK to wait for the other party to answer. The receiver only needs to short press OK to answer. b. Long press OK to use walkie-talkie communication. c. Short press volume “+/-” to increase or decrease volume. d. Short press Back key to return to the main menu. - 04 - [email protected] After the device is powered off, the voice setting will automatically reset to the default Original Voice. Display View: Short press the Right key to switch among four screen display modes: Picture-in-Picture A, Picture-in-Picture B, Remote View Only, and Local View Only. Voice Changer: Short press the Left key to switch voice effects. The device supports four voice modes: Micro Chat In Micro Chat, five functions are available at the bottom, from left to right: Emojis, Voice Intercom, Music, Camera, Pictures. Picture-in-Picture A Original VoiceKids VoiceRobot VoiceAdult Voice Emojis Voice IntercomMusicCameraPictures Picture-in-Picture BRemote View Only Local View Only - 05 - [email protected] Theme Press the Right button to browse through available background images. Press the OK button to confirm and apply your selection. Game Press the OK button to enter Game Mode.Use the Left / Right keys to select Rock, Paper, or Scissors.Press the OK button to confirm your choice. 1.Emojis Operation: Short press the left/right navigation keys to select an emoji, then press OK to send. 2.Voice Intercom Operation: Press and hold the OK key to talk. Release to finish and send the message. 3.Music Operation: Short press the left/right navigation keys to select a music track, then press OK to send. 4.Camera Operation: Enter the camera interface and press OK to take a photo and send immediately. 5.Pictures Operation: Enter the pictures interface, short press the left/right navigation keys to select an image, then press OK to send. Camera Enter the Camera interface and press the OK key to take a photo. Short press the Right key to activate fun sticker effects. Available stickers: Flower Crown, Mustache, Pumpkin Eyes Flower CrownMustachePumpkin Eyes Safety Information Use only a 5V / 1A charger and the supplied charging cable or an equivalent Type-C cable. Charge the product under adult supervision. Stop using the device if the housing, charging port, or battery area appears damaged. Charging & Battery This product is intended for everyday indoor and outdoor play. It is not waterproof. Keep it away from rain, sinks, swimming pools, bathtubs, and other liquids. Do not expose the device to fire, direct heat, or prolonged strong sunlight. After turning on, the device enters working state automatically. It will remain on even if unused. The device will automatically shut off when the battery is low. To stop using, switch to OFF. Use Environment ! Power On / Off and Auto Shut-Off Uses 2.4G Wi-Fi for transmission and connection. Each package contains two pre-paired walkie-talkies. These two units cannot connect with other devices. If multiple sets are purchased, pairing is one-to-one per set. Multiple products cannot interconnect simultaneously. Pairing and Connection - 06 - [email protected] • Switch the device off fully before long-term storage. • To restart the product, slide the power switch down to OFF, then back up to ON. • Store the device in a cool, dry place away from water, corrosive materials, and strong heat sources. Care, Notes & Troubleshooting Care Troubleshooting Charge the device fully, then confirm the power switch is in the ON position. No Power Make sure both original paired units are powered on and close enough to connect. No Connection Reduce obstacles such as walls, metal cabinets, and heavy interference sources. Weak Indoor Performance Confirm the other user is holding the Talk button while speaking and that the speaker volume is not set too low. No Audio From the Other Side - 07 - [email protected] Notes • Each set works as a two-unit, one-to-one pair. • Actual range varies with the environment. • Keep this manual for future reference. • Contact your seller or distributor for after-sales service. • This product is not suitable for children under 3 years of age. • Dispose of electronic products responsibly in accordance with local regulations. [email protected] Specifications 2.0 Inch IPS30W CMOS 3.7V 400mAh Type-C 68°F-140°F 86°F-158°F 5V/1A 4.88 in …

Text truncated - open the document above for the full version.

Rev 1/26/2023 Hengquan Technology (Dongguan) Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-07-31 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2BXDBGLT-VWT-01 Hengquan Technology (Dongguan) Co., Ltd. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Hengquan Technology (Dongguan) Co., Ltd. certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A SoftwareBill of Materials(SBOM)is providedto the TCB for review,and The end-useror thirdpartiescannotinstalladditionalsoftwareon this device. Sincerely, (Applicantsignature) (ShizhuTu ) Rev 1/26/2023 Hengquan Technology (Dongguan) Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-07-31 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2BXDBGLT-VWT-01 Hengquan Technology (Dongguan) Co., Ltd. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicantsignature) (ShizhuTu ))

HengquanTechnology(Dongguan)Co.,Ltd. Address:Room301,Building2,No.22LianhuRoad,Chang'anTown, DongguanCity,GuangdongProvince,China Date:2026-07-24 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Ref:AttestationStatementsPart2.911(d)(7)Filing SUBJECT:FCCApplicationforFCCID:2BXDBGLT-VWT-01 FRN:0038699708 (“HengquanTechnology(Dongguan)Co.,Ltd.”)certifiesthat,asofthedateofthefilingof theapplication,(BridgeportAdvisoryLLC)isourdesignatedU.S.agentforserviceof processfortheabovereferencedFCCID.(“HengquanTechnology(Dongguan)Co.,Ltd.”) acceptstomaintainanagentfornolessthanoneyearafterthegranteehasterminatedall marketingandimportationortheconclusionofanyCommission-relatedproceedinginvolving theequipment. (BridgeportAdvisoryLLC)accepts,asofthedateofthefilingoftheapplication,the obligationofthedesignatedU.S.agentforserviceofprocessfortheabovereferencedFCC ID. DesignatedU.S.AgentInformation: Name:BridgeportAdvisoryLLC Address:3330W38THPLCHICAGO,IL60632UnitedStates FRN:0037566148 ContactPerson:YongLiu Tel.:(708)680-6688 Email:[email protected] Sincerely, HengquanTechnology(Dongguan)Co.,Ltd.BridgeportAdvisoryLLC Name:ShizhuTuName:YongLiu Title:ManagerTitle:ManagingPartner Date:2026-07-24Date:2026-07-24

HengquanTechnology(Dongguan)Co., Ltd. Date：2026-07-31 Product Model Number: GLT-VWT-01 FCC ID:2BXDBGLT-VWT-01 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: Testing Approvalapplicationsand procedures We declarethat QAI LaboratoriesLtd. is allowedto forwardall information relatedto the approvalprojectto the appliedcertificationbody and to the notificationentitiesand to discussany issuesconcerningthe approval application.Any and all acts carriedout by QAI LaboratoriesLtd. on our behalfshall have the same effect as acts of our own. By: ContactListedon FCC Wesbite Title: Manager Email:[email protected] Telephone:18922928792 On behalfof: ShizhuTu

HengquanTechnology(Dongguan)Co., Ltd. Officeof EngineeringTechnology FederalCommunicationsCommission 7435 OaklandMills Road Columbia,MD 21046 USA Date: July 31, 2026 Subject; Request for Confidentiality FCC ID: 2BXDBGLT-VWT-01 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market.  SchematicDiagram  Block Diagram  OperationalDescription In additionalto abovementioneddocuments,in order to complywith the marketingregulations in Title 47 CFR §2.803 and the importationrules in Title 47 CFR §2.1204,while ensuringthat businesssensitiveinformationremainsconfidentialuntil the actualmarketingof newly authorizeddevices,we requestShort Term Confidentialityof the followingattachment(s); ExternalPhotos Test SetupPhotos InternalPhotos User Manual For 45 days, pursuantto PublicNoticeDA 04-1705. OR For 180 days pursuantto KDB 726920D01. It is our understandingthat all measurementtest reports,FCC ID label formatand correspondenceduringthe certificationreviewprocesscannotbe grantedas confidential documentsand this informationwill be availablefor publicreviewonce the grant of equipment authorizationis issued. Sincerely, Signature: Name:ShizhuTu Title: Manager

FCCID:2BXDBGLT-VWT-01 FCCID:2BXDBGLT-VWT-01 FCCID:2BXDBGLT-VWT-01 FCCID:2BXDBGLT-VWT-01

LabelLocation FCCID:2BXDBGLT-VWT-01

FCCID:2BXDBGLT-VWT-01 FCCID:2BXDBGLT-VWT-01 FCCID:2BXDBGLT-VWT-01 Antenna FCCID:2BXDBGLT-VWT-01

FCCID:2BXDBGLT-VWT-01 RFExposureEvaluation AccordingtoKDB447498andpart2.1093 ， Unlessspecificallyrequiredbythepublished RFexposureKDBprocedures,standalone1-gheadorbodyand10-gextremitySAR evaluationforgeneralpopulationexposureconditions,bymeasurementornumerical simulation,isnotrequiredwhenthecorrespondingSARTestExclusionThreshold condition(s),listedbelow,is(are)satisfied. For100MHzto6GHzandtestseparationdistances≤50mm,the1-gand10-gSARtest exclusionthresholdsaredeterminedbythefollowing: [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance, mm)]·[√f (GHz) ]≤3.0for1-gSAR,and≤7.5for10-gextremitySAR,where f (GHz) istheRFchanneltransmitfrequencyinGHz PoweranddistanceareroundedtothenearestmWandmmbeforecalculation Theresultisroundedtoonedecimalplaceforcomparison Here, ForWIFI2.4G tune-up power. (dBm) Max. tune-up power. (dBm) tune-up power. (mW) Frequency(MHz) Min. distance(mm) Calc. thresholds limit 8.63 ± 19.639.183241252.8523.0 Note:Result=P F /D P=Maximumturn-uppowerinmW F=ChannelfrequencyinGHz D=Mininmuntestseparationdistanceinmm SoaSARtestisnotrequired
