2BXFJ-ASKARWorm-and-Gear Automatic Telescope Focuser

WAF Technical Documentation 1. Description WAF (Worm-and-Gear Automatic Telescope Focuser) 2. Product Description The WAF features a predominantly black appearance, a metal body, and a matte finish. The logo "Askar | WAF" is laser engraved. WAF Features: 1. Quick and easy installation 2. Smooth and stable focusing process 3. High motor torque, high load capacity, stable and durable 4. Exquisite appearance 5. Smooth matte finish for a comfortable touch 6. Compatible with 95% of focusers on the market 7. Supports mobile app control with fast response, hands-free operation, stop on release, and both travel range and step size are adjustable 8. Supports precise focusing and autofocus for deep-sky astrophotography 9. Supports free switching between wired and wireless operation modes 10. Supports ASCOM and various ASCOM-compatible third-party software 11. No additional driver downloads required, plug-and-play 12. Customizable device name 13. Multi-device management, custom grouping; user-definable step size and travel reversal Package Contents (subject to change) - Electronic focuser body x1 - Mounting bracket x1 - Wrenches x2 (Allen wrench, Torx) - Pin x1 - M4x10 screws x2 - Gear mounts x2 (5, 6, 7 mm inner bore) 3. Detailed Specifications Housing Material Aluminum alloy End Cap Material ABS+PC Motor Type Worm gear stepper motor Step Angle 1.8° Gear Reduction Ratio 99 Output Torque 20 kgf/cm Payload Capacity 20 kg Output Speed 2.6587 rpm Steps per Revolution 19800 Power/Data Interface 12V / Type-C Input Current 0.79A Body Dimensions 101 mm × 47 mm × 43 mm Body Weight 420 g Communication Protocol ASCOM Alpaca and Indigo 4. Compatibility List (1)Software: Supports all third-party software compatible with ASCOM Alpaca, as well as the company's own Askar App. (2)Hardware: Fits most telescope focusers on the market, e.g., Sharpstar full series focusers, Sky-Rover full series focusers, etc. 5. Dimensional Drawing 6. Installation Instructions (1)Remove the focusing knob from the telescope. (2)Select the appropriate mounting bracket for your focuser model. (3)Install the connection bar (mounting plate). (4)Attach the electronic focuser body to the bracket. (5)Engage the focuser gear with the bracket gear. (6)Tighten the handle screw. Complete connection diagram (including 12V Type-C) 7. How to Configure Parameters Wired Mode (using N.I.N.A. as an example): The configuration interface features a black background with white text. The default maximum travel of the focuser is 100,000 steps, and the position after power-on is the midpoint (i.e., position 50,000). In N.I.N.A., first click "Refresh", then select the device from the dropdown list in the equipment panel, then click "Configure" to open the configuration interface. Here you can modify the maximum travel of the electronic focuser. The adjustable range is between 100 and 1,000,000 steps. Click "Update" to apply the change. After modification, the maximum travel and current position will refresh immediately, and the new maximum travel value will be retained for future use. The detailed steps are as follows: (1)Connect the Type-C data cable, then open N.I.N.A. (2) Click "Scan for Devices", then locate and select "Askar-WAF" under the ASCOM Alpaca module in the taskbar. (3)Click "Settings" and wait for the web interface to open. (Two image placeholders) (4)According to the travel of your imaging equipment's focuser, set the maximum travel. (Reference: Step 19800 = one revolution of the WAF output shaft = one revolution of the focuser coarse adjustment knob) (5)After entering the new Max Step value, click "Update". A green message reading "Maximum travel has been updated to" will appear upon success, then close the web page. Example illustration (showing 10 revolutions, i.e., Step 198,000): Wireless Mode (using the Askar App as an example): When using the device for the first time, you need to configure the network via the mobile app using Bluetooth. Connect the device to the same local network as your computer/mobile device, so that you can control it from the app or from your computer. After network configuration is complete, you can either control it via the app, or via N.I.N.A. (ensuring that your computer and the device are on the same network). Each time you subsequently use the electronic focuser, it will automatically connect to the network that was configured last time. If connection fails, it will enter Bluetooth configuration mode after 7–8 seconds, and you can reconfigure the network using the app. Detailed steps are as follows: Network Configuration Procedure 1. Open the "Device" tab at the bottom, then tap "Device Network Configuration". 2. Grant system permissions (Bluetooth, etc.). If previously denied or permanently marked as denied, go to your system settings, enable the corresponding permissions for the Askar App, and try again. 3. You will enter the "Scanning for Devices" page: (1)The app will scan for approximately ten seconds (you can also refresh manually). (2)The list will distinguish between "Askar" devices and ordinary Bluetooth devices for easy identification. (3)If the list is empty, a prompt will usually appear: "No devices found, please confirm that the device is in network configuration mode." (4)If Bluetooth is turned off, you can enable it according to the on-screen prompt or go to the system Bluetooth settings. 4. Select your device from the list and wait for connection. After successful connection, you will enter the "Wi-Fi Selection and Configuration" page: (1)The page will indicate: "Connected to this BLE device, please select the Wi-Fi network that the device will join. The device only supports 2.4 GHz. Failure may occur if the network cannot switch frequency bands or due to other reasons." (2)You can first "Scan for Wi-Fi". If no results appear, confirm that location and Wi-Fi are enabled, then retry. (3)The list may include "Saved" networks (hotspots for which a password was saved during this session) and "Avai…

Text truncated - open the document above for the full version.

Rev 1/26/2023 Jiaxing Sharpstar Optical Instrument Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 08-06-2026 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2BXFJ-ASKAR [Jiaxing Sharpstar Optical Instrument Co., Ltd.] certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [Jiaxing Sharpstar Optical Instrument Co., Ltd.] certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, (Applicant signature) (Applicant printed name) Bingbing Xu Rev 1/26/2023 Jiaxing Sharpstar Optical Instrument Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 08-06-2026 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2BXFJ-ASKAR [Jiaxing Sharpstar Optical Instrument Co., Ltd.] ce8rtifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Bingbing Xu

Jiaxing Sharpstar Optical Instrument Co., Ltd. U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: August 06, 2026 Ref: Attestation Statement – Part 2.911(d)(7) filing FCC ID: 2BXFJ-ASKAR Jiaxing Sharpstar Optical Instrument Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, CLF Import and Export Limited (“the agent”) is our designated U.S. agent for service of process for the above reference FCC ID. The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges it is our responsibility to inform the FCC whenever the agent information changes. CLF Import and Export Limited ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: CLF Import and Export Limited FRN: 0033489683 Address: 1312 17th Street #692, Denver, CO 80202, United States Signature: Contact Person: David Chen Tel: +1 949 254 2565 Email: [email protected] Applicant Company Name: Jiaxing Sharpstar Optical Instrument Co., Ltd. FRN: 0038715546 Address: 3/F, No.13 building, Jiaxing Intelligence and Innovation Park, No.36 Chang-Sheng Nan Road, Jia-Xing, Zhe-Jiang, China Signature: Contact Person: Chunxiang Yue Tel: +86-15757319002 Email: [email protected]

Jiaxing Sharpstar Optical Instrument Co., Ltd. Date: August 06, 2026 Product Model Number: Askar-WAF FCC ID: 2BXFJ-ASKAR To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. By: Bingbing Xu Contact Listed on FCC Wesbite Title: Manager Email: [email protected] Telephone: +86-15757319002 On behalf of: Jiaxing Sharpstar Optical Instrument Co., Ltd.

Jiaxing Sharpstar Optical Instrument Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 6, 2026 Subject; Request for Confidentiality FCC ID: 2BXFJ-ASKAR To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Bingbing Xu Title: Manager

Report No: SSP26060245-1&2E FCC ID: 2BXFJ-ASKAR Annex of Test Report Annex A. EUT External Photos Model: Askar-WAF EUT View 1 EUT View 2 Report No: SSP26060245-1&2E FCC ID: 2BXFJ-ASKAR Annex of Test Report EUT View 3 EUT View 4 Report No: SSP26060245-1&2E FCC ID: 2BXFJ-ASKAR Annex of Test Report EUT View 5 EUT View 6 Report No: SSP26060245-1&2E FCC ID: 2BXFJ-ASKAR Annex of Test Report EUT View 7 EUT View 8

Report No: SSP26060245-1&2E FCC ID: 2BXFJ-ASKAR Annex of Test Report Annex D. Label and Information FCC Label Sample Label Size:3cm*1cm FCC Label Specifications Text is Black in color and is justified. Labels are printed in indelible ink on permanent adhesive backing or silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Where the EUT is constructed in two or more sections connected by wires and marketed together, the above statement is required to be affixed only to the main control unit. When the EUT is so small or for such use that it is not practicable to place the statement on it, the above information shall be placed in a prominent location in the instruction manual or pamphlet supplied to the user or, alternatively, shall be placed on the container in which the device is marketed. FCC Label Location

Report No: SSP26060245-1&2E FCC ID: 2BXFJ-ASKAR Annex of Test Report Annex B. EUT Internal Photos Model: Askar-WAF EUT Internal View 1 EUT Internal View 2 FPCB Antenna Report No: SSP26060245-1&2E FCC ID: 2BXFJ-ASKAR Annex of Test Report EUT Internal View 3

FCC ID: 2BXFJ-ASKAR RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm2) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f2) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f2) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r2) Where Pd = power density in mW/cm2, Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm2. If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation BLE Mode Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result GFSK 2.35 1.72 0.0003 1.0 PASS 2.4G Wi-Fi Mode Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 11.27 13.40 0.0027 1.0 PASS Remark: antenna gain= BLE: 0dBi, 2.4GWiFi: 0dBi The device is capable of simultaneously transmitting 2.4G WiFi and Bluetooth. Calculations for simultaneously transmit Mode Ratios Result Limit Result BLE 0.0003 0.003 1 PASS 2.4G Wi-Fi 0.0027 Ratios = Power Density / Power density Limit So a SAR test is not required

Report No: SSP26060245-1E FCC Test Report Page 1 of 33 FCC TEST REPORT FCC ID: 2BXFJ-ASKAR Report No. : SSP26060245-1E Applicant : Jiaxing Sharpstar Optical Instrument Co., Ltd. Product Name : Worm-and-Gear Automatic Telescope Focuser Model Name : Askar-WAF Test Standard : FCC Part 15.247 Date of Issue : 2026-07-28 Shenzhen CCUT Quality Technology Co., Ltd. 1F, Building 35, Changxing Technology Industrial Park, Yutang Street, Guangming District, Shenzhen, Guangdong, China; (Tel.:+86-755-23406590 website: www.ccuttest.com) This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen CCUT Quality Technology Co., Ltd. Report No: SSP26060245-1E FCC Test Report Page 2 of 33 Test Report Basic Information Applicant..................................: Jiaxing Sharpstar Optical Instrument Co., Ltd. Address of Applicant...............: 3/F, No.13 building, Jiaxing Intelligence and Innovation Park, No.36 Chang-Sheng Nan Road, Jia-Xing, Zhe-Jiang, China Manufacturer..........................: Jiaxing Sharpstar Optical Instrument Co., Ltd. Address of Manufacturer........: 3/F, No.13 building, Jiaxing Intelligence and Innovation Park, No.36 Chang-Sheng Nan Road, Jia-Xing, Zhe-Jiang, China Product Name.........................: Worm-and-Gear Automatic Telescope Focuser Brand Name.............................: Askar Main Model..............................: Askar-WAF Series Models..........................: - Test Standard..........................: FCC Part 15 Subpart C KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.4-2014 ANSI C63.10-2020 + Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024 Date of Test .............................: 2026-06-10 to 2026-07-10 Test Result...............................: PASS Tested By ................................: (Coke Huang) Reviewed By............................: (Lorzix Luo) Authorized Signatory............: (Lahm Peng) Note : This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen CCUT Quality Technology Co., Ltd.. All test data presented in this test report is only applicable to presented test sample. Report No: SSP26060245-1E FCC Test Report Page 3 of 33 CONTENTS 1. General Information ....................................................................................................................................................5 1.1 Product Information .............................................................................................................................................5 1.2 Test Setup Information..........................................................................................................................................6 1.3 Compliance Standards ...........................................................................................................................................7 1.4 Test Facilities ........................................................................................................................................................7 1.5 List of Measurement Instruments ..........................................................................................................................8 1.6 Measurement Uncertainty .....................................................................................................................................9 2. Summary of Test Results ........................................................................................................................................... 10 3. Antenna Requirement ............................................................................................................................................... 11 3.1 Standard and Limit.............................................................................................................................................. 11 3.2 Test Result .......................................................................................................................................................... 11 4. Conducted Emissions ................................................................................................................................................ 12 4.1 Standard and Limit.............................................................................................................................................. 12 4.2 Test Procedure.................................................................................................................................................... 12 4.3 Test Data and Results .......................................................................................................................................... 13 5. Radiated Emissions ................................................................................................................................................... 16 5.1 Standard and Limit.............................................................................................................................................. 16 5.2 Test Procedure.................................................................................................................................................... 16 5.3 Test Data and Results .......................................................................................................................................... 18 6. Band-edge Emissions(Radiated) ............................................................................................................................... 22 6.1 Standard and Limit.............................................................................................................................................. 22 6.2 Test Procedure.........................................................................................................................................…

Text truncated - open the document above for the full version.

Report No: SSP26060245-2E FCC Test Report Page 1 of 50 FCC TEST REPORT FCC ID: 2BXFJ-ASKAR Report No. : SSP26060245-2E Applicant : Jiaxing Sharpstar Optical Instrument Co., Ltd. Product Name : Worm-and-Gear Automatic Telescope Focuser Model Name : Askar-WAF Test Standard : FCC Part 15.247 Date of Issue : 2026-07-28 Shenzhen CCUT Quality Technology Co., Ltd. 1F, Building 35, Changxing Technology Industrial Park, Yutang Street, Guangming District, Shenzhen, Guangdong, China; (Tel.:+86-755-23406590 website: www.ccuttest.com) This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen CCUT Quality Technology Co., Ltd. Report No: SSP26060245-2E FCC Test Report Page 2 of 50 Test Report Basic Information Applicant..................................: Jiaxing Sharpstar Optical Instrument Co., Ltd. Address of Applicant...............: 3/F, No.13 building, Jiaxing Intelligence and Innovation Park, No.36 Chang-Sheng Nan Road, Jia-Xing, Zhe-Jiang, China Manufacturer..........................: Jiaxing Sharpstar Optical Instrument Co., Ltd. Address of Manufacturer........: 3/F, No.13 building, Jiaxing Intelligence and Innovation Park, No.36 Chang-Sheng Nan Road, Jia-Xing, Zhe-Jiang, China Product Name.........................: Worm-and-Gear Automatic Telescope Focuser Brand Name.............................: Askar Main Model..............................: Askar-WAF Series Models..........................: - Test Standard..........................: FCC Part 15 Subpart C KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.4-2014 ANSI C63.10-2020 + Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024 Date of Test .............................: 2026-06-10 to 2026-07-10 Test Result...............................: PASS Tested By ................................: (Coke Huang) Reviewed By............................: (Lorzix Luo) Authorized Signatory............: (Lahm Peng) Note : This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen CCUT Quality Technology Co., Ltd.. All test data presented in this test report is only applicable to presented test sample. Report No: SSP26060245-2E FCC Test Report Page 3 of 50 CONTENTS 1. General Information ....................................................................................................................................................5 1.1 Product Information .............................................................................................................................................5 1.2 Test Setup Information..........................................................................................................................................6 1.3 Compliance Standards ...........................................................................................................................................7 1.4 Test Facilities ........................................................................................................................................................7 1.5 List of Measurement Instruments ..........................................................................................................................8 1.6 Measurement Uncertainty .....................................................................................................................................9 2. Summary of Test Results ........................................................................................................................................... 10 3. Antenna Requirement ............................................................................................................................................... 11 3.1 Standard and Limit.............................................................................................................................................. 11 3.2 Test Result .......................................................................................................................................................... 11 4. Conducted Emissions ................................................................................................................................................ 12 4.1 Standard and Limit.............................................................................................................................................. 12 4.2 Test Procedure.................................................................................................................................................... 12 4.3 Test Data and Results .......................................................................................................................................... 13 5. Radiated Emissions ................................................................................................................................................... 16 5.1 Standard and Limit.............................................................................................................................................. 16 5.2 Test Procedure.................................................................................................................................................... 16 5.3 Test Data and Results .......................................................................................................................................... 18 6. Band-edge Emissions(Radiated) ............................................................................................................................... 22 6.1 Standard and Limit.............................................................................................................................................. 22 6.2 Test Procedure.........................................................................................................................................…

Text truncated - open the document above for the full version.

Page 1 of 3 1. General Information 1.1 Product Information Manufacturer: Jiaxing Sharpstar Optical Instrument Co., Ltd. Address of Manufacturer: 3/F, No.13 building, Jiaxing Intelligence and Innovation Park, No.36 Chang-Sheng Nan Road, Jia-Xing, Zhe-Jiang, China Product Name: 2.4G Antenna Model Name: Askar-WAF Frequency Range: 2400MHz - 2500MHz Type of Antenna: FPCB Antenna Antenna Gain: 0dBi (Max.) Impedance: 50 ohm Antenna View: Length * Width (3.7cm * 1cm) Antenna body Length * Width (6.1cm * 0.2cm) Page 2 of 3 2. OTA Test 2.1 Gain Frequency Peak Gain (dBi) Polarity 2400MHz 0 Horizontal 2400MHz -0.33 Vertical 2450MHz -1.31 Horizontal 2450MHz -1.69 Vertical 2500MHz -1.85 Horizontal 2500MHz -2.06 Vertical Page 3 of 3 2.2 Radiation Pattern View

Report No: SSP26060245-1&2E FCC ID: 2BXFJ-ASKAR Annex of Test Report Annex C. Test Photos Conducted Emission Test View 1 Radiated Emission Test View Below 1GHz Report No: SSP26060245-1&2E FCC ID: 2BXFJ-ASKAR Annex of Test Report Radiated Emission Test View Above 1GHz
