2BXGN-C156Digital Calendar

User Manual Digital Cal endar ALL-in-One Family Calendar Power Supply Mounting Hole Wall-Mounting Hole Br acket Wall-Mounting Hole Type-c DC 01 02 Hold the power button for about 5 seconds to power on the frame. when the frame is on, press the power button once to turn the screen on or o. Hold the power button for about 2 seconds to get power o option. To avoid anypossible damage to the frame, please do not unplug the power adapter from the frame while the device is on. Power Button Product Specification Screen15.6" Touchscreen (16:10) 1920x1080 FHD 4GB 64GB A523Cortex™M-A55 Octa-Core 2.4GHz+5GHz Resolution Memory Storage CPU WI-FI Other accessories inside the packaging box Electric Drill Power Adapter Two Scr ewsTwo Expansion Anchors HammerWall Protection Tape The included scr ews and expansion anchors are suitable for drywall, brick, concrete, or tile walls. For more operation instructions, please contact the store customer service. Br acket 03 Before Device Installation Wall-Mounting Tips Required tools Take the height of all device users into consideration It is recommended to install the device at an eye-level height. Ensure sucient space for both horizontal and vertical mounting orientations. Do not drill holes above wall studs, electrical wires, or pipes. Before installation, unplug the device from the power socket and keep it away from water sources. * 04 Download AiMOR app on your mobile phone Bind and Connect Devices To share your schedule with compatible calendar devices worldwide, please first download the free AiMOR app on your mobile device. Search for "AiMOR" in the App Stor e (iOS) or Google Play (Android) to download the AiMOR app. To synchronize your schedule with AiMOR Calendar, y ou need to connect the AiMOR app to the AiMOR Calendar device. Follow the steps below for connection: ** ** ** **** ** ** ** ** ** ** ** Download the "AiMOR APP" through your mobile phone Open the device's member manage- ment settings Open device sharing Vie w the device sharing code Enter the device code in the "AiMOR APP" to bind the device You can now synchronize your mobile phone with the calendar Upload photos Transmission from mobile to device Introduction to Functions on Device Homepage: Main Functions on Homepage 05 DateTimeWeather Reminder Member Switch views Back to today Chore display Add schedule Click on the device(Profiles-Share device) sharing icon“ “, on the Calendar A pop-up will appear with a unique code, which is valid for 12 hours. Now, open the AiMOR app on your phone, tap the " " icon under the device tab, enter the code from the Calendar, and click. Your mobile app is now connected to the photo frame. Share the Calendar code with friends and family. They can add the Calendar and start synchronizing or creating schedules, household chores, etc., to it. There is no limit to the number of mobile users connected to the Calendar. Notification Ring reminderClose pop-ups NextMember display Content display 06 Message notification Unread status Read status Swipe right to delete Reminder information cat egory Display: Supports Automatic brightness settings. 07 Weather - Set Time Zone Navigate to Device Settings - General - Weather Location to ensur e that the weather positioning is accurat e. 08 JackPeter Smart Creation, Star Assignment, Rewar d Creation, Cat ering Plans: Smart Recipe Creation, Synchronized Import, Member Management, Photo Upload Synchronized Import: Introduction to Main Functional Pages on Mobile App: 09 Star Assignment: 10 Create rewar ds and set rules together. When you have collected enough star s, y ou can redeem our pre-agreed rewar ds with them! Rewar ds can be items or a special experience. Rewards are created by parents on the mobile app, and children can view their rewar ds and progress on the device. 11 Wi-Fi Ic on to view the WiFi status, means that the WiFi signal is str ong, means no WiFi, and icon to view the server status, means connecting to the server , means disconnecting the server . Factor y Reset Deletes all data from your frame. This will permanently delete all your photos/videos, contacts, and settings. Help & About User guide Opens the quick star t guide that is shown during initial setup of the frame. Check for Updates Check for available softwar e updates and download/install them on your frame. Thank you for purchasing this Digital Calendar. Before using the Digital Calendar, please read this manual carefully and keep it in a safe place. The description in this manual is based on the latest information at the time of editing. The actual product you receive may dier slightly from the descriptions in this manual owing to technical updates and production batch dierences. We reserve the right to change product specifications and update this information from time to time. For further assistance, please contact our sellers or after-sales team. The final interpretation right belongs to our company. Introduction 12 Dear Customer, Thank you very much for using our products, Please read the rules carefully. 1. One year warranty. According to the prescription, the period for protecting to fix our company's Digital Calendar is one year. (From the day when you have the invoice) During this periodany belongs to under normal usage circumstance cause because of the product quality's problemof breakdown, our company will be responsible for giving free maintain. 2. Free maintain won't be given under the following circumstance. Without Protection to fix warrantees. The device is out of the warranty period. The damage caused by customer inappropriate preservation, maintain, orthe usage. The serial number on the back cover is too dim to recognize if it is for our products. The breakdown caused by the manipulation that hasn’t follow the requests of the manual. The breakdown, row harm or damaged because of the move or drop. The breakdown and the damage caused by the force majeure. Digital Calendar | Warranty Rules 13 The breakdown caused careless protec…

Text truncated - open the document above for the full version.

TCB CALL página 1 File FCC ID: 2BXGN-C156 Please upload an exhibit that explains how does the TCB verify the new agent information: 1- Is the address of the agent a valid physical US mailing address (not a US post office box, not a virtual mailbox, not P.O. Boxes, not a vacant lot, not a public building, etc.) ○ We have checked if the address exists in a real and potential building (Google maps) + official US register, after this verification and the evidence below we can guarantee the following: not a US post office box not a virtual mailbox not P.O. Boxes not a vacant lot not a public building(note) ► We checked the FCC FRN Search based on the information provided by the grantee. On the official register from : https://www.sos.state.co.us/biz/BusinessEntityDetail.do?quitButtonDestination=BusinessEntityResults&nameTyp=ENT&masterFileId=20248279136&entityId2=20248279136&fileId=20248279136&srchTyp=ENTITY TCB CALL página 2 Google: EIN Number： TCB CALL página 3 ► CONCLUSION by TCB: The ASOP defined and provided by grantee is VALID and confirmed. Therefore the exhibit "C5266091_X23_Ed1_US_Agent_Letter" included in the file is ok. 2- Is the agent physically located at that valid US address such that the agent can be legally served at that address? Yes , check above 3- Has the listed agent clearly agreed in writing to serve as the agent for the grantee at that address? Yes, it is included in the exhibit "C5266091_X23_Ed1_US_Agent_Letter"

1/1 USAgentforServiceofProcessLETTEROFATTESTATION TO: OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USAgentforServiceofProcess: CompanyName:GOLDENVICTORYINTERNATIONALTRADINGCOLTD FRN:0036377570 ContactName:LeonHowar Address:11016THSTREETSUITE1400DENVER,CO80202UnitedStates TelephoneNo:(337)255-0461 Email:[email protected] Applicant: Companyname:SHENZHENPLOYERELECTRONICSCO.,LTD. ProductDescription:DigitalCalendar Granteecode:2BXGN FRN:0038720066 FCCID:2BXGN-C156 ContactName:JinRongWu Address:7FBuilding8,YushengIndustrialArea,NO.467ofXixiangSection,NationalRoad107, XixiangStreet,BaoanDistrict,ShenzhenChina TelephoneNo.:+8613790932214 Email:[email protected] [SHENZHENPLOYERELECTRONICSCO.,LTD.]certifiesthat,asofthedateof thisfilingoftheapplicationwiththeTCB,[GOLDENVICTORYINTERNATIONAL TRADINGCOLTD]isourdesignatedUSagentforserviceofprocessforthe abovereferencedFCCID.[SHENZHENPLOYERELECTRONICSCO.,LTD.] acceptstomaintainanagentfornolessthanoneyearafterthegranteehas terminatedallmarketingandimportationortheconclusionofanycommission relatedproceedinginvolvingequipment.[GOLDENVICTORYINTERNATIONAL TRADINGCOLTD]accepts,asofthedateofthefilingoftheapplication,the obligationofthedesignatedUSagentforserviceofprocessfortheabove referenceFCCID. TheUSAgentforServiceofProcessisawareofandagreestocomplywiththerequirements outlinedintheFCCEquipmentAuthorizationProgram,ReportandOrderFCC22-84,andclause §2.911. TheApplicantisawareofandagreestocomplywiththerequirementsoutlinedintheFCC EquipmentAuthorizationProgram,ReportandOrderFCC22-84,andclause§2.911. Date:2026.8.12 Applicant’sName:JinRongWuUSAgent’sName:LeonHowar Title:ManagerTitle:Manager Signature Signature

AttestationStatement. Old Code:C526609124New Code:00015544Ed.3 Changereason:FRN is addedto the Applicantinformationsection. 1/1 TO: Officeof EngineeringTechnology FederalCommunicationsCommission 7435 OaklandMills Road Columbia,MD 21046 The Commissionadoptedrulesthatprohibitequipmentauthorizationfor “covered” telecommunicationsequipmentand videosurveillanceequipmentproducedby entitiesidentified on the Commission’s CoveredList 1 , whichis periodicallyupdated.See the CoveredList for more details.This AttestationStatementis to confirmthat we followthe Section2.911(d)(5)(i)-(ii) Applicant Companyname: SHENZHENPLOYERELECTRONICSCO., LTD. Granteecode:2BXGN FRN:0038720066 FCC ID:2BXGN-C156 ContactName:JinRong Wu Address:7F Building8, YushengIndustrialArea, NO. 467 of XixiangSection,NationalRoad 107, XixiangStreet,BaoanDistrict,ShenzhenChina TelephoneNo.:+8613790932214 Email:[email protected] i.SHENZHENPLOYERELECTRONICSCO., LTD. (“the applicant”) certifies that the equipmentfor whichauthorizationis soughtis not “covered” equipmentprohibitedfrom receivingan equipmentauthorizationpursuantto section2.903 of the FCC rules. The applicantmust sign this certification. ii.SHENZHENPLOYERELECTRONICSCO., LTD. (“the applicant”) certifies that, as of the date of the filing of the application,the applicant[is not] (as a specificallynamedentity or any of its subsidiariesor affiliates)identifiedon the CoveredList as an entity producing“covered” equipment.The applicant must sign this certification. [SHENZHEN PLOYER ELECTRONICS CO., LTD.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered” equipment . Date:2026.8.12 Applicant’s Name:Jin Rong Wu Title: Manager Signature 1 The Commission’s CoveredListis publishedby the PublicSafetyand HomelandSecurityBureauand postedon the Commission’s website.This CoveredList, whichis periodicallyupdated,identifiesparticularequipment,producedby particularentities,that constitutes“covered”equipment.https://www.fcc.gov/supplychain/coveredlist

SHENZHENPLOYERELECTRONICSCO., LTD. Code00018768Ed. 2 Item 1.The deviceis able to install software/programinstallation? ☐ Yes, go to Item 2. ☒ No. In this case, the rest of the items do not apply.The devicecannotsupportinstallationof Kaspersky cybersecurityor anti-virussoftware. Item 2.TechnicalRequirementsfor KasperskyCybersecuritySoftware: #GeneralRequirements(For all Devices)Yes / No or N/AComments 1Internetconnectionfor activationand updates(For all Operating Systems) N/A #GeneralRequirements(For WindowsDevices)Yes / No or N/AComments DeviceDigitalCalendar CompanynameSHENZHENPLOYERELECTRONICSCO., LTD. Granteecode2BXGN FCC ID2BXGN-C156 FRN0038720066 ContactnameJin RongWu Address7F Building8, YushengIndustrialArea,NO. 467 of XixiangSection,NationalRoad107, Xixiang Street,BaoanDistrict,ShenzhenChina Telephonenumber+86 13790932214 [email protected] Chipset/moduleinformationAIC8800D80 OperatingSystem(if applicable)N/A StorageCapacity(hard drive or other permanentmemorystorage,if applicable) N/A 2 1Storage:1500MBfreespaceontheharddriveN/A 2OperatingSystem: MicrosoftWindows8,8.1,10&11Home/Pro/Enterprise Microsoft Windows7Starter/HomeBasic&Premium/Professional/ UltimateSP1orhigher N/A 3Processor:1GHzorhigher(x86orx64)N/A 4Memory(RAM)1GB(32-bit)or2GB(64-bit)N/A 5ScreenResolution:Minimumresolutionof1024x768N/A #GeneralRequirements(FormacOSdevices)Yes/NoorN/AComments 1OperatingSystemmacOS®13–14N/A 2Memory(RAM)4GBN/A 3Storage:3455MBfreespaceontheharddriveN/A #GeneralRequirements(ForAndroidDevices)Yes/NoorN/AComments 1Storage:150MBfreespaceN/A 2OperatingSystem:Android™10–14N/A 3ScreenResolution:Minimumresolutionof320x480N/A #GeneralRequirements(foriOSdevices)Yes/NoorN/AComments 1Storage:150MBfreespaceN/A 2OperatingSystem:iOS®17N/A #GeneralRequirements(ForLinuxsystem)Yes/NoorN/AComments 1Harddrive:1GBoffreespaceN/A 3 2CPU:IntelPentium1GHzorhigherN/A 3RAM:1GBN/A 4Minimumsoftwarerequirements: AlmaLinuxOS8orlater; AlterOS7.5orlater; AstraLinuxCommonEdition2.12orlater; CentOS6.7orlater; DebianGNU/Linux10.0orlater; EulerOS2.0orlater; OracleLinux7.3orlater; RedHatEnterpriseLinux6.7orlater; RockyLinux8.5orlater; SUSELinuxEnterpriseServer12.5orlater; Ubuntu12.04orlater; UncomOSHome/Business/Education/Enterprise2.2orlater; ALTLinuxWorkstaton/WorkstationK/Server/Education8or later; ROSALinuxWorkstation/Server12orlater; REDOS7.3andlater; N/A Afterreviewedthetechnicalrequirements,isthedevicecapableofsupportingtheinstallationof Kasperskysoftware? ☐Yes,gotoItem3. ☒ No.Inthiscase,therestoftheitemsdonotapply.ThedevicecannotsupportinstallationofKaspersky software Item3.ConnectivityCapabilities: 4 #PhysicalInterfacePurposeJustification 1 1 #WirelessInterfacePurposeJustification 1 1 After the reviewof this items,the device: ☒Cannotsupportinstallationof any cybersecurityor anti-virussoftwareon the coveredlist. ☐ Potentiallycan operatewith any cybersecurityor anti-virussoftwareon the coveredlist–additionalthird- party proof is providedto demonstratecompliancewith requirementsas of 2.911(d)5(i),(ii)–“Proof of Compliancewith CoveredList SoftwareRequirements”of this documentapplies Signature:Name:Jin RongWu Date: 2026.8.12 1 The justificationfield is usedto justifywhy the softwarecannotbe receivedthroughthat interface.Checkthe annexfor more indications.

SHENZHENPLOYERELECTRONICSCO.,LTD. ProductSimilarityDeclaration Productname:DigitalCalendar Modelname:C156 C101,C132,C215,C320 TradeName:N/A FCCID:2BXGN-C156 We(SHENZHENPLOYERELECTRONICSCO.,LTD.)hereby statethatallthemodelsareelectricalidenticalincludingthesame softwareparameterandhardwaredesign(i.e.,circuitdesign,PCB Layout,RFmodule/circuit,antennatype(s)andantennalocation, componentsonPCB,etc.,),samemechanicalstructureand design(includingproductenclosure,materials,etc.,),Theonly differenceisthemodelname. Signature: Name:JinRongWu Title:manager Place:7FBuilding8,YushengIndustrialArea,NO.467ofXixiangSection,NationalRoad107, XixiangStreet,BaoanDistrict,Shenzhen,China Date:Aug.03,2026

C5266091_X10_Ed.2 1/1 SHENZHENPLOYERELECTRONICSCO., LTD. Officeof EngineeringTechnology FederalCommunicationsCommission 7435 OaklandMills Road Columbia,MD 21046 Date: 2026.8.12 Subject:Requestfor Confidentiality FCC ID: 2BXGN-C156 To WhomIt May Concern, Pursuantto the provisionsof Sections0.457and 0.459of Commission'srules (47CFR0.457,0.459),we are requestingthe Commissionto withholdthe following attachment(s)as confidentialdocumentfrom publicdisclosure. ExhibitsLong-Term Confidentiality Short-Term Confidentiality NOTE2 ID Label/LocationNoNo AttestationStatementNoNo ExternalPhotosNo ☐ Block Diagram ☒☐ Schematics ☒☐ Test ReportNoNo Test SetupPhotosNo ☐ User’ s Manual ☐ NOTE 1 ☐ InternalPhotos ☐ NOTE 1 ☐ Parts List / Tune Up ☐☐ RF ExposureInfoNoNo OperationalDescription ☒☐ CoverLetter(s)NoNo SDR Software/ SecurityInfoNo NOTE1: Long-TermConfidentialitymay be permittedunderspecialconditions(SeeII. LONG-TERMCONFIDENTIALITY,Section3 of KDB 726920,use last in force) NOTE2: Short-TermConfidentialitycan be requestedfor a maximumof 180 daysfromthe dateof the grant. Abovementioneddocumentcontainsdetailedsystemand equipmentdescriptionare consideredas proprietaryinformationin operationof the equipment.The public disclosureof abovedocumentsmightbe harmfulto our companyand wouldgive competitoran unfairadvantagein the market. In case of short-termConfidentiality,the applicantrequeststhe exhibitsselected aboveare withheldfrom publicview for a periodof ______days from the date of the Grantof EquipmentAuthorizationand prior to marketing. It is our understandingthat all measurementtest reports,FCC ID label formatand correspondentduringcertificationreviewprocesscannotbe grantedas confidential documentsand thoseinformationwill be availablefor publicreviewonce the grantof equipmentauthorizationis issued. ☒ C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name:JinRongWu Title:Manager

C5266091_X8_Ed.1 1/1 LetterofAuthorization SHENZHENPLOYERELECTRONICSCO.,LTD. Company:SHENZHENPLOYERELECTRONICSCO.,LTD. Address:7FBuilding8,YushengIndustrialArea,NO.467ofXixiang Section,NationalRoad107,XixiangStreet,BaoanDistrict,Shenzhen China ProductName:DigitalCalendar ModelNumber:C156,C101,C132,C215,C320 FCCIdentifier:2BXGN-C156 WeauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdelCarme,s/n, 08193Bellaterra,Spain,toactonourbehalfonallmattersconcerningthe abovenamedequipment. AnyindividualwithinLGAITechnologicalCenterS.A.isauthorizedtoactonour behalfandtakeactionontheapplication. WedeclarethatauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdel Carme,s/n,08193Bellaterra,Spain,isallowedtoforwardallinformation relatedtotheapprovalprojecttotheFederalCommunicationCommissionand todiscussanyissuesconcerningtheapprovalapplication.Anyandallacts carriedoutbyLGAITechnologicalCenterS.A.onourbehalfshallhavethe sameeffectasactsofourown. Name:JinRongWuDate:2026.8.12 Title:Manager Signatureofapplicant:

EUTPHOTO(ExternalPhotos) TestModel:C156 ※※※※※ENDOFREPORT※※※※※

Labelandlabellocation FCCIDLABEL: High:1cm Wide:2cm LabelLocation: FCCID:2BXGN-C156

EUTPHOTO(InternalPhotos) TestModel:C156 ※※※※※ENDOFREPORT※※※※※ ANT

FCCID:2BXGN-C156 RFEXPOSUREEVALUATION AccordingtoKDB447498D01GeneralRFExposureGuidancev06andpart2.1093, UnlessspecificallyrequiredbythepublishedRFexposureKDBprocedures,standalone 1-gheadorbodyand10-gextremitySARevaluationforgeneralpopulationexposure conditions,bymeasurementornumericalsimulation,isnotrequiredwhenthe correspondingSARTestExclusionThresholdcondition(s),listedbelow,is(are)satisfied. For100MHzto6GHzandtestseparationdistances≤50mm,the1-gand10-gSARtest exclusionthresholdsaredeterminedbythefollowing: [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance, mm)]*[√f (GHz) ]≤3.0for1-gSAR,and≤7.5for10-gextremitySAR,where f (GHz) istheRFchanneltransmitfrequencyinGHz PoweranddistanceareroundedtothenearestmWandmmbeforecalculation Theresultisroundedtoonedecimalplaceforcomparison Here, ForWIFI2.4G Mode FrequencyPower Tune-up power Maxtune-up power Maxtune-up power Min. Distance Calc. thresholds limit (MHz)(dBm)(dBm)(dBm)(mW)(mm) 802.11b 24127.774 7±1 86.3151.96003.0 802.11g 24128.6488±197.9452.46633.0 802.11n 20 24128.8508±197.9452.46633.0 802.11n 40 24228.962 8±1 97.9452.47143.0 ForWIFI5.2G Mode FrequencyPower Tune-up power Maxtune-up power Maxtune-up power Min. Distance Calc. thresholds limit (MHz)(dBm)(dBm)(dBm)(mW)(mm) a 52406.570 6±1 75.0152.29373.0 n20 52405.8985±1 63.9851.82213.0 n40 52307.212 7±186.3152.88613.0 ac20 52405.712 5±163.9851.82213.0 ac40 5230 6.086 6±175.0152.29153.0 ac80 5210 5.993 5±163.9851.81693.0 ForWIFI5.8G Mode FrequencyPower Tune-up power Maxtune-up power Maxtune-up power Min. Distance Calc. thresholds limit (MHz)(dBm)(dBm)(dBm)(mW)(mm) a57456.141 6±1 75.0152.40173.0 n2057455.770 5±1 63.9851.90793.0 n4057555.598 5±1 63.9851.90963.0 ac2057456.002 6±1 75.0152.40173.0 ac4057556.254 6±1 75.0152.40383.0 ac8057756.248 6±1 75.0152.40793.0 Conclusion: 1.[(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparation distance,mm)]*[√f(GHz)]<3.0. 2.SARTestExclusionThresholdsis3.0forseparationdistance5mm.Therefore,SAR testisnotrequired. 3.2.4GHzWiFi&5.2GHzWiFi&5.8GHzWiFicannotsupportsimultaneoustransmission.

ProjectNo.:ZKT-2606251752E-1 Page 1 of 64 FCCTESTREPORT FCCID:2BXGN-C156 ReportNumber...................................:ZKT-2606251752E-1 DateofTest ....................................................... :Jul.15,2026toAug.03,2026 Dateofissue.........................................:Aug.03,2026 Totalnumberofpages .......................... 64 TestResult..........................................:PASS TestingLaboratory............................: ShenzhenZKTTechnologyCo.,Ltd. Address...............................................: 1/F,No.101,BuildingB,No.6,TangweiCommunityIndustrial Avenue,FuhaiStreet,Bao'anDistrict,Shenzhen,China Applicant'sname.............................: SHENZHENPLOYERELECTRONICSCO.,LTD. Address ............................................... : 7FBuilding8,YushengIndustrialArea,NO.467ofXixiangSection, NationalRoad107,XixiangStreet,BaoanDistrict,Shenzhen,China Manufacturer'sname ...................... : SHENZHENPLOYERELECTRONICSCO.,LTD. Address...............................................: 7FBuilding8,YushengIndustrialArea,NO.467ofXixiangSection, NationalRoad107,XixiangStreet,BaoanDistrict,Shenzhen,China Testspecification: Standard ................................................ : FCCCFRTitle47Part15SubpartCSection15.247 ANSIC63.10-2020+Cor.1-2023+C63.10a-2024+Erratato C63.10a-2024 Testprocedure.....................................: / Non-standardtestmethod ................ :N/A TestReportFormNo........................: TRF-EL-111_V0 TestReportForm(s)Originator ..... : ZKTTesting MasterTRF........................................: Dated:2020-01-06 ThisdevicedescribedabovehasbeentestedbyZKT,andthetestresultsshowthattheequipmentunder test(EUT)isincompliancewiththeFCCrequirements.Anditisapplicableonlytothetestedsample identifiedinthereport. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofZKT,thisdocumentmay bealteredorrevisedbyZKT,personalonly,andshallbenotedintherevisionofthedocument. Productname ..................................... :DigitalCalendar Trademark...........................................:N/A Model/Typereference......................: C156 C101,C132,C215,C320 Ratings .................................................. : Input:12V1.5A ProjectNo.:ZKT-2606251752E-1 Page 2 of 64 Testingprocedureandtestinglocation: TestingLaboratory.......................................: ShenzhenZKTTechnologyCo.,Ltd. Address ............................................................ :1/F,No.101,BuildingB,No.6,TangweiCommunity IndustrialAvenue,FuhaiStreet,Bao'anDistrict, Shenzhen,China JimLiu Testedby(name+signature).......................: JacksonFang Reviewer(name+signature).......................: LakeXie Approved(name+signature).......................: ProjectNo.:ZKT-2606251752E-1 Page 3 of 64 TableofContents Page 1.VERSION.....................................................................................................................5 2.SUMMARYOFTESTRESULTS..................................................................................6 2.1TESTFACILITY....................................................................................................................7 2.2MEASUREMENTUNCERTAINTY.......................................................................................7 3.GENERALINFORMATION..........................................................................................8 3.1GENERALDESCRIPTIONOFEUT....................................................................................8 3.2DESCRIPTIONOFTESTMODES......................................................................................9 3.3BLOCKDIGRAMSHOWINGTHECONFIGURATIONOFSYSTEMTESTED...............10 3.4DESCRIPTIONOFSUPPORTUNITS(CONDUCTEDMODE)........................................10 3.5EQUIPMENTSLISTFORALLTESTITEMS....................................................................11 4.EMCEMISSIONTEST...............................................................................................13 4.1CONDUCTEDEMISSIONMEASUREMENT....................................................................13 4.1.1POWERLINECONDUCTEDEMISSIONLimits.....................................................13 4.1.2TESTPROCEDURE..................................................................................................13 4.1.3DEVIATIONFROMTESTSTANDARD.....................................................................13 4.1.4TESTSETUP.............................................................................................................14 4.1.5EUTOPERATINGCONDITIONS..............................................................................14 4.1.6TESTRESULT...........................................................................................................15 4.2RADIATEDEMISSIONMEASUREMENT.........................................................................17 4.2.1RADIATEDEMISSIONLIMITS.................................................................................17 4.2.2TESTPROCEDURE..................................................................................................17 4.2.3DEVIATIONFROMTESTSTANDARD.....................................................................18 4.2.4TESTSETUP.............................................................................................................18 4.2.5EUTOPERATINGCONDITIONS..............................................................................19 4.2.6TESTRESULTS.........................................................................................................19 5.RADIATEDBANDEMISSIONMEASUREMENT.......................................................30 5.1TESTREQUIREMENT.......................................................................................................30 5.2TESTPROCEDURE..........................................................................................................30 5.3DEVIATIONFROMTESTSTANDARD..................................................................…

Text truncated - open the document above for the full version.

Address: 402TEL: 0755-23203435fax: 0755-23203435, Block C, Juxin Science and Technology Industrial Park, Nanchang community, xixiang, Baoan District, Shenzhen Shenzhen Aihui Technology Co. , Ltd. Antenna specification Antenna Sample Confirmation From Name of supplier ShenZhen Aihui Technology Co.，Ltd Customer name YI Heng Ke Sample name A1 model Sample size WiFi Antenna: SLK-YHK-2516Q V1 A1-WIFI Wire Length: 120mm Wire Dieter: 1.13mm Black Dual-Head Soldering Wire Inspection item Performance test Visual inspection Structure In the news Test results Notes Quality Audit Project Audit Business confirm ation The following is to be completed by the client Address: 402TEL: 0755-23203435fax: 0755-23203435, Block C, Juxin Science and Technology Industrial Park, Nanchang community, xixiang, Baoan District, Shenzhen Shenzhen Aihui Technology Co. , Ltd. Customer feedback Customer signature/seal date: Antenna Test Report Test Unit: Shenzhen Aihui Technology Co. , Ltd. Materials FPC Address: 402TEL: 0755-23203435fax: 0755-23203435, Block C, Juxin Science and Technology Industrial Park, Nanchang community, xixiang, Baoan District, Shenzhen Shenzhen Aihui Technology Co. , Ltd. Antenna form PIFA Polarization mode Linear Application scenario Wifi /BT Working band WIFI/BT VSWR ≤2 Power Max：2W Impedance 50Ω dBi Test Equipment HPE5071C、Shielding Room、3D automatic turntable Antenna Description:： 1. Grounding processing and picture description: no 2. Need to change the motherboard to match: no  Test voltage: 3.6V, check the antenna contact is good before testing.  The RF cable of the integrated tester is kept in a natural state and can not be curled. Specification:test the specified power level, all indicators must conform to the specifications. 1. Project Image 2. Test Fixture Address: 402TEL: 0755-23203435fax: 0755-23203435, Block C, Juxin Science and Technology Industrial Park, Nanchang community, xixiang, Baoan District, Shenzhen Shenzhen Aihui Technology Co. , Ltd. 3. Antenna matching circuit 4. S11 test 5. Antenna passive efficiency and gain 6. Darkroom test equipment and data 7. Schematic diagram of antenna assembly 8. Antenna environment handling 9. Antenna mass production index 10.Structural drawing 1.Project Image The final verification antenna performance prototype in our company for at least one year, easy to analyze and solve the problem of antenna mass production, to ensure the quality of antenna shipment Address: 402TEL: 0755-23203435fax: 0755-23203435, Block C, Juxin Science and Technology Industrial Park, Nanchang community, xixiang, Baoan District, Shenzhen Shenzhen Aihui Technology Co. , Ltd. 2.Test Fixture Objective: to test the passive parameters of antenna as accurately as possible. Making Method: the handset is made of a 50 ohm coaxial cable, one end of which is connected to the test point of the back end of the matching circuit of the handset motherboard (front end of the RF test hole) , and the other end is connected to the SMA joint. The diagram is as follows: 3、Antenna matching circuit Modify E01 E02 E03 No No No Note: The match is unmodified. 4.S11 test 4.0 4.0s11 test method description of test equipment: Network Analyzer (E5071C) test method: a 50 ohm CABLE is used to export from the instrument test port. The SMA connector for connecting the handset is calibrated using a calibration piece, record the echo loss and standing wave ratio corresponding to the relevant frequency points. The test schematic is as follows: Address: 402TEL: 0755-232034…
