2BXHG-AFACE01NAFace attendance machine

FCC Caution. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body.

Rev 1/26/2023 Noble Paragon Pte. Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-08-05 FCC ID: 2BXHG-AFACE01N Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing Noble Paragon Pte. Ltd. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Noble Paragon Pte. Ltd. certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing Noble Paragon Pte. Ltd. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Applicant: Noble Paragon Pte. Ltd. Address: 10 Anson Road, #12-08, International Plaza, Singapore 079903 Contact Person: Shi Feng Tel.: 0755-89668180 Email: [email protected] Sincerely, Signature:

Attestation Statements Date: 2026-08-05 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for(FCC ID: 2BXHG-AFACE01N) Noble Paragon Pte. Ltd., the undersigned, hereby authorize FCC US Agent, LLC to act as our designated agent for service of process, Noble Paragon Pte. Ltd. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. FCC US Agent, LLC accepts the responsibility to act as designated agent for service of process. Applicant Information： Company name: Noble Paragon Pte. Ltd. Contact Name: Shi Feng Address: 10 Anson Road, #12-08, International Plaza, Singapore 079903 Telephone No: 0755-89668180 Email: [email protected] FRN: 0038724548 Signature: Shi Feng Agent Information: Company Name: FCC US Agent, LLC Address:3722 Illinois Avenue, Saint Charles, IL, 60174, USA FRN: 0033402884 Contact Name: Tim Payne Telephone No: 708-571-3148 Email: [email protected] Signature: Tim Payne

Noble Paragon Pte. Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 11, 2026 Subject; Request for Confidentiality FCC ID: 2BXHG-AFACE01N To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Shi Feng Title: Chairman

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 Noble Paragon Pte. Ltd. Date：2026-08-05 Product Model Number: AFace01N, AFace01B, AFace01C, AFace01G, AFace01H, AFace01K, AFace01M, AFace01O, AFace01P, AFace01R, AFace01W, AFace01Y FCC ID：2BXHG-AFACE01N To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. Signature: By: Shi Feng Contact Listed on FCC Wesbite Title: Chairman Email: [email protected] On behalf of: Noble Paragon Pte. Ltd.

Noble Paragon Pte. Ltd. Declaration Letter of Model Difference Date: 2026-08-05 FCC ID: 2BXHG-AFACE01N Tested Model Number: AFace01N Adding Model Number(s): AFace01B, AFace01C, AFace01G, AFace01H, AFace01K, AFace01M, AFace01O, AFace01P, AFace01R, AFace01W, AFace01Y Only the product color is different. Hardware, software, electrical and RF characteristics are identical. Yours Sincerely, Applicant: Noble Paragon Pte. Ltd. Address: 10 Anson Road, #12-08, International Plaza, Singapore 079903 Contact Person: Shi Feng Tel.: 0755-89668180 Email: [email protected] Sincerely, Signature:

Page 1 of 4 Report No.: LGT26G136 Appendix - External Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 4 Report No.: LGT26G136 Appendix - External Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 4 Report No.: LGT26G136 Appendix - External Photographs of EUT Constructional Details Photo 5 Photo 6 Page 4 of 4 Report No.: LGT26G136 Appendix - External Photographs of EUT Constructional Details Photo 7

Label Size: 31*24mm FCC ID: 2BXHG-AFACE01N

Page 1 of 4 Report No.: LGT26G136 Appendix - Internal Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 4 Report No.: LGT26G136 Appendix - Internal Photographs of EUT Constructional Details Photo 3 Photo 4 ANT Page 3 of 4 Report No.: LGT26G136 Appendix - Internal Photographs of EUT Constructional Details Photo 5 Photo 6 Page 4 of 4 Report No.: LGT26G136 Appendix - Internal Photographs of EUT Constructional Details Photo 7 Photo 8

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 8 EMF TEST REPORT Product Name: AFace attendance machine Model Number: AFace01N, AFace01B, AFace01C, AFace01G, AFace01H, AFace01K, AFace01M, AFace01O, AFace01P, AFace01R, AFace01W, AFace01Y FCC ID: 2BXHG-AFACE01N Issued For : Noble Paragon Pte. Ltd. 10 Anson Road, #12-08, International Plaza, Singapore 079903 Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26G136HA01 Sample Received Date: Jul. 21, 2026 Date of Test: Jul. 21, 2026 ~ Jul. 28, 2026 Date of Issue: Jul. 28, 2026 Report No.: LGT26G136HA01 Page 2 of 8 TEST REPORT CERTIFICATION Applicant: Noble Paragon Pte. Ltd. Address: 10 Anson Road, #12-08, International Plaza, Singapore 079903 Manufacturer: Noble Paragon Pte. Ltd. Address: 10 Anson Road, #12-08, International Plaza, Singapore 079903 Product Name: AFace attendance machine Trademark: TIMOZIA Model Number: AFace01N, AFace01B, AFace01C, AFace01G, AFace01H, AFace01K, AFace01M, AFace01O, AFace01P, AFace01R, AFace01W, AFace01Y Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47 CFR §2.1091 KDB 447498 D01 General RF Exposure Guidance v06 PASS Prepared by: Approved by: Chris Chen Engineer Technical Director Report No.: LGT26G136HA01 Page 3 of 8 TABLE OF CONTENTS 1 . GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST LABORATORY 5 2 . FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 EUT OPERATION CONDITION 7 2.4 CLASSIFICATION 7 2.5 TEST RESULT 8 Report No.: LGT26G136HA01 Page 4 of 8 Revision History Rev. Issue Date Revisions 00 Jul. 28, 2026 Initial Issue Report No.: LGT26G136HA01 Page 5 of 8 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name: AFace attendance machine Test Model Number: AFace01N Series Number: AFace01B, AFace01C, AFace01G, AFace01H, AFace01K, AFace01M, AFace01O, AFace01P, AFace01R, AFace01W, AFace01Y Model Difference: Only the product color is different. Hardware, software, electrical and RF characteristics are identical. Frequency Bands: Bluetooth 2402-2480MHz Rating: Input: DC 5V 1A Battery: Rated Voltage: DC 3V Hardware Version: Main board V11; key board V10 Software Version: 0000 1.2 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 Report No.: LGT26G136HA01 Page 6 of 8 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 0.3-3.0 614 1.63 *(100) 3.0-30 1842/f 4.89/f *(900/f 2 ) 30-300 61.4 0.163 1.0 300 - 1500 -- -- F/300 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 1.34-30 824/f 2.19/f *(180/f 2 ) 30-300 27.5 0.073 0.2 300 - 1500 -- -- F/1500 1500 – 100000 -- -- 1.0 F= Frequency in MHz * = Plane-wave equivalent power density. Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. Report No.: LGT26G136HA01 Page 7 of 8 2.3 EUT OPERATION CONDITION EUT was enabled to transmit and receive at lowest, middle and highest channels. 2.4 CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance from the antenna should be included in the User manual. So, this device is classified as Mobile device. Report No.: LGT26G136HA01 Page 8 of 8 2.5 TEST RESULT Turn up Result Mode Turn up Power BLE 1M-GFSK -2.5±1dBm BLE 2M-GFSK -2±1.5dBm The MPE result of worst mode: RF Function Max Turn up Power (dBm) Max Turn up Power (mW) ANT Gain (dBi) ANT Gain (gain of antenna in linear scale) Power Density (mW/cm²) Limit (mW/cm²) Ratio Result BLE -0.50 0.89 5.19 3.30 0.001 1 0.001 Pass Note: 1. The RF Exposure is less than the limit, complies with the exemption requirements. ※※※※※END OF THE REPORT※※※※※

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 53 RF TEST REPORT Product Name: AFace attendance machine Model Number: AFace01N, AFace01B, AFace01C, AFace01G, AFace01H, AFace01K, AFace01M, AFace01O, AFace01P, AFace01R, AFace01W, AFace01Y FCC ID: 2BXHG-AFACE01N Issued For : Noble Paragon Pte. Ltd. 10 Anson Road, #12-08, International Plaza, Singapore 079903 Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26G136RF01 Sample Received Date: Jul. 21, 2026 Date of Test: Jul. 21, 2026 ~ Jul. 28, 2026 Date of Issue: Jul. 28, 2026 Report No.: LGT26G136RF01 Page 2 of 53 TEST REPORT CERTIFICATION Applicant: Noble Paragon Pte. Ltd. Address: 10 Anson Road, #12-08, International Plaza, Singapore 079903 Manufacturer: Noble Paragon Pte. Ltd. Address: 10 Anson Road, #12-08, International Plaza, Singapore 079903 Product Name: AFace attendance machine Trademark: TIMOZIA Model Number: AFace01N, AFace01B, AFace01C, AFace01G, AFace01H, AFace01K, AFace01M, AFace01O, AFace01P, AFace01R, AFace01W, AFace01Y Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2020 + Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024 PASS Prepared by: Approved by: Chris Chen Vita Li Engineer Technical Director Report No.: LGT26G136RF01 Page 3 of 53 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST LABORATORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 TEST SOFTWARE AND POWER LEVEL 9 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.5 EQUIPMENTS LIST 11 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 TEST PROCEDURE 14 3.3 TEST SETUP 14 3.4 EUT OPERATING CONDITIONS 14 3.5 TEST RESULTS 15 4. RADIATED EMISSION MEASUREMENT 17 4.1 RADIATED EMISSION LIMITS 17 4.2 TEST PROCEDURE 19 4.3 TEST SETUP 19 4.4 EUT OPERATING CONDITIONS 20 4.5 FIELD STRENGTH CALCULATION 20 4.6 TEST RESULTS (BAND EDGE REQUIREMENTS) 25 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 27 5.1 LIMIT 27 5.2 TEST PROCEDURE 27 5.3 TEST SETUP 27 5.4 EUT OPERATION CONDITIONS 27 5.5 TEST RESULTS 27 6. POWER SPECTRAL DENSITY TEST 28 6.1 LIMIT 28 6.2 TEST PROCEDURE 28 6.3 TEST SETUP 28 6.4 EUT OPERATION CONDITIONS 28 Report No.: LGT26G136RF01 Page 4 of 53 6.5 TEST RESULTS 28 7. BANDWIDTH TEST 29 7.1 LIMIT 29 7.2 TEST PROCEDURE 29 7.3 TEST SETUP 29 7.4 EUT OPERATION CONDITIONS 29 7.5 TEST RESULTS 29 8. PEAK OUTPUT POWER TEST 30 8.1 LIMIT 30 8.2 TEST PROCEDURE 30 8.3 TEST SETUP 30 8.4 EUT OPERATION CONDITIONS 30 8.5 TEST RESULTS 30 9. ANTENNA REQUIREMENT 31 9.1 STANDARD REQUIREMENT 31 9.2 EUT ANTENNA 31 APPENDIX I - TEST RESULTS 32 1. DUTY CYCLE 32 2. BANDWIDTH 35 3. MAXIMUM CONDUCTED OUTPUT POWER 40 4. MAXIMUM POWER SPECTRAL DENSITY 43 5. UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS 46 APPENDIX II - MEASUREMENT PHOTOS 53 Report No.: LGT26G136RF01 Page 5 of 53 Revision History Rev. Issue Date Revisions 00 Jul. 28, 2026 Initial Issue Report No.: LGT26G136RF01 Page 6 of 53 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 Part 15.247 Meas Guidance v05r02. FCC Part 15.247, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020 + Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024. Report No.: LGT26G136RF01 Page 7 of 53 1.1 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Occupied Channel Bandwidth ±0.46% 2 RF Output Power, Conducted ±0.71dB 3 Power Spectral Density, Conducted ±1.57dB 4 Unwanted Emission, Conducted ±0.63dB 5 Conducted emission ±2.80dB 6 All Emissions, Radiated (0.009-30MHz) ±2.16dB 7 All Emissions, Radiated (30MHz-1GHz) ±4.61dB 8 All Emissions, Radiated (1GHz-18GHz) ±5.49dB 9 All Emissions, Radiated (18GHz-40GHz) ±4.31dB 10 Temperature ±0.5°C 11 Humidity ±2% 12 Duty Cycle ±2.3% Note: The measurement uncertainty is not included in the test result. Report No.: LGT26G136RF01 Page 8 of 53 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: AFace attendance machine Test Model Number: AFace01N Series Number: AFace01B, AFace01C, AFace01G, AFace01H, AFace01K, AFace01M, AFace01O, AFace01P, AFace01R, AFace01W, AFace01Y Model Difference: Only the product color is different. Hardware, software, electrical and RF characteristics are identical. Product Description: Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Radio Technology:…

Text truncated - open the document above for the full version.

嘉兴佳利电子有限公司http://www.glead.com.cn阿里巴巴http://zydq.en.alibaba.com JIAXINGGLEADELECTRONICSCO.,LTD -1- 产品技术规格书 SPECIFICATION 中国浙江省嘉兴市经济开发区正原路66号 No.66ZhengyuanRoad,EconomicDevelopmentZone,Jiaxing,Zhejiang,China TEL：0086-573-83651818FAX：0086-573-83651858 拟制 Preparedby ：审核 Checkedby ：批准 Approvedby ： 送样日期 FormedOn 产品版本 DocumentVersion (V1.3) 产品型号PARTNO：LA31H2450-A35 客户料号CUSTOMERPARTNO： 客户确认CUSTOMERAPPROVEDBY： 确认日期APPROVEDDATE： 嘉兴佳利电子有限公司http://www.glead.com.cn阿里巴巴http://zydq.en.alibaba.com JIAXINGGLEADELECTRONICSCO.,LTD -4- 产品尺寸/Size：3.2×1.6×1.2 1.概述 INTRODUCTION " 佳利 " 微波多层陶瓷天线 LA 系列产品设计用于 WLAN 、 WiFi 、蓝牙、 PHS ，手机 多频天线 ,FM 等小体积 SMD 片式设计。 "GLEAD"MicrowaveMulti-LayerCeramicAntennaLAseriesaredesignedtobeused inWLAN 、 WiFi 、 Bluetooth 、 PHS 、 Multiple-bandMobilephoneantenna,FM,etcand compactsizeSMDchipdesign. 2.型号 PartNumber LA31H2450-A35 3.外型尺寸 Dimensions （ Unit ： mm ） 天线频率/AntennaFrequency:2450MHz 产品设计结构H型/ViaDesignSeries 多层结构天线/Multi-layerAntenna 产品名称，编号A35/ProductName:A35 嘉兴佳利电子有限公司http://www.glead.com.cn阿里巴巴http://zydq.en.alibaba.com JIAXINGGLEADELECTRONICSCO.,LTD -5- 4.测试电路和匹配电路EvaluationBoardandMatchingCircuits 5.电气性能ElectricalCharacteristics No. Item （项目） Specifications （特性） 5.1 CentralFrequency中心频率(Nomatching)2875MHz (带匹配电路测试)AfterMatching2450MHz 5.2BandWidth通带宽度100MHztyp. 5.3PeakGain峰值增益5.19dBi 5.4V.S.W.R驻波比≤2.0 5.5 Polarization极化方式 Linear线性 5.6 AzimuthBeamwidth方位角 Omni-directional全向 5.7 Impedance阻抗 50Ω 6.2n 1.8n 嘉兴佳利电子有限公司http://www.glead.com.cn阿里巴巴http://zydq.en.alibaba.com JIAXINGGLEADELECTRONICSCO.,LTD -6- 6.特性曲线 Characteristiccurve 7. 方向图 RadiationPattern coordinates： 嘉兴佳利电子有限公司http://www.glead.com.cn阿里巴巴http://zydq.en.alibaba.com JIAXINGGLEADELECTRONICSCO.,LTD -7- X-ZPlane Y-ZPlane X-YPlane 嘉兴佳利电子有限公司http://www.glead.com.cn阿里巴巴http://zydq.en.alibaba.com JIAXINGGLEADELECTRONICSCO.,LTD -8- 3DRadiationPattern Frequency (MHz) 240024502500 Avg.Gain (dBi) -0.23-0.36-0.51 PeckGain (dBi) 4.985.194.55 Efficiency (%) 7071.269 嘉兴佳利电子有限公司http://www.glead.com.cn阿里巴巴http://zydq.en.alibaba.com JIAXINGGLEADELECTRONICSCO.,LTD -9- 8可靠性试验后允许误差PostDependabilityTolerance 经可靠性试验后允许比起始读数偏差见下表 PostDependabilityTolerance(Refertothetable) 9可靠性试验DependabilityTest 基准条件：温度范围Temperaturerange25±5°C 相对湿度范围RelativeHumidityrange55~75%RH 工作温度OperatingTemperaturerange-40°C~+125°C 9.1耐振动VibrationResist 在振动频率为10~55Hz振幅为1.5mm沿X.Y.Z方向各振动2小时后测试符合表8.1~8.4规定。 Thedeviceshouldsatisfytheelectricalcharacteristicsspecifiedinparagraph8.1~8.4afterappliedto thevibrationof10to55Hzwithamplitudeof1.5mmfor2hourseachinX,YandZdirections. 9.2耐跌落冲击DropShock 在100cm高度处按X，Y，Z三个面分别自由跌落在木制地板上共3次后测试符合表8.1~8.4规 定。 Thedeviceshouldsatisfytheelectricalcharacteristicsspecifiedinparagraph8.1~8.4afterdropping ontothehardwoodenboardfromtheheightof100cmfor3timeseachfacetofthe3dimensionsofthe device. 9.3耐焊接热SolderHeatProof 能承受经120~150°C的温度预热120秒后，在255°C+10°C的焊锡浸5±0.5秒，或300°C-10°C的 电烙铁焊接3±0.5秒，焊接面无损伤。 Thedeviceshouldbesatisfiedafterpreheatingat120°C~150°Cfor120secondsanddippingin solderingSnat255°C+10°Cfor5±0.5seconds，orelectriciron300°C-10°Cfor3±0.5seconds， withoutdamnify. 9.4推力试验AdhesiveStrengthofTermination 在产品电极端子上或表面上可承受5N(≦0603)；10N(>0603)水平推力10±1秒而无明显外观损坏 与电极移位。 Thedevicehavenoremarkabledamageorremovaloftheterminationafterhorizontalforceof 5N(≦0603)；10N(>0603)with10±1seconds. No.Item（项目） PostDependabilityTolerance (可靠性试验后允许附加误差) 8.1CentralFrequency中心频率±5MHz 8.2BandWidth通带宽度±5MHz 8.3Gain增益±0.1dBi 8.4V.S.W.R(inBW)驻波比±0.1 嘉兴佳利电子有限公司http://www.glead.com.cn阿里巴巴http://zydq.en.alibaba.com JIAXINGGLEADELECTRONICSCO.,LTD -10- 9.5耐弯曲试验BendingResistTest 将产品按图焊在1.6±0.2mm的PCB板中间，由箭头方向施 力：1mm/S，弯曲距离：1.5mm，保持5±1S，产品金属层无脱落。 WeldtheproducttothecenterpartofthePCBwiththethickness 1.6±0.2mmastheillustrationshows,andkeepexertingforce arrow-wardonitatspeedof:1mm/S,andholdfor5±1Satthe positionof1.5mmbendingdistance,sofar,anypeelingoffofthe productmetalcoatingshouldnotbedetected. 9.6耐湿热特性MoistureProof 在温度为60±2°C，相对湿度90~95%的恒温湿箱中放置96小时，在常温中恢复1~2小时后测 试，符合表8.1~8.4规定。 Thedeviceshouldsatisfytheelectricalcharacteristicsspecifiedinparagraph8.1~8.4afterexposedto thetemperature60±2°Candtherelativehumidity90~95%RHfor96hoursand1~2hoursrecoverytime undernormalcondition. 9.7高温特性HighTemperatureEndurance 在温度为125±5°C的恒温箱中放置96±2小时，在常温中恢复1~2小时后测试。符合表8.1~8.4 规定。 Thedeviceshouldsatisfytheelectricalcharacteristicsspecifiedinparagraph8.1~8.4afterexposedto temperature125±5°Cfor96±2hoursand1~2hoursrecoverytimeundernormaltemperature. 9.8低温特性LowTemperatureEndurance 在温度为-40°C±5°C低温箱中放置96±2小时后恢复1~2小时测试符合表8.1~8.4规定。 Thedeviceshouldalsosatisfytheelectricalcharacteristicsspecifiedinparagraph8.1~8.4afterexposed tothetemperature-40°C±5°Cfor96±2hoursandto2hoursrecoverytimeundernormaltemperature. 9.9温度循环TemperatureCycleTest 在-40°C温度中保持30分钟，再在+125°C温度中保持30分钟，共循环5次后在常温中恢复1~2 小时后测试符合表8.1~8.4规定。 Thedeviceshouldalsosatisfytheelectricalcharacteristicsspecifiedinparagraph8.1~8.4after exposedtothelowtemperature-40°Candhightemperature+125°Cfor30±2mineachby5cyclesand1 to2hoursrecoverytimeundernormaltemperature. 10 回流焊温度 ReflowSolderingStandardCondition 嘉兴佳利电子有限公司http://www.glead.com.cn阿里巴巴http://zydq.en.alibaba.com JIAXINGGLEADELECTRONICSCO.,LTD -11- 11包装尺寸(3216)PackagingandDimensions 11.1PlasticTape 包装说明：RemarksforPackage 载带尾部空穴长度150～200mm，载带头部空穴长度250～300mm，头部的盖带加长250mm。 Reservealengthof150~200mmforthetrailerofthecarrierand250~300mmfortheleaderofthe carrierandfurther250mmofcovertapeattheleadingpartofthecarrier. 11.2Reel（3000pcs/Reel） 11.3储存条件StoragePeriod 产品收到后半年内使用完毕. Productshouldbeusedwithinsixmonthsofreceipt. 湿敏等级1/储存温度与湿度: MSL1/StorageTemperatureRange:<30degreeC,Humidity:<85%RH

Page 1 of 2 Report No.: LGT26G136 Appendix - Test Setup photos Set-up for Radiated Spurious Emission, Below 1GHz Set-up for Radiated Spurious Emission, Above 1GHz Page 2 of 2 Report No.: LGT26G136 Set-up for Conducted Emission
