2BXIF-IX01RANGER IX01 Controller Adapter

FCC Statement This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this device does cause harmful interference to radio or television reception, which can be determined by turning the device off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment Reorient or relocate the receiving antenna. Increase the separation between the device and receiver. Connect the device into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help APP DOWNLOAD Failed to connect Mapping mode Native mode 1 3 2 4 Phone Connector Controller Port Charging Port Mode Button Plug the Type-C connector of the IX01 into your iPhone® or iPad®. Connection Steps Phone Connector Connect your controller (e.g., Xbox controller) to the USB port on the side of the IX01 using a USB data cable. Controller Port Connect a charging cable to the Type-C port for pass-through charging (optional). Charging Port Press the button once to switch between Mapping Mode and Native Mode. Mode Button Green Indicator: Mapping Mode — Open the GEEKGAMER app to configure or calibrate button mappings. Mapping Mode requires iOS Accessibility permissions. Follow the in-app instructions to enable the required permissions in Settings > Accessibility. Purple Indicator: Native Mode — Plug and play for games with native controller support and cloud gaming. If your phone case is too thick to connect directly, use the included extension cable. 将IX01的Type-C接口连接到您的iPhone®或iPad®。 连接步骤： 手机连接口 ⬦黃䖤手柄瀚⢢μùőƟ手柄瀛强廧ₖ—‰㒐㊎䷟连接⅐Fμ漐漑ệ暂 䖤—‰瀤㫭口 手柄连接口 刅映䷹手机充电ℹ⬦充电䷟接₅ệ暂䖤‘ƠūĆ瀤口 充电口 嫞⠧按揎：䜍按℧㊂㕀⬤濁⊿䐿㥁ⸯ 按键 丟㾏᷎：㕀⬤㥁ⸯ
瀧
ᄠ⸠濸㖚㵘䯞㾕濹ūū
㴛⇀濁㝁⃦按键㕀 ⬤ṭ于灖 㕀⬤㥁ⸯḺ嬣䑈䰛䷿庥⇉↿倝㘭⇁濛刅
ūū
⸵⬜㋰䡚濏嬗按(八)⸵ 儓濲嫞于
炴
庥⇉↿倝濳ᵍ⸠⍏ᅲ映㙣数灖 䱋㾏᷎：⊿䐿㥁ⸯ
瀧
⊓㋲⊓䑈瀚弢⌨⊿䐿手柄㵘ㄯ
濁
ᶱ㵘ㄯ瀛灖 刅手机⠓庣⊺㔀㯵接₅嫞⠧⌏ẟ䑈岀弡䖤⸖撟䷟廻坬㍍恭ẟ䑈灖 IX01 本体の Type-C 端子をお持ちの iPhone® または iPad® に接続します。 接続手順 : スマホ接続端子 ➰㾩؛64#ךーٕـ׾⢪欽׃ծ؜ーيコントローラー9CPYコン トローラーוז׾*9⩎꬗ه64#ךートח接続ׅת׃կ コントローラー接続端子 ׾⩎꬗ٕـー؛ծ充電כ㜥ざְ׋׃׵スマホ׾充電ָז׃؎ٖف կְׁ׌ֻג׃䯏ח端子 $5ZQF ך 充電端子 ׾سーٌـ؍ذ؎طسンٌؚーؾحマד׃ׅ䬃ֻ劥⡤ボタン瀊 կׅתִⴗ׶剏 操作ボタン 筯挿抧 マؾحンٌؚー سՂ չ(&&,(".&3պ،דٔفボタンꂁ縨 ׾锄侮〳腊կ ׵埅ꣳ׾ַ鏤㹁ְ䖞ח呩ⰻٔف،䗳銳ծָ鏪〳ך؍ذٔؽءإؙ، կְׁ׌ֻג׃剣⸭⻊ 稘挿抧 ٌـ؍ذ؎طー سՂ 䯏ֽ׌ׅ⢪欽〳կコントローラー垥 կֽぢيー؜س٥ؙラؐيー؜彋㼏䘕 ׌ֻⵄ欽׀׾ٕـー؛➰㾩䒁Ꟁכ儗ְזׇ䯏ֻ阜ָース؛スマホ կְׁ Best regards The KEEVOOX Team Thank you for choosing KEEVOOX. We truly appreciate your support and hope you enjoy your gaming journey with the IX01. We are committed to providing you with the best possible gaming experience. If you need any assistance or have any questions about the product, please contact the retailer or our customer support team. Dear Gamer, RANGER ix01 FCCStatement Thisdevicecomplieswithpart15oftheFCCrules.Operationissubjecttothefollowingtwocond itions:(1)thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptanyinte rferencereceived,includinginterferencethatmaycauseundesiredoperation. Caution:Changesormodificationsnotexpresslyapprovedbythepartyresponsiblefor compliancecouldvoidtheuser’sauthoritytooperatetheequipment. NOTE:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitald evice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprote ctionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgeneratesusesandc anradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions, maycauseharmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinte rferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferenc etoradioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,th euserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures: ‐Reorientorrelocatethereceivingantenna. ‐Increasetheseparationbetweentheequipmentandreceiver. ‐Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris connected. ‐Consultthedealeroranexperiencedradio/TVtechnicianforhelpimportantannouncement RadiationExposureStatement ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.Thedevicecanbeused inportableexposureconditionwithoutrestriction.

Rev1/26/2023 ShenzhenLingSheIntelligentTechnologyCo.,Ltd. FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date: 2026.8.11 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID:2BXIF-IX01 ShenzhenLingSheIntelligentTechnologyCo.,Ltd.certifiesthattheequipmentforwhich authorizationissoughtisnot“covered”equipmentprohibitedfromreceivinganequipment authorizationpursuanttosection2.903oftheFCCrules. ShenzhenLingSheIntelligentTechnologyCo.,Ltd.certifiesthattheequipmentforwhich authorizationissoughtdoesnotincludecybersecurityoranti-virussoftwareproducedorprovidedby KasperskyLab,Inc.oranyofitssuccessorsandassignees,includingequipmentwithintegratedKaspersky Lab,Inc.(oranyofitssuccessorsandassignees)cybersecurityoranti-virussoftwarepursuanttoDA-24- 886andKDB986446D01CoveredEquipmentGuidancesectionB(2a). Deviceisinherentlycompliantbasedonhardwarelimitationsorsoftwarecontrols. or ASoftwareBillofMaterials(SBOM)isprovidedtotheTCBforreview,and Theend-userorthirdpartiescannotinstalladditionalsoftwareonthisdevice. Sincerely, (Applicantsignature) (Applicantprintedname)YiYang Rev1/26/2023 ShenzhenLingSheIntelligentTechnologyCo.,Ltd. FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date: 2026.8.11 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID:2BXIF-IX01 ShenzhenLingSheIntelligentTechnologyCo.,Ltd.certifiesthat,asofthedateofthefilingofthe application,theapplicantisnotidentifiedontheCoveredList(asaspecificallynamedentityoranyofits subsidiariesoraffiliates)asanentityproducing“covered”equipment. Sincerely, (Applicantsignature) (Applicantprintedname)YiYang

ShenzhenLingSheIntelligentTechnologyCo.,Ltd. FamilyModelsDeclarationLetter Date:2026.8.14 CompanyName: ShenzhenLingSheIntelligentTechnologyCo.,Ltd. Address:Room511,Building13,HuachuangdaCulture&Technology IndustrialPark,Bao'anDistrict,Shenzhen,China FCCID: 2BXIF-IX01 TestModel:IX01 AdditionalModel(s): IX01PRO,IX01A,IX01APRO,IX01PROMAX,IX01LITE AllmodelsarethesamecircuitandRFmodule,exceptthemodelname. Sincerely, Signature: ContactPerson:YiYang Title:ProjectManager Telephone:18033412371 Fax:18033412371 E-mail:[email protected] CompanyName: ShenzhenLingSheIntelligentTechnologyCo.,Ltd. Address:Room511,Building13,HuachuangdaCulture&Technology IndustrialPark,Bao'anDistrict,Shenzhen,China

ShenzhenLingSheIntelligentTechnologyCo.,Ltd. Date：2026.8.11 ProductModelNumber:RANGERIX01ControllerAdapter FCCID ： 2BXIF-IX01 Towhomitmayconcern, Re:ProductCertificationRepresentativeAuthorizationLetter WeauthorizeQAILaboratoriesLtd.3980NorthFraserWay,BurnabyB.C. CanadaV5J5K5toactonourbehalfonallmattersconcerningtheabove namedequipment. Thisshallincludethefollowing: Testing Approvalapplicationsandprocedures WedeclarethatQAILaboratoriesLtd.isallowedtoforwardallinformation relatedtotheapprovalprojecttotheappliedcertificationbodyandtothe notificationentitiesandtodiscussanyissuesconcerningtheapproval application.AnyandallactscarriedoutbyQAILaboratoriesLtd.onour behalfshallhavethesameeffectasactsofourown. By: ContactListedonFCCWesbite Title: ProjectManager Email:[email protected] Telephone:18033412371 Onbehalfof:ShenzhenLingSheIntelligentTechnologyCo.,Ltd.

ShenzhenLingSheIntelligentTechnologyCo.,Ltd. OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:August14,2026 Subject;RequestforConfidentiality FCCID:2BXIF-IX01 ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthese documentsmightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantage inthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure SoftwareSecurityRequirementsforUNIIdevices Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:YiYang Title:ProjectManager

ReportNo.:AB26070567 Page 1 of 3 AppendixBEUTExternalPhotos ReportNo.:AB26070567 Page 2 of 3 ReportNo.:AB26070567 Page 3 of 3

LabelandInformation FCCLabelSample Size:0.5cm*0.5cm FCCLabelSpecifications TextisBlackincolorandisjustified.Labelsareprintedinindelibleinkonpermanentadhesivebacking orsilk-screenedontotheEUTorshallbeaffixedataconspicuouslocationontheEUT.WheretheEUT isconstructedintwoormoresectionsconnectedbywiresandmarketedtogether,theabovestatement isrequiredtobeaffixedonlytothemaincontrolunit.WhentheEUTissosmallorforsuchusethatitis notpracticabletoplacethestatementonit,theaboveinformationshallbeplacedinaprominentlocation intheinstructionmanualorpamphletsuppliedtotheuseror,alternatively,shallbeplacedonthe containerinwhichthedeviceismarketed. FCCLabelLocation FCCID:2BXIF-IX01 Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjectto thefollowingtwoconditions:(1)thisdevicemaynotcauseharmful interference,and(2)thisdevicemustacceptanyinterferencereceived, includinginterferencethatmaycauseundesiredoperation.

ReportNo.:AB26070567 Page1of3 AppendixCInternalPhotos ReportNo.:AB26070567 Page2of3 ReportNo.:AB26070567 Page3of3 BTANT

ReportNo.:AB26070567FW02 AiboStandardTechnology(Shenzhen)Co.,Ltd. 101,BuildingB,TuoriNewEnergyIndustrialPark,High-techPark,TianliaoCommunity,YutangStreet, GuangmingDistrict,ShenzhenCity,GuangdongProvince,China Tel.:+8675585250797E-mail:[email protected]:www.aibonorm.com FCCTESTREPORT ReportNo. ............................................. : AB26070567FW02 FCCID ................................................... : 2BXIF-IX01 Applicant ................................................ : ShenzhenLingSheIntelligentTechnologyCo.,Ltd. Address.................................................: Room511,Building13,HuachuangdaCulture&Technology IndustrialPark,Bao'anDistrict,Shenzhen,China Manufacturer.....................................: ShenzhenLingSheIntelligentTechnologyCo.,Ltd. Address.............................................: Room511,Building13,HuachuangdaCulture&Technology IndustrialPark,Bao'anDistrict,Shenzhen,China ProductName......................................: RANGERIX01ControllerAdapter TradeMark ............................................ : / TestModel ............................................. : IX01 AdditionalModel(s)..............................: IX01PRO,IX01A,IX01APRO,IX01PROMAX,IX01LITE Standard................................................: FCC47CFR § 1.1310;FCC47CFR § 2.1093 KDB447498D01GeneralRFExposureGuidancev06 DateofReceipt....................................:2026.07.31 DateofIssue........................................:2026.08.07 TestResult............................................:Pass Compiledby: (PrintedName+Signature) HuaijieLi Supervisedby: (PrintedName+Signature) DavidHuang Approvedby: (PrintedName+Signature) JayLiu TestingLaboratoryName...................:AiboStandardTechnology(Shenzhen)Co.,Ltd. Address.................................................:101,BuildingB,TuoriNewEnergyIndustrialPark,High-techPark, TianliaoCommunity,YutangStreet,GuangmingDistrict,Shenzhen City,GuangdongProvince,China Thistestreportmaybeduplicatedcompletelyforlegalusewiththeapprovaloftheapplicant.Itshouldnotbe reproducedexceptinfull,withoutthewrittenapprovalofourlaboratory.Theclientshouldnotuseittoclaim productendorsementbyAibo.Thetestresultsinthereportonlyapplytothetestedsample.Thetestreport shallbeinvalidwithoutallthesignaturesoftestingengineers,reviewerandapprover.Anyobjectionsmustbe raisedtoAibowithin15dayssincethedatewhenthereportisreceived.Itwillnotbetakenintoconsideration beyondthislimit.Thetestreportmerelycorrespondtothetestsample. ReportNo.:AB25100021FW02 Page2of8 AiboStandardTechnology(Shenzhen)Co.,Ltd. FCCTESTREPORT TestResultPositive Thetestreportmerelycorrespondstothetestsample. Itisnotpermittedtocopyextractsofthesetestresultwithoutthewrittenpermissionofthetestlaboratory. EUT......................................... : RANGERIX01ControllerAdapter TestModel.............................. : IX01 Applicant...............................:ShenzhenLingSheIntelligentTechnologyCo.,Ltd. Address...................................:Room511,Building13,HuachuangdaCulture&Technology IndustrialPark,Bao'anDistrict,Shenzhen,China Manufacturer......................... : ShenzhenLingSheIntelligentTechnologyCo.,Ltd. Address...................................:Room511,Building13,HuachuangdaCulture&Technology IndustrialPark,Bao'anDistrict,Shenzhen,China ReportNo.:AB25100021FW02 Page3of8 AiboStandardTechnology(Shenzhen)Co.,Ltd. REPORTVERSION VersionNo.IssueDateDescription 012026.08.07InitialIssue ReportNo.:AB25100021FW02 Page4of8 AiboStandardTechnology(Shenzhen)Co.,Ltd. TABLEOFCONTENTS 1.GENERALINFORMATION...................................................................................................................................5 1.1.GENERALDESCRIPTIONOFEUT..................................................................................................................5 1.2.DESCRIPTIONOFTESTFACILITY.................................................................................................................6 2.RFEXPOSUREEVALUATION............................................................................................................................7 2.1LIMIT..........................................................................................................................................................................7 2.2EVALUATIONRESULT...............................................................................................................................................8 2.3CONCLUSION............................................................................................................................................................8 ReportNo.:AB25100021FW02 Page5of8 AiboStandardTechnology(Shenzhen)Co.,Ltd. 1.GENERALINFORMATION 1.1.GENERALDESCRIPTIONOFEUT ProductName:RANGERIX01ControllerAdapter TradeMark:/ TestModel:IX01 AdditionalModel(s):IX01PRO,IX01A,IX01APRO,IX01PROMAX,IX01LITE ModelDifference:AllmodelsarethesamecircuitandRFmodule,exceptthemodelname HardwareVersion:V2.020260626 SoftwareVersion:V13 PowerSupply:DC5V/1A EUTSupportsFunction: (Providedbythecustomer) 2.4GHzISMBands TestSample(s)Number:ABA417260701-S004(EngineerSample) RadioSpecificationSubjecttothisReport BluetoothVersion:BluetoothLE FrequencyRange:2402MHz~2480MHz ModulationType:GFSK ChannelSpacing:2MHz ChannelNumber(s):40 AntennaType:InternalAntenna AntennaGain:1.68dBi ReportNo.:AB25100021FW02 Page6of8 AiboStandardTechnology(Shenzhen)Co.,Ltd. 1.2.DESCRIPTIONOFTESTFACILITY TestLab:AiboStandardTechnology(Shenzhen)Co.,Ltd. Address:101,BuildingB,TuoriNewEnergyIndustrialPark,High-techPark,TianliaoCommunity,YutangStreet, GuangmingDistrict,ShenzhenCity,GuangdongProvince,China Tel.:+8675585250797 E-mail:[email protected] Website:www.aibonorm.com Thetestfacilityisrecognized,certified,oraccreditedbythefollowingorganizations: A2LA-LabCertificateNo.:7514.01 AiboStandardTechnology(Shenzhen)Co.,Ltd.hasbeenaccreditedbyA2LAfortechnicalcompetence inthefieldofelectricaltesting,andprovedtobeincomplia…

Text truncated - open the document above for the full version.

ReportNo.:AB26070567FW01 AiboStandardTechnology(Shenzhen)Co.,Ltd. 101,BuildingB,TuoriNewEnergyIndustrialPark,High-techPark,TianliaoCommunity,YutangStreet, GuangmingDistrict,ShenzhenCity,GuangdongProvince,China Tel.:+8675585250797E-mail:[email protected]:www.aibonorm.com FCCTESTREPORT ReportNo..............................................:AB26070567FW01 FCCID...................................................:2BXIF-IX01 Applicant................................................:ShenzhenLingSheIntelligentTechnologyCo.,Ltd. Address.................................................: Room511,Building13,HuachuangdaCulture&Technology IndustrialPark,Bao'anDistrict,Shenzhen,China Manufacturer......................................:ShenzhenLingSheIntelligentTechnologyCo.,Ltd. Address..............................................: Room511,Building13,HuachuangdaCulture&Technology IndustrialPark,Bao'anDistrict,Shenzhen,China ProductName.......................................:RANGERIX01ControllerAdapter TradeMark............................................:/ TestModel.............................................:IX01 AdditionalModel(s)..............................:IX01PRO,IX01A,IX01APRO,IX01PROMAX,IX01LITE Standard ................................................ :FCC47CFRPart15SubpartC(Part15.247) ANSI C63.10-2020+Cor.1-2023+C63.10a-2024+Erratato C63.10a-2024 DateofReceipt....................................:2026.07.31 DateofTestDate ................................. :2026.07.31-2026.08.07 DateofIssue ........................................ :2026.08.07 TestResult ............................................ :Pass Compiledby: (PrintedName+Signature) HuaijieLi Supervisedby: (PrintedName+Signature) DavidHuang Approvedby: (PrintedName+Signature) JayLiu TestingLaboratoryName ................... :AiboStandardTechnology(Shenzhen)Co.,Ltd. Address ................................................. :101,BuildingB,TuoriNewEnergyIndustrialPark,High-techPark, TianliaoCommunity,YutangStreet,GuangmingDistrict,Shenzhen City,GuangdongProvince,China Thistestreportmaybeduplicatedcompletelyforlegalusewiththeapprovaloftheapplicant.Itshouldnot bereproducedexceptinfull,withoutthewrittenapprovalofourlaboratory.Theclientshouldnotuseitto claimproductendorsementbyAibo.Thetestresultsinthereportonlyapplytothetestedsample.Thetest reportshallbeinvalidwithoutallthesignaturesoftestingengineers,reviewerandapprover.Anyobjections mustberaisedtoAibowithin15dayssincethedatewhenthereportisreceived.Itwillnotbetakeninto considerationbeyondthislimit.Thetestreportmerelycorrespondtothetestsample. ReportNo.:AB26070567FW01 Page2of29 AiboStandardTechnology(Shenzhen)Co.,Ltd. FCCTESTREPORT TestResultPositive Thetestreportmerelycorrespondstothetestsample. Itisnotpermittedtocopyextractsofthesetestresultwithoutthewrittenpermissionofthetestlaboratory. EUT......................................... : RANGERIX01ControllerAdapter TestModel.............................. : IX01 Applicant...............................:ShenzhenLingSheIntelligentTechnologyCo.,Ltd. Address...................................:Room511,Building13,HuachuangdaCulture&Technology IndustrialPark,Bao'anDistrict,Shenzhen,China Manufacturer......................... : ShenzhenLingSheIntelligentTechnologyCo.,Ltd. Address...................................:Room511,Building13,HuachuangdaCulture&Technology IndustrialPark,Bao'anDistrict,Shenzhen,China ReportNo.:AB26070567FW01 Page3of29 AiboStandardTechnology(Shenzhen)Co.,Ltd. REPORTVERSION VersionNo.IssueDateDescription 012026.08.07InitialIssue ReportNo.:AB26070567FW01 Page4of29 AiboStandardTechnology(Shenzhen)Co.,Ltd. TABLEOFCONTENTS 1.GENERALINFORMATION.........................................................................................................................................5 1.1.GENERALDESCRIPTIONOFEUT.....................................................................................................................................5 1.2.DESCRIPTIONOFSUPPORTEQUIPMENT........................................................................................................................5 1.3.DESCRIPTIONOFEXTERNALI/O.....................................................................................................................................5 1.4.GENERALDESCRIPTIONOFAPPLIEDSTANDARDS.........................................................................................................6 1.5.DESCRIPTIONOFTESTFACILITY.....................................................................................................................................6 1.6.MEASUREMENTUNCERTAINTY......................................................................................................................................7 1.7.ENVIRONMENTALCONDITIONS.....................................................................................................................................7 1.8.DESCRIPTIONOFTESTMODES.......................................................................................................................................8 2.SUMMARYOFTESTRESULT..................................................................................................................................9 3.MEASUREMENTINSTRUMENTSLIST.................................................................................................................10 4.ANTENNAREQUIREMENT ......................................................................................................................................11 5.CONDUCTEDOUTPUTPOWER.............................................................................................................................12 5.1.LIMIT.............................................................................................................................................................................12 5.2.TESTSETUP................................................................................................................…

Text truncated - open the document above for the full version.

Product specification Quick Reference Date Antenna module on the system board Frequenc Range 2400 ~ 2500MHz Ant. Port Input Pwr. (dBm) 0 (Typ. BT class 2 output power) Tot. Rad. Pwr. (dBm) -1.2 (Input pwr – loss pwr) Peak EIRP(dBm) 1.68 Directivity (dBi) 1 (all direction antenna) Efficiency (dB) 6 0.2 % Gain (dBi) 1.2 (Avg Gain XY-plane) Maximum Power (dBm) 1.7 (XY-plane) Minimum Power (dBm) -4(XY-plane) Avg. Power (dBm) -0.5(XY-plane) Input Impendence(ohm) 50 Antenna TypeInternal Antenna V . S .W . R < 1.4 All the technical data and information contained herein are subject to change without prior notice Antenna Layout & module on the system board Antenna Gain Gain Table Unit in dBi @2.44GHz XY-plane XZ-plane YZ-plane Efficiency Peak Avg. Peak Avg. Peak Avg. Module Board 1.2 -0.5 -1.683.6 1.1 -3.0 6 0.2 % Manufacturer:Guangzhou Cambrian Electronic Technology Co., Ltd. Address: Room 1119, Building 1, Hongda Commercial and Creative Park, No. 96, Yuanxiang Road, Yunpu Street, Huangpu District, Guangzhou City 2cm 0.5cm Retum Loss The Environment of Antenna Radiation Pattem 3D radiation pattern diagram XY-plane XZ-plane YZ-plane

ReportNo.:AB26070567FW01 1 / 18 AppendixD_BLE DutyCycle ConditionModeFrequency(MHz)AntennaDutyCycle(%)CorrectionFactor(dB)1/T(kHz) NVNTBLE1M2402Ant170.011.550.57 NVNTBLE1M2440Ant185.360.690.47 NVNTBLE1M2480Ant185.360.690.47 ReportNo.:AB26070567FW01 2 / 18 TestGraphs DutyCycleNVNTBLE1M2402MHzAnt1 DutyCycleNVNTBLE1M2440MHzAnt1 ReportNo.:AB26070567FW01 3 / 18 DutyCycleNVNTBLE1M2480MHzAnt1 ReportNo.:AB26070567FW01 4 / 18 MaximumConductedOutputPower ConditionModeFrequency(MHz)AntennaConductedPower(dBm)Limit(dBm)Verdict NVNTBLE1M2402Ant13.2330Pass NVNTBLE1M2440Ant13.7330Pass NVNTBLE1M2480Ant14.9830Pass ReportNo.:AB26070567FW01 5 / 18 TestGraphs PowerNVNTBLE1M2402MHzAnt1 PowerNVNTBLE1M2440MHzAnt1 ReportNo.:AB26070567FW01 6 / 18 PowerNVNTBLE1M2480MHzAnt1 ReportNo.:AB26070567FW01 7 / 18 -6dBBandwidth ConditionModeFrequency(MHz)Antenna-6dBBandwidth(MHz)Limit-6dBBandwidth(MHz)Verdict NVNTBLE1M2402Ant10.68930.5Pass NVNTBLE1M2440Ant10.71790.5Pass NVNTBLE1M2480Ant10.65360.5Pass ReportNo.:AB26070567FW01 8 / 18 TestGraphs -6dBBandwidthNVNTBLE1M2402MHzAnt1 -6dBBandwidthNVNTBLE1M2440MHzAnt1 ReportNo.:AB26070567FW01 9 / 18 -6dBBandwidthNVNTBLE1M2480MHzAnt1 ReportNo.:AB26070567FW01 10 / 18 OccupiedChannelBandwidth ConditionModeFrequency(MHz)Antenna99%OBW(MHz) NVNTBLE1M2402Ant11.06 NVNTBLE1M2440Ant11.0706 NVNTBLE1M2480Ant11.0504 ReportNo.:AB26070567FW01 11 / 18 TestGraphs OBWNVNTBLE1M2402MHzAnt1 OBWNVNTBLE1M2440MHzAnt1 ReportNo.:AB26070567FW01 12 / 18 OBWNVNTBLE1M2480MHzAnt1 ReportNo.:AB26070567FW01 13 / 18 MaximumPowerSpectralDensityLevel ConditionModeFrequency(MHz)AntennaConductedPSD(dBm/3kHz)Limit(dBm/3kHz)Verdict NVNTBLE1M2402Ant1-12.468Pass NVNTBLE1M2440Ant1-12.158Pass NVNTBLE1M2480Ant1-10.988Pass ReportNo.:AB26070567FW01 14 / 18 TestGraphs PSDNVNTBLE1M2402MHzAnt1 PSDNVNTBLE1M2440MHzAnt1 ReportNo.:AB26070567FW01 15 / 18 PSDNVNTBLE1M2480MHzAnt1 ReportNo.:AB26070567FW01 16 / 18 BandEdge ConditionModeFrequency(MHz)AntennaMaxValue(dBc)Limit(dBc)Verdict NVNTBLE1M2402Ant1-50.09-20Pass NVNTBLE1M2480Ant1-57.78-20Pass ReportNo.:AB26070567FW01 17 / 18 TestGraphs BandEdgeNVNTBLE1M2402MHzAnt1Ref BandEdgeNVNTBLE1M2402MHzAnt1Emission ReportNo.:AB26070567FW01 18 / 18 BandEdgeNVNTBLE1M2480MHzAnt1Ref BandEdgeNVNTBLE1M2480MHzAnt1Emission

ReportNo.:AB26070567 Page1of4 AppendixATestPhotos ACPowerLineConductedEmissionsTestView ReportNo.:AB26070567 Page2of4 RadiatedSpuriousEmissionTestView1 ReportNo.:AB26070567 Page3of4 RadiatedSpuriousEmissionTestView2 ReportNo.:AB26070567 Page4of4 RFTestView
