Acknowledgeme nt Sampe Appr oval Drawing client CUSTOME dat e 2023．07．23 Da te productmodel Product Ty pe P / N 5dB,long 195 mm,separateantenna Part No Manufac turer Confirmation Field engineering ENGINEER QA QC vocation al work SALES Cus tomer Confirmati on Field Engineering ENGINEER QA QC Produce MANUFACTORY Purchase PURCHASING ShenzhenFengruixiangIntelligentTechnologyCo., Ltd. N95 2108 Longhu Junhui, No. 4745 Longhua Avenue, Qinghua Community, Longhua Street, Longhua District, Shenzhen, China 1.ProductOverview The5dBiseparativeantennaisadual-frequencyseparativeantennadesignedbasedonthedipole antennaprinciple,featuringhighgain,excellentefficiency,omnidirectionalradiation,andsuperiorport matching.Whendeployedinwirelessterminaldevices,itprovidesextensivecoverageandreliable communicationperformance. 2.ApplicationArea uVehicle-mountedDVDs,remote-controlledsmarttoycars,etc.; uNetworkcameras,set-topboxes,etc.; uConsumerelectronicdevicesorsmarthomeappliances(e.g.,TVs,DVDplayers,Blu-rayplayers); 3.KeyProperty Itmeetsconventionalantennaperformancerequirementsandachievesnearomnidirectionalcoverage. Theaveragegainissufficientlyhigh,reducingcoverageblindspots. Theexcellentportmatchingsignificantlyenhancestheefficiencyofsignaltransmissionandreception. 4.ConventionalStructuralDimensions 1 UElectricalParameters Frequencyrange2.4～5.8GHz 50ΩCharacteristicimpedance Voltagestanding-waveratio Gain ≤2:1 5.0dB 2WPowercapacity PolarizationForm Radiationdirection Horiz- ontal Omnid- irectional uMechanicalParameters Length195±3mm CablesinthesamevehicleRG-178 uOperating/StorageTemperature Workingtemperature Storagetemperature -30°C～65°C -30°C～75°C utestingfacility SATIMO58SG 2 5.Product P roperty Benefits and Gains X-Z plane Phi=0 Y-Z plane Phi=90 X-Y plane theta=90 Frequency (MHz) E-total (dBi) Efficiency (%) Peak Average Peak Average Peak Average Gain 3.11 3.20 3.32 Gain -2.54 -2.21 -2.91 Gain 3.40 3.13 3.30 Gain -5.05 -5.19 -4.88 Gain 2.62 2.70 2.63 Gain 2.45 2.36 2.56 2400 2450 2500 4.65 4.85 5.00 71% 70% 72% directional diagram 3 4 5

FCC ID: 2BXNY-SIN-3095-N95 _______________________________________________________________________________________________ Page 1 of 2 1. TEST SETUP PHOTOGRAPHS 1.1. Photo of Radiated Emissions Measurement Fig. 1 Fig. 2 FCC ID: 2BXNY-SIN-3095-N95 _______________________________________________________________________________________________ Page 2 of 2 Photo of Conducted Emission Measurement Fig. 3 Photo of DFS Fig. 4

Shenzhen Global Test Service Co.,Ltd. Room No. 101, Building 1, and Room No. 101, Building 3, No. 88 Jinkang Road, Jinsha Community, Kengzi Sub-district, Pingshan District, Shenzhen City, Guangdong, China FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID............................................. : GTS20251215008-1-02 2BXNY-SIN-3095-N95 Compiled by ( position+printed name+signature) . : File administrators Peter Xiao Supervised by ( position+printed name+signature) . : Test Engineer Evan Ouyang Approved by ( position+printed name+signature) . : Manager Jason Hu Date of issue .................................... : Aug.01, 2026 Representative Laboratory Name . : Shenzhen Global Test Service Co.,Ltd. Address ............................................ : Room No. 101, Building 1, and Room No. 101, Building 3, No. 88 Jinkang Road, Jinsha Community,Kengzi Sub-district, Pingshan District, Shenzhen City, Guangdong, China Applicant’s name ............................ : Hangzhou Sailink Trading Co., Ltd. Address ............................................ : Room A307,Building 3, No. 7 Longtan Road, Cangqian Subdistrict, Yuhang District, Hangzhou City, Zhejiang Province, China Test specification ........................... : Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ...................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Microcomputer Trade Mark ....................................... : SINSMART Manufacturer .................................... : Hangzhou Xindongtian Intelligent Technology Co., Ltd. Model/Type reference ...................... : SIN-3095-N95 Listed Models .................................. : SIN-3XXX-XXXXX (The first three x's represent A-Z,0-9 or blank respectively, indicating different colors, and the last five x's represent A-Z,0-9 or blank respectively, indicating different sales areas, and the difference does not affect the safety and electromagnetic compatibility of the products.) Modulation Type ............................... : GFSK Operation Frequency ........................ : From 2402MHz to 2480MHz Hardware Version ............................ : N/A Software Version .............................. : N/A Rating ............................................... : DC 24.0 V by Adapter Result ............................................... : PASS Report No.:GTS20251215008-1-02 Page 2 of 27 T E S T R E P O R T Test Report No. : GTS20251215008-1-02 Aug.01, 2026 ____________________________________________________________________________________________ Date of issue Equipment under Test : Microcomputer Model /Type : SIN-3095-N95 Listed model : SIN-3XXX-XXXXX (The first three x's represent A-Z,0-9 or blank respectively, indicating different colors, and the last five x's represent A-Z,0-9 or blank respectively, indicating different sales areas, and the difference does not affect the safety and electromagnetic compatibility of the products.) Applicant : Hangzhou Sailink Trading Co., Ltd. Address : Room A307,Building 3, No. 7 Longtan Road, Cangqian Subdistrict, Yuhang District, Hangzhou City, Zhejiang Province, China Manufacturer : Hangzhou Xindongtian Intelligent Technology Co., Ltd. Address : Room A319-A320,Building 3, No. 7 Longtan Road, Cangqian Subdistrict, Yuhang District, Hangzhou City, Zhejiang Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.:GTS20251215008-1-02 Page 3 of 27 Contents 1. TEST STANDARDS ......................................................................................................................................... 4 2. SUMMARY ....................................................................................................................................................... 5 2.1. General Remarks ................................................................................................................................... 5 2.2. Product Description ................................................................................................................................ 5 2.3. Equipment Under Test ........................................................................................................................... 7 2.4. Short description of the Equipment under Test (EUT) ........................................................................... 7 2.5. EUT operation mode .............................................................................................................................. 7 2.6. Block Diagram of Test Setup ................................................................................................................. 8 2.7. EUT Exercise Software .......................................................................................................................... 8 2.8. Special Accessories ............................................................................................................................... 8 2.9. External I/O Cable .................................................................................................................................. 8 2.10. Related Submittal(s) / Grant (s) ....................................................…

Text truncated - open the document above for the full version.

Shenzhen Global Test Service Co.,Ltd. Room No. 101, Building 1, and Room No. 101, Building 3, No. 88 Jinkang Road, Jinsha Community, Kengzi Sub-district, Pingshan District, Shenzhen City, Guangdong, China FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. .....................: FCC ID. ............................................ : GTS20251215008-1-03 2BXNY-SIN-3095-N95 Compiled by ( position+printed name+signature) .. : File administrators Peter Xiao Supervised by ( position+printed name+signature) .. : Test Engineer Evan Ouyang Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Aug.01, 2026 Representative Laboratory Name .: Shenzhen Global Test Service Co.,Ltd. Address ............................................ : Room No. 101, Building 1, and Room No. 101, Building 3, No. 88 Jinkang Road, Jinsha Community,Kengzi Sub-district, Pingshan District, Shenzhen City, Guangdong, China Applicant’s name ............................ : Hangzhou Sailink Trading Co., Ltd. Address ............................................ : Room A307,Building 3, No. 7 Longtan Road, Cangqian Subdistrict, Yuhang District, Hangzhou City, Zhejiang Province, China Test specification ...........................: Standard ........................................... : FCC Part 15.247: Operation within the bands 902-928 MHz, 2400- 2483.5 MHz and 5725-5850 MHz TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Microcomputer Trade Mark ....................................... : SINSMART Manufacturer .................................... : Hangzhou Xindongtian Intelligent Technology Co., Ltd. Model/Type reference....................... : SIN-3095-N95 Listed Models .................................. : SIN-3XXX-XXXXX (The first three x's represent A-Z,0-9 or blank respectively, indicating different colors, and the last five x's represent A-Z,0-9 or blank respectively, indicating different sales areas, and the difference does not affect the safety and electromagnetic compatibility of the products.) Operation Frequency ........................ : From 2412MHz to 2462MHz Hardware Version ............................ : N/A Software Version .............................. : N/A Rating ............................................... : DC 24.0 V by Adapter Result................................................ : PASS Report No.: GTS20251215008-1-03 Page 2 of 31 T E S T R E P O R T Test Report No. : GTS20251215008-1-03 Aug.01, 2026 ____________________________________________________________________________________ Date of issue Equipment under Test : Microcomputer Model /Type : SIN-3095-N95 Listed model : SIN-3XXX-XXXXX (The first three x's represent A-Z,0-9 or blank respectively, indicating different colors, and the last five x's represent A-Z,0-9 or blank respectively, indicating different sales areas, and the difference does not affect the safety and electromagnetic compatibility of the products.) Applicant : Hangzhou Sailink Trading Co., Ltd. Address : Room A307,Building 3, No. 7 Longtan Road, Cangqian Subdistrict, Yuhang District, Hangzhou City, Zhejiang Province, China Manufacturer : Hangzhou Xindongtian Intelligent Technology Co., Ltd. Address : Room A319-A320,Building 3, No. 7 Longtan Road, Cangqian Subdistrict, Yuhang District, Hangzhou City, Zhejiang Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20251215008-1-03 Page 3 of 31 Contents 1. TEST STANDARDS ......................................................................................................................................... 4 2. SUMMARY ....................................................................................................................................................... 5 2.1. General Remarks ................................................................................................................................... 5 2.2. Product Description ................................................................................................................................ 5 2.3. Equipment Under Test ........................................................................................................................... 7 2.4. Short description of the Equipment under Test (EUT) ........................................................................... 7 2.5. EUT operation mode .............................................................................................................................. 7 2.6. Block Diagram of Test Setup ................................................................................................................. 7 2.7. Related Submittal(s) / Grant (s) ............................................................................................................. 8 2.8. EUT Exercise Software .......................................................................................................................... 8 2.9. Special Accessories ............................................................................................................................... 8 2.10. External I/O Cable ........................................................…

Text truncated - open the document above for the full version.

FCC ID: 2BXNY-SIN-3095-N95 35 AppendixC.6:Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant1 2412 Reference 1.35 1.35 --- PASS 30~1000 1.35 -60.63 ≤-18.65 PASS 1000~26500 1.35 -47.98 ≤-18.65 PASS 2437 Reference 1.79 1.79 --- PASS 30~1000 1.79 -59.91 ≤-18.21 PASS 1000~26500 1.79 -47.87 ≤-18.21 PASS 2462 Reference 3.09 3.09 --- PASS 30~1000 3.09 -60.13 ≤-16.91 PASS 1000~26500 3.09 -47.15 ≤-16.91 PASS 11G Ant1 2412 Reference -0.35 -0.35 --- PASS 30~1000 -0.35 -60.72 ≤-20.35 PASS 1000~26500 -0.35 -47.54 ≤-20.35 PASS 2437 Reference -1.57 -1.57 --- PASS 30~1000 -1.57 -59.45 ≤-21.57 PASS 1000~26500 -1.57 -47.83 ≤-21.57 PASS 2462 Reference -1.04 -1.04 --- PASS 30~1000 -1.04 -60.94 ≤-21.04 PASS 1000~26500 -1.04 -47.72 ≤-21.04 PASS 11N20SISO Ant1 2412 Reference -3.53 -3.53 --- PASS 30~1000 -3.53 -61.02 ≤-23.53 PASS 1000~26500 -3.53 -47.85 ≤-23.53 PASS 2437 Reference -0.53 -0.53 --- PASS 30~1000 -0.53 -60.77 ≤-20.53 PASS 1000~26500 -0.53 -48.05 ≤-20.53 PASS 2462 Reference -1.58 -1.58 --- PASS 30~1000 -1.58 -60.78 ≤-21.58 PASS 1000~26500 -1.58 -47.7 ≤-21.58 PASS 11N40SISO Ant1 2422 Reference -3.28 -3.28 --- PASS 30~1000 -3.28 -60.96 ≤-23.28 PASS 1000~26500 -3.28 -47.16 ≤-23.28 PASS 2437 Reference -2.35 -2.35 --- PASS 30~1000 -2.35 -60.55 ≤-22.35 PASS 1000~26500 -2.35 -47.35 ≤-22.35 PASS 2452 Reference -2.14 -2.14 --- PASS 30~1000 -2.14 -60.98 ≤-22.14 PASS 1000~26500 -2.14 -47.71 ≤-22.14 PASS FCC ID: 2BXNY-SIN-3095-N95 36 11AX20SISO Ant1 2412 Reference -2.48 -2.48 --- PASS 30~1000 -2.48 -60.54 ≤-22.48 PASS 1000~26500 -2.48 -47.65 ≤-22.48 PASS 2437 Reference -2.71 -2.71 --- PASS 30~1000 -2.71 -60.25 ≤-22.71 PASS 1000~26500 -2.71 -48.11 ≤-22.71 PASS 2462 Reference -0.91 -0.91 --- PASS 30~1000 -0.91 -60.62 ≤-20.91 PASS 1000~26500 -0.91 -47.9 ≤-20.91 PASS 11AX40SISO Ant1 2422 Reference -5.03 -5.03 --- PASS 30~1000 -5.03 -60.2 ≤-25.03 PASS 1000~26500 -5.03 -47.9 ≤-25.03 PASS 2437 Reference -3.28 -3.28 --- PASS 30~1000 -3.28 -59.59 ≤-23.28 PASS 1000~26500 -3.28 -47.77 ≤-23.28 PASS 2452 Reference -4.19 -4.19 --- PASS 30~1000 -4.19 -60.62 ≤-24.19 PASS 1000~26500 -4.19 -47.33 ≤-24.19 PASS FCC ID: 2BXNY-SIN-3095-N95 37 Test Graphs 11B_Ant1_2412_0~Reference 11B_Ant1_2412_30~1000 11B_Ant1_2412_1000~26500 FCC ID: 2BXNY-SIN-3095-N95 38 11B_Ant1_2437_0~Reference 11B_Ant1_2437_30~1000 FCC ID: 2BXNY-SIN-3095-N95 39 11B_Ant1_2437_1000~26500 11B_Ant1_2462_0~Reference 11B_Ant1_2462_30~1000 FCC ID: 2BXNY-SIN-3095-N95 40 11B_Ant1_2462_1000~26500 11G_Ant1_2412_0~Reference FCC ID: 2BXNY-SIN-3095-N95 41 11G_Ant1_2412_30~1000 11G_Ant1_2412_1000~26500 11G_Ant1_2437_0~Reference FCC ID: 2BXNY-SIN-3095-N95 42 11G_Ant1_2437_30~1000 11G_Ant1_2437_1000~26500 FCC ID: 2BXNY-SIN-3095-N95 43 11G_Ant1_2462_0~Reference 11G_Ant1_2462_30~1000 11G_Ant1_2462_1000~26500 FCC ID: 2BXNY-SIN-3095-N95 44 11N20SISO_Ant1_2412_0~Reference 11N20SISO_Ant1_2412_30~1000 FCC ID: 2BXNY-SIN-3095-N95 45 11N20SISO_Ant1_2412_1000~26500 11N20SISO_Ant1_2437_0~Reference 11N20SISO_Ant1_2437_30~1000 FCC ID: 2BXNY-SIN-3095-N95 46 11N20SISO_Ant1_2437_1000~26500 11N20SISO_Ant1_2462_0~Reference FCC ID: 2BXNY-SIN-3095-N95 47 11N20SISO_Ant1_2462_30~1000 11N20SISO_Ant1_2462_1000~26500 11N40SISO_Ant1_2422_0~Reference FCC ID: 2BXNY-SIN-3095-N95 48 11N40SISO_Ant1_2422_30~1000 11N40SISO_Ant1_2422_1000~26500 FCC ID: 2BXNY-SIN-3095-N95 49 11N40SISO_Ant1_2437_0~Reference 11N40SISO_Ant1_2437_30~1000 11N40SISO_Ant1_2437_1000~26500 FCC ID: 2BXNY-SIN-3095-N95 50 11N40SISO_Ant1_2452_0~Reference 11N40SISO_Ant1_2452_30~1000 FCC ID: 2BXNY-SIN-3095-N95 51 11N40SISO_Ant1_2452_1000~26500 11AX20SISO_Ant1_2412_0~Reference 11AX20SISO_Ant1_2412_30~1000 FCC ID: 2BXNY-SIN-3095-N95 52 11AX20SISO_Ant1_2412_1000~26500 11AX20SISO_Ant1_2437_0~Reference FCC ID: 2BXNY-SIN-3095-N95 53 11AX20SISO_Ant1_2437_30~1000 11AX20SISO_Ant1_2437_1000~26500 11AX20SISO_Ant1_2462_0~Reference FCC ID: 2BXNY-SIN-3095-N95 54 11AX20SISO_Ant1_2462_30~1000 11AX20SISO_Ant1_2462_1000~26500 FCC ID: 2BXNY-SIN-3095-N95 55 11AX40SISO_Ant1_2422_0~Reference 11AX40SISO_Ant1_2422_30~1000 11AX40SISO_Ant1_2422_1000~26500 FCC ID: 2BXNY-SIN-3095-N95 56 11AX40SISO_Ant1_2437_0~Reference 11AX40SISO_Ant1_2437_30~1000 FCC ID: 2BXNY-SIN-3095-N95 57 11AX40SISO_Ant1_2437_1000~26500 11AX40SISO_Ant1_2452_0~Reference 11AX40SISO_Ant1_2452_30~1000 FCC ID: 2BXNY-SIN-3095-N95 58 11AX40SISO_Ant1_2452_1000~26500 FCC ID: 2BXNY-SIN-3095-N95 59 AppendixC.7: Duty Cycle Test Result TestMode Antenna Frequency[MHz] Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] Duty Cycle Factor[dB] 1/T Factor[KHz] 11B Ant1 2412 14.66 17.16 85.43 0.68 0.07 2437 14.66 17.17 85.38 0.69 0.07 2462 14.66 17.16 85.43 0.68 0.07 11G Ant1 2412 5.16 7.67 67.28 1.72 0.19 2437 5.16 7.67 67.28 1.72 0.19 2462 5.18 7.68 67.45 1.71 0.19 11N20SISO Ant1 2412 3.74 6.25 59.84 2.23 0.27 2437 3.74 6.25 59.84 2.23 0.27 2462 3.74 6.25 59.84 2.23 0.27 11N40SISO Ant1 2422 5.36 7.87 68.11 1.67 0.19 2437 5.36 7.87 68.11 1.67 0.19 2452 5.36 7.87 68.11 1.67 0.19 11AX20SISO Ant1 2412 9.36 11.86 78.92 1.03 0.11 2437 9.36 11.86 78.92 1.03 0.11 2462 9.35 11.86 78.84 1.03 0.11 11AX40SISO Ant1 2422 4.70 7.21 65.19 1.86 0.21 2437 4.70 7.21 65.19 1.86 0.21 2452 4.70 7.20 65.28 1.85 0.21 FCC ID: 2BXNY-SIN-3095-N95 60 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 FCC ID: 2BXNY-SIN-3095-N95 61 11G_Ant1_2412 11G_Ant1_2437 FCC ID: 2BXNY-SIN-3095-N95 62 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 FCC ID: 2BXNY-SIN-3095-N95 63 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 FCC ID: 2BXNY-SIN-3095-N95 64 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 11AX20SISO_Ant1_2412 FCC ID: 2BXNY-SIN-3095-N95 65 11AX20SISO_Ant1_2437 11AX20SISO_Ant1_2462 FCC ID: 2BXNY-SIN-3095-N95 66 11AX40SISO_Ant1_2422 11AX40SISO_Ant1_2437 11AX40SISO_Ant1_2452 FCC ID: 2BXNY-SIN-3095-N95 67

FCC ID: 2BXNY-SIN-3095-N95 1 Case No. : GTS20251215008-1-03 Ambient Condition: 22°C,49%RH, Test Date: 2026.2.30-2026.7.31Test Engineer:Evan ouyang AppendixC.1: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 12.040 2405.960 2418.000 0.5 PASS 2437 11.240 2431.800 2443.040 0.5 PASS 2462 10.400 2456.800 2467.200 0.5 PASS 11G Ant1 2412 16.280 2403.840 2420.120 0.5 PASS 2437 16.320 2428.880 2445.200 0.5 PASS 2462 16.440 2453.760 2470.200 0.5 PASS 11N20SISO Ant1 2412 17.400 2403.280 2420.680 0.5 PASS 2437 17.480 2428.280 2445.760 0.5 PASS 2462 17.440 2453.280 2470.720 0.5 PASS 11N40SISO Ant1 2422 36.240 2404.000 2440.240 0.5 PASS 2437 36.000 2419.080 2455.080 0.5 PASS 2452 36.080 2434.000 2470.080 0.5 PASS 11AX20SISO Ant1 2412 18.840 2402.560 2421.400 0.5 PASS 2437 18.880 2427.600 2446.480 0.5 PASS 2462 18.920 2452.480 2471.400 0.5 PASS 11AX40SISO Ant1 2422 37.920 2403.120 2441.040 0.5 PASS 2437 37.760 2418.280 2456.040 0.5 PASS 2452 36.960 2433.600 2470.560 0.5 PASS FCC ID: 2BXNY-SIN-3095-N95 2 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 FCC ID: 2BXNY-SIN-3095-N95 3 11G_Ant1_2412 11G_Ant1_2437 FCC ID: 2BXNY-SIN-3095-N95 4 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 FCC ID: 2BXNY-SIN-3095-N95 5 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 FCC ID: 2BXNY-SIN-3095-N95 6 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 11AX20SISO_Ant1_2412 FCC ID: 2BXNY-SIN-3095-N95 7 11AX20SISO_Ant1_2437 11AX20SISO_Ant1_2462 FCC ID: 2BXNY-SIN-3095-N95 8 11AX40SISO_Ant1_2422 11AX40SISO_Ant1_2437 11AX40SISO_Ant1_2452 FCC ID: 2BXNY-SIN-3095-N95 9 FCC ID: 2BXNY-SIN-3095-N95 10 AppendixC.2: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 14.977 2404.4887 2419.4657 --- --- 2437 14.984 2429.5199 2444.5039 --- --- 2462 14.917 2454.5225 2469.4395 --- --- 11G Ant1 2412 16.544 2403.7246 2420.2686 --- --- 2437 16.530 2428.7520 2445.2820 --- --- 2462 16.493 2453.7501 2470.2431 --- --- 11N20SISO Ant1 2412 17.625 2403.1841 2420.8091 --- --- 2437 17.635 2428.1868 2445.8218 --- --- 2462 17.632 2453.1708 2470.8028 --- --- 11N40SISO Ant1 2422 36.296 2403.9483 2440.2443 --- --- 2437 36.184 2418.9851 2455.1691 --- --- 2452 36.229 2433.9374 2470.1664 --- --- 11AX20SISO Ant1 2412 18.948 2402.5013 2421.4493 --- --- 2437 18.981 2427.5355 2446.5165 --- --- 2462 18.970 2452.5111 2471.4811 --- --- 11AX40SISO Ant1 2422 37.919 2403.0729 2440.9919 --- --- 2437 37.861 2418.1617 2456.0227 --- --- 2452 37.980 2432.9939 2470.9739 --- --- FCC ID: 2BXNY-SIN-3095-N95 11 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 FCC ID: 2BXNY-SIN-3095-N95 12 11G_Ant1_2412 11G_Ant1_2437 FCC ID: 2BXNY-SIN-3095-N95 13 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 FCC ID: 2BXNY-SIN-3095-N95 14 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 FCC ID: 2BXNY-SIN-3095-N95 15 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 11AX20SISO_Ant1_2412 FCC ID: 2BXNY-SIN-3095-N95 16 11AX20SISO_Ant1_2437 11AX20SISO_Ant1_2462 FCC ID: 2BXNY-SIN-3095-N95 17 11AX40SISO_Ant1_2422 11AX40SISO_Ant1_2437 11AX40SISO_Ant1_2452 FCC ID: 2BXNY-SIN-3095-N95 18 FCC ID: 2BXNY-SIN-3095-N95 19 AppendixC.3: Maximum conducted output power Test Result -CHP Test Mode Antenna Frequency[MHz] Peak power [dBm] Limit [dBm] Verdict 11B Ant1 2412 15.52 ≤30.00 PASS 2437 15.26 ≤30.00 PASS 2462 16.07 ≤30.00 PASS 11G Ant1 2412 18.33 ≤30.00 PASS 2437 18.79 ≤30.00 PASS 2462 19.48 ≤30.00 PASS 11N20SISO Ant1 2412 18.36 ≤30.00 PASS 2437 18.85 ≤30.00 PASS 2462 19.54 ≤30.00 PASS 11N40SISO Ant1 2422 18.95 ≤30.00 PASS 2437 19.31 ≤30.00 PASS 2452 19.59 ≤30.00 PASS 11AX20SISO Ant1 2412 18.…
