2BXOR-C08Magnetic Wireless Charging Power Bank

正面 封面 成品尺寸：50*50mm 展开尺寸：100*50mm 双面印刷 封底 背面 50 mm 100 mm Safety Precautions & Warranty CategoryDetails Safety Warnings 1. Do not disassemble, crush, puncture, or drop the device. 2. Keep away from fire, water, and extreme temperatures. 3. Gently pull and store the built-in cables; do not yankforcefully. 4. Keep out of reach of children. Maintenance If not used for an extended period, please charge and discharge the power bank at least once every 3 months to maintain battery health. Compliance This product complies with CE, FCC, RoHS, and UN38.3 transportation standards. Warranty [12 Months] warranty against manufacturing defects. Damage caused by misuse is not covered. USER MANUAL Magnetic Wireless Charging Power Bank 5000mAh 22.5W Model: C08 Name: Magnetic Wireless Charging Power Bank 5000mAh 22.5W Battery Capacity: 5000mAh Battery Quantity: 546280 3.85V 5000mAh Battery Type: Polymer lithium-ion battery Type-C Input: 5V DC 3A, 9V DC 2A (Max 18W) Type-C Output: 5V DC 3A, 9V DC 2.22A, 10V DC 2.25A (SCP), 12V DC 1.67A (PD, Max 20W/22.5W) Wireless Output: 5W / 7.5W / 10W / Max 15W Material: PC + ABS (Fireproof Material) Product parameters Common knowledge of safety maintenance If used frequently, it can keep the electrons of the battery cell in the best moving state. If not used for a long time, please charge 50% of the battery and store it. If not used frequently, please remember to charge and discharge the product every three months. Any product must be used correctly in a safe environment, especially electronic products, and attention must be paid to safe use of electricity. When you find that the battery level display is not accurate, please press the cycle of fully charged, fully discharged, fully discharged, and then charged again. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure statement The device has been evaluatec to meel general RF exposure requirement. The device can be used in portable exposure condition without restriction.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: Herland International Trading Inc FRN: 0036324101 Contact Name: Jianfeng Gao Address: 1370 Valley Vista Dr Ste 200 Diamond Bar California 91765-3921 Telephone No: 001-909-772-1888 Email: [email protected] Applicant: Company name: Shenzhen Zhuopai Digital Technology Co.,Ltd Product Description: Magnetic Wireless Charging Power Bank Grantee code: 2BXOR FCC ID: 2BXOR-C08 FRN: 0038775581 Contact Name: Jack bu Address: Room 4103, East Tower Building, Star River Twin Towers, Bantian, Longgang District, Shenzhen City Telephone No: 18906679427 Email: [email protected] [Shenzhen Zhuopai Digital Technology Co.,Ltd] certifies that, as of the date of this filing of the application with the TCB, [Herland International Trading Inc] is our designated US agent for service of process for the above referenced FCC ID. [Shenzhen Zhuopai Digital Technology Co.,Ltd] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [Herland International Trading Inc] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2026/08/13 Applicant’s Name: Jack bu US Agent’s Name: Jianfeng Gao Title: Manager Title: Manager Signature Signature

Attestation Statement. Old Code: C5266091 24 New Code: 00015544 Ed.3 Change reason: FRN is added to the Applicant information section. 1/1 Shenzhen Zhuopai Digital Technology Co.,Ltd TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen Zhuopai Digital Technology Co.,Ltd Grantee code: 2BXOR FCC ID: 2BXOR-C08 FRN: 0038775581 Contact Name: Jack bu Address: Room 4103, East Tower Building, Star River Twin Towers, Bantian, Longgang District, Shenzhen City China Telephone No: 18906679427 Fax No: 18906679427 Email: [email protected] i. [Shenzhen Zhuopai Digital Technology Co.,Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Shenzhen Zhuopai Digital Technology Co.,Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Shenzhen Zhuopai Digital Technology Co.,Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered” equipment . Date: 2026/08/13 Applicant’s Name: Jack bu Title: Manager Signature: The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Shenzhen Zhuopai Digital Technology Co.,Ltd Code 00018768 Ed. 1 Item 1. The device is able to install software/program installation? ☐ Yes, go to Item 2. ☒ No. In this case, the rest of the items do not apply. The device cannot support installation of Kaspersky cybersecurity or anti-virus software. Item 2. Technical Requirements for Kaspersky Cybersecurity Software: # General Requirements (For all Devices) Yes / No or N/A Comments 1 Internet connection for activation and updates (For all Operating Systems) N/A Device Magnetic Wireless Charging Power Bank Company name Shenzhen Zhuopai Digital Technology Co.,Ltd Grantee code 2BXOR FCC ID 2BXOR-C08 FRN 0038775581 Contact name Jack bu Address Room 4103, East Tower Building, Star River Twin Towers, Bantian, Longgang District, Shenzhen City China Telephone number 18906679427 E-mail [email protected] Chipset/module information SW6224 Operating System (if applicable) N/A Storage Capacity (hard drive or other permanent memory storage, if applicable) N/A 2 # General Requirements (For Windows Devices) Yes / No or N/A Comments 1 Storage: 1500 MB free space on the hard drive N/A 2 Operating System: Microsoft Windows 8, 8.1, 10 & 11 Home / Pro / Enterprise Microsoft Windows 7 Starter / Home Basic & Premium / Professional / Ultimate SP1 or higher N/A 3 Processor: 1 GHz or higher (x86 or x64) N/A 4 Memory (RAM)1 GB (32-bit) or 2 GB (64-bit) N/A 5 Screen Resolution: Minimum resolution of 1024 x 768 N/A # General Requirements (For macOS devices) Yes / No or N/A Comments 1 Operating System macOS® 13 – 14 N/A 2 Memory (RAM)4 GB N/A 3 Storage: 3455 MB free space on the hard drive N/A # General Requirements (For Android Devices) Yes / No or N/A Comments 1 Storage: 150 MB free space N/A 2 Operating System: Android™ 10 – 14 N/A 3 Screen Resolution: Minimum resolution of 320 x 480 N/A # General Requirements (for iOS devices) Yes / No or N/A Comments 1 Storage: 150 MB free space N/A 2 Operating System: iOS® 17 N/A # General Requirements (For Linux system) Yes / No or N/A Comments 3 1 Hard drive: 1 GB of free space N/A 2 CPU: Intel Pentium 1 GHz or higher N/A 3 RAM: 1 GB N/A 4 Minimum software requirements: AlmaLinux OS 8 or later; AlterOS 7.5 or later; Astra Linux Common Edition 2.12 or later; CentOS 6.7 or later; Debian GNU/Linux 10.0 or later; EulerOS 2.0 or later; Oracle Linux 7.3 or later ; Red Hat Enterprise Linux 6.7 or later ; Rocky Linux 8.5 or later ; SUSE Linux Enterprise Server 12.5 or later; Ubuntu 12.04 or later ; Uncom OS Home / Business / Education / Enterprise 2.2 or later; ALT Linux Workstaton / Workstation K / Server / Education 8 or later; ROSA Linux Workstation / Server 12 or later ; RED OS 7.3 and later ; N/A After reviewed the technical requirements, is the device capable of supporting the installation of Kaspersky software? ☐ Yes, go to Item 3. ☒ No. In this case, the rest of the items do not apply. The device cannot support installation of Kaspersky software Item 3. Connectivity Capabilities: 4 # Physical Interface Purpose Justification 1 1 # Wireless Interface Purpose Justification 1 1 After the review of this items, the device: ☒ Cannot support installation of any cybersecurity or anti-virus software on the covered list. ☐ Potentially can operate with any cybersecurity or anti-virus software on the covered list – additional third- party proof is provided to demonstrate compliance with requirements as of 2.911(d)5(i),(ii) – “Proof of Compliance with Covered List Software Requirements” of this document applies Signature: Name: Jack bu Date:2026-08-13 1 The justification field is used to justify why the software cannot be received through that interface. Check the annex for more indications.

TCB CALL página 1 File FCC ID: 2BXOR-C08 Please upload an exhibit that explains how does the TCB verify the new agent information: 1- Is the address of the agent a valid physical US mailing address (not a US post office box, not a virtual mailbox, not P.O. Boxes, not a vacant lot, not a public building, etc.) ○ We have checked if the address exists in a real and potential building (Google maps) + official US register, after this verification and the evidence below we can guarantee the following: not a US post office box not a virtual mailbox not P.O. Boxes not a vacant lot not a public building(note) ► We checked the FCC FRN Search based on the information provided by the grantee. On the official register from : Search | California Secretary of State TCB CALL página 2 TCB CALL página 3 TCB CALL página 4 TCB CALL página 5 TCB CALL página 6 TCB CALL página 7 TCB CALL página 8 TCB CALL página 9 ► CONCLUSION by TCB: The ASOP defined and provided by grantee is VALID and confirmed. Therefore the exhibit "C5266091_X23_Ed1_US_Agent_Letter" included in the file is ok. 2- Is the agent physically located at that valid US address such that the agent can be legally served at that address? Yes , check above 3- Has the listed agent clearly agreed in writing to serve as the agent for the grantee at that address? Yes, it is included in the exhibit "C5266091_X23_Ed1_US_Agent_Letter" >

C5266091_X10_Ed.2 1/1 Shenzhen Zhuopai Digital Technology Co.,Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2026.08.13 Subject: Request for Confidentiality FCC ID: 2BXOR-C08 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, C5266091_X10_Ed.2 1/1 Signature: Name: Jack bu Title: Manager 2026.08. 13

C5266091_X8_Ed.1 1/1 Letter of Authorization Shenzhen Zhuopai Digital Technology Co.,Ltd Company: Shenzhen Zhuopai Digital Technology Co.,Ltd Address: Room 4103, East Tower Building, Star River Twin Towers, Bantian, Longgang District, Shenzhen City China Product Name: Magnetic Wireless Charging Power Bank Model Number: C08 FCC Identifier: 2BXOR-C08 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Jack bu Date: 2026.08.13 Title: Manager Signature of applicant:

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(External Photos) Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

Size: 28*8mm M/N: C08 FCC ID: 2BXOR-C08 Label location

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(Internal Photos) Phone Coil antenna Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

Page 1 of 21 Report No.: DLE-260803011R Test Report FCC ID: 2BXOR-C08 Applicant: Shenzhen Zhuopai Digital Technology Co.,Ltd Address: Room 4103, East Tower Building, Star River Twin Towers, Bantian, Longgang District, Shenzhen City Manufacturer: Dongguan Zhuopai Electronic Technology Co., Ltd Address: No.1 Of 8, Xinxing road, Hengtang Industrial zone, Tangxia Town Dongguan Product Name: Magnetic Wireless Charging Power Bank Trade Mark: N/A Model Number: C08 Date of Receipt: Aug. 03, 2026 Test Date: Aug. 03, 2026 - Aug. 12, 2026 Date of Report: Aug. 12, 2026 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China Prepared (Engineer): Ken Tan Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Page 2 of 21 Report No.: DLE-260803011R Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 21 Report No.: DLE-260803011R Contents 1 General Description ................................................................................................................................. 5 1.1 Description of the EUT.................................................................................................................................................. 5 1.2 Description of test modes ............................................................................................................................................. 5 1.3 Description of support units .......................................................................................................................................... 6 2 Measurement uncertainty ........................................................................................................................ 6 3 Test facilities and accreditations ............................................................................................................ 7 3.1 Test laboratory .............................................................................................................................................................. 7 4 List of test equipment .............................................................................................................................. 8 5 Test result ................................................................................................................................................. 9 5.1 Requirement ................................................................................................................................................................. 9 5.2 Test setup ................................................................................................................................................................... 10 5.3 Test Procedures .......................................................................................................................................................... 11 5.4 Test results.................................................................................................................................................................. 12 Photographs of the Test Setup .................................................................................................................... 17 Photographs of the EUT ............................................................................................................................... 21 ----End of Report---- .......................................................................................................................................................... 21 Page 4 of 21 Report No.: DLE-260803011R Test Result Certification Applicant: Shenzhen Zhuopai Digital Technology Co.,Ltd Address: Room 4103, East Tower Building, Star River Twin Towers, Bantian, Longgang District, Shenzhen City Manufacturer: Dongguan Zhuopai Electronic Technology Co., Ltd Address: No.1 Of 8, Xinxing road, Hengtang Industrial zone, Tangxia Town Dongguan Product description Product name: Magnetic Wireless Charging Power Bank Trademark: N/A Model name: C08 Series Model: N/A Standards: FCC CFR 47 PART 1, § 1.1310 FCC CFR 47 PART 2, § 2.1093 Test method: KDB 680106 D01 Wireless Power Transfer v04 Date of Test Date of test: Aug. 03, 2026 - Aug. 12, 2026 Test result: Pass Page 5 of 21 Report No.: DLE-260803011R 1 General Description 1.1 Description of the EUT Product Name: Magnetic Wireless Charging Power Bank Trade Mark: N/A Model No.: C08 Series Model: N/A Model difference: N/A Electrical rating: Type-C Input: 5V3A, 9V2A Type-C Output: 5V3A, 9V2.22A, 12V1.67A Wireless Charging Output: 5W, 7.5W, 10W, 15W Battery:3.85V, 5000mAh Accessories: / RF specification: Operation frequency: 115-205kHz Modulation type: MSK Antenna type: Coil 1.2 Description of test modes All the test modes were carried out with the EUT in normal operation, the final test mode of the EUT was the worst test mode for emission test, which was shown in this report and defined as: No. Emission test modes Mode1 Wireless Phone Output Mode(5W) Mode2 Wireless Phone Output Mode(7.5W) Mode3 Wireless Phone Output Mode(10W) Mode4 Wireless Phone Output Mode(15W) Mode5 Stanby mode Note: 1. We have evaluated 1%, 50% and 99%…

Text truncated - open the document above for the full version.

Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260803011R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 18 TEST REPORT FCC ID: 2BXOR-C08 Applicant: Shenzhen Zhuopai Digital Technology Co.,Ltd Address: Room 4103, East Tower Building, Star River Twin Towers, Bantian, Longgang District, Shenzhen City Manufacturer: Dongguan Zhuopai Electronic Technology Co., Ltd Address: No.1 Of 8, Xinxing road, Hengtang Industrial zone, Tangxia Town Dongguan Product Name: Magnetic Wireless Charging Power Bank Trade Mark: N/A Model Number: C08 Date of Receipt: Aug. 03, 2026 Test Date: Aug. 03, 2026 - Aug. 12, 2026 Date of Report: Aug. 12, 2026 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China Applicable Standards: FCC PART 15 Subpart C ANSI C63.10-2020 + Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024 Test Result: Pass Report Number: DLE-260803011R Prepared (Engineer): Ken Tan Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260803011R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 18 TABLE OF CONTENT Test Report Declaration Page 1. VERSION .................................................................................................................................. 3 2. TEST SUMMARY .................................................................................................................... 3 3. GENERAL INFORMATION ................................................................................................... 4 4. TEST INSTRUMENT USED .................................................................................................. 6 5. CONDUCTED EMISSION TEST .......................................................................................... 7 6. RADIATION EMISSION TEST ............................................................................................ 11 7. BANDWIDTH TEST .............................................................................................................. 17 8. ANTENNA REQUIREMENT ................................................................................................ 18 9. SETUP PHOTOGRAPHS .................................................................................................... 18 10. EUT PHOTOGRAPHS ...................................................................................................... 18 Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260803011R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 18 1. VERSION Version No. Date Description 00 Aug. 12, 2026 Original 2. TEST SUMMARY EMC Emission Test Item Section in CFR 47 Result Remark AC Power Line Conducted Emission 15.207 PASS Spurious Emission 15.209(a)(f) PASS 20dB Bandwidth 15.215 PASS Antenna requirement 15.203 PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Test lab: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 IC Registered No.: 27485 CAB ID.: CN0118 Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260803011R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 18 3. GENERAL INFORMATION 3.1 Description of Device (EUT) Product Name: Magnetic Wireless Charging Power Bank Trade Mark: N/A Model Number: C08 Model Difference: N/A Serial No.: N/A Hardware version: H1.0 Software version: S1.0 Operation Frequency: 115kHz ~ 205KHz Modulation type: MSK Antenna Type: Coil Antenna Antenna gain: 0dBi Power supply: Type-C Input: 5V3A, 9V2A Type-C Output: 5V3A, 9V2.22A, 12V1.67A Wireless Charging Output: 5W, 7.5W, 10W, 15W Battery:3.85V, 5000mAh 3.2 Tested System Details None. 3.3 Block Diagram of Test Set-up AC Mode DC Mode 3.4 Test Mode Description Mode1. Type-C Input+ Wireless charger Output Mode(5W, 1%/50%/99%) Mode2. Type-C Input+ Wireless charger Output Mode(7.5W, 1%/50%/99%) Mode3. Type-C Input+ Wireless charger Output Mode(10W, 1%/50%/99%) Mode4. Type-C Input+ Wireless charger Output Mode(15W, 1%/50%/99%) Mode5. Wireless charger Output Mode(5W, 1%/50%/99%) Mode6. Wireless charger Output Mode(7.5W, 1%/50%/99%) Mode7. Wireless charger Output Mode(10W, 1%/50%/99%) Mode8. Wireless charger Output Mode(15W, 1%/50%/99%) Note: 1. We have evaluated 1%, 50% and 99% battery charging mode, and the worst mode (99%) is showed in this report. 2. All modes have been tested, and the report only shows the results of the worst mode8. AC Mains EUT EUT Phone Adapter Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260803011R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 18 3.5 Test Auxiliary Equipment Adapter (Provide by test lab): Manufacturer: XIAOMI Model: MDY-14-EU Mobile phone (Provide by test lab): Manufacturer: SAMSUNG Model: Galaxy S21 5G 3.6 Test Uncertainty Conducted Emission Uncertainty(150KHz-30MHz) : ±2.56dB 20dB Bandwidth : ±0.5kHz Radiated Emission Uncertainty(9KHz-1GHz) : ±3.24dB Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260803011R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 6 of 18 4. TEST INSTRUMENT USED For Conducted Emission Test (843 Shielded Room) Equipment Manufacturer Model Serial Last Cal. Next Cal. 843 Shielded Room YIHENG 843 Room 843 Nov. 05, 2023 Nov. 04, 2026 …

Text truncated - open the document above for the full version.

Fine Page 1 of 3 承 認 書 SPECIFICATION FOR APPROVAL 客 戶： CUSTOMER: 深圳市金天下科技有限公司 客 戶 料 號： CUST P/N: 松 岛 料 號： FINE P/N: G43.5-6.5uH 单线圈0.08*24*2P*10TS 産 品 型 號： DESC: Φ43.5MMX5.3MMX0.65MM双槽磁片 日 期： DATE: 2023/11/2 版 本： Version: A.0 擬制 PREPARED BY 審核 CHECKED BY 批准 APPROVED BY 客戶承認 CUSTOMER APPROVE 黄燕铭 宁元安 黄锦华 版本變更履歷 Version Change History 版本 Rev. 變 更 前 Before Change 變 更 後 After Change 更 改 日 期 Change Date 批 准 Approved By A.0 新发行 ---- 2018/04/24 黄锦华 Fine Page 2 of 3 SPECIFICATION 産 品 型 號： DESC Φ 20.5x38.5-6.5uH-0.08x24*2P-45mm-43. 5C 版本 Rev：A.0 客戶CUST: XXX 客户料号CUST P/N: 一、尺寸DIMENSION:(mm) A 38.5±0.5 B 20.5±0.5 C 1.25 Max D 45±1 E 4±2 Fine Page 3 of 3 二、原理图SCHEMATIC DIAGRAM: F 43.5±0.5 G 8.0 ref H 1.6±0.2 I 5.3 ref M 8.0 ref J 42±1 K 3.0±1 注： 1.交叉出线; 2.出线位置缠5mm(ref)宽度高 温胶纸1-2Ts; 3.线圈贴圆形硬磁片带槽，磁 片尺寸43.5±0.5mm,内孔 5.3mm,厚度为0.65±0.2mm磁 片背胶 三、绕线参数Winding Specification: 序号 NO. 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 Winding Direction 1 S F 自粘漆包线0.08*24*2P 10Ts CCW 四、电气特性ELECTRICAL CHARACTERISTICS: 温度TEMPERATURE:25±10°C, 湿度RELATIVE HUMIDITY:65±20% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TEST FREQUENCY 测试仪器 TEST EQUIPMENTS 1 IND. S-F 3.8uH ±20%单独线圈 100KHz/0.25V UC2836 2 IND. S-F 6.5uH ±10%加磁片 100KHz/0.25V UC2836 3 DCR S-F ≤84mΩ 100KHz/0.25V UC2836 4 Q S-F ≥35 100KHz/0.25V UC2836 擬制/日期PREPARED BY/DATE 審核/日期CHECKED BY/DATE 黄燕铭2023/11/2 黄锦华2023/11/2

Shenzhen DL Testing Technology Co., Ltd. EUT TEST PHOTO Radiated Measurement Photos Shenzhen DL Testing Technology Co., Ltd. Conducted Measurement Photos ※※※※※ END OF REPORT ※※※※※
