2BXXH-208UCOREMINIMINI/NANO SPEAKERS

U NANO SPEAKER 1.Speaker Grille 3.Microphone 5.USB-C Charging Port 7.Lanyard Attachment Hole 2.RGB LED Indicator 4.Charging LED Indicator 6.Power / Multifunction Button Charging the Battery: Connect the USB-C cable to the speaker and plug the USB-A end into a 5 V USB power source. The charging LED indicator will light up. When charging is complete, the charging LED indicator will turn o. When you hear the "Di-Di" warning tone or notice reduced volume, recharge the speaker. Bluetooth Pairing: Press and hold the Power button to turn on the speaker. You will hear a voice prompt, and the LED indicator will begin ashing to indicate pairing mode. Enable Bluetooth on your device and search for "U SPEAKER-NANO ." Select "U SPEAKER-NANO" to pair. A voice prompt will conrm successful pairing. Once paired, the speaker will automatically reconnect to your device when Bluetooth is enabled and the speaker is powered on. True Wireless Stereo (TWS) Pairing: Turn on both speakers. Double-press the Power button on either speaker. The speakers will automatically pair with each other within approximately 3 seconds. Enable Bluetooth on your device. Select "U SPEAKER-NANO " from the Bluetooth menu. A voice prompt will conrm successful pairing. Music Playback & Calls: Open your preferred music app on your Bluetooth device. Use the multifunction button to: Play/Pause music Skip tracks Answer calls End calls To turn o the speaker, press and hold the Power button for 2 seconds. Usage Notes: Bluetooth performance may be aected by obstacles such as walls, metal objects, trees, or other materials. These may reduce the eective operating range. Fully charge the speaker before rst use for optimal performance. Low battery power may aect sound quality. Do not expose the speaker to high temperatures or excessive moisture. www.uspeaker.com © 2026 I&G Designs and Logistics, DBA Fashionit. All rights reserved. RoHS Power Output 3W 20 Hz–20 kHz < 1% ≥ 80 dB Ø36 mm, 4 Ω, 3 W 3.7 V / 300 mAh Bluetooth® 5.3 Ø50 × 33 mm 70 g Frequency Response THD Signal-to-Noise Ratio Speaker Driver Battery Bluetooth Version Product Size Product Weight Specications: FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 0cm between the radiator and your body.

I&G DESIGNS AND LOGISTICS DBA FASHIONIT 14999 Preston Rd Suite 112 #310 Dallas Texas 75254 United States 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: I&G DESIGNS AND LOGISTICS DBA FASHIONIT Address: 14999 Preston Rd Suite 112 #310 Dallas Texas 75254 United States Product Name: MINI/NANO SPEAKERS FCC ID: 2BXXH-208UCOREMINI Model(s): 208-U-CORE-MINI, U MINI, U NANO, U CORE 2.911(d)(5)(i) Equipment Type We, [I&G DESIGNS AND LOGISTICS DBA FASHIONIT] (“the applicant”) certify that the equipment for which authorization is sought through certification is not: • Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules. • Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Annabel Wolman Date: 2026-9-11 Title and Company name: Manager/ I&G DESIGNS AND LOGISTICS DBA FASHIONIT NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

2.911 (d)(5)(ii) Applicant Attestation v1.3 I&G DESIGNS AND LOGISTICS DBA FASHIONIT 14999 Preston Rd Suite 112 #310 Dalla s Texas 75254 United States Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: I&G DESIGNS AND LOGISTICS DBA FASHIONIT Address: 14999 Preston Rd Suite 112 #310 Dallas Texa s 75254 United States Product Name: MINI/NANO SPEAKERS FCC ID: 2BXXH-208UCOREMINI Model(s): 208-U-CORE-MINI , U MINI, U NANO, U CORE 2.911(d)(5)(ii) Applicant filing We, [I&G DESIGNS AND LOGISTICS DBA FASHIONIT] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Annabel Wolman Date: 2026-9-11 Title and Company name: Manager/ I&G DESIGNS AND LOGISTICS DBA FASHIONIT NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1)986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

I&G DESIGNS AND LOGISTICS DBA FASHIONIT 14999 Preston Rd Suite 112 #310 Dallas Texas 75254 United States Date: 2026-9-11 FCC ID: 2BXXH-208UCOREMINI Dear Sir/Madam, We, I&G DESIGNS AND LOGISTICS DBA FASHIONIT Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, only model number and colour are different for these model. So the tests were performed on model 208-U-CORE-MINI and the test results for the main test model can cover the listed models.: Product name: MINI/NANO SPEAKERS Model no.: 208-U-CORE-MINI, U MINI, U NANO, U CORE Sincerely, Name/Title： Annabel Wolman/Manager Company: I&G DESIGNS AND LOGISTICS DBA FASHIONIT Address: 14999 Preston Rd Suite 112 #310 Dallas Texas 75254 United States Phone: (800) 546-7302 Fax: N/A E-Mail: [email protected]

I&G DESIGNS AND LOGISTICS DBA FASHIONIT 14999 Preston Rd Suite 112 #310 Dallas Texas 75254 United States Letter of Authorization Company: I&G DESIGNS AND LOGISTICS DBA FASHIONIT Address: 14999 Preston Rd Suite 112 #310 Dallas Texas 75254 United States FCC ID: 2BXXH-208UCOREMINI Model Number(s): 208-U-CORE-MINI, U MINI, U NANO, U CORE Product Description: MINI/NANO SPEAKERS We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Sincerely, Name/Title： Annabel Wolman/Manager Company: I&G DESIGNS AND LOGISTICS DBA FASHIONIT Address: 14999 Preston Rd Suite 112 #310 Dallas Texas 75254 United States Phone: (800) 546-7302 Fax: N/A E-Mail: [email protected]

I&G DESIGNS AND LOGISTICS DBA FASHIONIT 14999 Preston Rd Suite 112 #310 Dallas Texas 75254 United States Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-9-11 Subject; Request for Confidentiality FCC ID: 2BXXH-208UCOREMINI Product name: MINI/NANO SPEAKERS Model no.: 208-U-CORE-MINI, U MINI, U NANO, U CORE To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. I&G DESIGNS AND LOGISTICS DBA FASHIONIT 14999 Preston Rd Suite 112 #310 Dallas Texas 75254 United States Sincerely, Name/Title： Annabel Wolman/Manager Company: I&G DESIGNS AND LOGISTICS DBA FASHIONIT Address: 14999 Preston Rd Suite 112 #310 Dallas Texas 75254 United States Phone: (800) 546-7302 Fax: N/A E-Mail: [email protected]

FCC ID: 2BXXH-208UCOREMINI External Photos of the EUT FCC ID: 2BXXH-208UCOREMINI FCC ID: 2BXXH-208UCOREMINI

Label and Location Size: L: 2.0cm*W: 1.0cm Label and Location FCC ID : 2BXXH-208UCOREMINI

FCC ID: 2BXXH-208UCOREMINI Internal Photos of the EUT Antenna FCC ID: 2BXXH-208UCOREMINI FCC ID: 2BXXH-208UCOREMINI

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn RF Exposure evaluation Report Reference No. ..................... : FCC ID............................................. : CTA26072700102 2BXXH-208UCOREMINI Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Aug. 05, 2026 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ............................ : I&G DESIGNS AND LOGISTICS DBA FASHIONIT Address............................................ : 14999 Preston Rd Suite 112 #310 Dallas TX 75254 Standard ........................................... : 47CFR §1.1310 47CFR §2.1093 KDB447498 D01 General RF Exposure Guidance v06 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purpses as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : MINI/NANO SPEAKERS Trade Mark ....................................... : U SPEAKERS Manufacturer .................................... : Shenzhen Senshao Technology Co., Ltd. Model/Type reference ...................... : 208-U-CORE-MINI Listed Models ................................... : U MINI, U NANO, U CORE Rating ............................................... : Input: DC 5V Battery: 3.7V 300mAh 1.85Wh Result ............................................... : PASS Report No.: CTA26072700102 Page 2 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : MINI/NANO SPEAKERS Model /Type : 208-U-CORE-MINI Listed Models : U MINI, U NANO, U CORE Model difference : The PCB board, circuit, structure and internal of these models are the same, only model number and colour are different for these model. So the tests were performed on model 208-U-CORE-MINI and the test results for the main test model can cover the listed models. Applicant : I&G DESIGNS AND LOGISTICS DBA FASHIONIT Address : 14999 Preston Rd Suite 112 #310 Dallas TX 75254 Manufacturer : Shenzhen Senshao Technology Co., Ltd. Address : 3rd Floor,Block 1 ,ChangGuang Industrial Park,AoBei Second Village, HengGang Street, LongGang District, ShenZhen, GuangDong, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA26072700102 Page 3 of 8 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ............................................................................................................ 4 2 SUMMARY .......................................................................................................................... 5 2.1 General Remarks ..................................................................................................... 5 2.2 Product Description ................................................................................................. 5 2.3 Special Accessories ................................................................................................. 5 2.4 Modifications ............................................................................................................ 5 3 TEST ENVIRONMENT ....................................................................................................... 6 3.1 Address of the test laboratory .................................................................................. 6 3.2 Test Facility .............................................................................................................. 6 3.3 Statement of the measurement uncertainty ............................................................. 6 4 Test limit .............................................................................................................................. 7 4.1 Requirement ............................................................................................................ 7 4.2 Conducted Power Results ....................................................................................... 7 4.3 Manufacturing tolerance .......................................................................................... 8 4.4 Evaluation Result ..................................................................................................... 8 4.5 Simultaneous Transmission for SAR Exclusion ...................................................... 8 5 Conclusion ........................................................................................................................... 8 Report No.: CTA26072…

Text truncated - open the document above for the full version.

Productspecification QuickReferenceDate Antennamoduleonthesystemboard Frequency 2.45GHz *1 Ant.PortInputPwr.(dBm)0(Typ.BTclass2outputpower) Tot.Rad.Pwr.(dBm)-2.3(Inputpwr–losspwr) PeakEIRP(dBm)1.3 Directivity(dBi)1 (alldirectionantenna) Efficiency(dB)-2.3(58.5%) Gain(dBi)1.3(PeakGainXY-plane) MaximumPower(dBm)1.3(XY-plane) MinimumPower(dBm)-4(XY-plane) Avg.Power(dBm)-0.5(XY-plane) Max/MinRatio(dB)5.3(XY-plane) Max/AvgRatio(dB)1.8(XY-plane) Min/AvgRatio(dB)-3.5(XY-plane) AverageGain(dB)-0.5(AvgGainXY-plane) Allthetechnicaldataandinformationcontainedhereinaresubjecttochangewithoutpriornotice AntennaLayout&moduleonthesystemboard AntennaGain GainTable [email protected] PeakAvg.PeakAvg.PeakAvg. ModuleBoard 1.3-0.51.7-3.81.1-3.058.5% ReturnLoss TheEnvironmentofAntennaRadiationPattern 3Dradiationpatterndiagram XY-planeXZ-planeYZ-plane Manufacturer:Shenzhen Senshao Technology Co., Ltd. Address:3rd Floor,Block 1 ,ChangGuang Industrial Park,AoBei Second Village, HengGang Street, LongGang District, ShenZhen, GuangDong, China

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. .................... : FCC ID. ........................................... : CTA26072700101 2BXXH-208UCOREMINI Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Aug. 05, 2026 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ........................... : I&G DESIGNS AND LOGISTICS DBA FASHIONIT Address ............................................ : 14999 Preston Rd Suite 112 #310 Dallas TX 75254 Test specification ........................... : Standard ........................................... : FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : MINI/NANO SPEAKERS Trade Mark ....................................... : U SPEAKERS Manufacturer .................................... : Shenzhen Senshao Technology Co., Ltd. Model/Type reference ...................... : 208-U-CORE-MINI Listed Models ................................... : U MINI, U NANO, U CORE Modulation ....................................... : GFSK, Π/4DQPSK, 8DPSK Frequency ........................................ : From 2402MHz to 2480MHz Ratings ............................................. : Input: DC 5V Battery: 3.7V 300mAh 1.85Wh Result ............................................... : PASS Report No.: CTA26072700101 Page 2 of 39 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : MINI/NANO SPEAKERS Model /Type : 208-U-CORE-MINI Listed Models : U MINI, U NANO, U CORE Model difference : The PCB board, circuit, structure and internal of these models are the same, only model number and colour are different for these model. So the tests were performed on model 208-U-CORE-MINI and the test results for the main test model can cover the listed models. Applicant : I&G DESIGNS AND LOGISTICS DBA FASHIONIT Address : 14999 Preston Rd Suite 112 #310 Dallas TX 75254 Manufacturer : Shenzhen Senshao Technology Co., Ltd. Address : 3rd Floor,Block 1 ,ChangGuang Industrial Park,AoBei Second Village, HengGang Street, LongGang District, ShenZhen, GuangDong, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA26072700101 Page 3 of 39 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ...................................................................................................................................... 4 2 SUMMARY .................................................................................................................................................... 5 2.1 General Remarks .............................................................................................................................. 5 2.2 Product Description .......................................................................................................................... 5 2.3 Equipment Under Test ...................................................................................................................... 5 2.4 Short description of the Equipment under Test (EUT) ..................................................................... 5 2.5 EUT configuration ............................................................................................................................. 6 2.6 EUT operation mode......................................................................................................................... 6 2.7 Block Diagram of Test Setup ............................................................................................................ 6 2.8 Related Submittal(s) / Grant (s) ........................................................................................................ 6 2.9 Modifications ..................................................................................................................................... 6 3 TEST ENVIRONMENT ................................................................................................................................. 7 3.1 Address of the test laboratory ........................................................................................................... 7 3.2 Test Facility ......................................…

Text truncated - open the document above for the full version.

1 FCC Appendix RF Test Data for BT FCC ID : 2BXXH-208UCOREMINI Company : I&G DESIGNS AND LOGISTICS DBA FASHIONIT EUT : MINI/NANO SPEAKERS Model Number : 208-U-CORE-MINI Report No. : CTA26072700101 Reviewed By : Eric Wang 2 Appendix A: 20dB Emission Bandwidth Test Result TestMode Antenna Freq(MHz) 20dB EBW[MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.951 2401.550 2402.501 --- --- 2441 0.945 2440.547 2441.492 --- --- 2480 0.948 2479.550 2480.498 --- --- 2DH5 Ant1 2402 1.329 2401.346 2402.675 --- --- 2441 1.284 2440.379 2441.663 --- --- 2480 1.338 2479.340 2480.678 --- --- 3DH5 Ant1 2402 1.290 2401.364 2402.654 --- --- 2441 1.296 2440.364 2441.660 --- --- 2480 1.299 2479.364 2480.663 --- --- 3 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 4 2DH5_Ant1_2402 2DH5_Ant1_2441 5 2DH5_Ant1_2480 3DH5_Ant1_2402 3DH5_Ant1_2441 6 3DH5_Ant1_2480 7 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Freq(MHz) OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.85712 2401.5763 2402.4334 --- --- 2441 0.86122 2440.5806 2441.4418 --- --- 2480 0.86434 2479.5806 2480.4450 --- --- 2DH5 Ant1 2402 1.1943 2401.4149 2402.6092 --- --- 2441 1.1901 2440.4156 2441.6057 --- --- 2480 1.1940 2479.4149 2480.6089 --- --- 3DH5 Ant1 2402 1.1874 2401.4202 2402.6076 --- --- 2441 1.1836 2440.4213 2441.6049 --- --- 2480 1.1842 2479.4173 2480.6015 --- --- 8 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 9 2DH5_Ant1_2402 2DH5_Ant1_2441 10 2DH5_Ant1_2480 3DH5_Ant1_2402 3DH5_Ant1_2441 11 3DH5_Ant1_2480 12 Appendix C: Maximum conducted output power Test Result Peak Test Mode Antenna Freq(MHz) Conducted Peak Powert[dBm] Conducted Limit[dBm] Verdict DH5 Ant1 2402 -3.33 ≤20.97 PASS 2441 -3.18 ≤20.97 PASS 2480 -3.19 ≤20.97 PASS 2DH5 Ant1 2402 -0.60 ≤20.97 PASS 2441 -0.76 ≤20.97 PASS 2480 -0.99 ≤20.97 PASS 3DH5 Ant1 2402 -0.28 ≤20.97 PASS 2441 -0.38 ≤20.97 PASS 2480 -0.65 ≤20.97 PASS 13 Appendix D: Carrier frequency separation Test Result TestMode Antenna Freq(MHz) Result[MHz] Limit[MHz] Verdict DH5 Ant1 Hop 1.008 ≥0.951 PASS 2DH5 Ant1 Hop 1.004 ≥0.892 PASS 3DH5 Ant1 Hop 1.022 ≥0.866 PASS 14 Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 3DH5_Ant1_Hop 15 16 Appendix E: Time of occupancy Test Result TestMode Antenna Freq(MHz) BurstWidth [ms] TotalHops [Num] Result[s] Limit[s] Verdict DH1 Ant1 Hop 0.407 315 0.128 ≤0.4 PASS DH3 Ant1 Hop 1.662 159 0.264 ≤0.4 PASS DH5 Ant1 Hop 2.910 105 0.306 ≤0.4 PASS 2DH1 Ant1 Hop 0.417 318 0.133 ≤0.4 PASS 2DH3 Ant1 Hop 1.667 159 0.265 ≤0.4 PASS 2DH5 Ant1 Hop 2.915 108 0.315 ≤0.4 PASS 3DH1 Ant1 Hop 0.417 318 0.133 ≤0.4 PASS 3DH3 Ant1 Hop 1.666 165 0.275 ≤0.4 PASS 3DH5 Ant1 Hop 2.917 108 0.315 ≤0.4 PASS 17 Test Graphs DH1_Ant1_Hop DH3_Ant1_Hop 18 DH5_Ant1_Hop 19 2DH1_Ant1_Hop 2DH3_Ant1_Hop 20 2DH5_Ant1_Hop 21 3DH1_Ant1_Hop 3DH3_Ant1_Hop 22 3DH5_Ant1_Hop 23 24 Appendix F: Number of hopping channels Test Result TestMode Antenna Freq(MHz) Result[Num] Limit[Num] Verdict DH5 Ant1 Hop 79 ≥15 PASS 2DH5 Ant1 Hop 79 ≥15 PASS 3DH5 Ant1 Hop 79 ≥15 PASS 25 Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 3DH5_Ant1_Hop 26 27 Appendix G: Band edge measurements Test Result TestMode Antenna ChName Freq(MHz) RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 Low 2402 -3.87 -58.03 ≤-23.87 PASS High 2480 -3.67 -54.37 ≤-23.67 PASS Low Hop_2402 -4.05 -57.32 ≤-24.05 PASS High Hop_2480 -4.20 -57 ≤-24.2 PASS 2DH5 Ant1 Low 2402 -4.16 -57.87 ≤-24.16 PASS High 2480 -4.91 -57.46 ≤-24.91 PASS Low Hop_2402 -4.41 -58.22 ≤-24.41 PASS High Hop_2480 -3.67 -57.61 ≤-23.67 PASS 3DH5 Ant1 Low 2402 -4.48 -57.9 ≤-24.48 PASS High 2480 -3.86 -55.62 ≤-23.86 PASS Low Hop_2402 -6.02 -58.05 ≤-26.02 PASS High Hop_2480 -4.61 -57.27 ≤-24.61 PASS 28 Test Graphs DH5_Ant1_Low_2402 DH5_Ant1_High_2480 DH5_Ant1_Low_Hop_2402

29 DH5_Ant1_High_Hop_2480 2DH5_Ant1_Low_2402 30 2DH5_Ant1_High_2480 2DH5_Ant1_Low_Hop_2402 2DH5_Ant1_High_Hop_2480 31 3DH5_Ant1_Low_2402 3DH5_Ant1_High_2480 32 3DH5_Ant1_Low_Hop_2402 3DH5_Ant1_High_Hop_2480 33 Appendix H: Conducted Spurious Emission Test Result TestMode Antenna Freq(MHz) FreqRange [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 2402 Reference -4.50 -4.50 --- PASS 30~1000 -4.50 -69.22 ≤-24.5 PASS 1000~26500 -4.50 -46.14 ≤-24.5 PASS 2441 Reference -4.39 -4.39 --- PASS 30~1000 -4.39 -69.3 ≤-24.39 PASS 1000~26500 -4.39 -46.76 ≤-24.39 PASS 2480 Reference -5.06 -5.06 --- PASS 30~1000 -5.06 -68.8 ≤-25.06 PASS 1000~26500 -5.06 -47.23 ≤-25.06 PASS 2DH5 Ant1 2402 Reference -6.19 -6.19 --- PASS 30~1000 -6.19 -69.18 ≤-26.19 PASS 1000~26500 -6.19 -46.39 ≤-26.19 PASS 2441 Reference -4.82 -4.82 --- PASS 30~1000 -4.82 -68.13 ≤-24.82 PASS 1000~26500 -4.82 -45.64 ≤-24.82 PASS 2480 Reference -5.31 -5.31 --- PASS 30~1000 -5.31 -68.81 ≤-25.31 PASS 1000~26500 -5.31 -46.25 ≤-25.31 PASS 3DH5 Ant1 2402 Reference -6.36 -6.36 --- PASS 30~1000 -6.36 -69.12 ≤-26.36 PASS 1000~26500 -6.36 -44.47 ≤-26.36 PASS 2441 Reference -6.34 -6.34 --- PASS 30~1000 -6.34 -68.93 ≤-26.34 PASS 1000~26500 -6.34 -46.72 ≤-26.34 PASS 2480 Reference -4.36 -4.36 --- PASS 30~1000 -4.36 -69.3 ≤-24.36 PASS 1000~26500 -4.36 -46.71 ≤-24.36 PASS 34 Test Graphs DH5_Ant1_2402_0~Reference DH5_Ant1_2402_30~1000 DH5_Ant1_2402_1000~26500 35 DH5_Ant1_2441_0~Reference DH5_Ant1_2441_30~1000 36 DH5_Ant1_2441_1000~26500 DH5_Ant1_2480_0~Reference DH5_Ant1_2480_30~1000 37 DH5_Ant1_2480_1000~26500 2DH5_Ant1_2402_0~Reference 38 2DH5_Ant1_2402_30~1000 2DH5_Ant1_2402_1000~26500 2DH5_Ant1_2441_0~Reference 39 2DH5_Ant1_2441_30~1000 2DH5_Ant1_2441_1000~26500 40 2DH5_Ant1_2480_0~Reference 2DH5_Ant1_2480_30~1000 2DH5_Ant1_2480_1000~26500 41 3DH5_Ant1_2402_0~Reference 3DH5_Ant1_2402_30~1000 42 3DH5_Ant1_2402_1000~26500 3DH5_Ant1_2441_0~Reference 3DH5_Ant1_2441_30~1000 43 …
