2BXZK-MX15Smart Terminal

1 USER MANUAL FOR 15.6 " Bedside Infotainment Terminal 2 Important Safety Instructions Read these safety instructions carefully: ⚫Keep this equipment away from humidity and extreme temperature. ⚫Avoid exposing the device to direct sunlight or strong ultraviolet light for a long time. ⚫Do not drop the device or expose it to strong vibrations. ⚫Do not scratch or rub the screen with a hard or sharp object. ⚫Please turn off the power and unplug the power cable before cleaning the device, then wipe it with a moist and soft cloth. ⚫Do not disassemble or repair the device by yourselves without our authorization. If the damage is caused during the disassembly or repair, it will be out of warranty. ⚫Do not place your device or its accessories with flammable liquids, gases or explosive materials to avoid danger. FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interferenceto radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. 3 Content Chapter 1 Introduction ............................................................................................... 4 1.1 Product Features ....................................................................................................................... 4 1.2 Product Specifications ............................................................................................................... 5 Chapter 2 Parts Of The Device ..................................................................................... 8 2.1 The Details Of Button ............................................................................................................... 8 2.2 The Details Of Back Interface .................................................................................................... 9 2.3 The Details Of Handset ........................................................................................................... 10 Chapter 3 Functions Of The Device ............................................................................ 11 3.1 Power On/Off .......................................................................................................................... 11 3.2 Functions Of The Desktop ....................................................................................................... 11 3.3 The Usage Of Settings ............................................................................................................. 16 Chapter 4 Root Access Switch Steps ........................................................................... 22 Chapter 5 Device Files Transfer ................................................................................. 24 Chapter 6 Icons ........................................................................................................ 26 Chapter 8 Accessories .............................................................................................. 29 Chapter 9 Troubleshooting ....................................................................................... 30 4 Chapter 1 Introduction 1.1 Product Features ⚫ 15.6" 1920 × 1080 IPS LCD ⚫ 10-point capacitive touchscreen with anti-bacteria, antivirus and anti-alcohol, supporting gloves touch ⚫ High-performance Qualcomm ARM KryoTM260 processor, Octa-core 64bit ⚫ Android 13.0 system, 4G RAM +64G Flash (8G+128G is optional) ⚫ Handset for service call (optional) ⚫ Built-in 16 MP × CMOS camera ⚫ Built-in reading light ⚫ With Ethernet port, supporting PoE+ (optional) ⚫ Support Wi-Fi and Bluetooth 5.0 ⚫ NFC/RFID reader (optional) ⚫ Optical Bonding & lP65 Front Panel ⚫ Comply with IEC60601-1, EN60601-1, ISO22196, CE, FCC 5 1.2 Product Specifications SYSTEM Processor Qualcomm ARM KryoTM260 processor, Octa- core 64bit Graphic Adreno TM 610 RAM 4G DDR4 (default) / 8GB (optional) ROM 64G eMMC (default) / 128GB (optional) OS Android 13.0 Video Encoding: 4K@30fps, H.264/VP8; Decoding: 4K@30fps, H.264/VP8/VP9, 1080p@30fps, MPEG-2 DISPLAY Audio EVRC, EVRC-B, EVRC-WB, G.711, G.729A/AB, GSM- FR, GSM-EFR, GSM-H, AMR-NB, AMR-WB, AMR- eAMR, AMR- BeAMR LCD panel 15.6 ", IPS Resolution 1920(H) × 1080(V) Brightness 300 cd/m² (optional: 500 cd/m²) Contrast Ratio 800:1 View Angle 85°/85°(L/R), 85°/85°(U/D) Touch Panel Sensitive 10-point capacitive touchscreen FUNCTION WIFI IEEE802.11a/b/g/n/ac; 2.4GHz & 5GHz Bluetooth 2402MHz~2480MHz 6 NFC/RFID Combo smart card reader & Mifar…
