A25-TX00IRemote Control-Transmitter

OPERATION INSTRUCTION Note: Install the 12-volt battery to the remote control. 1 2 3 Front Back 4 5 (Optional) (Optional) :, ◎ ◎ :. 1.Fan speed control button To control the ceiling fan speed HIGH MEDIUM,LOW. 2.FAN/OFF button:Turn off the fan; Press and hold for 5 seconds to enter Light Delay Off mode. 3.LIGHT ON/OFF/DIMMER button To control light on,off and dimming (Optional). (Optional). (Optional). 4.Extended Function Switch: 1/0 Extended Function Switch: D/CFL Extended Function Switch: Learn 5. 6. Remote Control Functions: (Optional) 6 MODEL: TX00I-R1 TX00 TX00 I-R2 I-R3 OPERATION INSTRUCTION ●Products shall be subject to any changes without additional notices due to DawnSun will keep innovation and optimization on the products. FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference This device must accept any interference received including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. . ,(2) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and use in accordance with the instructions, may cause harmful interference to radio communications. However there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1.Reorient or relocate the receiving antenna. 2.Increase the separation between the equipment and receiver. 3.Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4.Consult the dealer or an experienced radio/TV technician for help. , This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. IC STATEMENT Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

Declaration letter We confirmed： The below products have the same technical construction including circuit diagram, PCB Layout, components and component layout, all electrical construction and mechanical construction. The difference lies only below: Model Difference Optional 4 Optional 5 Optional 6 TX00I x o o TX00I-R1 o o o TX00I-R2 o x o The Extended Function Switch 4, 5, and 6 are function keys. These are optional for all models and no influence to RF performance. Applicant: DawnSun Electronic Technology Co., Ltd.Zhongshan July 23, 2021 _______________________________________ Applicant’s authorized signature Date

July 23, 2021 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: A25-TX00I Product Name: Remote Control – Transmitter Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this: July 23, 2021 Agency agreement expiration date: 12 Months By: YaoMing Huang Signature Printed Title: Manager On behalf of: DawnSun Electronic Technology Co., Ltd.Zhongshan Tel No: (86) 0760-87336328

July Fede Auth 7345 Colu On o Bloc Distr agen subm certif defin labe For i beha for c Ltd Zho Dated Agenc By: Title: On b e Tel N o 23, 2021 eral Commu horization & 5 Oakland M umbia, Mary our behalf, ck B, Jun Xi rict, Shenzh nt in the p mitted docu fication is so ned in the F l identical to instances w alf, I acknow certification, .Zhongsh ongshan, d this: July cy agreeme Signatu r Manager ehalf of: Daw o: (86) 07 unications C Evaluation D Mills Road land 21046 I appoint S ang Da Bui hen, China preparation uments prop ought. I also Federal Com o that submit where our au wledge that still resides an/ No.8 Guangdo 23, 2021 ent expiratio re wnSun Elec 760-873363 ommission Division Author i Shenzhen T lding, Zhong (Name of A of this app perly descr o certify that mmunications tted for appr uthorized ag all responsi with D a w n Nanyi St ong, Chin on date: 12 ctronic Tech 328 ity to Act as Timeway Te gshan Park Agent comp plication for ribe the de t each unit m s Commissi roval with th ent signs th ibility for com nSun Ele treet, Xin a 2 Months hnology Co s Agent esting Labor Road West pany name r equipment evice or sy manufacture ion’s regulat his applicatio he applicatio mplying with ctronic T nggong R Ya o P ., Ltd.Zhong ratories/ Zo t, Tong Le V and addres t certificatio stem for w ed, imported tions will ha on. on for certific h the terms echnolog oad, Sha oMing Huan Printed gshan ne C, 1st F Village, Nan ss) to act as on. I certify which equip d or markete ave affixed t cation on ou and conditio gy Co., axi Town, ng Floor, nshan s our y that pment ed, as to it a ur ons

Label Location

RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m So pt = (EXd) 2 /30 x gt Field strength = 83.34dBuV/m @3m Ant gain =0dBi ;so Ant numeric gain= 1 So pt={ [10 (83.34 /20) /10 6 x3] 2 /30x1 }x1000 mW =0.0647 mW So (0.0647 mW/5mm)x √0.304GHz = 0.007135 <3 Then SAR evaluation is not required

Report No.: TW2106365E File reference No.: 2021-07-08 Applicant: DawnSun Electronic Technology Co., Ltd. Zhongshan Product: Remote Control – Transmitter Model No.: TX00I, TX00I-R1, TX00I-R2 Trademark: N/A Test Standards: FCC Part 15 Subpart C, Paragraph 15.231 Test result: It is herewith confirmed and found to comply with the requirements set up by ANSI C63.4&FCC Part 15 Subpart C, Paragraph 15.231 for the evaluation of electromagnetic compatibility Approved By Jack Chung Manager Dated: July 08, 2021 Results appearing herein relate only to the sample tested The technical reports is issued errors and omissions exempt and is subject to withdrawal at SHENZHEN TIMEWAY TESTING LABORATORIES Zone C, 1st Floor, Block B, Jun Xiang Da Building, Zhongshan Park Road West, Tong Le Village, Nanshan District, Shenzhen, China Tel (755) 83448688, Fax (755) 83442996, E-Mail:[email protected] Report No: TW2106365E Page 2 of 34 Date: 2021-07-08 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Special Statement： The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19. The testing quality system of our laboratory meets with ISO/IEC-17025 requirements, which is approved by CNAS. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAS-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAS-CL01 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:1999 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 744189 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.:744189. Industry Canada (IC) —Registration No.:5205A The EMC Laboratory has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing with Registration No.: 5205A. A2LA (Certification Number:5013.01) The EMC Laboratory has been accredited by the American Association for Laboratory Accreditation (A2LA). Certification Number:5013.01 Report No: TW2106365E Page 3 of 34 Date: 2021-07-08 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Test Report Conclusion Content 1.0 General Details ................................................................................................ 4 1.1 Test Lab Details................................................................................................ 4 1.2 Applicant Details.............................................................................................. 4 1.3 Description of EUT .......................................................................................... 4 1.4 Submitted Sample............................................................................................. 4 1.5 Test Duration.................................................................................................... 5 1.6 Test Uncertainty.................................................................................................5 1.7 Test By.......................................................................................................... 5 2.0 List of Measurement Equipment......................................................................... 5 3.0 Technical Details............................................................................................. 6 3.1 Summary of Test Results..................................................................................... 6 3.2 Test Standards.................................................................................................. 6 4.0 EUT Modification............................................................................................. 6 5.0 Power Line Conducted Emission Test...................................................................... 7 5.1 Schematics of the Test........................................................................................ 7 5.2 Test Method and Test Procedure............................................................................ 7 5.3 Configuration of the EUT..................................................…

Text truncated - open the document above for the full version.

Radiated Emission Test Setup:
