A3CJYM830905Mobile Phone

1 Contents Safety .................................................................................................................... 3 Environment ........................................................................................................ 4 1 Getting Started ................................................................................................. 5 1.1 Getting to know your touch phone .................................................... 5 1.2 Installing the SIM card, battery, and storage card ............................. 5 1.3 Charging the Battery .......................................................................... 6 1.4 Starting up the device......................................................................... 7 1.5 Status Icons ........................................................................................ 9 2 Using phone features ..................................................................................... 10 2.1 Turning the phone function on and off ............................................ 10 2.2 Making a call ................................................................................... 11 2.3 Answering and Ending a call ........................................................... 11 2.4 In-call options .................................................................................. 12 2.5 Using call history ............................................................................. 12 3 Setting on your device .................................................................................... 13 4 ActiveSync ....................................................................................................... 17 5 Contacts .......................................................................................................... 20 6 Exchanging Messages .................................................................................... 22 7 Internet ........................................................................................................... 28 7.1 Ways of Connecting to the Internet ................................................. 28 7.2 Browser ............................................................................................ 28 8 Google ............................................................................................................. 32 8.1 Google mail ...................................................................................... 32 8.2 Google talk ....................................................................................... 35 8.3 Google Maps .................................................................................... 35 8.4 Google Calendar .............................................................................. 37 9 Experiencing Multimedia .............................................................................. 42 9.1 Camera & Picture ............................................................................. 42 2 9.2 Music................................................................................................ 44 9.3 FM Radio ......................................................................................... 47 10 Android Market ........................................................................................... 47 11 Other applications ........................................................................................ 50 11.1 Alarm Clock ................................................................................... 50 11.2 Calculator ....................................................................................... 52 3 Safety Never attempt to disassemble your phone. You alone are responsible for how you use your phone and any consequences of its use. As a general rule, always switch off your phone wherever the use of a phone is prohibited. Use of your phone is subject to safety measures designed to protect users and their environment. Do not use your phone in damp areas (bathroom, swimming pool...). Protect it from liquids and other moisture. Do not expose your phone to extreme temperatures lower than - 10°C and higher than + 45°C. The physicochemical processes created by chargers impose temperature limits when charging the battery. Your phone automatically protects the batteries in extreme temperatures. Do not leave your phone within the reach of small children (certain removable parts may be accidentally ingested). Electrical safety: Only use the chargers listed in the manufacturer’s catalogue. Using any other charger may be dangerous; it would also invalidate your warranty. Line voltage must be exactly the one indicated on the charger’s serial plate. Aircraft safety: When traveling by plane, you will need to switch your phone off when so instructed by the cabin crew or the warning signs. Using a mobile phone may be dangerous to the operation of the aircraft and may disrupt the phone network. Its use is illegal and you could be prosecuted or banned from using cellular networks in the future if you do not abide by these regulations. Explosive materials: Please comply with warning signs at petrol station asking you to switch your phone off. You will need to comply with radio equipment usage restrictions in places such as chemical plants, fuel depots and at any location where blasting operations are under way. Electronic equipment: To avoid the risk of demagnetization, do not let electronic devices close to your phone for a long time. Electronic medical equipment: Your phone is a radio transmitter which may interfere with electronic medical equipment or implants, such as hearing aids, pacemakers, insulin pumps, etc. It is recommended that a minimum separation of 15 cm be maintained between the phone and an implant. Your doctor or the 4 manufacturers of such equipment will be able to give you any advice you may need in this area. Hospitals: Always make sure that your phone is switched off in hospitals whe…

Text truncated - open the document above for the full version.

FCC Confidentiality Request To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Shenzhen Jie Yu Shi Ji Electronic Technology Co., Ltd. Addresss Rm 8B/F, C Tower Electronic technology Building, Shennan Road(M),Futian District,Shenzhen. City Shenzhen,Guangdong Country China request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: A3C JYM830905 of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) x Operational Description x Block Diagrams x Schematics Diagrams Bill of Materials Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date:Name: (this must be a person) Function:Signature: (or official company stamp) shenzhen 11/27/2011 Junming Chen General manager

Authorization Letter We, (the approval holder) Company name Shenzhen Jie Yu Shi Ji Electronic Technology Co., Ltd. Addresss Rm 8B/F, C Tower Electronic technology Building, Shennan Road(M),Futian District,Shenzhen. City Shenzhen,Guangdong Country China decl are that the following representative (agent): Name (person) Bovey.yang Company name NTEK Testing Technology Co., Ltd. Addresss 1/F, Building E, Fenda Science Park Sanwei Community, Xixiang Street, Baoan District City Shenzhen Country China to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Description Mobile Phone Type or Model(s) STAR A3 ，STAR A3+， WENTTO A3，STARA2, STARA1 Tradename or Brand(s) Android We also authorize BZT – TCP Certification GmbH, Ms.Wanida Patthanavoj (address: Hermann - Loens - Weg 6, 15859 Storkow b. Berlin Germany) to process the application. Attestation: City and Country: Date:Name: (this must be a person) Function:Signature: (or official company stamp) shenzhen 11/27/2011 Junmin Chen General manager

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

15*20mm

Photo 7 Photo 8

Test Laboratory: Compliance Certification Services Inc. System Performance Head Check-D850_2011.11.27 DUT: Dipole 850 MHz D835V2; Type: D835V2; SN:4d114 Communication System: CW; Frequency: 850 MHz Medium parameters used: f = 850 MHz; σ = 0.94 mho/m; ε r = 41.59; ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY5 Configuration: • Probe: EX3DV4 - SN3755; ConvF(8.99, 8.99, 8.99); Calibrated: 1/20/2011 • Sensor-Surface: 3mm (Mechanical Surface Detection), Sensor-Surface: 4mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1245; Calibrated: 1/11/2011 • Phantom: Twin SAM Phantom; Type: QD 000 P40 CD; Serial: 1609 • Measurement SW: DASY52, Version 52.6 (1); SEMCAD X Version 14.4.2 (2595) System Performance Check at Frequencies above 1 GHz/d=10mm, Pin=xx mW, dist=3.0mm (EX-Probe)/Area Scan (7x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 3.359mW/g System Performance Check at Frequencies above 1 GHz/d=10mm, Pin=xx mW, dist=3.0mm (EX-Probe)/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 58.77 V/m; Power Drift = 0.00052 dB Peak SAR (extrapolated) = 3.654W/kg SAR(1 g) = 2.42 mW/g; SAR(10 g) = 1.56 mW/g Maximum value of SAR (measured) =3.297 mW/g Test Laboratory: Compliance Certification Services Inc. System Performance Body Check-D850_2011.11.27 DUT: Dipole 850 MHz D835V2; Type: D835V2; SN:4d114 Communication System: CW; Frequency: 850 MHz Medium parameters used: f = 850 MHz; σ = 0.98 mho/m; ε r = 55.32; ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY5 Configuration: • Probe: EX3DV4 - SN3755; ConvF(9.07, 9.07, 9.07); Calibrated: 1/20/2011 • Sensor-Surface: 3mm (Mechanical Surface Detection), Sensor-Surface: 4mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1245; Calibrated: 1/11/2011 • Phantom: Twin SAM Phantom; Type: QD 000 P40 CD; Serial: 1609 • Measurement SW: DASY52, Version 52.6 (1); SEMCAD X Version 14.4.2 (2595) System Performance Check at Frequencies above 1 GHz/d=10mm, Pin=xx mW, dist=3.0mm (EX-Probe)/Area Scan (7x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 3.297mW/g System Performance Check at Frequencies above 1 GHz/d=10mm, Pin=xx mW, dist=3.0mm (EX-Probe)/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 58.74 V/m; Power Drift = 0.0021 dB Peak SAR (extrapolated) = 3.437 W/kg SAR(1 g) = 2.52 mW/g; SAR(10 g) = 1.65 mW/g Maximum value of SAR (measured) = 3.355mW/g Test Laboratory: Compliance Certification Services Inc. System Performance Head Check-D1900_2011.11.27 DUT: Dipole 1900 MHz D1900V2; Type: D1900V2; Serial: D1900V2 - SN:5d136 Communication System: CW; Frequency: 1900 MHz Medium parameters used: f = 1900 MHz; σ = 1.39 mho/m; ε r = 39.97 ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY5 Configuration: • Probe: EX3DV4 - SN3755; ConvF(7.84, 7.84, 7.84); Calibrated: 1/20/2011 • Sensor-Surface: 3mm (Mechanical Surface Detection), Sensor-Surface: 4mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1245; Calibrated: 1/11/2011 • Phantom: SAM1; Type: SAM; Serial: 1609 • Measurement SW: DASY52, Version 52.6 (1); SEMCAD X Version 14.4.2 (2595) System Performance Check at Frequencies above 1 GHz/d=10mm, Pin=xx mW, dist=3.0mm (EX-Probe) 2/Area Scan (7x7x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 10.141 mW/g System Performance Check at Frequencies above 1 GHz/d=10mm, Pin=xx mW, dist=3.0mm (EX-Probe) 2/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 104.61 V/m; Power Drift = 0.0032 dB Peak SAR (extrapolated) = 16.549 W/kg SAR(1 g) = 10.16 mW/g; SAR(10 g) = 5.22 mW/g Maximum value of SAR (measured) = 10.919 mW/g Test Laboratory: Compliance Certification Services Inc. System Performance Body Check-D1900_2011.11.27 DUT: Dipole 1900 MHz D1900V2; Type: D1900V2; Serial: D1900V2 - SN:5d136 Communication System: CW; Frequency: 1900 MHz Medium parameters used: f = 1900 MHz; σ = 1.51 mho/m; ε r = 53.28; ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY5 Configuration: • Probe: EX3DV4 - SN3755; ConvF(7.23, 7.23, 7.23); Calibrated: 1/20/2011 • Sensor-Surface: 3mm (Mechanical Surface Detection), Sensor-Surface: 4mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1245; Calibrated: 1/11/2011 • Phantom: SAM1; Type: SAM; Serial: 1609 • Measurement SW: DASY52, Version 52.6 (1); SEMCAD X Version 14.4.2 (2595) System Performance Check at Frequencies above 1 GHz/d=10mm, Pin=xx mW, dist=3.0mm (EX-Probe) 2/Area Scan (7x7x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 10.139 mW/g System Performance Check at Frequencies above 1 GHz/d=10mm, Pin=xx mW, dist=3.0mm (EX-Probe) 2/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 104.3 V/m; Power Drift = 0.0001 dB Peak SAR (extrapolated) = 15.529 W/kg SAR(1 g) = 10.35 mW/g; SAR(10 g) = 5.15 mW/g Maximum value of SAR (measured) = 10.953 mW/g Test Laboratory: Compliance Certification Services Inc. SystemPerformanceHeadCheck-D2450_2011.11.27 DUT: Dipole 2450 MHz D2450V2; Type: D2450V2; SN:817 Communication System: CW; Frequency: 2450 MHz Medium parameters used: f = 2450 MHz; σ = 1.81 mho/m; ε r = 39.41; ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY5 Configuration: • Probe: EX3DV4 - SN3755; ConvF(7.07, 7.07, 7.07); Calibrated: 1/20/2011 • Sensor-Surface: 3mm (Mechanical Surface Detection), Sensor-Surface: 4mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1245; Calibrated: 1/11/2011 • Phantom: Twin SAM Phantom; Type: QD 000 P40 CD; Serial: 1609 • Measurement SW: DASY52, Version 52.6 (1); SEMCAD X Version 14.4.2 (2595) System Performance Check at Frequencies above 1 GHz/d=10mm, …
