A3DCRW4012AInternal DVD CD-R/ RW Drive

NIX December 23, 2001 NEC Technologies. Inc. Porsv%ll rJkzplsy Olviion 125G N. Ann&w Hd$ts And llwcn. IL 60143 ‘nx&uG)167-5000 W(63GMG747fl Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S. C. 862. Sincerely, n-.- I &+-----* M.A.Fatani Senior Compliance Engineer Compliance Engineering Dept. NEC Technologies, Inc.

December 23, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: NEC TECHNOLOGIES, INC. FCC ID: A3DCRW4012A Abbreviated Filing Gentlemen: Submitted herewith, on behalf of NEC TECHNOLOGIES CO., LTD. is an application for certification of the following Internal DVD CD-R/RW Drive: FCC ID: A3DCRW4012A MODEL: CRW4012A TRADE NAMES: NEC EUT TYPE: Internal DVD CD-R/RW Drive The device is electrically identical to FCC ID: A3DND-1100A granted Sept. 26, 2002. Attached are the applicant’s authorization letter, measurement report (test data and test plots), FCC ID label and location, test setup photographs, internal and external photographs, block diagram, schematics, and user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Mr. Amin Fatani NEC Technologies Co., Ltd.

© 2002 PCTEST Lab NEC FCC ID: A3DCRW4012A NVLAP Lab Code: 100431-0 Internal DVD CD-R/RW Drive © 2002 PCTEST Lab NEC FCC ID: A3DCRW4012A NVLAP Lab Code: 100431-0 Internal DVD CD-R/RW Drive © 2002 PCTEST Lab NEC FCC ID: A3DCRW4012A NVLAP Lab Code: 100431-0 Internal DVD CD-R/RW Drive © 2002 PCTEST Lab NEC FCC ID: A3DCRW4012A NVLAP Lab Code: 100431-0 Internal DVD CD-R/RW Drive © 2002 PCTEST Lab NEC FCC ID: A3DCRW4012A NVLAP Lab Code: 100431-0 Internal DVD CD-R/RW Drive

© 2002 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) © 2002 PCTEST Lab NEC Model: ND-1100A NVLAP Lab Code: 100431-0 Internal DVD CD-R/RW Drive

© 2002 PCTEST Lab NEC FCC ID: A3DCRW4012A NVLAP Lab Code: 100431-0 Internal DVD CD-R/RW Drive © 2002 PCTEST Lab NEC FCC ID: A3DCRW4012A NVLAP Lab Code: 100431-0 Internal DVD CD-R/RW Drive © 2002 PCTEST Lab NEC FCC ID: A3DCRW4012A NVLAP Lab Code: 100431-0 Internal DVD CD-R/RW Drive © 2002 PCTEST Lab NEC FCC ID: A3DCRW4012A NVLAP Lab Code: 100431-0 Internal DVD CD-R/RW Drive © 2002 PCTEST Lab NEC FCC ID: A3DCRW4012A NVLAP Lab Code: 100431-0 Internal DVD CD-R/RW Drive

 2002 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE Manufacturer: NEC Corporation Dates of Tests: August 6-9, 2002 7-1, Shiba Go-Chome, Test Report S/N: B.220805665.A3D Minato-ku, Tokyo 108-01, JAPAN Test Site: PCTEST Lab, Columbia, MD USA TRADE NAME ACTIMA Model CRW4012A FCC ID A3DCRW4012A CORPORATE NAME Actima Technology Corporation ADDRESS 4F, No.2, Technology Road, V Science-Based Industrial Park, Hsin-Chu 300, Taiwan, R.O.C. FCC Rule Part(s): FCC Part 15 Subpart Classification: FCC Class B Peripheral Device (JBP) Equipment (EUT) Type: Internal DVD CD-R/RW Drive FCC ID: A3DCRW4012A Original FCC ID: A3DND-1100A granted Sept. 26, 2002 The device bearing the trade name and model specified above has been shown to comply with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4-1992 (See Test Report if any modifications were made for compliance.) These measurements were performed with no deviation from the standards. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Approved Signatories: Randy Ortanez — President Alfred Cirwithian — Vice-President 220805665.A3D © 2002 PCTEST Engineering Laboratory, Inc. TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT SCOPE 3 INTRODUCTION (SITE DESCRIPTION) 4 PRODUCTION INFORMATION 5 DESCRIPTION OF TESTS (CONDUCTED) 6 DESCRIPTION OF TESTS (RADIATED) 7 LIST OF SUPPORT EQUIPMENT 8 TEST DATA (RADIATED) 9 SAMPLE CALCULATIONS 10 ACCURACY OF MEASUREMENT 11 LIST OF TEST EQUIPMENT 12 TEST SOFTWARE USED 13 CONCLUSION 14 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL & LOCATION ATTACHMENT F: BLOCK DIAGRAM(S) ATTACHMENT G: SCHEMATIC DIAGRAM(S) ATTACHMENT H: TEST SETUP PHOTOGRAPHS ATTACHMENT I: EXTERNAL PHOTOGRAPHS ATTACHMENT J: INTERNAL PHOTOGRAPHS ATTACHMENT K: USER’S MANUAL Test Report S/N: B.220805665.A3D FCC Part 15 Class B Dates of Tests: August 6-9, 2002 Certification © 2002 PCTEST LAB NEC FCC ID: A3DCRW4012A Internal DVD CD-R/RW Drive PRODUCT EVALUATION REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission under ET Docket 95-19 Declaration of Conformity (DoC). Manufacturer: NEC CORPORATION Address: 7-1, Shiba Go-chome, Minato-ku Tokyo 108-01, JAPAN Corporate Name: Actima Technology Corporation Address: 4F, No.2, Technology Road, V Science-Based Industrial Park, Hsin-Chu 300, Taiwan, R.O.C. • Trade Name: ACTIMA • Model: CRW4012A • FCC ID: A3DCRW4012A • EUT Type: Internal DVD CD-R/RW Drive • Rule Part(s): FCC Part 15 Subpart B • Classification: B Digital Device / Peripheral (JBP) • Test Procedure(s): ANSI C63.4 (1992) • Dates of Tests: August 6-9, 2002 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: B.220805665.A3D Lab Code 100431-0 220805665.A3D Test Report S/N: B.220805665.A3D FCC Part 15 Class B Dates of Tests: August 6-9, 2002 Certification © 2002 PCTEST LAB NEC FCC ID: A3DCRW4012A Internal DVD CD-R/RW Drive 2.1 Introduction The measurement procedure described in American National Standard for Methods of Measurement of Radio- Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-1992) was used in determining radiated and conducted emissions emanating from NEC Internal DVD CD-R/RW Drive FCC ID: A3DCRW4012A. These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area, with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'19” N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. 2.2 PCTEST Location The map at right shows the location of the PCTEST Lab, its proximity to the FCC Lab, the Columbia vicinity area, the Baltimore-Washington International (BWI) airport, and the city of Baltimore, and the Washington, D.C. area. (see Figure1). Figure 1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area. Test Report S/N: B.220805665.A3D FCC Part 15 Class B Dates of Tests: August 6-9, 2002 Certification © 2002 PCTEST LAB NEC FCC ID: A3DCRW4012A Internal DVD CD-R/RW Drive 3.1 Product Information 3.2 Equipment Description The Equipment Under Test (EUT) is the NEC Internal DVD CD-R/RW Drive FCC ID: A3DCRW4012A. CD-R/RW & CD ROM Section: User Data Capacity: 656 Mbytes, Mode 1 User Data Blocks: 2048 Bytes/block Burst Transfer Rate: PIO mode 4, DMA Single Word mode 2 Access Time: 98msec (1/3 Stroke read, typical) Hard Error Rate: Below 10 -12 (After error correction) CD Audio Section: Frequency Respons: 20 …
