A3DDV-5800AInternal IDE DVD-ROM Reader

NIX December 08, 1999 NEC Technologies. Inc. Porsv%ll rJkzplsy Olviion 125G N. &SII~ Hd$ts Aned llwcn. IL 60143 ‘nx&uG)167-5000 W(63GMG747fl Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act on our behalf in all matters relating to applications for equipment authorization including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S. C. 862. Sincerely, n-.- I &+-----* M.A. Fatani Senior Compliance Engineer Compliance Engineering Dept. NBC Technologies, Inc.

October 3, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: NEC TECHNOLOGIES, INC. FCC ID: A3DDV-5800A Gentlemen: Submitted herewith, on behalf of NEC TECHNOLOGIES CO., LTD. is an application for certification of the following IDE Device – Internal DVD-ROM Reader: FCC ID: A3DDV-5800A MODEL No.: DV-5800A TRADE NAME: NEC EUT TYPE: IDE Device – Internal DVD-ROM Reader Attached is the applicant’s attestation statement, measurement report (test data and test plots), FCC ID label and location, test setup photographs, internal and external photographs, block diagram, schematics, and user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Mr. Amin Fatani NEC Technologies, Inc. Lab Code 100431-0

© 2000 PCTEST Lab NEC FCC ID: A3DDV-5800A NVLAP Lab Code: 1004310 Internal IDE DVD-ROM Drive Reader (Model: DV-5800A) © 2000 PCTEST Lab NEC FCC ID: A3DDV-5800A NVLAP Lab Code: 1004310 Internal IDE DVD-ROM Drive Reader (Model: DV-5800A) © 2000 PCTEST Lab NEC FCC ID: A3DDV-5800A NVLAP Lab Code: 1004310 Internal IDE DVD-ROM Drive Reader (Model: DV-5800A) © 2000 PCTEST Lab NEC FCC ID: A3DDV-5800A NVLAP Lab Code: 1004310 Internal IDE DVD-ROM Drive Reader (Model: DV-5800A) © 2000 PCTEST Lab NEC FCC ID: A3DDV-5800A NVLAP Lab Code: 1004310 Internal IDE DVD-ROM Drive Reader (Model: DV-5800A) © 2000 PCTEST Lab NEC FCC ID: A3DDV-5800A NVLAP Lab Code: 1004310 Internal IDE DVD-ROM Drive Reader (Model: DV-5800A) © 2000 PCTEST Lab NEC FCC ID: A3DDV-5800A NVLAP Lab Code: 1004310 Internal IDE DVD-ROM Drive Reader (Model: DV-5800A) © 2000 PCTEST Lab NEC FCC ID: A3DDV-5800A NVLAP Lab Code: 1004310 Internal IDE DVD-ROM Drive Reader (Model: DV-5800A)

© 2000 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

© 2000 PCTEST Lab NEC FCC ID: A3DDV-5800A NVLAP Lab Code: 1004310 Internal IDE DVD-ROM Drive Reader (Model: DV-5800A) © 2000 PCTEST Lab NEC FCC ID: A3DDV-5800A NVLAP Lab Code: 1004310 Internal IDE DVD-ROM Drive Reader (Model: DV-5800A) © 2000 PCTEST Lab NEC FCC ID: A3DDV-5800A NVLAP Lab Code: 1004310 Internal IDE DVD-ROM Drive Reader (Model: DV-5800A) © 2000 PCTEST Lab NEC FCC ID: A3DDV-5800A NVLAP Lab Code: 1004310 Internal IDE DVD-ROM Drive Reader (Model: DV-5800A) © 2000 PCTEST Lab NEC FCC ID: A3DDV-5800A NVLAP Lab Code: 1004310 Internal IDE DVD-ROM Drive Reader (Model: DV-5800A) © 2000 PCTEST Lab NEC FCC ID: A3DDV-5800A NVLAP Lab Code: 1004310 Internal IDE DVD-ROM Drive Reader (Model: DV-5800A)

© 2000 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 66606660--B Dobbin Road B Dobbin Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290TEL (410) 290--6652 6652 •• FAX (410) 290 FAX (410) 290--66546654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE NEC Technologies, Inc. Dates of Tests: September 26-27, 2000 1250 N. Arlington Heights Rd., Suite 500 Test Report S/N: B.200922480.A3D Itasca, IL 60143-1248 Test Site: PCTEST Lab, Columbia, MD Attn: Amin Fatani, Senior Engineer Compliance Engineering Dept. FCC ID A3DDV-5800A APPLICANT NEC TECHNOLOGIES, INC. Rule Part(s): FCC Part 15 Subpart B Equipment Class: Class B Peripheral Device (JBP) EUT Type: Internal IDE DVD-ROM Reader Trade Name: NEC © Model: DV-5800A This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified is ANSI C63.4-1992 (Note Codes: #37). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Lab Code 100431-0 © 2000 PCTEST Engineering Laboratory, Inc. FCC Class B TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT SCOPE 1 INTRODUCTION (SITE DESCRIPTION) 2 PRODUCTION INFORMATION 3 DESCRIPTION OF TESTS (CONDUCTED) 4 DESCRIPTION OF TESTS (RADIATED) 5 LIST OF SUPPORT EQUIPMENT 6 TEST DATA (CONDUCTED) 7 TEST DATA (RADIATED) 8 SAMPLE CALCULATIONS 9 ACCURACY OF MEASUREMENT 10 LIST OF TEST EQUIPMENT 11 TEST SOFTWARE USED 12 CONCLUSION 13 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL & LOCATION ATTACHMENT F: BLOCK DIAGRAM(S) ATTACHMENT G: SCHEMATIC DIAGRAM(S) ATTACHMENT H: TEST SETUP PHOTOGRAPHS ATTACHMENT I: EXTERNAL PHOTOGRAPHS ATTACHMENT J: INTERNAL PHOTOGRAPHS ATTACHMENT K: USER’S MANUAL Test Report S/N: B.200922480.A3D FCC Class B Dates of Tests: September 26-27, 2000 Certification © 2000 PCTEST Lab FCC ID: A3DDV-5800A 1 NEC Internal IDE DVD-ROM Reader PRODUCT EVALUATION REPORT Scope - Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. Company Name: NEC TECHNOLOGIES, INC. Address: 1250 N. Arlington Heights Road, Suite 500 Itasca, IL 60143-1248 Attention: Amin Fatani – Senior Engineer Compliance Engineering Department • FCC ID: A3DDV-5800A • Class: B Digital Device / Peripheral (JBP) • EUT Type: Internal IDE DVD-ROM Reader • Trade Name: NEC ® • Model: DV-5800A • Crystal(s)/Oscillator(s): 22.57MHz, 25.00MHz, 66.66MHz • Cable(s): Unshielded IDE ribbon cable (internal) • Rule Part(s): FCC Part 15 Subpart B • Test Procedure(s): ANSI C63.4 (1992) • Dates of Tests: September 26-27, 2000 • Place of Tests: PCTEST Lab, Columbia, MD • Test Report S/N: B.200922480.A3D Lab Code 100431-0 Test Report S/N: B.200922480.A3D FCC Class B Dates of Tests: September 26-27, 2000 Certification © 2000 PCTEST Lab FCC ID: A3DDV-5800A 2 NEC Internal IDE DVD-ROM Reader 1.1 INTRODUCTION The measurement procedure described in American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-1992) was used in determining radiated and conducted emissions emanating from NEC Internal IDE DVD-ROM Reader FCC ID: A3DDV-5800A. These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. 1.2 PCTEST Location The map at right shows the location of the PCTEST Lab, its proximity to the FCC Lab, the Columbia vicinity area, the Baltimore-Washington International (BWI) airport, and the city of Baltimore, and the Washington, D.C. area. (see Figure1). Figure 1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area. Test Report S/N: B.200922480.A3D FCC Class B Dates of Tests: September 26-27, 2000 Certification © 2000 PCTEST Lab FCC ID: A3DDV-5800A 3 NEC Internal IDE DVD-ROM Reader 2.1 Product Information 2.2 Equipment Description The Equipment Under Test (EUT) is the NEC Internal IDE DVD-ROM Reader Model: DV-5800A. DVD-ROM Section: User Data Capacity: 4.7G bytes (Single layer, 12cm), 8.54G bytes (Dual layer, 12cm), 1.46G bytes (Single layer, 8cm), 2.66G bytes (Dual layer, 8cm) User Data Blocks: 2048 Bytes/block Data Transfer Rate: 21.1M bytes/sec. (Maximum) Burst Transfer Rate: PIO mode 4, DMA Single Word mode 2 DMA Multi Word mode 2, Ultra DMA 33 mode 2 Access Time: 120msec (1/3 Stroke read, average) Hard Error Rate: Below 10 -12 (After error correction) CD-ROM Section: User Data Capacity: 656M bytes (Mode 1), 748M bytes (Mode 2) User Data Blocks: 2048 Bytes/block (Mode 1 and Mode 2, Form 1) 2336 Bytes/block (Mode 2), 2328 Bytes/block (Mode 2 Form 2) …
