A3DNR-7900AInternal CD-R/RW Drive

© 2001 PCTEST Lab ATTACHMENT J – USER’S MANUAL

© 2000 PCTEST Lab ATTACHMENT B – ATTESTATION STATEMENT(S) NIX December 08, 2001 NEC Technologies. Inc. Porsv%ll rJkzplsy Olviion 125G N. Ann&w Hd$ts And llwcn. IL 60143 ‘nx&uG)167-5000 W(63GMG747fl Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S. C. 862. Sincerely, n-.- I &+-----* M.A.Fatani Senior Compliance Engineer Compliance Engineering Dept. NEC Technologies, Inc.

© 2001 PCTEST Lab ATTACHMENT F – BLOCK DIAGRAM(S) / SCHEMATIC DIAGRAM(S)

© 2001 PCTEST Lab ATTACHMENT A – COVER LETTER(S) September 10, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:NEC TECHNOLOGIES, INC. FCC ID: A3DNR-7900A Gentlemen: Submitted herewith, on behalf of NEC TECHNOLOGIES CO., LTD. is an application for certification of the following Internal CD-R/RW Drive: FCC ID:A3DNR-7900A MODEL No.:NR-7900A TRADE NAME:NEC EUT TYPE:Internal CD-R/RW Drive Attached is the applicant’s attestation statement, measurement report (test data and test plots), FCC ID label and location, test setup photographs, internal and external photographs, block diagram, schematics, and user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Mr. Amin Fatani NEC Technologies, Inc.

© 2001 PCTEST Lab ATTACHMENT H – EXTERNAL PHOTOGRAPHS © 2001 PCTEST Lab FCC ID: A3DNR-7900A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2001 PCTEST Lab FCC ID: A3DNR-7900A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2001 PCTEST Lab FCC ID: A3DNR-7900A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2001 PCTEST Lab FCC ID: A3DNR-7900A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2001 PCTEST Lab FCC ID: A3DNR-7900A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2001 PCTEST Lab FCC ID: A3DNR-7900A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive

© 2001 PCTEST Lab ATTACHMENT E – FCC ID LABEL & LOCATION © 2001 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

© 2001 PCTEST Lab ATTACHMENT I – INTERNAL PHOTOGRAPHS © 2001 PCTEST Lab FCC ID: A3DNR-7900A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2001 PCTEST Lab FCC ID: A3DNR-7900A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2001 PCTEST Lab FCC ID: A3DNR-7900A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2001 PCTEST Lab FCC ID: A3DNR-7900A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2001 PCTEST Lab FCC ID: A3DNR-7900A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive

© 2001 PCTEST Lab ATTACHMENT C – TEST REPORT © 2001 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road 6660-B Dobbin Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290-6652 TEL (410) 290-6652 •• FAX (410) 290-6654 FAX (410) 290-6654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE NEC Technologies, Inc.Dates of Tests: August 22-23, 2001 1250 N. Arlington Heights Rd., Suite 500Test Report S/N: B.210822506.A3D Itasca, IL 60143-1248Test Site: PCTEST Lab, Columbia, MD Attn: Amin Fatani, Senior Engineer Compliance Engineering Dept. FCC ID A3DNR-7900A APPLICANT NEC TECHNOLOGIES, INC. Rule Part(s):FCC Part 15 Subpart B Equipment Class:Class B Peripheral Device (JBP) EUT Type:Internal CD-R/RW Drive Trade Name: NEC © Model:NR-7900A This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified is ANSI C63.4-1992. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Lab Code 100431-0 © 2001 PCTEST Engineering Laboratory, Inc. FCC Class B TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT SCOPE 1 INTRODUCTION (SITE DESCRIPTION) 2 PRODUCTION INFORMATION 3 DESCRIPTION OF TESTS (CONDUCTED) 4 DESCRIPTION OF TESTS (RADIATED) 5 LIST OF SUPPORT EQUIPMENT 6 TEST DATA (CONDUCTED) 7 TEST DATA (RADIATED) 8 SAMPLE CALCULATIONS 9 ACCURACY OF MEASUREMENT10 LIST OF TEST EQUIPMENT11 TEST SOFTWARE USED12 CONCLUSION13 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL & LOCATION ATTACHMENT F: BLOCK DIAGRAM(S) / SCHEMATIC DIAGRAM(S) ATTACHMENT G: TEST SETUP PHOTOGRAPHS ATTACHMENT H: EXTERNAL PHOTOGRAPHS ATTACHMENT I: INTERNAL PHOTOGRAPHS ATTACHMENT J: USER’S MANUAL Test Report S/N: B.210822506.A3DFCC Class B Dates of Tests: August 22-23, 2001Certification © 2001 PCTEST LabFCC ID: A3DNR-7900A 1 NEC Internal CD-R/RW Drive PRODUCT EVALUATION REPORT Scope - Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. Company Name:NEC TECHNOLOGIES, INC. Address:1250 N. Arlington Heights Road, Suite 500 Itasca, IL 60143-1248 Attention:Amin Fatani – Senior Engineer Compliance Engineering Department • FCC ID:A3DNR-7900A • Class:B Digital Device / Peripheral (JBP) • EUT Type:Internal CD-R/RW Drive • Trade Name:NEC ® • Model:NR-7900A • Crystal(s)/Oscillator(s):20.0MHz, 100.0MHz • Cable(s):Unshielded IDE ribbon cable (internal) • Rule Part(s):FCC Part 15 Subpart B • Test Procedure(s):ANSI C63.4 (1992) • Dates of Tests:August 22-23, 2001 • Place of Tests:PCTEST Lab, Columbia, MD • Test Report S/N:B.210822506.A3D NOTE: The NEC Model NR-7900A internal CD-R/RW Drive was tested with the internal terminator enabled. Lab Code 100431-0 Test Report S/N: B.210822506.A3DFCC Class B Dates of Tests: August 22-23, 2001Certification © 2001 PCTEST LabFCC ID: A3DNR-7900A 2 NEC Internal CD-R/RW Drive 1.1 INTRODUCTION The measurement procedure described in American National Standard for Methods of Measurement of Radio- Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-1992) was used in determining radiated and conducted emissions emanating from NEC Internal CD-R/RW Drive FCC ID: A3DNR-7900A. These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. 1.2 PCTEST Location The map at right shows the location of the PCTEST Lab, its proximity to the FCC Lab, the Columbia vicinity area, the Baltimore-Washington International (BWI) airport, and the city of Baltimore, and the Washington, D.C. area. (see Figure1). Figure 1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area. Test Report S/N: B.210822506.A3DFCC Class B Dates of Tests: August 22-23, 2001Certification © 2001 PCTEST LabFCC ID: A3DNR-7900A 3 NEC Internal CD-R/RW Drive 2.1 Product Information 2.2 Equipment Description The Equipment Under Test (EUT) is the NEC Internal CD-R/RW Drive Model: NR-7900A. Max 24xCLV spinning (for CD-R write) Max 10XCLV spinning (for CD-RW write) IDE interface CPU Frequency:20.00MHz, 28.81MHz, 34.5744MHz Power Supply: 5V 1.5A/ 12V 1.5 A Dimensions (W x H x D): 14.8 x 4.2 x 19.8 cm Weight: 1020 g Test Report S/N: B.210822506.A3DFCC Class B Dates of Tests: August 22-23, 2001Certification © 2001 PCTEST LabFCC ID: A3DNR-7900A 4 NEC Internal CD-R/RW Drive 3.1 Description of Tests 3.2 Conducted Emissions The line-conducted facility is located inside a 16'x20'x10' shielded enclosure. It is manufactured by Ray Proof Series 81 (see Figure 2). The shielding effectiveness of the shielded room is in a…

Text truncated - open the document above for the full version.

© 2001 PCTEST Lab ATTACHMENT D – TEST PLOTS

© 2001 PCTEST Lab ATTACHMENT G – TEST SETUP PHOTOGRAPHS © 2001 PCTEST Lab FCC ID: A3DNR-7900A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2001 PCTEST Lab FCC ID: A3DNR-7900A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2001 PCTEST Lab FCC ID: A3DNR-7900A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive
