━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ Internal CD-R/RW Drive NR-9300 User's Manual ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ Laser Safety Information This drive employs a laser. Do not remove the cover or attempt to service this device when connected due to the possibility of eye damage. CAUTION Use of control of adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. This label is located on top enclosure of this drive. Laser Specification (for CD) Type : Semiconductor laser GaAlAs Wave length : 779 - 789 nm (at 25°C) Output : Max. 80 mW (Pulse) ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ NOTICE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: — Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help. This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications. LE PRÉSENT APPAREIL NUMÉRIQUE N’ÉMET PAS DE BRUITS RADIOÉLECTRIQUES DÉPASSANT LES LIMITES APPLICABLES AUX APPAREILS NUMÉRIQUES DE CLASSE B PRESCRITES DANS LE RÈGLEMENT SUR LE BROUILLAGE RADIOÉLECTRIQUE ÉDICTÉ PAR LE MINISTÈRE DES COMMUNICATIONS DU CANADA. CAUTION The user who makes changes or modifications to the unit without the express approval by the manufacturer will void user authority to operate the equipment. ACHTUNG Der arbeitsplatzbezogene Geräuschemissionswert dieses Gerätes beträgt ≤70dB (A) nach EN 27779/1991. Notice Only CD discs and DVD discs carrying the label below can be used with this CD-R/RW drive. ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ HEED THE FOLLOWING Read the operating instructions carefully before using the unit and be sure to use it properly. After reading the instructions, store them in an easily accessible place so they can be consulted whenever necessary. WARNING • Continued use should there be an irregularity (smoke, abnormal smell or sound, etc.) will lead to fires or electric shocks. If there should be an irregularity, immediately turn off the power of the computer on which the unit is installed and request servicing. • Do not disassemble or modify the unit in any way. Doing so will lead to fires or electric shocks. • Make sure that no foreign objects get in the unit, as this will lead to fires or electric shocks. If a foreign object should get in the unit, immediately turn off the power of the computer on which the unit is installed and request servicing. • Do not let fluids get in the unit or let the unit get wet, as this will lead to fires or electric shocks. If fluid should get in the unit, immediately turn off the power of the computer on which the unit is installed and request servicing. • Do not use with any power voltage other than the indicated voltage. Doing so will lead to fires or electric shocks. • Do not store or use the unit in places where it may be subject to shocks or strong vibrations. Doing so will lead to fires or electric shocks. • Do not store or use the unit in places where it may be exposed to chemicals or chemical vapors. Doing so will lead to fires or electric shocks. ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ CAUTION • When connecting computer equipment, audio equipment, speakers, etc., be sure to read the respective manuals carefully, turn of the power and follow the connection instructions. Using cords other than the specified cords or extending cords could generate heat and result in burns, etc. • Set the volume to the minimum before turning on the power. Sudden bursts of loud sound could result in hearing impairment. • Do not store or use the unit in extremely hot places or places where the humidity fluctuates greatly. Doing so could lead to fires or electric shocks. • Do not store or use the unit in places exposed to direct sunlight or near equipment that generates heat. Doing so could lead to fires. • Do not place the unit on unsteady tables, slanted surfaces or other unstable surfaces. The unit could fall or tip over, resulting in injury. • Do not store or use the unit in humid or dusty places. Doing so could lead to fires or electric shocks. • Do not store or use the unit with heavy objects or objects that stick out passed the frame on top of it. The object or unit may lose its balance and tip over or fall, resulting in injury. • Do not let stick your hands into the disc insertion slot, as this could cause injury. • Do not use cracked or misshapen discs or discs that have been repaired with adhesives, etc. Discs rotate at high speeds inside the unit. If such discs are used, they may break and fly out, resulting in injury. • Do not look directly at the laser source. Exposing the eyes to the laser beam could result in vision impairment. • When used near a radio or TV, the unit may generate noise in the radio or TV. Also, if there is equipment generating strong magnetic forces nearby, this may generate noise in the unit. • Keep the disc tray closed except when inserting or removing discs in order to prevent injury from bumping into the disc tray. • When disconnecting fro…

Text truncated - open the document above for the full version.

NIX November, 2002 NEC Technologies. Inc. Porsv%ll rJkzplsy Olviion 125G N. Ann&w Hd$ts And llwcn. IL 60143 ‘nx&uG)167-5000 W(63GMG747fl Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S. C. 862. Sincerely, n-.- I &+-----* M.A.Fatani Senior Compliance Engineer Compliance Engineering Dept. NEC Technologies, Inc.

November 29, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:NEC TECHNOLOGIES, INC. FCC ID: A3DNR-9300A Gentlemen: Submitted herewith, on behalf of NEC TECHNOLOGIES CO., LTD. is an application for certification of the following Internal CD-R/RW Drive: FCC ID: A3DNR-9300A MODEL No.: NR-9300A TRADE NAME:NEC EUT TYPE:Internal CD-R/RW Drive Attached is the applicant’s attestation statement, measurement report (test data and test plots), FCC ID label and location, test setup photographs, internal and external photographs, block diagram, schematics, and user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Mr. Amin Fatani NEC Technologies, Inc.

© 2002 PCTEST Lab FCC ID: A3DNR-9300A NVLAP Lab Code: 100431- 0 NEC Internal CD-R/RW Drive © 2002 PCTEST Lab FCC ID: A3DNR-9300A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2002 PCTEST Lab FCC ID: A3DNR-9300A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2002 PCTEST Lab FCC ID: A3DNR-9300A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2002 PCTEST Lab FCC ID: A3DNR-9300A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2002 PCTEST Lab FCC ID: A3DNR-9300A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive

© 2001 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) © 2002 PCTEST Lab FCC ID: A3DNR-9300A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive

© 2002 PCTEST Lab FCC ID: A3DNR-9300A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2002 PCTEST Lab FCC ID: A3DNR-9300A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2002 PCTEST Lab FCC ID: A3DNR-9300A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2002 PCTEST Lab FCC ID: A3DNR-9300A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2002 PCTEST Lab FCC ID: A3DNR-9300A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive © 2002 PCTEST Lab FCC ID: A3DNR-9300A NVLAP Lab Code: 100431-0 NEC Internal CD-R/RW Drive

 2002 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE Manufacturer: NEC Corporation Dates of Tests: Oct. 28 ~ Nov. 01, 2002 7-1, Shiba Go-Chome, Test Report S/N: B.221024559.A3D Minato-ku, Tokyo 108-01, JAPAN Test Site: PCTEST Lab, Columbia, MD USA TRADE NAME NEC ® FCC ID A3DNR-9300A U.S. RESPONSIBLE PARTY NEC TECHNOLOGIES, INC. ADDRESS 1250 N. Arlington Heights Road, Suite 500 Itasca, IL 60143-1248 CONTACT PERSON Mr. Amin Fatani, Senior Engineer Compliance Engineering Dept. Tel. No. (630) 467-5095 Rule Part(s): FCC Part 15 Subpart B Equipment Class: Class B Peripheral Device (JBP) Equipment (EUT) Type: Internal CD-R/RW Drive (48x) Model: NR-9300A The device bearing the trade name and model specified above has been shown to comply with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4-1992 (See Test Report if any modifications were made for compliance.) These measurements were performed with no deviation from the standards. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Approved Signatories: Randy Ortanez — President Alfred Cirwithian — Vice-President 221024559.A3D © 2002 PCTEST Engineering Laboratory, Inc. TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT SCOPE 1 INTRODUCTION (SITE DESCRIPTION) 2 PRODUCTION INFORMATION 3 DESCRIPTION OF TESTS (CONDUCTED) 4 DESCRIPTION OF TESTS (RADIATED) 5 LIST OF SUPPORT EQUIPMENT 6 TEST DATA (CONDUCTED) 7 TEST DATA (RADIATED) 8 SAMPLE CALCULATIONS 9 ACCURACY OF MEASUREMENT 10 LIST OF TEST EQUIPMENT 11 TEST SOFTWARE USED 12 CONCLUSION 13 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL & LOCATION ATTACHMENT F: BLOCK DIAGRAM(S) / SCHEMATIC DIAGRAM(S) ATTACHMENT G: TEST SETUP PHOTOGRAPHS ATTACHMENT H: EXTERNAL PHOTOGRAPHS ATTACHMENT I: INTERNAL PHOTOGRAPHS ATTACHMENT J: USER’S MANUAL Test Report S/N: B.221024559.A3D FCC Part 15 Class B Dates of Tests: Oct. 28 ~ Nov. 01, 2002 Certification © 2002 PCTEST LAB FCC ID: A3DNR-9300A NEC Internal CD-R/RW Drive PRODUCT EVALUATION REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission under ET Docket 95-19 Declaration of Conformity (DoC). Manufacturer: NEC CORPORATION Address: 7-1, Shiba Go-chome, Minato-ku Tokyo 108-01, JAPAN U.S. Responsible Party 1 : NEC TECHNOLOGIES, INC. Address: 1250 N. Arlington Heights Road, Suite 500 Itasca, IL 60143-1248 Contact Person: Mr. Amin Fatani, Senior Engineer Compliance Engineering Dept. Telephone No.: (630) 467-5095 • FCC ID: A3DNR-9300A • Class: B Digital Device / Peripheral (JBP) • EUT Type: Internal CD-R/RW Drive (48x) • Trade Name: NEC ® • Model: NR-9300A • Cable(s): Unshielded IDE ribbon cable (internal) • Rule Part(s): FCC Part 15 Subpart B • Test Procedure(s): ANSI C63.4 (1992) • Dates of Tests: Oct. 28 ~ Nov. 01, 2002 • Place of Tests: PCTEST Lab, Columbia, MD • Test Report S/N: B.221024559.A3D 1 Please refer to the duties and responsibilities of the Responsible Party attached. Lab Code 100431-0 221024559.A3D Test Report S/N: B.221024559.A3D FCC Part 15 Class B Dates of Tests: Oct. 28 ~ Nov. 01, 2002 Certification © 2002 PCTEST LAB FCC ID: A3DNR-9300A NEC Internal CD-R/RW Drive 2.1 Introduction The measurement procedure described in American National Standard for Methods of Measurement of Radio- Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-1992) was used in determining radiated and conducted emissions emanating from NEC Internal CD-R/RW Drive FCC ID: A3DNR-9300A. These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area, with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'19” N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. 2.2 PCTEST Location The map at right shows the location of the PCTEST Lab, its proximity to the FCC Lab, the Columbia vicinity area, the Baltimore-Washington International (BWI) airport, and the city of Baltimore, and the Washington, D.C. area. (see Figure1). Figure 1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area. Test Report S/N: B.221024559.A3D FCC Part 15 Class B Dates of Tests: Oct. 28 ~ Nov. 01, 2002 Certification © 2002 PCTEST LAB FCC ID: A3DNR-9300A NEC Internal CD-R/RW Drive 3.1 Product Information 3.2 Equipment Description The Equipment Under Test (EUT) is the NEC Internal CD-R/RW Drive FCC ID: A3DNR-9300A. CD-R/RW & CD ROM Section: User Data Capacity: 656 Mbytes, Mode…
