Samsung Confidential M/S(SD...) PCI USB 5 3 ELECTRONICS Charger SODIMM 0 PG 62 PG 62 GFX_CORE PG 56 RJ11 PG 52 94P Lake Lane 4 D ROBSON CD / DVD PG 64 MDC CRT Mobile Processor GMCH-M Super I/O 3 EXCEPT AS AUTHORIZED BY SAMSUNG. PG 39 LED External Graphics AMP PG 60 OPTION P3.3V_AUX PG 25 RJ45 PG 22 - 25 A P1.25V Express Card CD-ROM C PG 55 PCIE x1PCIE x1 800 MT/S PG 9 B SAMSUNG PROPRIETARY SPI ROM Thermistor CK-505 676 BGA DDR II SPI HDD HDMI 1 Aud. 2 SAMSUNG ELECTRONICS CO’S PROPERTY. 4 DVI + USB + VGA + LAN+PCIE Diamond SATA DDR II PG 65 Channel A Bluetooth LCD/CRT PCIE x1 4 52P PG 9 PG 19 D FSB Clocking PG 50 SAMSUNG PG 38 PCIE x1 Lane 3 PG 63 478pin PCIE x1 PG 40 88E8055 2 Lane 1 Parallel NB8P R5C843 MIC-IN Merom-4M A PCIE x1 (USB 3) PG 13 - 17 Modem 52P PG 39 Lane 2 (USB 6) PG 59 SATA 0 6pin PG 44 Serial PG 64 PG 8 PG 37 PG 63 USB 0,1,2 PG 46 HD Secondary Channel B CPU Switched Audio CardBus Mini Card 2 PG 36 ICH8-M DDR II 667/533 965PM P1.05V PG 10,11,12 PG 40 IMVP-6MICOM DDR II 667/533 HP Line ANT ALC262 USB 8 FAN USB 7 PG 41 PG 26-32 Fingerprint 80 Port Dock PG 18 EEPROM CARDBUS PG 25 LPC47N207 PG 51 Nand Flash PROPRIETARY INFORMATION THAT IS Mini Card 1 Dual channel THIS DOCUMENT CONTAINS CONFIDENTIAL 1 KBD Nand Flash Touch Lane 5 (USB 4) SPDIF. PG 47 PG 47 Graphic PATA HDAUDIO PG 58 LCD LPC DMI 1394 120P PG 64 PG 33 USB 0,1,2 HD Primary MS+IEEE1394 PG 35 PG 53 (800MHz) PG 57 P5.0V_AUX CPU HD64F2111B Power PG 67 CORE 1299 FCBGA PG 63 DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS B DDR2 PAD Lane 0 C Pri. IDE slave SODIMM 1 PG 36, 37 NVIDIA

{Œš›GGyŒ—–™›Gu–UGGaGsilW^XW\]G -21/21- Picture 7. Label Location Picture 8. Label

-4/21- 1.2 Detail Information related product 1.2.1 Specification Item Specification Remark CPU Intel Core 2 Duo Merom 2.2 GHz L2 Cache 4MB, FSB 800MHz, Intel Merom QS CPU - ChipsetIntel PM965, 800MHz FSB - Main Memory Samsung, DDR2 PC2-5300S 667Mhz, 1GB(M470T2953CZ3-CE6) * 1 - Graphic controller Nvidia Geforce 8600M GS Graphic memory 128MB/256MB - LCD DISPLAY Samsung, LTN154P1-L03, 15.4, G, WSXGA+, 1680 x 1050 Pixels - Inverter BoardDarfon(VK.21209.201) - Modem Agere systems,DELPHI(D40) S/W Modem, 56KBPS, Fax/Data Azalia MDC, - HDD Fujitsu, SATA type 100GB(MHV2100BH), 2.5. 100GB, 50G/P, Sata, 9.5MM, FDB, 5400RPM, ROHS Product - Turbo Flash ModuleIntel Turbo Memory 1G Module, NVCPEMWR001G1ES - ODDTEAC, DV-W28EC, SuperMulti - LANMarvell 88E8055 PCI Express Gigabit - Wireless LAN - Intel, 4965AGN MRW, 802.11agn, 54Mbps, Mini-card MIC No.:INT-4965AGNKR - Bluetooth Broadcom, BCM92045NMD, USB 2.0 type, Bluetooth Ver 2.0 Foxconn Module, MIC No.:R-LARN-05-0240 - ADAPTERLite-on, PA-1900-08S, 90W, 19V, 4.74A - BatterySanyo(AA-PB2NC6B/5200mAh/11.1V) Input Devices Keyboard, Travel length 2.6mm / Key Pitch 19.05mm Synaptics Touchpad, Ports LAN, Modem,1 X 1394, 3 USB, 1 CRT, HDMI, PCMCIA slot, DC IN, 1 MIC-IN, 1 HP-OUT, 1 LINE-IN, SIO port 2.20GHz(CPU speed), 800MHz(Host Clock), 667MHz(DDR2), 32.768MHz(PCI Clock), 100MHz (PCIE, SATA Clock), 14.318MHz(Ref), 25Mhz ( LAN Ref ), 10Mhz ( MICOM Ref ) Operating Frequency

-1/21- EMC TEST REPORT Samsung Electronics Co., Ltd. 416 Maetan 3-Dong, Yeongtong-Gu, Suwon-Si,Gyeonggi-Do, 443-742 Korea (Tel: 82 31 277 7752, Fax: 82 31 277 7753) Project No. : LBE071056 Page (1)/(21) 1. Applicant ◦ Name of organization : Samsung Electronics Co., Ltd. ◦ Address : 416 Maetan 3-Dong, Yeongtong-Gu,Suwon-Si,Gyeonggi-Do 443-742 Korea 2. Purpose for the report : Approval for EMC 3. Kind of product : Notebook Computer (Model name : Transport T2500, Brand name : SAMSUNG) 4. Date of test : 2007. 3. 30 ~ 2007. 4. 3 5. Applied standard : FCC Part 15 B, Class B 6. FCC ID : A3L-NP-X65 7. Test result : Complied The equipment under test has found to be compliant with the applied standards. (Refer to the attached test result for more detail.) Tested by Name : Sang Kyu, Seo Reviewed by Name : No Cheon, Park This report is the test result about the sphere accredited by KOLAS which signed the Mutual Recognition Arrangement of International Laboratory Accreditation Cooperation. 2007. 4. 13 Samsung Electronics Co., Ltd. Chief of CS Management Center -2/21- Table of contents 1. General information 1.1 Basic information related product 1.2 Detail information related product 1.3 Operating mode and condition 1.4 Equipment modifications 1.5 Test procedure 1.6 Test configuration 1.7 Applied standard 1.8 Test facility 2. Summary of test results 3. Description of individual tests 3.1 Conducted Emission 3.2 Radiated Emission 4. Appendix 4.1 Test photography 4.2 EUT photography -3/21- 1. General information 1.1 Basic information related product Applicant Samsung Electronics Co., Ltd. Model name Transport T2500 Applicant address 416 Maetan 3-Dong, Yeongtong-Gu,Suwon-Si,Gyeonggi-Do 443-742 Korea Contact person John SC LEE Kind of product Notebook Computer Variant model NP-X65 Manufacturer Samsung Electronics Co., Ltd. 416 Maetan 3-Dong, Yeongtong-Gu,Suwon-Si,Gyeonggi-Do 443-742 Korea Rated power AC 120 V, 60 Hz New / Alternative / Permissive change information New -4/21- 1.2 Detail Information related product 1.2.1 Specification Item Specification Remark CPU Intel Core 2 Duo Merom 2.2 GHz L2 Cache 4MB, FSB 800MHz, Intel Merom QS CPU - ChipsetIntel PM965, 800MHz FSB - Main Memory Samsung, DDR2 PC2-5300S 667Mhz, 1GB(M470T2953CZ3-CE6) * 1 - Graphic controller Nvidia Geforce 8600M GS Graphic memory 128MB/256MB - LCD DISPLAY Samsung, LTN154P1-L03, 15.4, G, WSXGA+, 1680 x 1050 Pixels - Inverter BoardDarfon(VK.21209.201) - Modem Agere systems,DELPHI(D40) S/W Modem, 56KBPS, Fax/Data Azalia MDC, - HDD Fujitsu, SATA type 100GB(MHV2100BH), 2.5. 100GB, 50G/P, Sata, 9.5MM, FDB, 5400RPM, ROHS Product - Turbo Flash ModuleIntel Turbo Memory 1G Module, NVCPEMWR001G1ES - ODDTEAC, DV-W28EC, SuperMulti - LANMarvell 88E8055 PCI Express Gigabit - Wireless LAN - Intel, 4965AGN MRW, 802.11agn, 54Mbps, Mini-card MIC No.:INT-4965AGNKR - Bluetooth Broadcom, BCM92045NMD, USB 2.0 type, Bluetooth Ver 2.0 Foxconn Module, MIC No.:R-LARN-05-0240 - ADAPTERLite-on, PA-1900-08S, 90W, 19V, 4.74A - BatterySanyo(AA-PB2NC6B/5200mAh/11.1V) Input Devices Keyboard, Travel length 2.6mm / Key Pitch 19.05mm Synaptics Touchpad, Ports LAN, Modem,1 X 1394, 3 USB, 1 CRT, HDMI, PCMCIA slot, DC IN, 1 MIC-IN, 1 HP-OUT, 1 LINE-IN, SIO port 2.20GHz(CPU speed), 800MHz(Host Clock), 667MHz(DDR2), 32.768MHz(PCI Clock), 100MHz (PCIE, SATA Clock), 14.318MHz(Ref), 25Mhz ( LAN Ref ), 10Mhz ( MICOM Ref ) Operating Frequency -5/21- 1.3 Operating mode and condition The EUT exercise program used during radiated and conducted emissions testing was the Samsung Stan dardized Emission Test Program for Windows. During the certification test, the LCD panel was open and v ideo signals were simultaneously active on the LCD panel, and the VGA port. The system was configured for testing in a typical fashion that a customer would normally use, and was te sted while in an automated non-attendant mode. The program repetitively sends a screen of ‘H’ to the display, reads and writes to the hard drive. Musics are played from the CD player which connected externally to the Line-In jack and ported out to the earphones. A hard drive from the remote PC was mapped to the EUT and a data file was read and written over the net work connection to provide continuous activity. The EUT was connected to a remote PC through the Ether net port with Unshielded Twisted Pair Ethernet cable. Ethernet testing was performed at 1Gbps operation. Cables were attached to each of the available I/O Ports. Where applicable, peripherals were attached to the I/O cables. The EUT was tested with the WLAN communicating during the radiated immunity testing. The hopping channels of the Bluetooth hopped and operated in the 2400-2483.5 MHz band, with 79 channels - Test Voltage : AC 120 V, 60 Hz 1.4 Equipment modifications This section provide details of the equipment under test(EUT)and the peripheral assemblies attached during radiated and conducted emission testing. The AC adapter was connected and All external peripherals were connected to the I/O ports to the EUT. -6/21- 1.5 Test procedure 1.5.1 Conducted emission EUT was placed on a platform nominal size, 1 m by 1.5 m, raised 80 cm above the conducting ground plane. The rear of tabletop was located 40 cm to the vertical conducting ground plane. The rear of EUT, including peripherals was aligned and flush with rear of tabletop. All other surfaces of tabletop was at least 80 cm from any other grounded conducting surface. I/O cables and AC cables that were connected to the peripherals were bundled in center. They were folded back and forth forming a bindle 30 cm to 40 cm long and were handed at a 40 cm height to the ground plane. Each EUT current-carrying power lead, except the ground(safety) lead, were individually connected through a LISN to the input power source. All unused 50 ohm connectors of the LISN were resistively terminated in 50 ohm when not connected to the measuring equipment. Frequency Band [MHz] Instrument Detector Resolution Bandwidth Video Bandwidth …

Text truncated - open the document above for the full version.

{Œš›GGyŒ—–™›Gu–UGGaGsilW^XW\]G -18/21- 4. Appendix 4.1 Test photography Picture 1. Conducted emission (Front) Picture 2. Conducted emission (Rear) {Œš›GGyŒ—–™›Gu–UGGaGsilW^XW\]G -19/21- Picture 3. Radiated emission (Front) Picture 4. Radiated emission (Rear)
