A3L04OMEGA2DIGITAL CAMCORDER

ENGLISH Digital Video CamcorderOwner’s Instruction BookBefore operating the unit, please read thisinstruction book thoroughly, and retain it forfuture reference. AF Auto Focus CCD Charge Coupled Device LCD Liquid Crystal Display SCD903 ELECTRONICS S T A R T / S T O P S E L F T I M E R A . D U B Z E R O M E M O R Y P H O T O D I S P L A Y X 2 S L O W F .A D V P H O T O S E A R C H D A T E / T IM E US PATENT 4415844 00000? SCD903 USA (01~27) 4/14/04 12:36 PM Page 101 ENGLISH Notices and Safety Instructions Safety Instructions RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOTREMOVE COVER(OR BACK). NO USER SERVICEABLEPARTS INSIDE, REFER SERVICING TO QUALIFIEDSERVICE PERSONNEL. This symbol is intended to alert the user to the presence of uninsulateddangerous voltage within the product’s enclosure that may be ofsufficient magnitude to constitute a risk of fire or electric shock. This symbol is intended to alert the user to the presence of importantoperating and maintenance instructions in the literature accompanyingthis product. To prevent electric shock, match wide blade of plugto wide slot and fully insert.1. READ INSTRUCTIONS: All the safety and operating instructions should be read before the CAMCORDER is operated. 2. RETAIN INSTRUCTIONS: The safety and operating instructions should be retained for future reference. 3. HEED WARNINGS: All warnings on the CAMCORDER and in the operating instructions should be adhered to. 4. FOLLOW INSTRUCTIONS: All operating and maintenance instructions should be followed. 5. CLEANING: Unplug this CAMCORDER from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a dry cloth used for dusting cabinets. 6. ATTACHMENTS: Do not use attachments not recommended by the CAMCORDER product manufacturer as they may be hazardous. 7. WATER AND MOISTURE: Do not use this CAMCORDER near water; for example, near a bathtub, wash bowl, kitchen sink, laundry tub, in a wet basement, near a swimming pool or lake. 8. ACCESSORIES: Do not place this CAMCORDER on an unstable cart, stand, tripod,bracket or table. The CAMCORDER may fall, causing serious injuryto a child or adult, and serious damage to the unit. Use only with a cart, stand, tripod, bracket, or table recommendedby the manufacturer or sold with the CAMCORDER. Any mountingof the unit should follow the manufacturer’s instructions and shoulduse a mounting accessory recommended by the manufacturer.A. An appliance and cart combination should be moved with care. Quick stops, excessive force and uneven surfaces may cause the appliance and cart combination to overturn. PORTABLE CART WARNING(Symbol provided by RETAC) CAUTION 00000? SCD903 USA-SAFETY 4/14/04 12:36 PM Page 100 ENGLISH Notices and Safety Instructions9. VENTILATION: Slots and openings in the cabinet are provided for ventilation to ensure reliable operation of the CAMCORDER and to protect it from overheating. These openings must not be blocked or covered. Never place your CAMCORDER on a bed, sofa, rug, or other similar surface: on or near a radiator or heat register. This CAMCORDER should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is providedor the manufacturer’s instructions have been adhered to. 10. POWER SOURCES: The CAMCORDER should be operated only from the type of power source indicated on the label.If you are not sure of the type of power supply at your home, consult your appliance dealer or local power company. A CAMCORDER is intended to be operated from battery power, or other sources, refer to the operating instructions. 11. GROUNDING OR POLARIZATION: This CAMCORDER may be equipped with either a polarized 2-wire AC line plug (a plug having one blade wider than the other)or a 3-wire grounding type plug, a plug having a third (grounding)pin.If you are unable to insert the plug fully into the outlet, try reversingthe plug. If the plug still fails to fit, contact your electrician to replace your outlet. Do not defeat the safety purpose of the polarized plug. 12. POWER-CORD PROTECTION: Power-supply cords should be routed so that they are not likely tobe walked on or pinched by items placed upon or against them, paying particular attention to cords or plugs, convenient receptacles, and the point where they exit from the unit. 13. OUTDOOR ANTENNA GROUNDING: If an outside antenna or cable system is connected to the CAMCORDER, be sure the antenna or cable system is groundedto provide some protection against voltage surges and built-up static charges, Section 810 of the National Electrical Code, ANSI/NFPA No. 70-1984, provides information with respect to proper grounding of the mast and supporting structure, groundingof the lead-in wire and supporting structure, grounding of the mastand supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding to conductors, locationof antenna-discharge unit, connection to grounding electrodes and requirements for the grounding electrode.See figure below. GROUNDING CONDUCTORS (NEC SECTION 810-21) GROUND CLAMPS POWER SERVICE GROUNDINGELECTRODE SYSTEM(NEC ART 250, PART H) NEC NATIONAL ELECTRICAL CODE ELECTRICSERVICEEQUIPMENT GROUNDCLAMP ANTENNALEAD INWIRE ANTENNADISCHARGE UNIT(NEC SECTION 810-20) 00000? SCD903 USA-SAFETY 4/14/04 12:36 PM Page 101 ENGLISH Notices and Safety Instructions14. LIGHTNING: For added protection of this CAMCORDER during a lightning storm or when it is left unattended and unused for long periods oftime, unplug it from the wall outlet and disconnect the antenna orcable system. This will prevent damage to the CAMCORDER due to lightning and power-line surges. 15. POWER LINES: An outside antenna system should not be located in the vicinity ofoverhead power lines or other electric light or power circuits whereit can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or…

Text truncated - open the document above for the full version.

ENGLISH 5858 Advanced Recording  TV DISPLAY✤ The TV DISPLAY function works in CAMERA, PLAYER, M.REC and M.PLAY modes. ✤ You can select the output path of the OSD (On Screen Display).  OFF: The OSD appears in the LCD screen and Viewfinder.  ON: The OSD appears in the LCD screen, View Finder and TV.  Use the DISPLAY button located at the left side of the camcorder to turn ON/OFF all of the OSD displayed on the LCD/View Finder/TV. 1. Set the camcorder to CAMERA, PLAYER, M.REC and M.PLAY mode.2. Press the MENU button.  The menu list will appear. 3. Move the MENU SELECTOR to highlight VIEWER and push the MENU SELECTOR.4. Select the TV DISPLAY and push the MENU SELECTOR.  The DISPLAY mode switches between ON/OFF with each push. 5. To exit, press the MENU button. CAM MODE VIEWER SET LCD ADJUSTDATE / TIME TV DISPLAY CAM MODE INITIAL LCD ADJUSTDATE / TIMETV DISPLAY CAMERAA/VMEMORYVIEWER 00000? SCD903 USA (28~63) 4/14/04 12:37 PM Page 58 ENGLISH 5959 Advanced Recording✤ Quick menu is available only in CAMERA and M.REC mode. ✤ Quick menu is used to adjust camera functions by simply using the MENU SELECTOR button. This feature is useful for when you want to make simple adjustments without having to access menus and submenus.  DATE/TIME (see page 57)- Each time you select DATE/TIME and push the MENU SELECTOR, it will be displayed in order of DATE - TIME - DATE/TIME - OFF.  WL.REMOTE( ) (see page 39) - Each time you select WL.REMOTE and push the MENU SELECTOR, the WL.REMOTE is switched to either enabled ( ) or disabled ( ).  EIS ( ) (see page 48) - Each time you select EIS and push the MENU SELECTOR, the EIS icon is displayed or set to OFF.  DSE (Digital Special Effect) (see page 49)- Each time you select DSE and push the MENU SELECTOR, the DSE preset values are applied or set to OFF. DSE values will not switch between On and Off if they have not been preset in the menu.  PROGRAM AE (see page 43)- Each time you select PROGRAM AE and push the MENU SELECTOR, you can choose between the preset PROGRAM AE values and AUTO. You can ’ t choose between Auto and PROGRAM AE values if the values have not been preset in the regular menu. Using Quick Menu(Navigation Menu) 1 0 : 0 0 A M J A N . 10 , 2 0 0 4 MIRROR (CAMERA mode) 00000? SCD903 USA (28~63) 4/14/04 12:37 PM Page 59 ENGLISH 6060 Advanced Recording WHT. BALANCE (see page 45)- Each time you select WHT. BALANCE and push the MENU SELECTOR, you can choose between preset WHT.BALANCE values and AUTO. As in PROGRAM AE, you can't choose betweenAuto and WHT.BALANCE values it they have not been preset.  FOCUS (Auto Focus/Manual Focus) (see page 64)- Each time you select FOCUS and push the MENU SELECTOR, the FOCUS is switched to either Manual Focus (MF) or Auto Focus ( ).  SHUTTER SPEED & EXPOSURE- You can set values for SHUTTER SPEED and EXPOSURE by selecting ( ) icon and pushing the MENU SELECTOR. For more information, see the next page. Setting the Quick menu 1. Set the camcorder to CAMERA mode.2. Move the MENU SELECTOR to select a function you want and then push the MENU SELECTOR to change the values. Note  Quick menu function will not operate in EASY mode.  If you are using the M.FOCUS(MF) function, you cannot use the Quick menu.If you want to use the Quick menu function, release the M.FOCUS(MF) mode. SHUTTER MF EXPOSURE 0 : 0 0 : 0 0 1 0 : 0 0 A M J A N . 1 0 , 2 0 0 4 STBY MIRROR WL.REMOTE DSE PROGRAM AE WHT. BALANCE SHUTTTER EXPOSURE EIS DATE/TIME FOCUS 00000? SCD903 USA (28~63) 4/14/04 12:37 PM Page 60 ENGLISH 6161 Advanced Recording SHUTTER SPEED & EXPOSURE ✤ You can set SHUTTER SPEED and EXPOSURE only in CAMERA/M.REC mode. ✤ SHUTTER SPEED and EXPOSURE values can only be set in the Quick Menu. ✤ SHUTTER SPEED and EXPOSURE are automatically switched and/or deactivated. 1. Set the power switch to CAMERA mode.2. Move the MENU SELECTOR until you see icon( ) on, and then push the MENU SELECTOR.  You see a screen on which you can select SHUTTER SPEED and EXPOSURE.  Move the MENU SELECTOR to select the item you want and then push the MENU SELECTOR.  SHUTTER SPEED can be set to 1/60, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000 or 1/10000.  Only SHUTTER SPEED up to 1/250 are available when using a M.REC mode.  EXPOSURE can be set between 00 and 29. 3. To exit from the setting screen, select the icon( ) and push the MENU SELECTOR. Recommended Shutter speeds when recording ✤ Outdoor sports such as golf or tennis : 1/2000 or 1/4000. ✤ Moving cars or trains or other rapidly moving vehicles such as roller coasters : 1/1000, 1/500 or 1/250 ✤ Indoor sports such as basketball : 1/100 Notes  If you want to use the selected shutter speed and exposure value, you should begin the recording with shutter speed andexposure adjustment screens displayed on the LCD.  If you manually change the shutter speed and exposure value when Auto-exposure option is selected, the manual changeswill be applied first.  Image may not seem as smooth when a high shutter speed is set.  The camcorder returns to auto shutter setting and auto exposure setting when you change to the EASY, SLOW SHUTTERmodes.  When recording with a SHUTTER SPEED of 1/1000 or higher, make sure the sun is not shining into the lens.  When recording with a SHUTTER SPEED or EXPOSURE, the Flash function does not work. 00000? SCD903 USA (28~63) 4/14/04 12:37 PM Page 61 ENGLISH 6262 Advanced Recording✤ The SLOW SHUTTER function works in CAMERA mode only. ✤ The shutter speed can be controlled, allowing you to record slow moving objects. 1. Set the power switch to CAMERA mode.2. Press the SLOW SHUTTER button.3. Each time you press the SLOW SHUTTER button, SHUTTER SPEED is changed to S1/30, S1/15, S1/8, off. 4. To exit, press the SLOW SHUTTER button. Notes  When using "SLOW SHUTTER" the image takes on a slow motion like effect.  The SLOW SHUTTER function will not operate in EASY mode.  While using the SLOW SHUTTER function, you cannot use the following functions:- PROGRAM AE, EIS, Digital Zoom, SHUTTER S…

Text truncated - open the document above for the full version.

EMC Compliance Ltd. 82-1, JEIL-RI, YANGJI-MYUN, YONGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 9919 FAX : 82 31 336 4767 This test report shall not be reproduced except in full, Without the written approval. SCD903 External photos EMC Compliance Ltd. 82-1, JEIL-RI, YANGJI-MYUN, YONGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 9919 FAX : 82 31 336 4767 This test report shall not be reproduced except in full, Without the written approval. Adapter

EMC Compliance Ltd. 82-1, JEIL-RI, YANGJI-MYUN, YONGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 9919 FAX : 82 31 336 4767 This test report shall not be reproduced except in full, Without the written approval ID Label EMC Compliance Ltd. 82-1, JEIL-RI, YANGJI-MYUN, YONGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 9919 FAX : 82 31 336 4767 This test report shall not be reproduced except in full, Without the written approval ID Label Location

EMC Compliance Ltd. 82-1, JEIL-RI, YANGJI-MYUN, YONGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 9919 FAX : 82 31 336 4767 This test report shall not be reproduced except in full, Without the written approval SCD903 Internal photos EMC Compliance Ltd. 82-1, JEIL-RI, YANGJI-MYUN, YONGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 9919 FAX : 82 31 336 4767 This test report shall not be reproduced except in full, Without the written approval Main board EMC Compliance Ltd. 82-1, JEIL-RI, YANGJI-MYUN, YONGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 9919 FAX : 82 31 336 4767 This test report shall not be reproduced except in full, Without the written approval SUB board EMC Compliance Ltd. 82-1, JEIL-RI, YANGJI-MYUN, YONGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 9919 FAX : 82 31 336 4767 This test report shall not be reproduced except in full, Without the written approval TAPE HEAD Board MIC Board

EMC Compliance Ltd. 82-1, JEIL-RI, YANGJI-MYUN, YONGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 9919 FAX : 82 31 336 4767 This test report shall not be reproduced except in full, Without the written approval. Operation Description This device is DIGITAL CAMCORDER. It uses either lithium ion battery or power supply. A data transfer through USB connection to a PC or IEEE1394 connection to a PC.

EMC Compliance Ltd. 82-1, JEIL-RI, YANGJI-MYUN, YONGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 9919 FAX : 82 31 336 4767 This test report shall not be reproduced except in full, Without the written approval. Report No.: EMC-FCC-0144 Page : 1 of 15 EMI TEST REPORT Test report No. : EMC- FCC- 0144 Type of equipment : DIGITAL CAMCORDER Model No. : SCD903 FCC ID. : A3L04OMEGA2 Applicant : SAMSUNG ELECTRONICS CO., LTD. Test standards : FCC part 15 subpart B, Class B Test Procedure and Items : - AC Power Line Conducted Emissions Measurement: ANSI C63.4-1992 - Radiated Emissions Measurement : ANSI C63.4-1992 Test result : Complied The above equipment was tested by EMC compliance Testing Laboratory for compliance with the requirements of FCC Rules and Regulations. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of test: 2004. 4.21~4.22 Issued date: 2004 .4. 26 Test ed b y : Approved by: Kim, Jung-Soo Chung, Min-Seok EMC Compliance Ltd. 82-1, JEIL-RI, YANGJI-MYUN, YONGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 9919 FAX : 82 31 336 4767 This test report shall not be reproduced except in full, Without the written approval. Report No.: EMC-FCC-0144 Page : 2 of 15 [ Contents ] 1. Client information ................................................................................... 3 2. Laboratory information ............................................................................ 4 3. Test system configuration......................................................................... 5 3.1 Operation Environment .................................................................... 5 3.2 Measurement Uncertainty ................................................................. 5 3.3 Sample calculation .......................................................................... 6 4. Description of EUT .................................................................................. 7 4.1 Product Description ......................................................................... 7 4.2 Peripherals ..................................................................................... 7 4.3 Used cables .................................................................................... 8 4.4 Operating conditions ........................................................................ 8 4.5 EUT test configuration ...................................................................... 9 5. Summary of test results........................................................................... 9 5.1 Modification to the E.U.T. .................................................................. 9 5.2 Standards & results ......................................................................... 9 6. Test results .......................................................................................... 10 6.1 Conducted emission....................................................................... 10 6.1.1 Measurement procedure................................................... 10 6.1.2 Used equipments ............................................................ 10 6.1.3 Measurement uncertainty................................................. 10 6.1.4 Test data ....................................................................... 11 6.1.5. Result .......................................................................... 11 6.2 Radiated emission ......................................................................... 12 6.2.1 Measurement procedure .................................................... 12 6.2.2 Used equipments ............................................................ 12 6.2.3 Measurement uncertainty................................................. 12 6.2.4 Test data ....................................................................... 13 6.2.5. Result .......................................................................... 13 7. Test Graph ........................................................................................... 14 Conducted emission test graph EMC Compliance Ltd. 82-1, JEIL-RI, YANGJI-MYUN, YONGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 9919 FAX : 82 31 336 4767 This test report shall not be reproduced except in full, Without the written approval. Report No.: EMC-FCC-0144 Page : 3 of 15 1. Client information Applicant: SAMSUNG ELECTRONICS CO., LTD. Address: 416, Maetan-3Dong, Yeongtong-Gu, Suwon City, Kyungki-Do, Korea Telephone number: 82-31-200-5922 Facsimile number: 82-31-200-5938 Contact person: Jei-Soon Kang / Manager Manufacture: SAMSUNG ELECTRONICS CO., LTD. Address: 416, Maetan-3Dong, Yeongtong-Gu, Suwon City, Kyungki-Do, Korea Telephone number: 82-31-200-5922 Facsimile number: 82-31-200-5938 EMC Compliance Ltd. 82-1, JEIL-RI, YANGJI-MYUN, YONGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 9919 FAX : 82 31 336 4767 This test report shall not be reproduced except in full, Without the written approval. Report No.: EMC-FCC-0144 Page : 4 of 15 2. Laboratory information Address EMC compliance Ltd. 82-1, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA Telephone Number : 82 31 336 9919 Facsimile Number : 82 31 336 4767 FCC Filing No. : 793334 VCCI Registration No. : C-1713, R-1606 SITE MAP EMC compliance Yongin city EMC Compliance Ltd. 82-1, JEIL-RI, YANGJI-MYUN, YONGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 9919 FAX : 82 31 336 4767 This test report shall not be reproduced except in full, Without the written approval. Report No.: EMC-FCC-0144 Page : 5 of 15 3. Test system configuration 3.1 Operation Environment Temperature Humidity Pressure OATS : 14 °C 36 % 1014 hPa Shielded room : 26 °C 33 % 1014 hPa Test site These testing were performed following locations; Shielded room: Conducted emission OATS (10m) : Radiated emission 3.2 Measurement Uncertainty All measurements involve certain levels of uncertainties, …
