A3L04SPIDERDigital Video Camcorder

ENGLISH Digital Video CAM Owner’s Instruction BookBefore operating the unit, please read thisInstruction Book thoroughly, and retain it forfuture reference. AF Auto Focus CCD Charge Coupled Device LCD Liquid Crystal Display SC-M 102/ M 105/ M 110 US PATENT 4415844 ELECTRONICS ENGLISH *Samsung Electronics’ Internet Home Pagehttp://www.samsungusa.com AD68-00814F THE CAM IS MANUFACTURED BY: SERVICE DIVISION 400 Valley Road, Suite 201, Mt. Arlington N.J. 07856 Tel: 1-800-SAMSUNG (1-800-726-7864) ELECTRONICS 00814F SC-M102 USA_ Contents 2004.8.30 9:52 AM Page 2 ENGLISH Notices and Safety Instructions9. VENTILATION: Slots and openings in the cabinet are provided for ventilation to ensurereliable operation of the CAM and to protect it from overheating. Theseopenings must not be blocked or covered. Never place your the CAM ona bed, sofa, rug, or other similar surface: on or near a radiator or heatregister. The CAM should not be placed in a built-in installation such as abookcase or rack unless proper ventilation is provided or themanufacturer s instructions have been adhered to. 10. POWER SOURCES: The CAM should be operated only from the type of power sourceindicated on the label.If you are not sure of the type of power supply at your home, consult yourappliance dealer or local power company. If the CAM is intended to be operated from battery power, or othersources, refer to the operating instructions. 11. GROUNDING OR POLARIZATION: The CAM may be equipped with either a polarized 2-wire AC line plug (a plug having one blade wider than the other) or a 3-wire grounding type plug, a plug having a third (grounding) pin. If you are unable to insert the plug fully into the outlet, try reversing theplug. If the plug still fails to fit, contact your electrician to replace youroutlet. Do not defeat the safety purpose of the polarized plug. 12. POWER-CORD PROTECTION: Power-supply cords should be routed so that they are not likely to bewalked on or pinched by items placed upon or against them, playingparticular attention to cords or plugs, convenient receptacles, and thepoint where they exit from the unit. 13. OUTDOOR ANTENNAGROUNDING: If an outside antenna or cable system is connected to the CAM, be surethe antenna or cable system is grounded to provide some protectionagainst voltage surges and built-up static charges, Section 810 of theNational Electrical Code, ANSI/NFPA No. 70-1984, provides informationwith respect to proper grounding of the mast and supporting structure,grounding of the lead-in wire and supporting structure, grounding of themast and supporting structure, grounding of the lead-in wire to anantenna discharge unit, size of grounding to conductors, location ofantenna-discharge unit, connection to grounding electrodes andrequirements for the grounding electrode. See figure below. ENGLISH Notices and Safety Precautions Notices and Safety Instructions 1.READ INSTRUCTIONS: All the safety and operating instructions should be read before the CAM isoperated. 2.RETAIN INSTRUCTIONS: The safety and operating instructions should be retained for futurereference. 3.HEED WARNINGS: All warnings on the CAM and in the operating instructions should beadhered to. 4.FOLLOW INSTRUCTIONS: All operating and maintenance instructions should be followed. 5.CLEANING: Unplug this the CAM from the wall outlet before cleaning. Do not use liquidor aerosol cleaners. Use a dry cloth used for dusting cabinets. 6.ATTACHMENTS: Do not use attachments not recommended by the CAM productmanufacturer as they may be hazardous. 7.WATER AND MOISTURE. Do not use the CAM near water; for example, near a bathtub, wash bowl, kitchen sink, laundry tub, in a wetbasement, near a swimming pool or lake. 8. ACCESSORIES: Do not place the CAM on an unstable cart, stand, tripod, bracket or table.the CAM may fall, causing serious injury to a child or adult, and seriousdamage to the unit.Use only with a cart, stand, tripod, bracket, or table recommended by themanufacturer or sold with the CAM. Any mounting of the unit should followthe manufacturer s instructions and should use a mounting accessoryrecommended by the manufacturer.  An appliance and cart combination should be moved with care. Quick stops, excessive force and uneven surfaces may cause the appliance and cart combination to overturn. PORTABLE CART WARNING (Symbol provided by RETAC) This symbol is intended to alert the user to the presence of uninsulateddangerous voltage within the product s enclosure that may be ofsufficient magnitude to constitute a risk of fire or electric shock.This symbol is intended to alert the user to the presence of importantoperating and maintenance instructions in the literature accompanyingthis product. To prevent electric shock, match wide blade of plug towide slot and fully insert. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVECOVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. ELECTRIC SERVICE EQUIPMENT GROUND CLAMP ANTENNALEAD IN WIREANTENNADASCHARGE UNIT(NEC SECTION 810-20) GROUNDING CONDUCTORS(NEC SECTION 810-21) GROUND CLAMPS POWER SERVICE GROUNDINGELECTRODE SYSTEM(NEC ART 250, PART H) NEC NATIONAL ELECTRICAL CODE 00814F SC-M102 USA_ Contents 2004.8.30 9:52 AM Page 4 ENGLISH 21. POWER SUPPLY If this power supply is used at 240V AC, a suitable plug adapter should be used. NOTE TO CATV SYSTEM INSTALLER:This reminder is provided to call the CATV system installer’s attention toArticle 820-40 of the NEC that provides guidelines for proper grounding and,in particular, specifies that the cable ground shall be connected to thegrounding system of the building as close to the point of cable entry aspractical.USER INSTALLER CAUTION:Your authority to operate this FCC certified equipment could be voided if youmake changes or modifications not expressly approved by this partyresponsible for compliance to part 15 FCC rules.NOTE:Hg LAMP(S) INSIDE THIS PRODUCT CONTAINM…

Text truncated - open the document above for the full version.

Page : 1 of 26 Samsung EMC Testing and Certification Laboratory Project NO. :LBE042073 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. EMC Test Report According to FCC Part 15 Subpart B Project No. LBE042073 Equipment under Test Address 416 Maetan3-Dong,Yeongtong-Gu,Suwon-City,Gyeonggi-Do, Korea,443-742 Product Name Digital Camcorder Model Name SC-M110 Manufacturer SAMSUNG Brand Name SAMSUNG Variant Model See Page 3 Date of Test October 15 ~ 15, 2004 Issued Date November 8, 2004 Name/Position Signature Tested by Sung Wook, Choi Test Engineer Reviewed by No Cheon, Park Manager of EMC Lab. Authorized by Kyu Baek, Chung Chief of EMC Lab. 1. This test reports does not constitute an endorsement by NIST/NVLAP or U.S Government. 2. This test report is to certify that the tested device properly complies with the requirements of FCC Rules and Regulations Part 15 Subpart B Unintentional Radiators. All tests necessary to show compliance to the requirements were and these results met the specifications requirement. This laboratory is registered by the NIST/NVLAP, U.S.A. The test reported herein have been performed in accordance with its terms of registration. NVLAP LAB CODE 200623-0 Page : 2 of 26 Samsung EMC Testing and Certification Laboratory Project NO. :LBE042073 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Table of Contents 1. General Information 1.1 Basic Information related Product 1.2 Detail Information related Product 1.3 Test Configuration 1.4 EUT Operating Conditions 1.5 Applied Standard 1.6 Test Facility 2. Summary of Test Results 3. Description of individual tests 3. 1 Conducted Emission 3. 2 Radiated Emission 4. Appendix A 4.1 Test Photography 4.2 EUT Photography Page : 3 of 26 Samsung EMC Testing and Certification Laboratory Project NO. :LBE042073 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1. General Information 1.1 Basic Information related Product Applicant Samsung Electronics Co. Ltd; Model name SC-M110 Applicant Address Samsung Electronics Co. Ltd; 416 Maetan3- Dong, Yeongtong-Gu, Suwon-City, Gyeonggi-Do, Korea, 443-742 Contact Person Sung Wook, Choi Kind of product Digital Camcorder Valiant list SC-M102, SC-M105 Manufacturer Samsung Electronics Co.Ltd; New / Alternative / Permissive change Information This report is original report # 1.2 Detail Information related Product Specification Page : 4 of 26 Samsung EMC Testing and Certification Laboratory Project NO. :LBE042073 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Page : 5 of 26 Samsung EMC Testing and Certification Laboratory Project NO. :LBE042073 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.3 Operating Mode and Condition The system was configured for testing in typical fashion use. The mode of operation utilized for testing was selected to best simulate typical EUT use. - PLAY - RECORDING - PC 1.4 Equipment Modifications No equipment modifications were required. Page : 6 of 26 Samsung EMC Testing and Certification Laboratory Project NO. :LBE042073 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.5 Test Configuration Used EUT and Peripherals Mark Item Model No. Serial No. Manufacturer FCC ID A Digital Camcorder SC-M110 - SAMSUNG A3L04SPIDER B Adapter - - SAMSUNG DOC C Note PC OX-138-A01-T1009-007 DELL DOC D Adapter ADP-50FH TH-08H051-17971-19A- 01DV DELL DOC E Printer ML-1750 RP1750-120V-018 SAMSUNG A3LML-1750 F Mouse M-S48a LZA00153189 SAMSUNG DOC Used Cable Description Connect Cable Length [m] Shielded [Y/N] Remark 1 AC Power cable 1.7 No 2 AC Power cable 1.7 No 3 USB 1.5 No 4 Earphones 1.5 No 5 AV 1.5 No 6 1394 Cable 1.5 No 7 Printer 1.5 No 8 Mouse 1.5 No 9 Printer cable 1.5 No Page : 7 of 26 Samsung EMC Testing and Certification Laboratory Project NO. :LBE042073 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Block Diagram Page : 8 of 26 Samsung EMC Testing and Certification Laboratory Project NO. :LBE042073 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.6 Applied Standards List Product or Generic Standards Basic Standards FCC Part15 Subpart B ANSI 63.4 : 2000 Page : 9 of 26 Samsung EMC Testing and Certification Laboratory Project NO. :LBE042073 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.7 Test Facility General Information The sites are constructed in conformance with the requirements of ANSI C63.4 and CISPR 22, 16-1, 16-2, 11. This EMC Testing Lab. is accredited by Korea Laboratory Accreditation Scheme(KOLAS) which signed the International Laboratory Accreditation Cooperation (ILAC) Mutual Recognition Arrangement (MRA) for the above test item(s) and test method(s). This Lab. is operated as testing laboratory in accordance with the requirements of ISO/IEC 17025:1998. Accreditation and Listing Uncertainty Test Item Expanded Uncertainty Radiated Disturbance 5.09 Disturbance voltage at the mains terminals 1.64 (According to NAMAS Pub.NIS81) Page : 10 of 26 Samsung EMC Testing and Certification Laboratory Project NO. :LBE042073 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 2. Summary of Test Results Result : PASS The equipment under test(EUT) has been found to comply with the applied standards. Test Name Applied Standard Result Electromagnetic Emission Test 3.1 Conducted Emission FCC Part15 Subpart B Complied 3.2 Radiated Emission FCC Part15 Subpart B Complied Page : 11 of 26 Samsung EMC Testing and Certification Laboratory Project NO. :LBE042073 This report shall not b…

Text truncated - open the document above for the full version.

Page : 19 of 26 Samsung EMC Testing and Certification Laboratory Project NO. :LBE042073 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 4. Appendix A 4.1 Test Photography Picture 1. Conducted Emission (Front) Picture 2. Conducted Emission (Rear) Page : 20 of 26 Samsung EMC Testing and Certification Laboratory Project NO. :LBE042073 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Picture 3. Radiated Emission (Front) Picture 4. Radiated Emission (Rear)
