This Document can not be used without Samsung’s authorization Samsung Electronics 5-1 5. Block Diagram

Photograph of VR8406 - FCC ID : A3L2004KHAN2 Fro nt View Rear View Photograph of VR8406 - FCC ID : A3L2004KHAN2 To p V i e w Bottom View

Labeling requirement FCC IDENTIFICATION LOCATION: on the label rating STATEMENT LOCATION: on the bottom of product

Photograph of VR8406 - FCC ID : A3L2004KHAN2 Front View – Front/Top cover open Top View – Top cover open Photograph of VR8406 - FCC ID : A3L2004KHAN2 Top of Main PCB View Bottom of Main PCB View

Photograph of VR8406 - FCC ID : A3L2004KHAN2 Top of VHS Deck Mechanism View Bottom of VHS Deck Mechanism View Photograph of TM-BLOCK TM-BLOCK TYPE: TMZH2-002A To p V i e w Bottom View

Page : 1 of 40 Samsung EMC Testing and Certification LaboratoryProject No. : LBE032580 Applicant FCC ID Product Name Model Name Manufacturer Brand Name Variant Model Name/Position Kyung Chul, Min Test Engineer No Cheon, Park Manager of EMC Lab. Kyu Baek, Chung Chief of EMC Lab. Address Telephone No. Fax No. This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory EMC Test Report Project No. LBE032580 Equipment under Test Video Cassette Recorder VR8460 Samsung Electronics Co. Ltd SAMSUNG See Page 2 Issued Date 6-Jan-04 Applied StandardsFCC Part 15 Date of Tests December 16 ~ 26 , 2003 Samsung Electronics Co.Ltd 416 Maetan-3 Dong, Yeongtong-Ku, Suwon City, Gyeonggi-Do, Korea, 442-742 A3L2004KHAN2 Result Passed The equipment under test has found to be compliant with the applied standards. Signature Tested by Reviewed by Authorized by 1. This test reports does not constitute an endorsement by NIST/NVLAP or U.S Government. 2. This test report is to certify that the tested device properly complies with the requirements of FCC Rules and Regulations Part 15 Subpart B Unintentional Radiators.All tests necessary to show compliance to the requirements were and these results met the specifications requirement. This laboratory is registered by the NIST/NVLAP, U.S.A. The test reported herein have been performed in accordance with its terms of registration. SAMSUNG ELECTRONICS Co., Ltd. SUWON EMC Test Lab. 416 Maetan-3 Dong, Yeongtong-Ku, Suwon City, Kyungki-Do,Korea, 442-742 82-31-200-2135 82-31-200-2189 NVLAP LAB CODE 200623-0 Page : 2 of 40 Samsung EMC Testing and Certification Laboratory 1. General Information 1.1 Basic Information related Product 1.2 Power Input Ports DescriptionVoltage(V)Frequency(Hz)No of phases Mains Cable120V60Hz1 1.3 EUT & Support Equipment MarkItemModel No.Serial No.ManufacturerRemark AVideo Cassette RecorderVR8460-SAMSUNGEUT BRemote Controller--SAMSUNGEUT This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory A3L2004KHAN2 Visual Carrier : 61.25 MHz Aural Carrier : 65.75 MHz CH. 4 Visual Carrier : 67.25 MHz Aural Carrier : 71.75 MHz Applicant Samsung Electronics Co. Ltd Product name Video Cassette Recorder Model name VR8460 Brand Name SAMSUNG Used EUT and Peripherals Manufacturer Samsung Electronics Co. Ltd Variant Models None Type of RF Output Connector Type "F" Connector 75 ohm(Unbalanced) FCC ID Number CH. 3 Operating (RF Modulator) Frequency Page : 3 of 40 Samsung EMC Testing and Certification Laboratory This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory Page : 4 of 40 Samsung EMC Testing and Certification Laboratory Project No. : LBE032580 1.4 Operating Mode and Conditions The EUT was tested in the following operating modes(at both channel 3 and 4) for the tests mention in this report : 1) Recording ( NTSC Signal ) A NTSC signal(Color bar) was supplied at ch.5(77.25MHz) through the ant. Input connector for recording. 2) Recording ( 1V VITS Signal ) A 1V peak-to-peak VITS signal was supplied through the video input connector for recording. 3) Recording ( 5V VITS Signal ) A 5V peak-to-peak VITS signal was supplied through the video input connector for recording. 4) VCR Play In this test mode, a video tape recorded with VITS signal was played on the EUT. Note : Recording( NTSC Signal ) mode is not applicable to the antenna transfer switch test. 1.5 Block Diagram This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory A B Page : 5 of 40 Samsung EMC Testing and Certification Laboratory Project No. : LBE032580 1.6 Test Facility The EMI/EMS measurement facilities used to collect the tested data are located at 416 Maetan 3 Dong, Yeongtong-Ku, Suwon City, Gyeonggi-Do, Korea. This sites are constructed in conformance with the requirements of ANSI C63.4 and CISPR 16-1 & 16-2. SAMSUNG Electronics Co.,Ltd is accredited by Korea Laboratory Accreditation scheme(KOLAS) which . signed the International Laboratory Accreditation Cooperation(ILAC) Mutual Recognition Arrangement (MRA) for the above test item(s) and test method(S) This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory General Information Accreditation and Listing LAB CODE 200623-0 R-1221,C-1095 No.195 Reg. No.98856 Reg. No. KR0004 App. No.001 H9354285 Reg. No. 124 Page : 6 of 40 Samsung EMC Testing and Certification Laboratory Project No. : LBE032580 1.7 Applied Standards List This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory FCC Rule Part(s)Test Procedure(s) FCC Part 15 Subpart BANSI C63.4-2001 - - Page : 7 of 40 Samsung EMC Testing and Certification Laboratory Project No. : LBE032580 2. Summary of Test Results Result : The equipment under test(EUT) has been found to comply with the applied standards Applied StandardResult 3.1AC Powerline Conducted Emission MeasurementFCC Part 15Complied 3.2Radiated Emission MeasurementFCC Part 15Complied 3.3Output Signal Level MeasurementFCC Part 15Complied 3.4 Output Terminal Conducted Spurious Emission Measurement FCC Part 15Complied 3.5Antenna Transfer Switch MeasurementFCC Part 15Complied * N/A : Test not applicable This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory Section of the Product Standard Electromagnetic Emission Test Page : 8 of 40 Samsung EMC Testing and Certification Laboratory Project No. : LBE032580 3. Description of Individual Tests 3.1 AC Powerline Conducted Emission Measurement Test Information Test Engineer Test Date Climate Condition Test Place Test Equipments EquipmentModel NameManufacturerSerial No.Next Cal. Date TEST RECEIVERESI26R & S839809/00204-Nov-04 LISNESH3-Z5R & S847265/02816-Jul-04 LISNESH3-Z5R & S10026116-Jul-04 Test SoftwareEP5/CETOYOVersion : 2.0.860N/A Test …

Text truncated - open the document above for the full version.

Page : 37 of 40 Samsung EMC Testing and Certification Laboratory Project No. : LBE032580 4. Appendix 4.1 Test Photography This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory Pic. 1 AC Powerline Conducted Emission [Front] Pic. 2 AC Powerline Conducted Emission [Rear] Page : 38 of 40 Samsung EMC Testing and Certification Laboratory Project No. : LBE032580 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory Pic. 3 Radiated Emission [Front] Pic. 4 Radiated Emission [Rear] Page : 39 of 40 Samsung EMC Testing and Certification Laboratory Project No. : LBE032580 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory Pic. 5 RF Output Signal Level & Output Terminal Conducted Spurious Emission Pic. 6 Antenna Transfer Switch
