Page 1 of 16 Project No. : SE-01-0723 Product :Notebook PC Model No. :SOLO 5350 FCC ID : A3L5350015318R 1. This test reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 2. This test reports does not constitute an endorsement by NIST/NVLAP or U.S Government. 3. This test report is to certify that the tested device properly complies with the requirements of FCC Rules and Regulations Part 15 Subpart B Unintentional Radiators. All tests necessary to show compliance to the requirements were and these results met the specifications requirement. Date of test :December 18, 2001 - December 21, 2001 Issued Date :January 2 , 2002 Tested by: Jay Yong, PARK / Test Engineer Reviewed by: Yang Soo, KIM / Manager of EMC Lab. Authorised by: Kyu Baek, CHUNG / Chief of EMC Lab. This laboratory is registered by the NIST/NVLAP, U.S.A. The test reported herein have been performed in accordance with its terms of registration. EMI TEST REPORT According to FCC Part 15 Subpart B/Class B NVLAP Code: 200447 Page 2 of 16 Project No. : SE-01-0723 Table of Contents 1. General Information 1.1 Product Description 1.2 Configuration of EUT and peripherals 1.3 Used Cable Description 1.4 System Block Diagram of Test Configuration 1.5 Test Facility 2. System Test Configuration 2.1 Configuration of Radiated and Conducted Interference Measurement 2.2 Operation Environment 2.3 Test Procedure 3. Conducted Emission Test Data 4. Radiated Emission Test Data 5. Label Configuration and Location 6. Test Equipment Used Distribution This test report has been made available as follows: CS Management Center, EMC Laboratory1 original Computer Division1 copy This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Page 3 of 16 Project No. : SE-01-0723 1. General Information Applicant :Samsung Electronics Co., Ltd. CS Management Center EMC Test Laboratory Tel.: +81-(0)31-200-2135 Fax.: +81-(0)31-200-2189 Full Address :416 Maetan 3 Dong, Paldal-Ku, Suwon City, Kyungki Do, Korea, 442-742 Kind of Product :Notebook PC FCC ID:A3L5350015318R Project Name :Drake II Model & Variant Names :SOLO 5350(Brand Name: Gateway) Test Report Produced by :Jay Yong, PARK / Test Eng. 1.1 Product Description 1) Justification The system was configured for testing in typical fashion use. Cable were attached to each of the available I/O Ports. Where applicable, peripherals were attached to the I/O cables. The mode of operation utilized for testing was selected to best simulate typical EUT use. This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Page 4 of 16 Project No. : SE-01-0723 2) Operating Frequency : 1266MHz(CPU Speed), 133MHz(Host Clock), 133MHz(SDRAM Clock), 33.3MHz(PCI Clock), 14.318MHz(Ref. OSC), 49.152MHz(Audio Clock), 25M(Network) 12.288MHz(Audio Bit Clock), 24.576MHz(Audio C24), 66.6MHz(VCH/ICH Clock) 10MHz(Micom Clock), 48MHz(USB Clock), 65MHz(LCD Clock), 66.6(Hub) 3) Description of Testing operating mode LCD Screen CRT Monitor, TV Monitor Hard disk drive & DVD_CD-RW Combo drive LPT1 to Printer Media Player Playing through Video CD in Network Server Audio out to Speaker 4) Tested Resolution : 1024 X 76860Hz32bits 1024 X 76885Hz32bits 800 X 60060Hz16bits This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Network Audio Output Operating Mode Operating section of EUT "H" Pattern display & Read / Write Colors LCD(14.1") Ext. Monitor Tested Video modeResolutions TV Monitor Refresh rates Page 5 of 16 Project No. : SE-01-0723 5) Assemble Parts ItemSpecificationRemark CPUIntel Pentium-III 1266MHz TualatinPSB 133 uFCPGA2, Cache 512KB Main MemorySEC, PC133, 512MB (256MB x 2EA)M464S3254 x 2EA (RAM)Max. 1GB (512MB x 2EA)M464S6453 x 2EA Video ControllerIGD(Internal Graphics Device) in GMCH-MSupport Composite Video out 16MB, 400MHz DRDRAM Graphics Memory Video DisplaySEC, LCD 14.1" TFT, LTN141XU-L02 Upto 1024x768 Pixels; 18-bit colors Swap BayToshiba CD R/W / DVD COMBO Drive SC-C2002, 4x(CDR)/24x(CD), 6x (DVD) HDDToshiba 30GB , MK3017GAPUser-removable ; 2.5", 9.5mmH LAN10/100 Base-T Ethernet support Modem SEC, SEM-2400iC, V.90 compliant / V92 ready , 56KbpsAC-Link (Conexant SmartMCII) BluetoothBluetooth 2.402GHz~2.480GHz Spec. 1.1, USB interface Wireless LANAgere, MPCI3A-20, Mini-PCI Type IIIAIEEE 802.11b(11MBPS), Mini PCI Input DevicesKeyboard, 19mm pitch, 2.5mmH travel length Pointing Device, PS/2 Touchpad w/ 4 buttonSynaptics TM41P-351 AC AdapterASTEC, 80-Watts, AC 100~240V FREE-VOLTAGESA80T-3115 BatteryToshiba, Removable 8-cell Li-Ion Smart, 58.46Wh Ports(MD-3)2 USB, DIGITAL AUDIO OUT, DC IN, SVHS-in/out EXT MONITOR, MIDI Port, Serial Port, Parallel Port, TV-in/out, Audio Out R/L, MIC-IN, LINE-IN, HEADPHONE-OUT, SPDIF, Joy Stick, RCA, LINE-OUT, MIC, 2 PS/2, 2 Card bus slot. Etc This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Page 6 of 16 Project No. : SE-01-0723 1.2 Tested System Details MarkItemModel No.Serial No.ManufacturerFCC ID ANotebook PCSOLO 5350-SamsungEUT BTVCCM-052C54059495COMPAQ- CExternal MonitorTFT7010147CK23DA272COMPAQDoc DDigital SpeakerDigital BA7357001332BOSTON- EUSB MouseM-U48aLZE01604737LogitechJNZ211360 FUSB MouseM-U48aLZC10703957LogitechJNZ211360 GPS/2 MouseNICE MOUSEK9137324KEYSYSTEMSDoc HSerial MouseM-M35LZA71155447LOGITECHDoc IKeyboardSEM-A17K-SamsungE2XSEM-A17K JAudio DeviceMY-250160KB0620Samsung- KCamcorderDCR-PC1101091827SONY- LJoystickX03-57540--- MEarPhone---- NHeadPhone---- OPrinterK10158CLG000800377CannonDoc PTelephoneSSP-2300042051841Samsung- QPrinter AdapterSA70-3105-Gateway- REUT AdapterADP-80CBBTPC0127000179 DELTA ELECTRONICS - SMonitor AdapterPSCV420102ACO10603504COMPAQ- This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Page 7 of 16 Project No. : SE-01-0723 1.3 Configuration of…

Text truncated - open the document above for the full version.

Page 9 of 16 Project No. : SE-01-0723 2. System Test Configuration 2.1 Configuration of Radiated and Conducted Interference Measurement * Cabling was taken into consideration and test data was taken under worse case conditions. 1)Conduction(Front View) 2)Conduction(Rear View) This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Page 10 of 16 Project No. : SE-01-0723 3) Radiation(Front View) 4) Radiation(Rear View) This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory.
