10 Block Diagrams 9519-A** 10-1 DDC (24LC21A) PLL (ICS1523) OSD (LMOSD II) Automatic Adjustment (ASIC181-1) EEPROM (24C08) SDRAM (KM416S1020BT) Scaling Engine (MX88282FC) (AD9483) ADC & Pre-Amp (M52747) Video Switch (BA7657F) Sync Separater (LM1881) TMDS (SIL150) MICOM (ST7275) Brightness & Contrast Control X-T AL X-T AL 15pin D-sub DC 14 V 13W3 DC-DC Inverter Control Key Output – DC 14 V – DC 12 V – DC 5 V – DC 3.3V to LCD Panel to W/S or PC Adaptor Video Y Video X RGBxSYNCx SOG RGBySYNCy Green, Digital OSD Control Sampling Clk PDEN DC 14 V DDC Signal DC 5 V to MICOM RGBdigital Datasync RGBlcd to LCD Panel Delayed Vsync SYNC Control Signals Key Input BrightnessControl for FRC

FCC CFR47 PART 15 DIGITAL DEVICE TEST REPORT FOR 18.1" TFT MONITOR W/ MAX. RESOLUTION OF 1280X1024 NON-INTERLACED (80.1 KHz) MODEL: 9519-A** , LSA800 FCC ID: A3L9519A REPORT NUMBER: 98U0034-1 ISSUE DATE: NOVEMBER 16, 1998 Prepared for IBM P. O. BOX 12195 RESEARCH TRIANGLE PARK, NC 27709 USA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 REPORT NO: 98U0034-1 DATE: NOVEMBER 16, 1998 FCC ID: A3L9519A EUT: 18.1 TFT MONITOR W/ MAX. RESOLUTION OF 1280X1024 NON-INTERLACED (80.1 KHz) COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4002C 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE..............................................1 2. PRODUCT DESCRIPTION.....................................................2 3. TESTED SYSTEM DETAILS...................................................2 4. TEST FACILITY...........................................................3 5. ACCREDITATION AND LISTING...............................................3 6. MEASUREMENT INSTRUMENTATION.............................................3 7. MEASURING INSTRUMENT CALIBRATION........................................3 8. UNITS OF MEASUREMENT....................................................4 9. ANTENNAS................................................................4 10. CLASSIFICATION OF DIGITAL DEVICE........................................5 11. RADIATED EMISSION LIMITS................................................5 12. CONDUCTED EMISSION LIMITS...............................................6 13. CONDUCTED EMISSION TEST PROCEDURE.......................................8 14. RADIATED EMISSION TEST PROCEDURE........................................8 15. AMBIENT CONDITIONS......................................................9 16. SYSTEM TEST CONFIGURATION...............................................9 17. EQUIPMENT MODIFICATIONS................................................10 18. EUT SETUP PHOTOS.......................................................11 19. TEST EQUIPMENT LIST....................................................12 20. TEST RESULT SUMMARY....................................................13 APPENDICES..................................................................15 .EXTERNAL I/O CABLE CONSTRUCTION DESCRIPTION .CONFIGURATION BLOCK DIAGRAM .EUT PHOTOGRAPHS REPORT NO: 98U0034-1 DATE: NOVEMBER 16, 1998 FCC ID: A3L9519A EUT: 18.1 TFT MONITOR W/ MAX. RESOLUTION OF 1280X1024 NON-INTERLACED (80.1 KHz) 1OF20 COMPLIANCE CERTIFICATION SERVICESDOCUMENT NO:CCSUP4002D 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 1. VERIFICATION OF COMPLIANCE COMPANY NAME: IBM P. O. BOX 12195 RESEARCH TRIANGLE PARK, NC 27709 USA CONTACT PERSON: BEN KIM / MANAGER TELEPHONE NO: 408-544-5124 MODEL NO/NAME: 9519-A**, LSA800 SERIAL NO: N/A DATE TESTED: NOVEMBER 16, 1998 TYPE OF EQUIPMENT: INFORMATION TECHNOLOGY EQUIPMENT (ITE) MEASUREMENT DISTANCE:()3METER (X)10METER TECHNICAL LIMIT: CLASS B FCC RULES: PART 15 MEASUREMENT PROCEDURE ANSI C63.4:92 / EN 55022 EQUIPMENT AUTHORIZATION PROCEDURE CERTIFICATION MODIFICATIONS MADE ON EUTYESNO DEVIATIONS FROM MEASUREMENT PROCEDURE YES (refer to section 20 for comments) NO RADIATED EMISSION TEST RESULT -2.65 dB @ 212.61 MHz/VERTICAL CONDUCTED EMISSION TEST RESULT -7.30 dB @ 13.62 MHz/L1 The above equipment was tested by Compliance Certification Services for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved By MIKE C.I. KUO / VICE PRESIDENT COMPLIANCE CERTIFICATION SERVICES REPORT NO: 98U0034-1 DATE: NOVEMBER 16, 1998 FCC ID: A3L9519A EUT: 18.1 TFT MONITOR W/ MAX. RESOLUTION OF 1280X1024 NON-INTERLACED (80.1 KHz) 2OF20 COMPLIANCE CERTIFICATION SERVICESDOCUMENT NO:CCSUP4002D 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 2. PRODUCT DESCRIPTION CHASSIS TYPE PLASTIC LIST OF EACH OSC. OR XTAL. FREQ. (FREQ.>=1 MHz) 14.3, 24.0 MHz CPU SPEEDS TESTED 133 MHz PENTIUM CHIPSET BRAND AND PART NO. MXIC POWER SUPPLY/NAME/MODEL/S.N. IBM PSCV560101A NUMBER OF PCB LAYERS 6 BOARD REVISION NO 1.0 LINE FILTER NAME AND MODEL BUILT-IN POWER REQUIREMENTS 100-240 V AC, 60/50 Hz NO. OF EXTERNAL I/O CONNECTORS 1 MAX. RESOLUTION 1280X1024 NI MAX. HOR/VERT. FREQUENCY 80.1 KHz, 75 Hz Model Differences: Model NameDifferencesTested (Checked) 9519-A**ORIGINAL MODEL The star indicates that there can and will be model differences. These differences are cosmetic and for marketing purposes only. LSA800FOR MARKETING PURPOESES 3. TESTED SYSTEM DETAILS The Model names for all equipment, plus descriptions of all cables used in the tested system (including inserted cards) are: External Peripheral Devices Device Type ManufacturerModel NumberSerial No.FCC ID / DoC KEYBOARD DIGITAL RT6656TW 62051025 AQ6-MTN4XZ15 MOUSE DIGITAL M-S35 LT54402451 DZL210472 MODEM HAYES 4007AM A00840073172 BFJ4000AM PRINTER HP 2225C 2930S52630 DSI6XU2225 COMPUTER DIGITAL 963WW TA551T2397 A09-96XWW REPORT NO: 98U0034-1 DATE: NOVEMBER 16, 1998 FCC ID: A3L9519A EUT: 18.1 TFT MONITOR W/ MAX. RESOLUTION OF 1280X1024 NON-INTERLACED (80.1 KHz) 3OF20 COMPLIANCE CERTIFICATION SERVICESDOCUMENT NO:CCSUP4002D 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 4. TEST FACILITY The…

Text truncated - open the document above for the full version.

PROPOSED FCC ID LABEL AREA APPLICANT :SAMSUNG ELECTRONICS CO., LTD. FCC ID:A3L9519A FCC ID LABEL AREA

FCC CFR47 PART 15 DIGITAL DEVICE TEST REPORT FOR 18.1" TFT MONITOR W/ MAX. RESOLUTION OF 1280X1024 NON-INTERLACED (80.1 KHz) MODEL: 9519-A** , LSA800 FCC ID: A3L9519A REPORT NUMBER: 98U0034-1 ISSUE DATE: NOVEMBER 16, 1998 Prepared for IBM P. O. BOX 12195 RESEARCH TRIANGLE PARK, NC 27709 USA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 REPORT NO: 98U0034-1 DATE: NOVEMBER 16, 1998 FCC ID: A3L9519A EUT: 18.1 TFT MONITOR W/ MAX. RESOLUTION OF 1280X1024 NON-INTERLACED (80.1 KHz) COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4002C 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE..............................................1 2. PRODUCT DESCRIPTION.....................................................2 3. TESTED SYSTEM DETAILS...................................................2 4. TEST FACILITY...........................................................3 5. ACCREDITATION AND LISTING...............................................3 6. MEASUREMENT INSTRUMENTATION.............................................3 7. MEASURING INSTRUMENT CALIBRATION........................................3 8. UNITS OF MEASUREMENT....................................................4 9. ANTENNAS................................................................4 10. CLASSIFICATION OF DIGITAL DEVICE........................................5 11. RADIATED EMISSION LIMITS................................................5 12. CONDUCTED EMISSION LIMITS...............................................6 13. CONDUCTED EMISSION TEST PROCEDURE.......................................8 14. RADIATED EMISSION TEST PROCEDURE........................................8 15. AMBIENT CONDITIONS......................................................9 16. SYSTEM TEST CONFIGURATION...............................................9 17. EQUIPMENT MODIFICATIONS................................................10 18. EUT SETUP PHOTOS.......................................................11 19. TEST EQUIPMENT LIST....................................................12 20. TEST RESULT SUMMARY....................................................13 APPENDICES..................................................................15 .EXTERNAL I/O CABLE CONSTRUCTION DESCRIPTION .CONFIGURATION BLOCK DIAGRAM .EUT PHOTOGRAPHS REPORT NO: 98U0034-1 DATE: NOVEMBER 16, 1998 FCC ID: A3L9519A EUT: 18.1 TFT MONITOR W/ MAX. RESOLUTION OF 1280X1024 NON-INTERLACED (80.1 KHz) 1OF20 COMPLIANCE CERTIFICATION SERVICESDOCUMENT NO:CCSUP4002D 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 1. VERIFICATION OF COMPLIANCE COMPANY NAME: IBM P. O. BOX 12195 RESEARCH TRIANGLE PARK, NC 27709 USA CONTACT PERSON: BEN KIM / MANAGER TELEPHONE NO: 408-544-5124 MODEL NO/NAME: 9519-A**, LSA800 SERIAL NO: N/A DATE TESTED: NOVEMBER 16, 1998 TYPE OF EQUIPMENT: INFORMATION TECHNOLOGY EQUIPMENT (ITE) MEASUREMENT DISTANCE:()3METER (X)10METER TECHNICAL LIMIT: CLASS B FCC RULES: PART 15 MEASUREMENT PROCEDURE ANSI C63.4:92 / EN 55022 EQUIPMENT AUTHORIZATION PROCEDURE CERTIFICATION MODIFICATIONS MADE ON EUTYESNO DEVIATIONS FROM MEASUREMENT PROCEDURE YES (refer to section 20 for comments) NO RADIATED EMISSION TEST RESULT -2.65 dB @ 212.61 MHz/VERTICAL CONDUCTED EMISSION TEST RESULT -7.30 dB @ 13.62 MHz/L1 The above equipment was tested by Compliance Certification Services for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved By MIKE C.I. KUO / VICE PRESIDENT COMPLIANCE CERTIFICATION SERVICES REPORT NO: 98U0034-1 DATE: NOVEMBER 16, 1998 FCC ID: A3L9519A EUT: 18.1 TFT MONITOR W/ MAX. RESOLUTION OF 1280X1024 NON-INTERLACED (80.1 KHz) 2OF20 COMPLIANCE CERTIFICATION SERVICESDOCUMENT NO:CCSUP4002D 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 2. PRODUCT DESCRIPTION CHASSIS TYPE PLASTIC LIST OF EACH OSC. OR XTAL. FREQ. (FREQ.>=1 MHz) 14.3, 24.0 MHz CPU SPEEDS TESTED 133 MHz PENTIUM CHIPSET BRAND AND PART NO. MXIC POWER SUPPLY/NAME/MODEL/S.N. IBM PSCV560101A NUMBER OF PCB LAYERS 6 BOARD REVISION NO 1.0 LINE FILTER NAME AND MODEL BUILT-IN POWER REQUIREMENTS 100-240 V AC, 60/50 Hz NO. OF EXTERNAL I/O CONNECTORS 1 MAX. RESOLUTION 1280X1024 NI MAX. HOR/VERT. FREQUENCY 80.1 KHz, 75 Hz Model Differences: Model NameDifferencesTested (Checked) 9519-A**ORIGINAL MODEL The star indicates that there can and will be model differences. These differences are cosmetic and for marketing purposes only. LSA800FOR MARKETING PURPOESES 3. TESTED SYSTEM DETAILS The Model names for all equipment, plus descriptions of all cables used in the tested system (including inserted cards) are: External Peripheral Devices Device Type ManufacturerModel NumberSerial No.FCC ID / DoC KEYBOARD DIGITAL RT6656TW 62051025 AQ6-MTN4XZ15 MOUSE DIGITAL M-S35 LT54402451 DZL210472 MODEM HAYES 4007AM A00840073172 BFJ4000AM PRINTER HP 2225C 2930S52630 DSI6XU2225 COMPUTER DIGITAL 963WW TA551T2397 A09-96XWW REPORT NO: 98U0034-1 DATE: NOVEMBER 16, 1998 FCC ID: A3L9519A EUT: 18.1 TFT MONITOR W/ MAX. RESOLUTION OF 1280X1024 NON-INTERLACED (80.1 KHz) 3OF20 COMPLIANCE CERTIFICATION SERVICESDOCUMENT NO:CCSUP4002D 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 4. TEST FACILITY The…
