A3LA900FAX/COLOR PRINTER/SCANNER/COPIER SYSTEM

Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia MD 21046 Attention:Application Examiner Subject :Application for Certification Reference:FCC ID:A3LA900 Dear Application Examiner : On behalf of Samsung Electronics Co.,Ltd., I, the undersigned, hereby submit the application for certification per FCC Part 15 rules. EUT is an unintentional radiator to be classified as computing device peripherals. The following attachments are included in the electronic filling : Attachment A: This letter Attachment B: Agent authorization letter Attachment C: FCC ID label format and location Attachment D: Block Diagram Attachment E: Technical report w/ setup photo Attachment F: Internal / External photo Attachment G: User Manual If you have any question, please feel free to contact me. Best Regards Mike C.I. Kuo / Vice President Compliance Engineering Services, Inc. 1366 Bordeaux Drive Sunnyvale CA 94089 Tel(408)752-8166 x:105 E-Mail :[email protected]

FCC ID:A3LA900 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID LABEL & LOCATION Note: This label is located on rear enclosure of this equipment. Signature : Printed : Ben Kim Title :Engineering Manager PROPOSED FCC ID LABEL LOCATION APPLICANT:SAMSUNG ELECTRONICS CO., LTD. FCC ID:A3LA900 FCC ID LABEL AREA

FCC CFR47 PART 15 DIGITAL DEVICE TEST REPORT FOR FAX/COLOR PRINTER/SCANNER/COPIER MODEL: A900 FCC ID: A3LA900 REPORT NUMBER: 98E7756 ISSUE DATE: SEPTEMBER 23, 1998 Prepared for SAMSUNG ELECTRONICS CO., LTD. 416 MAETAN DONG, PALDAL GU SUWON SHI, KOREA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 REPORT NO:98E7756 DATE:SEPTEMBER 23, 1998 FCC ID:A3LA900 EUT: FAX/PRINTER/SCANNER COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4002B2 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE..............................................1 2. PRODUCT DESCRIPTION.....................................................2 3. TESTED SYSTEM DETAILS...................................................2 4. TEST FACILITY...........................................................3 5. ACCREDITATION AND LISTING...............................................3 6. MEASUREMENT INSTRUMENTATION.............................................3 7. MEASURING INSTRUMENT CALIBRATION........................................4 8. UNITS OF MEASUREMENT....................................................4 9. ANTENNAS................................................................5 10. CLASSIFICATION OF DIGITAL DEVICE........................................5 11. RADIATED EMISSION LIMITS................................................5 12. CONDUCTED EMISSION LIMITS...............................................6 13. CONDUCTED EMISSION TEST PROCEDURE.......................................7 14. RADIATED EMISSION TEST PROCEDURE........................................7 15. AMBIENT CONDITIONS......................................................9 16. SYSTEM TEST CONFIGURATION...............................................9 17. EQUIPMENT MODIFICATIONS................................................10 18. EUT SETUP PHOTOS.......................................................11 19. TEST EQUIPMENT LIST....................................................12 20. TEST RESULT SUMMARY....................................................13 APPENDICES..................................................................15 .EXTERNAL I/O CABLE CONSTRUCTION DESCRIPTION .CONFIGURATION BLOCK DIAGRAM .EUT PHOTOGRAPHS REPORT NO:98E7756 DATE:SEPTEMBER 23, 1998 FCC ID:A3LA900 EUT: FAX/COLOR PRINTER/SCANNER/COPIER SYSTEM 1OF15 COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4002B2 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 1. VERIFICATION OF COMPLIANCE COMPANY NAME: SAMSUNG ELECTRONICS CO., LTD. 416 MAETAN DONG, PALDAL GU SUWON SHI, KOREA CONTACT PERSON: BEN KIM / MANAGER TELEPHONE NO: 408-544-5124 MODEL NO/NAME: A900 SERIAL NO: N/A DATE TESTED: SEPTEMBER 23, 1998 TYPE OF EQUIPMENT: INFORMATION TECHNOLOGY EQUIPMENT (ITE) MEASUREMENT DISTANCE: (X) 3 METER ( ) 10 METER TECHNICAL LIMIT: CLASS B FCC RULES: PART 15 MEASUREMENT PROCEDURE ANSI C63.4:92 EQUIPMENT AUTHORIZATION PROCEDURE CERTIFICATION MODIFICATIONS MADE ON EUTYESNO DEVIATIONS FROM MEASUREMENT PROCEDURE YES (refer to section 21 for comments) NO RADIATED EMISSION TEST RESULT -5.34 dB @ 80.0 MHz/VERTICAL CONDUCTED EMISSION TEST RESULT -6.4 dB @ 13.515 & 22.71 MHz/L1 & L2 The above equipment was tested by Compliance Consulting Services for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved By MIKE C.I. KUO / VICE PRESIDENT COMPLIANCE CONSULTING SERVICES REPORT NO:98E7756 DATE:SEPTEMBER 23, 1998 FCC ID:A3LA900 EUT: FAX/COLOR PRINTER/SCANNER/COPIER SYSTEM 2OF15 COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4002B2 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 2. PRODUCT DESCRIPTION CHASSIS TYPE PLASTIC CPU SPEEDS TESTED 75 MHz PENTIUM LIST OF EACH OSC. OR XTAL. FREQ. (FREQ.>=1 MHz) 40, 32.786, 38 MHz CHIPSET BRAND AND PART NO. SAMSUNG KS32C6400-01 POWER SUPPLY/NAME/MODEL/S.N. BUILT-IN NUMBER OF PCB LAYERS 4 BOARD REVISION NO REV 01 POWER REQUIREMENTS 110 V AC, 60 Hz NO. OF EXTERNAL I/O CONNECTORS 3 3. TESTED SYSTEM DETAILS The Model names for all equipment, plus descriptions of all cables used in the tested system (including inserted cards) are: External Peripheral Devices Device Type ManufacturerModel NumberSerial No.FCC ID / DoC MONITOR DAYTEK DT-1531D DV9709I204475 EWBOC15DB03 KEYBOARD COMPAQ KPQ-E99ZC-13 B04000B66E441K4 CMYKPQ7258 MOUSE COMPAQ MUS9J B01920H67E40LUI EMJMUSJJ MODEM SMARTEAM 103/212A 1038329 EF56A5103/212A COMPUTER COMPAQ SERIES 3590 7643HYQ30256 CNT75MEZ6 REPORT NO:98E7756 DATE:SEPTEMBER 23, 1998 FCC ID:A3LA900 EUT: FAX/COLOR PRINTER/SCANNER/COPIER SYSTEM 3OF15 COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4002B2 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 4. TEST FACILITY The open area test sites and conducted measurement facilities used to collect the radiated data are located at 561F Monterey Road, Morgan Hill, California, USA. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22. 5. ACCREDITATION AND LISTING The test facilities used to perform radiated and conducted emissions tests are accredited by National Voluntary Laboratory Accreditation Program for the specific scope of accreditation under Lab Code:200065-0 to perform Electromagnetic Interference tests accordi…
