A3LCHC72217 INCHES MONITOR

USER’S MANUAL 43cm 17”Color Monitor M780 50/70-E 9/17/98 3:10 PM Page i ii 3 Safety Instructions A 1 Before connecting the AC power cord to an outlet, make sure the voltage designation on your monitor corre- sponds to the local electrical supply. 2 Never insert anything metallic into the monitor openings. Doing so may create the danger of electric shock. 3 To avoid electric shock, never touch the inside of the monitor. Only a qualified technician should open the monitor’s case. 4 Never use your monitor if the power cord has been damaged. Do not allow anything to rest on the power cord, and keep the cord away from areas where people can trip over it. 5 Be sure to hold the plug, not the cord, when disconnecting the monitor from an electric socket. 6 Openings in the monitor cabinet are provided for ventilation. To prevent overheating, these openings should not be blocked or covered. Also, avoid using the monitor on a bed, sofa, rug, or other soft surface. Doing so may block the ventilation openings in the bottom of the cabinet. If you put the monitor in a bookcase or some other enclosed space, be sure to provide adequate ventilation. 7 Put your monitor in a location with low humidity and a minimum of dust. 8 Do not expose the monitor to rain or use it near water (in kitchens, near swimming pools, etc.). If the monitor accidentally gets wet, unplug it and contact an authorized dealer immedi- ately. You can clean the monitor with a damp cloth when necessary, but be sure to unplug the monitor first. 9 Place the monitor on a solid surface and treat it carefully. The screen is made of glass and can be damaged if dropped, hit or scratched. 10 Locate your monitor near an easily accessible AC outlet. 11 If your monitor does not operate normally – in particular, if there are any unusual sounds or smells coming from it – unplug it immediately and contact an authorized dealer or service center. 12 High temperatures can cause problems. Don’t use your monitor in direct sunlight, and keep it away from heaters, stoves, fireplaces, and other sources of heat. 13 Unplug the monitor when it is going to be left unused for an extended period of time. 14 Unplug your monitor from the AC outlet before any service. C A U T I O N RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. 50/70-E 9/17/98 3:10 PM Page ii 1 Table of Contents Safety Instructions .................................................................................................................ii Your New Monitor ..................................................................................................................2 Connecting Your Monitor ................................................................................................................2 Front Panel ........................................................................................................................................3 Direct Access Buttons ....................................................................................................................3 Operation .................................................................................................................................4 On-screen Menu System ................................................................................................................4 Monitor Function Control ................................................................................................................5 Brightness ..........................................................................................................................5 Contrast ..............................................................................................................................5 Horizontal Position ...........................................................................................................5 Vertical Position ................................................................................................................5 Horizontal Size ...................................................................................................................5 Vertical Size ........................................................................................................................5 Pincushion ..........................................................................................................................5 Display Timing ....................................................................................................................5 Advanced Features ...........................................................................................................6 Color Temperature......................................................................................................6 Language .....................................................................................................................6 Half tone .......................................................................................................................6 Moire ...................................................................................................................................6 Degauss ..............................................................................................................................6 Recall ...................................................................................................................................6 Geometry.............................................................................................................................6 Pinbalance ...................................................................................................................6 Parallelogram ..............................................................................................................6 Rotation .........…

Text truncated - open the document above for the full version.

10 Block Diagram M78010-1 TO D - COILON THE CRT CRT -210V( FROM FBT) +12V –210V +30V FOCUS1 SCREEN R G B H/V VIDEO BOARD MAIN BOARD H-SYNC1V-SYNC1SDASCLH-SIZE VER.-BLANKING (KSC945) Q331 H/V OUTPUT (SSP6N90) Q504 G1 ACL CIRCUIT BRIGHTNESS CONTROL BRIGHTNESS CONTROL DEGAUSSING BLOCK RL601 AC-INLET SOCKET CN601 LINE FILTER L601 CRT SOCKET BOARD SOCKET G1 HEATER CONTRAST CONTROL CONTRAST CONTROL R G B Video Pre-Amp IC101(KA2506) VIDEO OUTPUT IC102(LM2407) OSD DRIVE CONTROL IC104(MC4320, MC4322 MC4326) R G B - CUTOFF QR01, QR02, QG01, QG02, QB01, QB02 H-SYNC, V-SYNC V-MUTES-CORRECTIONPS-1 (SUSPEND)PS-2 (POWER-OFF)HOR.LIN. Power PWM Control (KA2S0680) IC601 RECTIFIER(1N5397GP)D602,D603, D604,D605 SWITCHING TRANS. T601 +75V+13V -10V +7V TO VIDEO PS-1,PS-2 (FROM Micom) CRT HEATER +12V REGULATOR +46V +12V PS-2 POWER-OFF MODE CONTROL (Q622) EPROM(24LC04) IC202 FRONT CONTROL BOARD V-SYNC H-SYNC, HOR./VER. OSC PROCESSOR (TDA9109S) MICOM (BD24) IC202 DYNAMICFOCUST502,Q551(KSP44) VER. - DY CN301 FBTT501 H.D.TT401 VER. OUTPUT(2N3904)IC301 High Volt.-DRIVE Q503 HOR.-DRIVE(KSP44)Q443 MENU EXITBRIGHTNESSCONTRASTENTERLEDPOWER VER. OUTPUT, TILT & H_Lin. control I-SENSEREGINTILT S/Cable INPUT & Video Gain Control CRT HEATER PQ12RD11 HOR.OUT (KSC5088) Q447 HOR.DY CN441~3 H/V PWM CONTROL IC501 TL494CN HOR.DEF.STEP-UPIFR630 CRYSTAL 6MHz

Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Attention: To whom it may concerns Subject: POWER OF ATTORNEY AND AUTHORIZATION LETTER Dear Madam or Sir: I appoint Compliance Consulting Services to act as agents in the preparation and singing of this FCC application for the following model under FCC rules and regulations The applicant certificates that, in the case of an individual applicant, he or she is not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C 853(a), or, in the case of a non-individual applicant ( corporation, partnership or other unincorporated association ) no party in the application is subject to a denial of federal benefits, that includes FCC benefits, pursuant to that section, FCC Part 15 of the rules and regulations of the Federal Communications Commission. I certify that the report properly describes the device for which certification is sought. MODEL: M780 FCC ID: A3LCHC722 APPLICANT: Samsung Electronics Co.,Ltd ADDRESS: 416 Maetan Dong, Paldal Gu, Suwon Shi, Korea PHONE: 408-544-5124 FAX: 408-544-5191 Signature: Date:Oct.5, 1998 Printed: Ben Kim Title: Manager

PROPOSED FCC ID LABEL LOCATION APPLICANT:SAMSUNG ELECTRONICS CO.,LTD. FCC ID:A3LCHC722 FCC ID LABEL AREA

FCC CFR47 PART 15 DIGITAL DEVICE TEST REPORT FOR 17" COLOR MONITOR W/ MAX. RESOLUTION OF 1280X1024 NON-INTERLACED (80 KHz) MODEL: M780 FCC ID: A3LCHC722 REPORT NUMBER: 98E7769 ISSUE DATE: SEPTEMBER 28, 1998 Prepared for DELL COMPUTER 1 DELL WAY ROUND ROCK, TX 78682 USA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 REPORT NO: 98E7769 DATE: SEPTEMBER 28, 1998 FCC ID:A3LCHC722 EUT: 17" COLOR MONITOR W/ MAX. RESOLUTION OF 1280X1024 NON-INTERLACED (80 KHz) COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4002C 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE..............................................1 2. PRODUCT DESCRIPTION.....................................................2 3. TESTED SYSTEM DETAILS...................................................2 4. TEST FACILITY...........................................................3 5. ACCREDITATION AND LISTING...............................................3 6. MEASUREMENT INSTRUMENTATION.............................................3 7. MEASURING INSTRUMENT CALIBRATION........................................3 8. UNITS OF MEASUREMENT....................................................4 9. ANTENNAS................................................................4 10. CLASSIFICATION OF DIGITAL DEVICE........................................5 11. RADIATED EMISSION LIMITS................................................5 12. CONDUCTED EMISSION LIMITS...............................................6 13. CONDUCTED EMISSION TEST PROCEDURE.......................................8 14. RADIATED EMISSION TEST PROCEDURE........................................8 15. AMBIENT CONDITIONS......................................................9 16. SYSTEM TEST CONFIGURATION...............................................9 17. EQUIPMENT MODIFICATIONS................................................10 18. EUT SETUP PHOTOS.......................................................11 19. TEST EQUIPMENT LIST....................................................12 20. TEST RESULT SUMMARY....................................................13 APPENDICES..................................................................15 .EXTERNAL I/O CABLE CONSTRUCTION DESCRIPTION .CONFIGURATION BLOCK DIAGRAM .EUT PHOTOGRAPHS REPORT NO:98E7769 DATE:SEPTEMBER 28, 1998 FCC ID: A3LCHC722 EUT: 17" COLOR MONITOR W/ MAX. RESOLUTION OF 1280X1024 NON-INTERLACED (80 KHz) 1OF15 COMPLIANCE CERTIFICATION SERVICESDOCUMENT NO:CCSUP4002D 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 1. VERIFICATION OF COMPLIANCE COMPANY NAME: DELL COMPUTER 1 DELL WAY ROUND ROCK, TX 78682 CONTACT PERSON: BEN KIM / MANAGER TELEPHONE NO: 408-544-5124 MODEL NO/NAME: M780 SERIAL NO: N/A DATE TESTED: SEPTEMBER 28, 1998 TYPE OF EQUIPMENT: INFORMATION TECHNOLOGY EQUIPMENT (ITE) MEASUREMENT DISTANCE:()3METER (X)10METER TECHNICAL LIMIT: CLASS B FCC RULES: PART 15 MEASUREMENT PROCEDURE ANSI C63.4:92 / EN 55022 EQUIPMENT AUTHORIZATION PROCEDURE CERTIFICATION MODIFICATIONS MADE ON EUTYESNO DEVIATIONS FROM MEASUREMENT PROCEDURE YES (refer to section 20 for comments) NO RADIATED EMISSION TEST RESULT -4.95 dB @ 433.12 MHz/VERTICAL CONDUCTED EMISSION TEST RESULT -8.1 dB @ 0.159 MHz/L2 The above equipment was tested by Compliance Certification Services for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved By MIKE C.I. KUO / VICE PRESIDENT COMPLIANCE CERTIFICATION SERVICES REPORT NO:98E7769 DATE:SEPTEMBER 28, 1998 FCC ID: A3LCHC722 EUT: 17" COLOR MONITOR W/ MAX. RESOLUTION OF 1280X1024 NON-INTERLACED (80 KHz) 2OF15 COMPLIANCE CERTIFICATION SERVICESDOCUMENT NO:CCSUP4002D 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 2. PRODUCT DESCRIPTION CHASSIS TYPE PLASTIC CPU SPEEDS TESTED 133 MHz PENTIUM LIST OF EACH OSC. OR XTAL. FREQ. (FREQ.>=1 MHz) 8 MHz CHIPSET BRAND AND PART NO. SAMSUNG ES04 POWER SUPPLY/NAME/MODEL/S.N. BUILT-IN NUMBER OF PCB LAYERS 1 BOARD REVISION NO REV 01 POWER REQUIREMENTS 100-240 V AC, 60/50 Hz NO. OF EXTERNAL I/O CONNECTORS 1 MAX. RESOLUTION 1280X1024 NI MAX. HOR/VERT FREQUENCY 80 KHz/75 Hz 3. TESTED SYSTEM DETAILS The Model names for all equipment, plus descriptions of all cables used in the tested system (including inserted cards) are: External Peripheral Devices Device Type ManufacturerModel NumberSerial No.FCC ID / DoC KEYBOARD DIGITAL RT6656TW 62051025 AQ6-MTN4XZ15 MOUSE DIGITAL M-S35 LT54402451 DZL210472 MODEM HAYES 4007AM A00840073172 BFJ4000AM PRINTER HP 2225C 2930S52630 DSI6XU2225 COMPUTER DIGITAL 963WW TA551T2397 A09-96XWW REPORT NO:98E7769 DATE:SEPTEMBER 28, 1998 FCC ID: A3LCHC722 EUT: 17" COLOR MONITOR W/ MAX. RESOLUTION OF 1280X1024 NON-INTERLACED (80 KHz) 3OF15 COMPLIANCE CERTIFICATION SERVICESDOCUMENT NO:CCSUP4002D 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 4. TEST FACILITY The open area test sites and conducted measurement facilities used to collect the radiated data are located at 561F Monterey Road, Morgan Hill, California, USA. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22. 5. ACCREDITATION AND LISTING The test facilities used to perform ra…
