A3LCM1529Microwave Oven

Owner’s Instructions Code No. : DE68-00031A MICROWAVE OVEN CM1829A(1800Watts) CM1529A(1500Watts) CM1829-EU-1 1/6/99 5:40 AM Page i (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b)Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. (c)Do not operate the oven if it is damaged. It is particularly important that the oven door close properly and that there is no damage to the: (1) Door (bent) (2) Hinges and latches (broken or loosened) (3) Door seals and sealing surfaces (d)The oven should not be adjusted or repaired by anyone except properly qualified service personnel. WARNING Always observe Safety Precautions when using your oven. See “Important Safety Instructions” on the next page. Never try to repair the oven on your own – dangerous voltage is inside. If the oven needs to be repaired, call 1-800-SAMSUNG for the name of an authorized service center near you. Please record the model number and serial number from the side of your Samsung microwave oven and the date of purchase in the space provided below. We recommend that you keep your purchase receipt with this manual for easy warran- ty service. Model Number _______________________________ Serial Number_______________________________ Date Purchased_______________________________ Dealer_______________________________ The step-by-step procedures use the different symbols below. * * â PRECAUTIONSTOAVOIDPOSSIBLE EXPOSURETOEXCESSIVE MICROWAVEENERGY : Press * â ImportantNote CM1829-EU-1 1/6/99 5:40 AM Page ii 1 GB Thank You for Choosing Samsung Thank you for choosing Samsung! Your new oven represents the very latest in microwave cooking technology. This oven is a full-featured, easy-to-use appliance built to strict quality standards set by Samsung — the highest in the industry. We ’ r e proud to offer you a product that will provide convenient, dependable service for years to come. IMPORTANTSAFETYINSTRUCTIONS When Using Any Electrical Appliance •When using any electrical appliance, basic safety precautions should be followed, including the following: WARNING : To reduce the risk of burns, electric shock, fire, injury to per sons or exposure to excessive microwave energy : •Read all safety instructions before using the appliance. •Read and follow the specific “PRECAUTIONSTO AVOIDPOSSIBLEEXPOSURETOEXCESSIVE MICROWAVEENERGY ” inside the front cover of this manual. •This appliance must be grounded. Connect only to properly grounded outlets. See “Grounding Instructions” on page 3. •Install or locate this appliance only in accordance with the provided installation instructions. •Some products, such as whole eggs and sealed containers, may explode and should not be heated in this oven. •Use this appliance only for its intended use as described in the manual. Do not use corrosive chemicals or vapors in this appliance. This type of oven is specifically designed to heat, cook, or dry food. It is not designed for laboratory use. •As with any appliance, close supervision is necessary when used by children. •Do not operate this appliance if it has a damaged cord or plug, if it is not working properly, or if it has been damaged or dropped. •This appliance should be serviced only by qualified service personnel. Contact the nearest authorized service facility for examination, repair, or adjustment. •Do not cover or block any of the openings on the appliance. •Do not store this appliance outdoors. Do not use this product near water – for example, near a kitchen sink, in a wet basement, or near a swimming pool, and the like. •Keep the inside of oven clean. Food particles or spattered oils stuck to the oven walls or floor can cause reduce the efficiency of the oven. * SAVETHESEINSTRUCTIONS CM1829-EU-1 1/6/99 5:40 AM Page 1 2 GB When Using Any Electrical Appliance (cont.) •Do not immerse cord or plug in water. •Keep cord away from heated surfaces. •Do not let cord hang over edge of table or counter. •When cleaning door and oven surfaces, use only mild, non-abrasive soaps or detergents applied with a sponge or soft cloth. • To reduce the risk of fire in the oven cavity: a.Do not overcook food. Carefully attend appliance if paper, plastic,or other combustible materials are placed inside the oven to facilitate cooking. b.Remove wire twist-ties from plastic cooking bags before placing bags in oven. c.If materials inside the oven ignite, keep the oven door closed, turn the oven off, disconnect the power cord, or shut off the power at the fuse or circuit breaker panel. d.Do not use the oven compartment for storage purposes. Do not leave paper products, cooking utensils, or food in the oven when not in use. •Do not try to preheat oven or operate while empty. •Do not cook without the plate tray in place on the oven floor as food will not cook properly. •Do not cover the rear ventilation slots with cloths or paper. •Dishes and containers can become hot. Handle with care. •Carefully remove utensil coverings, directing steam away from hands and face. •Do not defrost frozen beverges in narrow-necked bottles. The container may break. •Remove lids from baby food before heating. After heating stir well and test temperature before serving to baby. SAVETHESEINSTRUCTIONS CM1829-EU-1 1/6/99 5:40 AM Page 2 3 GB WARNING: Improper use of the grounding can result in a risk of elec- tric shock. Consult a qualified electrician or serviceperson if the grounding instructions completely understand, or if doubt exist as to whether the appliance is properly grounded. WARNING:Do not cut or remove the third (ground)prong from the power cord under any circumstances. Preferred method of grounding Plug the three-prong power cord into a properly grounded outlet of standard AC 230 voltage, 60 Hz. Your oven should be the only appliance on this circuit. Using an a…

Text truncated - open the document above for the full version.

Mar 12, 1999 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: Microwave Oven (FCC P.18) Model: CM1529 FCC ID No: A3LCM1529 FCC Confirmation Number: Gentleman: The above application has been submitted to FCC OET web site on Mar. 11, 1999. A check, $940.00 will be directly mailed to Mellon Bank to pay this application. The above Microwave Oven includes 2 Magnetrons model, OM-75P made by Samsung Electronics. The frequency range of this equipment is 2400MHz to 2500MHz. The attached files are, for your reference, as follows: 1. FCC ID Label and location 2. Block Diagram 3. Test report 4. External photo’s 5. Internal photo’s 6. User Manual If you have any question on this application, please let me know at [email protected] or Phone) 408-544-5124. Sincerely Yours, Ben Kim Engineering Manager Samsung Electronics America

MODEL NO.SERIAL NO.230Vac60Hz Kw MICROWAVE MANUFACTURED : JANUARY-1999 MADE IN KOREA FCC ID : THIS PRODUCT COMPLIES WITH DHHS RULES 21 CFR SUBCHAPTER J. CAUTION THIS DEVICE IS TO BE SERVICED ONLY BY PROPERLY QUALIFIED SERVICE PERSONNEL. CONSULT THE SERVICE MANUAL FOR PROPER SERVICE PROCEDURES TO ASSURE CONTINUED COMPLIANCE WITH THE FEDERAL PERFORMANCE STANDARD FOR MICROWAVE OVENS AND FOR PRECAUTIONS TO BE TAKEN TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY. WARNING * TO ENSURE CONTINUED PROTECTION AGAINST ELECTRIC SHOCK HAZARD CONNECT TO PROPERLY GROUNDED OUTLETS ONLY. * DISCONNECT APPLIANCE BEFORE SERVICING REMOVAL OF OUTER CASE WITH PORDUCT ENERGIZED MAY EXPOSE SERVICEMAN TO HAZARDOUS HIGH VOLTAGE POTENTIALS. WARNING CERTAIN INTERNAL PARTS ARE INTENTIONALLY NOT GROUNDED AND MAY PRESENT A RISK OF ELECTRICAL SHOCK ONLY DURING SERVICING. SERVICE PERSONNEL- DO NOT CONTACT THE FOLLOWING PARTS WHILE THE APPLIANCE IS ENERGIZED : FAN MOTOR, LOW VOLTAGE TRANSFORMER (TOUCH CONTROL TYPE), TIMER & TIMER MOUNTING BRACKET (MECHANICAL TYPE). COMMERCIAL MICROWAVE OVEN 416 MAETANDONG, SUWON, KOREA SEC LISTED 725F U L R CM1529A71BK100655 A3LCM1529 2.7 NOT FOR BUILT-IN INSTALLATION

230V 60HZ CN4 CN4CN4 CN4 (AZR) FUSE 1(250V 10A) INTERLOCK INTERLOCK (SECONDARY INTERLOCK) (SECONDARY INTERLOCK) WIRING DIAGRAM (CM1819A / 1829A / 1519A / 1529A) WIRE COLOR BLK : BLACKWHT : WHITEORG : ORANGEVIL : VIOLET PNK : PINK YEL : YELLOWAZR : AZUREBLU : BLUERED : REDBRN : BROWN P .C.B Circuit Diagram CM1829A / CM1529A
