A3LCSE98319 INCHES MONITOR

CSE 9839L Color Monitor Owner’s Instructions CS9839-E 10/8/98 10:51 AM Page i ii C A U T I O N RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and servicing instructions in the literature accompanying the appliance. Unpacking your Monitor Please make sure the following items are included with your computer monitor: Monitor and Stand Power Cable This Manual Warranty Card (Not available in all areas) Signal Cable CS9839-E 10/8/98 10:51 AM Page ii 1 Table of Contents Preface: Safety Information . . . . . . . . . .2 Chapter One: Overview of Your Monitor . . . . . . . . . . . . . . . . . . . . . . . . .3 Front Panel.....................................................................................3 Rear Panel......................................................................................4 Chapter Two: Installation . . . . . . . . . . . . .5 Connecting Your Monitor to a Computer ..................................5 Chapter Three: Adjusting Your Monitor . .6 Overview ........................................................................................6 Brightness......................................................................................6 Contrast ..........................................................................................6 Direct Access Features ...............................................................7 Position....................................................................................7 Size ...........................................................................................7 Pincushion/Trapezoid............................................................7 Parallel/Rotation ....................................................................8 Menu Features ..............................................................................8 Color temperature .................................................................8 Color Control...........................................................................9 Degauss...................................................................................9 Recall .......................................................................................9 Menu Position ......................................................................10 Menu Duration .....................................................................10 D-SUB / BNC ........................................................................11 Pinbalance ............................................................................11 Clear Moire ...........................................................................11 Language ..............................................................................12 Display Timing ......................................................................12 Video Input Level .................................................................12 Sync. Input Type...................................................................13 Exit ..........................................................................................13 PowerSaver .................................................................................14 Troubleshooting ..........................................................................15 A p p e n d i x . . . . . . . . . . . . . . . . . . . . . . . . .1 6 Specifications..............................................................................16 Pin Assignments .........................................................................17 Display Modes Timing Chart .....................................................18 CS9839-E 10/8/98 10:52 AM Page 1 Preface: Safety Information 2 Please read and follow these instruc- tions when connecting and using your computer monitor. 1 Before connecting the AC power cord to an outlet, make sure the voltage designation on your moni- tor corresponds to the local elec- trical supply. 2 Never insert anything metallic into the monitor openings. Doing so may create the danger of electric shock. 3 To avoid electric shock, never touch the inside of the monitor. Only a qualified technician should open the monitor’s case. 4 Never use your monitor if the power cord has been damaged. Do not allow anything to rest on the power cord, and keep the cord away from where people could trip over it. 5 Be sure to hold the plug, not the cord, when disconnecting the monitor from an electric socket. 6 Openings in the monitor cabinet are provided for ventilation. To prevent overheating, these open- ings should not be blocked or cov- ered. Also, avoid using the monitor on a bed, sofa, rug, or other soft surface. Doing so may block the ventilation openings in the bottom of the cabinet. If you put the moni- tor in a bookcase or some other enclosed space, be sure to pro- vide adequate ventilation. 7 Put your monitor in a location with low humidity and a minimum of dust. Avoid places like damp basements or dusty hallways. 8 Do not expose the monitor to rain or use it near water (in kitchens, next to swimming pools, etc.). If the monitor accidentally gets wet, unplug it and contact an autho- rized dealer immediately. You can clean the monitor with a damp cloth when necessary, but be sure to unplug the monitor first. 9 Place the monitor on a solid sur- face and treat it carefully. The screen is made of glass and can be damaged if dropped or sharply hit. 10 Locate your monitor near an easily accessible AC outlet. 11 If your monitor does not operate nor…

Text truncated - open the document above for the full version.

10 Block Diagram CSE7839L/CSE9839L10-1 VIDEOOUTPUT VPS14 BNC/D-SUB SELECT COLOR ADJUSTCONTROL (JIG) COLOR CONTROL VIDEO CUTOFF CONTROL M52324 HORIZONTAL BLANK CONTRAST CONTROL BRIGHTNESSCONTROL HORIZONTAL BLANK VIDEO MUTE AC INLET SOCKET LINE FILTER RECTIFIER AC INPUT90-264VAC 60/50Hz DEGAUSSOPERATION D-COIL SWITCHINGTRANS +24V +14V 8V-14V +14V_I +80V+220V H-DRIVE CRT HEATER VERT OUT SUSPEND DEGAUSS USB DDC S-RASTER H-SYNC/ V-SYNC OUT SDA/SCA VIDEO MUTE G1 R G B CRT R G B MICROPROCESSOR ST7272 D D CCONTROL 24LC211 S-CORRECTION LED VIDEO PRE-AMP M52748 OSDLSC4398 COMPARATOR SOG ERROR DETECT & FEED BACK POWER SYNC H-SYNC TRIGGER PWM CONTROL &SWITCHING FET STR-S6719A BNC/D-SUB INPUT H-SYNC V-SYNC POWER OFFCONTROL VIDEO OUTPUT VOLTAGEREGULATOR KA78R12 VOLTAGEREGULATOR KA7805 +5V SOG HOR.VER. OSC PROCESSING TDA9110 H/V DRIVE DYNAMIC FOCUS HORIZONTALFOCUS CIRCUIT H-AFC HOR. OUTPUT MJL16218 H-DY HORIZONTALREGULATION CONTROL HOR. REGULATION OUTPUT (PWM CONTROL) REGULATION SENSER HOR. DRIVE S-CORRECTION FBT H/V OUTPUT KSC5088 H/V REGULATION ERRORFEEDBACK X-RAYPROTECTOR VERTICAL BLANKING GENERATOR VERTICAL OUTPUT TDA8172 V-DY VERTICAL FOCUS CIRCUIT HIGH VOLTAGE SCREEN G2 FOCUS1, 2 H_LIN. MOIRE ACL B/UNIFORMITY M52759 TILT CONTROL BUTTONOSD CALL/ENTER POSITION/SIZE PIN/TRAPPARALL/ROTATION CHOOSE OR ADJUST MENU BUTTONPOWER BUTTON CONTRAST BRIGHTNESS CRYSTAL 24MHz

PROPOSED FCC ID LABEL LOCATION APPLICANT:SAMSUNG ELECTRONICS CO.,LTD. FCC ID:A3LCSE983 FCC ID LABEL AREA

FCC CFR47 PART 15 DIGITAL DEVICE TEST REPORT FOR 19" COLOR MONITOR W/ MAX. RESOLUTION OF 1600X1200 NON-INTERLACED (92 KHz) MODEL : SYNCMASTER 900P, CSE 9839, CSE98**B FCC ID: A3LCSE983 REPORT NUMBER: 98E7795 ISSUE DATE: OCTOBER 14, 1998 Prepared for SAMSUNG ELECTRONICS CO., LTD. 416 MAETAN DONG, PALDAL GU SUWON SHI, KOREA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 REPORT NO:98E779 DATE:OCTOBER 14, 1998 FCC ID:A3LCSE983 EUT: 19" COLOR MONITOR W/ MAX. RESOLUTION OF 1600X1200 NON-INTERLACED (92 KHz) COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4002C 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE ..............................................1 2. PRODUCT DESCRIPTION. ....................................................2 3. TESTED SYSTEM DETAILS ...................................................2 4. TEST FACILITY ...........................................................3 5. ACCREDITATION AND LISTING... ............................................3 6. MEASUREMENT INSTRUMENTATION .............................................3 7. MEASURING INSTRUMENT CALIBRATION ........................................3 8. UNITS OF MEASUREMENT... .................................................4 9. ANTENNAS.................... ............................................4 10. CLASSIFICATION OF DIGITAL DEVICE. .......................................5 11. RADIATED EMISSION LIMITS ................................................5 12. CONDUCTED EMISSION LIMITS ...............................................6 13. CONDUCTED EMISSION TEST PROCEDURE .......................................8 14. RADIATED EMISSION TEST PROCEDURE ........................................8 15. AMBIENT CONDITIONS... ...................................................9 16. SYSTEM TEST CONFIGURATION ...............................................9 17. EQUIPMENT MODIFICATIONS...... ..........................................10 18. EUT SETUP PHOTOS..... ..................................................11 19. TEST EQUIPMENT LIST ....................................................12 20. TEST RESULT SUMMARY ....................................................13 APPENDICES ..................................................................15 .EXTERNAL I/O CABLE CONSTRUCTION DESCRIPTION .CONFIGURATION BLOCK DIAGRAM .EUT PHOTOGRAPHS REPORT NO:98E7795 DATE:OCTOBER 14, 1998 FCC ID: A3LCSE983 EUT: 19" COLOR MONITOR W/ MAX. RESOLUTION OF 1600X1200 NON-INTERLACED (92 KHz) 1 OF 15 COMPLIANCE CERTIFICATION SERVICESDOCUMENT NO:CCSUP4002D 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 1. VERIFICATION OF COMPLIANCE COMPANY NAME: SAMSUNG ELECTRONICS CO., LTD. 416 MAETAN DONG, PALDAL GU SUWON SHI, KOREA CONTACT PERSON: BEN KIM / MANAGER TELEPHONE NO: 408-544-5124 MODEL NO/NAME: SYNCMASTER 900P, CSE 9839, CSE98**B SERIAL NO: N/A DATE TESTED: OCTOBER 14, 1998 TYPE OF EQUIPMENT: INFORMATION TECHNOLOGY EQUIPMENT (ITE) MEASUREMENT DISTANCE: ( ) 3 METER (X) 10 METER TECHNICAL LIMIT: CLASS B FCC RULES: PART 15 MEASUREMENT PROCEDURE ANSI C63.4:92 / EN 55022 EQUIPMENT AUTHORIZATION PROCEDURE CERTIFICATION MODIFICATIONS MADE ON EUT YES NO DEVIATIONS FROM MEASUREMENT PROCEDURE YES (refer to section 20 for comments) NO RADIATED EMISSION TEST RESULT -3.11 dB @ 286.36 MHz/VERTICAL CONDUCTED EMISSION TEST RESULT -4.2 dB @ 0.182 MHz/L2 The above equipment was tested by Compliance Certification Services for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved By MIKE C.I. KUO / VICE PRESIDENT COMPLIANCE CERTIFICATION SERVICES REPORT NO:98E7795 DATE:OCTOBER 14, 1998 FCC ID: A3LCSE983 EUT: 19" COLOR MONITOR W/ MAX. RESOLUTION OF 1600X1200 NON-INTERLACED (92 KHz) 2 OF 15 COMPLIANCE CERTIFICATION SERVICESDOCUMENT NO:CCSUP4002D 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 2. PRODUCT DESCRIPTION CHASSIS TYPE PLASTIC CPU SPEEDS TESTED 133 MHz PENTIUM LIST OF EACH OSC. OR XTAL. FREQ. (FREQ.>=1 MHz) 24.0 MHz CHIPSET BRAND AND PART NO. GS MCM-01 POWER SUPPLY/NAME/MODEL/S.N. BUILT-IN NUMBER OF PCB LAYERS 1 BOARD REVISION NO 01 LINE FILTER NAME AND MODEL DIT IG-L03A2-P POWER REQUIREMENTS 100-240 V AC, 60/50 Hz NO. OF EXTERNAL I/O CONNECTORS 6 MAX. RESOLUTION 1600X1200 NI MAX. HOR/VERT FREQUENCY 92 KHz, 72 Hz Model Differences: Model NameDifferencesTested (Checked) SYNCMASTER 900P ORIGINAL MODEL CSE 9839 FOR MARKETING PURPOSES CSE 98**B The star indicates that there can and will be model differences. These differences are cosmetic and for marketing purposes only. 3. TESTED SYSTEM DETAILS The Model names for all equipment, plus descriptions of all cables used in the tested system (including inserted cards) are: External Peripheral Devices Device Type ManufacturerModel NumberSerial No.FCC ID / DoC COMPUTER DIGITAL 963WW TA551T2397 A09-96XWW KEYBOARD DIGITAL RT6656TW 62051025 AQ6-MTN4XZ15 MOUSE DIGITAL M-S35 LT54402451 DZL210472 MODEM SMARTEAM 103/212A A038329 EF56A5103/212A PRINTER HP 2225C 2930S52630 DSI6XU2225 4. TEST FACILITY The open area test sites and conducted measurement facilities used to collect the radiated data are located at 561F REPORT NO:98E7795 DATE:OCTOBER 14, 1998 FCC ID: A3LCSE983 EUT: 19" COLOR MONITOR W/ MAX. RESOLUTION OF 1600X1200 NON-INTERLACED (92 KHz) 3 OF 15 COMPLIANCE CERTI…

Text truncated - open the document above for the full version.
