A3LCYSWR1100Wireless Router

Page 2SamSung WireleSS router uSer manual Safety InformatIon Safety WarnIngS To reduce the risk of electric shock, do not remove the cover (or back). No user serviceable parts are inside. Refer to qualified service personnel. This symbol indicates “dangerous volt- age” inside the product that presents a risk of electric shock or personal injury. Caution: To prevent electric shock, match wide blade of plug to the wide slot, fully insert. This symbol indicates important in- structions accompanying the product. Warning • To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. Caution • Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus. • The Mains plug is used as a disconnect device and shall stay readily operable at any time. • This apparatus shall always be connected to a AC outlet with a protective grounding connection. • To disconnect the apparatus from the mains, the plug must be pulled out from the mains socket, therefore the mains plug shall be readily operable. PrecautIonS • Ensure that the AC power supply in your house complies with the identification sticker located on the back of your prod- uct. • Install your product horizontally or vertically, on a suitable base (furniture), with enough space around it for ventilation (7.5~10cm). • Do not place the product on amplifiers or other equipment which may become hot. • Do not stack anything on top of the product. • In order to disconnect the product completely from the power supply, remove the main plug from the wall outlet, espe- cially when left unused for a long period of time. • During thunderstorms, disconnect the AC main plug from the wall outlet. Voltage peaks due to lightning could damage the product. • Do not expose the product to direct sunlight or other heat sources. This could lead to overheating and malfunction of the product. • Protect the product from moisture, and excess heat or equipment creating strong magnetic or electric fields (i.e. speak- ers.). • Disconnect the power cable from the AC supply if the product malfunctions. • Your product is not intended for industrial use. Use of this product is for personal use only. • Condensation may occur if your product has been stored in cold temperatures. If transporting the product during the winter, wait approximately 2 hours until the product has reached room temperature before using. Page 3SamSung WireleSS router uSer manual table of contentS Safety Information ����������������������������������������2 Safety Warnings ...................................................................................2 Precautions ..........................................................................................2 Getting Started ��������������������������������������������4 Package Contents ................................................................................4 System Requirements ..........................................................................4 About this Product ...............................................................................5 Features ...............................................................................................5 Description ..........................................................................................6 Front View .......................................................................................6 Back View .......................................................................................6 Installation ...........................................................................................7 Before you Begin .............................................................................7 Wireless Installation Considerations ...............................................7 Connect to Cable/DSL/Satellite Modem..........................................7 Connect to Another Router ..............................................................8 Connecting to the Web UI ....................................................................9 Router’s Defaults .............................................................................9 Connecting using the Browser ........................................................9 Web User Interface �������������������������������������10 Setup Category ..................................................................................11 Internet - Wizard ...........................................................................12 Internet - Manual Internet Connection ...........................................18 Wireless Settings ..........................................................................27 Network Settings ...........................................................................35 Advanced Category ............................................................................37 Virtual Server ................................................................................38 Port Forwarding ............................................................................39 Application Rules ..........................................................................40 Quality of Service (QoS) ...............................................................41 Network Filter ................................................................................43 Access Control ..............................................................................44 Website Filter ................................................................................47 Inbound Filter ...............................................................................48 Firewall Settings ...........................................................................49 Routing .........................................................................................50 Advanced Wireless ........................................................................51 Wi-Fi Protected …

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division Declaration Letter We, Samsung Electronics Co., Ltd. declares that the device does not have “Ad Hoc on non-US frequencies” and/or “on DFS frequencies” while applying for the following product. FCC ID: A3LCYSWR1100 Sincelery yours, ------------------------------------------ NAME : Sang Kyung (Peter) Ra TITLE : S. Manager Tuesday, January 25, 2011

Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: A3LCYSWR1100 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincelery yours, ------------------------------------------ NAME : Sang Kyung (Peter) Ra TITLE : S. Manager Tuesday, January 25, 2011

Power of Attorney To whom it may concern: We, the undersigned Samsung Electronics Co., Ltd. hereby authorize BV CPS (H.K.) Ltd., Taoyuan Branch of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C/ 15E approval and any communication needed with the national authority. Any and all acts carried out by BV CPS (H.K.) Ltd., Taoyuan Branch of Taiwan on our behalf shall have the same effects as acts of our own. FCC ID: A3LCYSWR1100 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely, NAME : Sang Kyung (Peter) Ra TITLE : S. Manager Friday, January 14, 2011

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5

FCC ID： A3LCYSWR1100 LABEL Location LABEL Drawing Label here

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5

FCC ID: A3LCYSWR1100 Report No.: RF991229E03 Operational Description This device is a Wireless Router which operates in both of the 5GHz and 2.4GHz bands; the maximum data rate could be up to 300Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 300Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by 12Vdc from the power adapter. There are two antennas provided to this EUT, please refer the following table: The other instruction, please have a look at the users manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

Report No.: SA991229E03 Report Format Version 4.0.0 1 RF EXPOSURE REPORT REPORT NO.: SA991229E03 MODEL NO.: CY-SWR1100 FCC ID: A3LCYSWR1100 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Samsung Electronics Co., Ltd. ADDRESS: 416 Maetan-dong, Young-Tong gu, Suwon, Korea 442-742 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan Report No.: SA991229E03 Report Format Version 4.0.0 2 1. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 3. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA991229E03 Report Format Version 4.0.0 3 4. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For 15.247(2.4GHz): FREQUENCY BAND (MHz) MAX POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 26.2 4.24 20 0.216 1.00 For 15.247(5GHz): FREQUENCY BAND (MHz) MAX POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5745-5825 27.2 4.24 20 0.556 1.00 For 15.407(5GHz): FREQUENCY BAND (MHz) MAX POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5180-5240 14.9 4.24 20 0.016 1.00 CONCLUSION: Both of the 2.4GHz and 5GHz can transmit simultaneously, the formula of calculated the MPE is: CPD 1 / LPD 1 + CPD 2 / LPD 2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density Therefore, the worst-case situation is 0.216 / 1 + 0.556 / 1= 0.772, which is less than “1”. This confirmed that the device comply with FCC 1.1310 MPE limit. --- END ---

Report No.: RF991229E03 1 Report Format Version 4.0.0 FCC TEST REPORT (15.247) REPORT NO.: RF991229E03 MODEL NO.: CY-SWR1100 FCC ID: A3LCYSWR1100 RECEIVED: Dec. 29, 2010 TESTED: Dec. 31, 2010 to Jan. 10, 2011 ISSUED: Jan. 31, 2011 APPLICANT: Samsung Electronics Co., Ltd. ADDRESS: 416 Maetan-dong, Young-Tong gu, Suwon, Korea 442-742 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 119 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF991229E03 2 Report Format Version 4.0.0 Table of Contents RELEASE CONTROL RECORD....................................................................................5 1. CERTIFICATION................................................................................................6 2. SUMMARY OF TEST RESULTS.........................................................................7 2.1 MEASUREMENT UNCERTAINTY.......................................................................9 3. GENERAL INFORMATION................................................................................10 3.1 GENERAL DESCRIPTION OF EUT..................................................................10 3.2 DESCRIPTION OF TEST MODES....................................................................13 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL.......................14 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.....................................18 3.4 DESCRIPTION OF SUPPORT UNITS...............................................................19 3.5 CONFIGURATION OF SYSTEM UNDER TEST.................................................21 4. TEST TYPES AND RESULTS (802.11b & g, 2400 ~ 2483.5MHz Band)..............23 4.1 CONDUCTED EMISSION MEASUREMENT......................................................23 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT....................................23 4.1.2 TEST INSTRUMENTS......................................................................................23 4.1.3 TEST PROCEDURES.......................................................................................24 4.1.4 DEVIATION FROM TEST STANDARD..............................................................24 4.1.5 TEST SETUP...................................................................................................25 4.1.6 EUT OPERATING CONDITIONS......................................................................25 4.1.7 TEST RESULTS...............................................................................................26 4.2 RADIATED EMISSION MEASUREMENT..........................................................28 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.........................................28 4.2.2 TEST INSTRUMENTS......................................................................................29 4.2.3 TEST PROCEDURES.......................................................................................30 4.2.4 DEVIATION FROM TEST STANDARD..............................................................30 4.2.5 TEST SETUP...................................................................................................31 4.2.6 EUT OPERATING CONDITIONS......................................................................31 4.2.7 TEST RESULTS...............................................................................................32 4.3 6dB BANDWIDTH MEASUREMENT.................................................................61 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT................................................61 4.3.2 TEST INSTRUMENTS......................................................................................61 4.3.3 TEST PROCEDURE.........................................................................................61 4.3.4 DEVIATION FROM TEST STANDARD..............................................................61 4.3.5 TEST SETUP...................................................................................................61 4.3.6 EUT OPERATING CONDITIONS......................................................................61 4.3.7 TEST RESULTS...............................................................................................62 4.4 MAXIMUM PEAK OUTPUT POWER.................................................................66 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT....................66 4.4.2 INSTRUMENTS................................................................................................66 4.4.3 TEST PROCEDURES.......................................................................................66 Report No.: RF991229E03 3 Report Format Version 4.0.0 4.4.4 DEVIATION FROM TEST STANDARD..............................................................66 4.4.5 TEST SETUP...................................................................................................66 4.4.6 EUT OPERATING CONDITIONS......................................................................66 4.4.7 TEST RESULTS...............................................................................................67 4.5 POWER SPECTRAL DENSITY MEASUREMENT..............................................69 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT............................69 4.5.2 TEST INS…
